Wired Device Installation Guide
LMUs with internal antennas should be placed to maximize their GPS
performance with the white label facing the sky. A typical location is under the
dash close to the front wind-shield. Attach the LMU to the solid body of the
vehicle, not to plastic panels. The LMU can be placed out of sight by removing
interior trim and molding to expose available space, then replacing the trim
once the LMU is in place.
Connect power, ignition, and ground
1. The power input (red wire) must be connected to a constant (un-
switched) +12 VDC or+24 VDC supply; preferably, connected directly to
the vehicle battery terminal or as close to it as possible. This connection
point should be fuse protected to not more than 5 Amps.

TrackNet LMU-2600 Series Installation and Troubleshooting guide
Contact Customer Service 866-654-2226 or Email [email protected]om
2. The ground line (black wire) must be connected to chassis ground. Failure
to connect these lines in the manner described may result in discharge of
the vehicle battery.
3. The ignition input (white wire) must be connected to the vehicle ignition
or another appropriate key operated line, such as ACCESSORY, ensuring
that power to the ignition wire is available only when the vehicle ignition
is on.

TrackNet LMU-2600 Series Installation and Troubleshooting guide
Contact Customer Service 866-654-2226 or Email [email protected]om

TrackNet LMU-2600 Series Installation and Troubleshooting guide
Contact Customer Service 866-654-2226 or Email [email protected]om

TrackNet LMU-2600 Series Installation and Troubleshooting guide
Contact Customer Service 866-654-2226 or Email [email protected]om

TrackNet LMU-2600 Series Installation and Troubleshooting guide
Contact Customer Service 866-654-2226 or Email [email protected]om
CalAmp 2600 Light sequences:
