TP-Link MU-MIMO User manual

Quick Installation Guide
MU-MIMO Wi-Fi Router
* Images may dier from actual products.
Set up with videos:
Scan the QR code or visit
https://www.tp-link.com/support/setup-video/#wi--routers
to search for the setup video of your product.
If your internet comes from an Ethernet outlet, connect the router’s WAN port to it, then follow Step 4 and Step 5.
If you want to configure this new router as an access point to extend your network, refer to the Access Point Mode
section on the back page.
Connect the Hardware
On / O
Flip the page over to complete network setup.
Connect the power adapter to
the router and turn it on.
Note: If the 2.4 GHz LED and 5 GHz LED are off, press and hold the
WPS/Wi-Fi button on the back for more than 5 seconds. Both the LEDs
should turn solid.
Power
On
Internet
On
2.4 GHz
On
5 GHz
On
Check for the following LEDs to confirm the
hardware connection, then refer to the next
section to set up the internet.
Modem
Power adapter
Power adapter
Router
Unplug your modem, and remove
the backup battery if it has one.
Connect the powered-off modem
to the router’s WAN port with an
Ethernet cable.
Power on the modem, and
then wait about 2 minutes
for it to restart.
WAN
WAN
POWER
POWER

©2022 TP-Link 7106509611 REV4.0.0
Method 1: Via TP-Link Tether App
1. Download the Tether app.
2. Open the Tether app and log in with your TP-Link ID.
Note: If you don’t have an account, create one first.
Scan for Tether Tether
or
Launch a web browser, and enter http://tplinkwifi.net or http://192.168.0.1
in the address bar. Create a password to log in.
Follow the step-by-step instructions to set up the internet connection and
register for the TP-Link Cloud service.
2. Connect the router to the internet.
http://tplinkwi.net
Let’s Get Started
Conrm Password
Password
Note: If the login window does not appear, please refer to Q1 of Need Help? in this guide.
a
b
Method 2: Via a Web Browser
Wired
Turn off the Wi-Fi on your computer and connect to the router using an
Ethernet cable.
1. Connect your device to the router (wired or wireless).
Wireless
Find the SSID (network name) and Wireless Password printed on the label
at the bottom of the router.
a
Click the network icon of your computer or go to Wi-Fi settings of your
smart device, and then select the SSID to join the network.
b
Need Help?
Q1. What should I do if I cannot access the web management page?
Reboot your router and try again.
If the computer is set to a static IP address, change its settings to obtain an IP
address automatically.
Verify that http://tplinkwifi.net is correctly entered in the web browser.
Alternatively, enter http://192.168.0.1 or http://192.168.1.1 in the web browser
and press Enter.
Use another web browser and try again.
Disable and enable the network adapter being used.
Q2. What should I do if I cannot access the internet?
Power off your modem for about 5 minutes, then power it on and check the
internet. If your modem has more than one Ethernet port, keep other ports
unconnected.
Check if the internet is working normally by connecting a computer directly to the
modem via an Ethernet cable. If it is not, contact your internet service provider.
Log in to the web management page, and go to the Network Map page to check
whether the internet IP address is valid or not. If it’s valid, go to Advanced >
Network > Internet, click Advanced Settings, select Use the Following DNS
Addresses, set the primary DNS to 8.8.8.8, and set the secondary DNS to 8.8.4.4.
If it is not, check the hardware connection or contact your internet service
provider.
For cable modem users, log in to the web management page of the router and go
to Advanced > Network > Internet > MAC Clone. Select Clone Current Device
MAC and click SAVE. Then reboot both the modem and the router.
Q3. How do I restore the router to its factory default settings?
With the router powered on, use a pin to press and hold the RESET button on the
back until the Power LED blinks.
Log in to the web management page of the router, go to Advanced > System >
Backup & Restore > Factory Default Restore, and click FACTORY RESTORE. The
router will restore and reboot automatically.
Q4. What should I do if I forget my web management page password?
If you are using a TP-Link ID to log in, click Forgot password on the login page and
then follow the instructions to reset it.
Alternatively, refer to Q3 to reset your router, then visit http://tplinkwifi.net to create
a new login password.
Q5. What should I do if I forget my wireless network password?
If you have not changed the default wireless password, it can be found on the label
at the bottom of the router.
Connect a computer directly to the router using an Ethernet cable. Log in to the
router’s web management page at http://tplinkwifi.net, and go to Wireless to
retrieve or reset your wireless password.
Access Point Mode
If you already have a router, you can switch this new router to Access Point
mode to extend your existing network. Follow the steps below.
1. Power on the router.
2. Connect the router’s WAN port to your existing router’s Ethernet port
via an Ethernet cable as shown above.
3. Connect a computer to the router via an Ethernet cable or wirelessly by
using the SSID (network name) and Wireless Password printed on the
label at the bottom of the router.
4. Launch a web browser, and enter http://tplinkwifi.net in the address bar.
Create a password to log in.
5. Go to Advanced > Operation Mode and switch to Access Point Mode.
6. Wait for the router to reboot, then log in and follow the Quick Setup to
complete the setup.
Set Up the Network2
Existing Router
Ethernet4Ethernet3Ethernet1Ethernet2Internet
Ethernet4
Ethernet
Internet
New Router
WAN
Clients
Safety Information
Keep the device away from water, fire, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please
contact us.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Do not use the device where wireless devices are not allowed.
Adapter shall be installed near the equipment and shall be easily accessible.
For technical support, replacement services, user guides, and
other information, please visit https://www.tp-link.com/support,
or simply scan the QR code.
If you have any suggestions or needs for our product guides, you are
welcome to email [e-mail].
To communicate with TP-Link users or engineers, please join the TP-Link
Community at https://community.tp-link.com.
3. Tap the button in the Tether app and select Wireless
Router > Standard Routers. Follow the steps to
complete the setup and connect to the internet.
Choose Your Device Type
Gaming Router
Range Extender
Wireless Router
