Tracmaster Camon SG30 User guide

ORIGINAL INSTRUCTION MANUAL
Before commissioning the machine, read operang instrucons
and observe warning and safety instrucons.
Manufactured by Tracmaster Ltd
CAMON STUMP GRINDER

CAMON SG30 Stump Grinder
Manufacturer Details
Tracmaster Ltd
Units 6-7 Winterpick Business Park
Hurstpierpoint Road
Wineham
Heneld
BN5 9BJ
UNITED KINGDOM
Tel: [phone]
www.tracmaster.co.uk
[e-mail]
Machine Details
Model: CAMON SG30 Stump Grinder
Serial No: A 0 8 - 11111
Engine Serial No: GA A A A -1111111
Purchase Date: D D -M M -Y Y Y Y
Supplier:

CAMON SG30 Stump Grinder
SG30 Stump Grinder Page 1
Table of Contents
1.0 Introducon .............................................................................................................................2
1.1 Welcome ................................................................................................................................2
1.2 About This Manual ................................................................................................................2
2.0 What the Machine is Designed For............................................................................................3
2.1 Applicaons ...........................................................................................................................3
3.0 Specicaons............................................................................................................................4
4.0 Unpacking and Assembly ..........................................................................................................5
4.1 Major Components Diagram .................................................................................................5
4.2 Unpacking Instrucons ..........................................................................................................5
5.0 SafetyInstrucons–Pre-Operaon..........................................................................................7
5.1 Basic Safety Instrucons ........................................................................................................7
5.2 Main Components and Operang Elements .........................................................................7
5.3 Engine and Drive ....................................................................................................................7
5.4 Operang Lever .....................................................................................................................7
5.5 Throle Lever ........................................................................................................................7
5.6 Choke Lever ...........................................................................................................................8
5.7 Rotor Disc and Teeth ..............................................................................................................8
5.8 Commissioning ......................................................................................................................8
5.9 General Safety Instrucons ...................................................................................................8
5.10 Engine Specic Safety Instrucons ........................................................................................9
5.11 Machine Safety Scker Explanaons .....................................................................................9
6.0 SafetyInstruconsStarngandOperang..............................................................................11
6.1 Before Starng the Engine ...................................................................................................11
6.2 To Start the Engine ..............................................................................................................12
6.3 To Stop the Engine ...............................................................................................................13
6.4 Safety Equipment ................................................................................................................13
6.5 Operaon - Removing Stumps .............................................................................................13
6.6 Procedure for Cung the Stump .........................................................................................14
6.7 Procedure for Unexpected Shut Down ................................................................................15
6.8 Residual Risks of the SG30 Stump Grinder ..........................................................................15
7.0 Maintenance ..........................................................................................................................16
7.1 Schedule ..............................................................................................................................16
7.2 Basic Maintenance ..............................................................................................................16
7.3 Advanced Maintenance .......................................................................................................16
7.3.1 Rotang Teeth ...........................................................................................................16
7.3.2 Replacing Teeth .........................................................................................................17
7.3.3 Changing the Teeth Holder .......................................................................................17
7.4 Engine ..................................................................................................................................18
7.4.1 Check Engine Oil Level ..............................................................................................18
7.4.2 Change Engine Oil .....................................................................................................18
7.4.3 Air Filter ....................................................................................................................19
7.4.4 Spark Plug .................................................................................................................19
7.5 Cleaning ...............................................................................................................................19
7.6 Troubleshoong ...................................................................................................................20
7.6.1 Machine ....................................................................................................................20
7.6.2 Engine ......................................................................................................................20
7.6.3 Lubricants ..................................................................................................................20
8.0 Transportaon,StorageandHandling.....................................................................................21
8.1 Transportaon .....................................................................................................................21
8.2 Storage.................................................................................................................................21
8.3 Handling ..............................................................................................................................21
9.0 Spare Parts .............................................................................................................................22
10.0 Service Record ........................................................................................................................23
11.0 ECDeclaraonofConformity..................................................................................................24
12.0 WarrantyInformaon.............................................................................................................25

CAMON SG30 Stump Grinder
Page 2 SG30 Stump Grinder
CAMON LA25 Lawn Aerator
1.0 Introducon
1.1 Welcome
Welcome to Tracmaster and thank you for choosing CAMON.
We are condent that you will be more than happy with your machine.
Your machine is covered by a comprehensive warranty. However, the lifespan of
your CAMON machine depends on a number of factors. It is important that you read
this manual carefully and follow the instrucons regarding operaon, maintenance,
and care.
1.2 About This Manual
It is crucial that you read this manual carefully and understand it. Reading and
understanding this manual should prevent you from operang the SG30 incorrectly
and so extend the life of the machine.
This manual also contains important safety informaon about your machine.
You must observe all safety instrucons at all mes. CAMON machines are oen
updated and improved so models may vary due to dierences in specicaons.
Any illustraons, descripons, specicaons, and technical data in this manual is
correct at the me of prinng.
For any quesons relang to this manual please contact us.
During oce hours (UK) we can be contacted on:
Phone: [phone]
Email: [e-mail]
Website: www.tracmaster.co.uk
IMPORTANT!
READ THIS MANUAL
CAREFULLY
!

