TPI 3480 Series User manual

INSTALLATION
INSTRUCTIONS
ATTENTION: Read carefully
before attempting to install
or operate the heater.
3480/RCH SERIES
GENERALINFORMATION
MOUNT HORIZONTAL POSITION ONLY.
DO NOT INSTALLANY CLOSER THAN 12” TO NEAREST WALL
CHECK TO SEE THAT SERVICE VOLTAGE IS THE SAME AS HEATER VOLTAGE.
ALL WIRING MUST CONFORM TO THE NATIONAL ELECTRIC CODEAND EXISTING LOCAL CODE
REQUIREMENTS.
FORM: 9480
ECO 1-5917
NOTE: If plaster frame is required for installation
order it as an option.
WARNING: To avoid the risk of fire, shock or personal
injury; make sure that the power source is disconnected
before attempting to install, service, clean or disas-
semble the heater or any of its components. If the power
disconnect is out of the line of sight, lock in in the open
position and tag it to prevent the application of power.
INSTALLATION INSTRUCTIONS:
1. Detach heater unit from the ceiling mounting plate
in the recessed can by disengaging the stabilizing
arms on ceiling plate from the heater unit.
4 - #8 drive screws.
2. For a dropped or suspended ceiling, anchor the
recessed can useing either threaded rod, or wire in
an approved method that is sufficient to support
the heater assembly such that the bottom edge of
the recessed can just rest on the T-bar frame. For
plaster or similar finished ceilings, the can should
be installed so the flanges (of the can) are even
with the interior finish or ceiling line.
3. For plaster or other similar finish ceilings attach
the PT3480 accessory plaster frame to the
recessed can using 8 - #8 x 3/4 drive screws.
(detail “AA”)
4. Hang heater unit from two stabilizing arms on the
ceiling mounting plate in the can. Be sure to
engage the two arms with the hooked ends on the
ceiling plate with the slots in the heater plate.
5. Connect the heater leads with their corresponding
supply leads in the outlet box (75OC wire must be
used). The outlet box is permanently attached to
the top of the can. After this is complete, install the
ceiling plate access hole cover with
2 - #8 drive screws which have been provided.
6. Swing the heater unit up to the ceiling mounting
plate and secure with 4 - #8 drive screws that have
been provided. Do this by placing one screw in
each of the four stabilizing arms on the ceiling
plate.
7. Install heater exterior grille by attaching it directly to
the heater unit. Rotate the exterior grille so that the
two 1/4” dia. holes in the exterior grille aligne with
the manual reset limit control located on the bottom
of the venturi of the heater assembly, also make
alignements so that the venturi of the heater
assembly is on the outside the venturi of the
exterior grille. Secure to the four bracket arms on
the heater case with 4 - 10/32 x 3/4 button head
machine screws provided.
IMPORTANT: OWNER SHOULD RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1REV. 06/08

THERMAL CUTOUT (480 volt models)
If for any reason temperatures increase beyond normal
limits, safety thermal limit will open de-energizing heat-
ing element and fan motor. Check entire installation to
determine cause of overheating and take corrective
measures. The limit control is the automatic reset type
and after cooling will reset, allowing heater to resume
operation.
CAUTION: To avoid the risk of fire, shock or personal
injury; do not insert or allow any foreign objects or
hands to enter any ventilation or exhaust openings.
THERMAL CUTOUT OPERATION
(WITH ZERO-VOLT RESET)
To reset thermal cutout disconnect all power for 5
minutes then energize unit. If fault continues discon-
nect power and check for causes.
THERMAL CUTOUT OPERATION
(WITH CAPILLARY MANUALRESET)
To reset thermal cutout, first disconnect power from
the unit allowing time to cool, locate the two 1/4” dia.
openings in the front grille.Using a small screwdriver
or pencil press the reset button (with minimal amount
of force) through the 1/4” opening, then restore power
to the unit. If fault continues disconnect power and
check for causes.
THERMAL CUTOUT IDENTIFICATION
All 480V Models employ a automatic limit control.
208, 240 and 277V models may employ zero-volt or
capillary manual reset limit control.
Models with capillary type manual reset limit control.
This device is located on the heater venturi (bottom of
unit as installed) with the capillary routed around the
outside of the element assembly.
2
3480 / RCH SERIES CEILING HEATER
WIRING DIAGRAMS: Shown on pages 4, 5, 6 and 7
WD-1, -3, -5, -7, -9, -11, -13, -15, -17 and -19 are dia-
gramsofunitsthatemploy(zero-volt)manual reset limit
control devices.
WD-2, -4, -6, -8, -10, -12, -14, -16, -18 and -20 are dia-
grams of units that employ (capillary) manual reset limit
control devices.
OPTIONALLOUVEREDDIFFUSER
The factory installed louvered diffuser can be
adjusted to direct air flow as desired. If necessary the
louvered diffuser can be rotated 90 degrees by
removing the four mounting scews and turning the
louvered diffuser to the desired position and attaching
to the grille. Care must be taken to align the notched
corners of the diffuser frame with the reset holes in the
grille. The louvered diffuser cannot be used in
conjunction with the standard circular outlet.