CAMON SG30 Stump Grinder
SG30 Stump Grinder Page 3
2.0 What the Machine is Designed For
2.1 Applicaons
The CAMON SG30 Stump Grinder has been designed by Tracmaster for removing
tree stumps from above and below the surface of the ground.
The benet of removing a tree stump is that it allows the landscape to be redesigned
without the stump.
The teeth of the CAMON SG30 Grinder are designed to grind TREE STUMPS ONLY
- they are NOT designed to make contact with solid ground at any point during
operaon.
The machine will be damaged should the teeth connuously come into contact
with solid ground.
DO NOT use the CAMON SG30 Grinder for cung grass or digging the ground.
These operaons will result in damage to the machine.
Operang the machine on non-grass surfaces such as concrete or tarmac will cause
damage to the SG30 Grinder.
DO NOT use the Stump Grinder if there is a likelihood of high temperatures.

CAMON SG30 Stump Grinder
Page 4 SG30 Stump Grinder
3.0 Specicaons
ENGINE
Engine Manufacturer Honda
Engine Model GX360
Engine Type 4-stroke OHV, single cylinder
Net Engine Power 8.7kW (11.7hp) @ 3600rpm
Engine Sha Size 1” straight
Spark Plug BPR6ES (NGK) / W20EPR-U (DENSO)
Spark Plug Gap 0.70 - 0.80mm
Engine Ignion Type Recoil
Cold Start System Choke
Fuel Tank Capacity 6.1 litres
Fuel Type Unleaded
Fuel Consumpon 3.5 litres per hour @ 3600rpm
Air Filter Paper
Rated Engine Speed 3600rpm
Working RPM 2800rpm
Engine Oil 10w/30 API SJ or equivalent
Engine Oil Capacity 1.1 litres
Dry Weight 30kg
The power rang of the engine indicated in this table is the net power output tested on a producon engine for
the engine model and measured in accordance with SAE J1349 at a specied rpm.
MACHINE
Model SG30
Disc Width 30cm
No of Teeth Solid and hollow
Clutch Type Centrifugal clutch
Working Height 45cm above ground to 30cm below ground
Discharge Rear discharge
Wheel Types Pneumac
Handlebar Foldable
Wheel Type Pneumac
Noise Level 104 dB(A)
Vibraon Acceleraon Value 3.1ms2
Max Gradient for Operaon on Slope 15 degrees
Weight 135kg
Dimensions (l x w x h) 190 x 63 x 126cm

CAMON SG30 Stump Grinder
SG30 Stump Grinder Page 5
4.0 Unpacking and Assembly
4.1 Major Components Diagram
① Top Handlebar
② Lower Handlebar
③ Operator Presence
(OPC) Lever
④ Throle Lever
⑤ Choke Lever
⑥ Brake Lever
⑦ Engine
⑧ Cung Disc
⑨ Discharge Area
⑩ Belt Guard
⑪ Wheels
4.2 UnpackingInstrucons
The machine is delivered strapped to a pallet and wrapped with plasc sheet.
Unwrap the plasc wrapping. Cut carefully using a knife if required.
Using a knife or pair of cuers, cut the straps holding the machine onto the pallet.
Push the machine forward safely and gently o of
the pallet once the straps have been removed.
The handlebars will have been folded over the
engine into a transport posion.
To posion the handlebars in their working posion,
remove and relocate the bolts at the boom of the
lower handlebar into the top posion on the chassis
(g. 1).
2
7
8
11
9
5
10
6
3
1
4
Fig. 1

CAMON SG30 Stump Grinder
Page 6 SG30 Stump Grinder
Loosen the large buery knob on
the right hand side of the machine
(g. 2) to allow the top handlebars to
be rotated into the upright working
posion.
Re-ghten the buery knob to x
the top handlebars in the working
posion.
Dispose of the packing material
responsibly.
Fig. 2
Buery
knob