3480 / RCH SERIES CEILING HEATER REPLACEMENT PARTS
REF DESCRIPTION CODE / PART NO. QTY.
A BottomGrille 3480COMPGRL 1
B Fan Blade 51554-002 1
F Circular Louver 56561-101 1
G HolePlug 57882-001 1
H ACC Mtg. Bracket 54871-001 1
I Disconnect Switch 51617-003 1
J Control Relay See Variations Below 1
41274-001 24 V COIL
28163-004 120 V COIL
28163-006 208/277 V COIL
K Class2Transformer 60719-001 - 208 240/24 V SEC. 1
60719-005 - 277/24 V SEC.
60719-006 - 480/24 V SEC.
L Thermostat Mtg. Bracket 54870-001 1
M SinglePoleThermostat 60074-003 1
N DoublePoleThermostat 56291-001 1
O Wire Barrier 52948-001 2
P PurgeControl 43560-001 1
Q Purge Baffle 52949-001 1
Wattage
81RCH2
21RCH2
71RCH2
81RCH3
21RCH3
71RCH3
81RVH4
21RCH4
71RCH4
81RCH5
21RCH5
71RCH5
83RCH4
23RCH4
83RCH5
23RCH5
41RCH2
41RCH3
41RCH4
41RCH5
43RCH4
43RCH5
F3482
H3482
G3482
F3483
H3483
G3483
F3484
H3484
G3484
F3485
H3485
G3485
J3484
K3484
J3485
K3485
P3482
P3483
P3484
P3485
Y3484
Y3485
208-1
240-1
277-1
208-1
240-1
277-1
208-1
240-1
277-1
208-1
240-1
277-1
208-3
240-3
208-3
240-3
480-1
480-1
480-1
480-1
480-3
480-3
2000
2000
2000
3000
3000
3000
4000
4000
4000
5000
5000
5000
4000
4000
5000
5000
2000
3000
4000
5000
4000
5000
3480
Model
RCH
Model Volts -
Phase
73042-026
73042-027
73042-028
73042-030
73042-031
73042-032
73042-034
73042-035
73042-036
73042-038
73042-039
73042-040
73042-034
73042-035
73042-038
73042-039
73042-029
73042-033
73042-037
73042-041
73042-036
73042-040
56562-011
56562-013
56562-015
56562-011
56562-013
56562-015
56562-011
56562-013
56562-015
56562-011
56562-013
56562-015
56562-011
56562-013
56562-011
56562-013
56562-018
56562-018
56562-018
56562-018
56562-018
56562-018
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
51139-001
51139-001
51139-002
51139-002
51139-002
51139-002
E
Element
assy.
D
Motor
P/N
C
Disc Type
LimitControl
C
(Capillary) Manual Reset
Limit Control
Reference Letter
58530-001
58530-001
58530-001
58530-001
58530-001
58530-001
58530-002
58530-002
58530-002
58530-002
58530-002
58530-002
58530-002
58530-002
58530-002
58530-002
-
-
-
-
-
-
3

3480 / RCH SERIES CEILING HEATER WIRING DIAGRAM
WIRING DIAGRAM FOR
SINGLE PHASE 208, 240
OR 277V HEATERS
WIRING DIAGRAM FOR
SINGLE PHASE 208, 240
OR 277V HEATERS
WD-1 WD-2
WD-3 WD-4
WD-5 WD-6
WIRING DIAGRAM FOR
SINGLE PHASE 208, 240
OR 277V HEATERS WITH
DISCONNECT SWITCH
WIRING DIAGRAM FOR
SINGLE PHASE 208, 240
OR 277V HEATERS WITH
DISCONNECT SWITCH
WIRING DIAGRAM FOR
THREE PHASE 208AND
240V HEATERS
WIRING DIAGRAM FOR
THREE PHASE 208AND
240V HEATERS
4
“S” option “S” option

3480 / RCH SERIES CEILING HEATER WIRING DIAGRAM
WD-7 WD-8
WD-9 WD-10
WIRING DIAGRAM FOR SINGLE
PHASE 208, 240 OR 277V HEATERS
WITH CONTROL RELAY, FAN DELAY
AND DISCONNECT SWITCH
WIRING DIAGRAM FOR SINGLE
PHASE 208, 240 OR 277V
HEATERS WITH DISCONNECT
SWITCH, DOUBLE POLE
TAMPERPROOF THERMOSTAT
AND FAN DELAY
WIRING DIAGRAM FOR SINGLE
PHASE 208, 240 OR 277V
HEATERS WITH DISCONNECT
SWITCH, DOUBLE POLE
TAMPERPROOF THERMOSTAT
AND FAN DELAY
5
“T2S” option “T2S” option
“R, R1 OR R2” option
*NOTE: CONTROL VOLTAGE
R: LINE VOLTAGE
R1: 24 VAC
R2: 120 VAC
WIRING DIAGRAM FOR SINGLE
PHASE 208, 240 OR 277V HEATERS
WITH CONTROL RELAY, FAN DELAY
AND DISCONNECT SWITCH
“R, R1 OR R2” option
*NOTE: CONTROL VOLTAGE
R: LINE VOLTAGE
R1: 24 VAC
R2: 120 VAC
WD-11 WD-12
WIRING DIAGRAM FOR SINGLE
PHASE 208, 240 OR 277V HEATERS
WITH DISCONNECT SWITCH, CLASS
2 TRANSFORMER, RELAY W/LOW
VOLTAGE COIL, SINGLE POLE
TAMPERPROOF THERMOSTATAND
FAN DELAY CONTROL
WIRING DIAGRAM FOR SINGLE
PHASE 208, 240 OR 277V HEATERS
WITH DISCONNECT SWITCH, CLASS
2 TRANSFORMER, RELAY W/LOW
VOLTAGE COIL, SINGLE POLE
TAMPERPROOF THERMOSTATAND
FAN DELAY CONTROL
“TA1S” option “TA1S” option

3480 / RCH SERIES CEILING HEATER WIRING DIAGRAM
WD-13 WD-14
WD-15 WD-16
WIRING DIAGRAM FOR THREE
PHASE 208, 240V HEATERS WITH
DISCONNECT SWITCH, DOUBLE
POLE TAMPERPROOF THERMO-
STATAND FAN DELAY
WIRING DIAGRAM FOR THREE
PHASE 208, 240V HEATERS WITH
DISCONNECT SWITCH, DOUBLE
POLE TAMPERPROOF THERMO-
STAT AND FAN DELAY
WIRING DIAGRAM FOR THREE
PHASE 208, 240V HEATERS WITH
DISCONNECT SWITCH, RELAY WITH
LINE VOLTAGE CONTROLCOILAND
FAN DELAY
WIRING DIAGRAM FOR THREE
PHASE 208, 240V HEATERS WITH
DISCONNECT SWITCH, RELAY WITH
LINE VOLTAGE CONTROLCOILAND
FAN DELAY
WD-17 WD-18
WIRING DIAGRAM FOR THREE
PHASE 208, 240V HEATERS WITH
DISCONNECT SWITCH, CLASS 2
TRANSFORMER, RELAY W/LOW
VOLTAGE COIL, SINGLE POLE
TAMPERPROOF THERMOSTATAND
FAN DELAY CONTROL
WIRING DIAGRAM FOR THREE
PHASE 208, 240V HEATERS WITH
DISCONNECT SWITCH, CLASS 2
TRANSFORMER, RELAY W/LOW
VOLTAGE COIL, SINGLE POLE
TAMPERPROOF THERMOSTATAND
FAN DELAY CONTROL
6
3-“T2S” option 3-“T2S” option
3-“A1S” option 3-“A1S” option
3-“TA1S” option 3-“TA1S” option

3480 / RCH SERIES CEILING HEATER WIRING DIAGRAM
7
LIMIT CONTROL
BLACK
HEATING ELEMENT
MOTOR
BLACK
WHITE 277V ONLY
REMOTE MTD. RELAY
BLACK
BLUE
YELLOW
HEATER SUPPLY
1Ø208/240V
TO LOW VOLTAGE
ROOM THERMOSTAT
57912-002 "F" 208V
57912-003 "H" 240V
CRIMP NUT
LIMIT CONTROL
BLACK
HEATING ELEMENT
MOTOR
BLACK
WHITE 277V ONLY
REMOTE MTD. RELAY
BLACK
BLUE
YELLOW
HEATER SUPPLY
1Ø208/240V
TO LOW VOLTAGE
ROOM THERMOSTAT
57912-002 "F" 208V
57912-003 "H" 240V
CRIMP NUT
WD-19 WD-20
RELAYCONNECTION:
* CONNECT THE YELLOW WIRE WITH L1 AND SUPPLY
WIRE USINGA SUITABLEAPPROVED CONNECTOR
* CONNECT BLUE WIRE WITH L2 USINGAN APPROVED
CONNECTOR
* CONNECT BLACK WIRE WITH SUPPLY WIRE USING AN
APPROVED CONNECTOR
*ALL WIRING SHOULD BE PERFORMED BYAQUALIFIED
ELECTRICIAN INACCORDANCE WITH N.E.C., ALLSTATE
AND LOCAL CODES