CAMON SG30 Stump Grinder
SG30 Stump Grinder Page 7
5.0 SafetyInstrucons–Pre-Operaon
5.1 BasicSafetyInstrucons
Before starng the machine, read and understand these operang instrucons.
5.2 MainComponentsandOperangElements
Below is a descripon of the main components of the SG30 Stump Grinder and how
they operate.
5.3 Engine and Drive
The Honda GX390 is a four stroke engine that runs on
standard unleaded fuel.
The engine is air cooled and therefore it is important
that the grille covering the recoil rope is kept clear from
debris.
The engine air lter cleans the air sucked in by the
engine. A clogged air lter will reduce performance.
The engine is ed with a fuel on/o lever and a choke lever. Read the engine
operang instrucons to understand the operaon of these levers.
5.4 OperangLever
The engine of the SG30 Stump Grinder is controlled
by the Operator Presence Control (OPC) lever (g. 3).
This lever turns the engine ON or OFF.
Squeezing the Operator Presence Control lever allows
the engine to be started.
Leng go of the Operator Presence Control lever
turns the engine o.
5.5 ThroleLever
The throle lever controls the engagement and speed of the rotor disc and teeth.
If the throle lever is in the SLOW posion the engine revoluons of the crank sha
is too low for the centrifugal clutch to engage and transfer power to the rotor sha
and cung disc.
Posioning the throle lever in the FAST posion will engage the centrifugal clutch
and the rotor sha and cung disc will rotate.
WARNING: MOVING THE THROTTLE FROM SLOW TO FAST MUST ALWAYS
BE CARRIED OUT IN A CONTROLLED MANNER WITH THE OPERATOR UNDER
COMPLETE CONTROL OF THE MACHINE.
!
Fig. 3
OPC lever

CAMON SG30 Stump Grinder
Page 8 SG30 Stump Grinder
5.6 Choke Lever
The choke lever is used to help start the engine when it is cold or being started for
the rst me.
Refer to the engine instrucons for detailed instrucons on the operaon of the
choke lever.
5.7 Rotor Disc and Teeth
The main rotor disc holds 8 teeth holders with each holder holding one carbide-
pped cung tooth.
Each tooth can be turned through three posions in the holder, allowing the teeth
to be used three mes before they need changing.
5.8 Commissioning
Prior to operaon it is necessary to check the engine oil level and add engine oil
level to the levels indicated in the table in secon 6.2.
The engine fuel tank will not contain fuel so will need lling to the recommended
level before use.
5.9 GeneralSafetyInstrucons
Be aware of all the safety requirements for the machine.
Visually check the machine for operaonal safety, complete components and xed
guarding prior to each use.
Read and be aware of the warning and instrucon signs located on the machinery.
Cordon o the work area to access from the general public.
Before starng work clear the area of any objects that may cause damage to the
machine.
Do not operate the machine if you are under the inuence of alcohol or drugs. This
equipment must only be operated by persons who are medically t both physically
and mentally.
Only work in good light and visibility.
Only operate the machine outdoors.
Wear the correct personal protecon equipment (PPE) as instructed by this manual
- gloves, steel toe capped boots or similar, eye protecon and ear defenders.
Operator clothing should not be loose and footwear should oer good grip.
Know how to stop the machine in an emergency.

CAMON SG30 Stump Grinder
SG30 Stump Grinder Page 9
5.10 EngineSpecicSafetyInstrucons
PETROLIS HIGHLYFLAMMABLE.ALWAYSSTOP THEENGINE ANDENSURETHE
FUELTAPISTURNEDOFFBEFOREREFUELING,ORWHENTRANSPORTING,
CLEANING,ORMAKINGADJUSTMENTSTOTHEMACHINERY.
Do not smoke or use a naked ame when refueling.
Use only unleaded petrol from fuel containers designed for this purpose. Refuel
outdoors only and replace the fuel tank cap securely.
Do not mix oil with the fuel.
Leave one inch of space in the fuel tank during relling.
Clear up any petrol spillages immediately.
Always start the engine in the open air. Starng an engine within a conned space
can lead to the inhalaon of toxic substances.
Avoid contact with the engine during operaon as it will become hot. Leave the
engine to cool prior to contact and storage.
Never interfere with the control sengs of the engine.
NEVER TILT THE MACHINE BACKWARDS WHEN CLEANING.
5.11 MachineSafetySckerExplanaons
Readoperanginstrucons
before use.
Remove spark plug before
servicing or performing
maintenance.
Warning: Keep bystanders
away.
Warning! Keep away from
grindingdiscaershutdown.
Shutdown procedure images.
Chokeleverposions.
Throleleverposions.
Starngprocedureimages.
!
432
1
SHUTDOWN PROCEDURE
The grinding
disc will con�nue
to spin during
the machine
shutdown.
WARNING
!
MAX
THROTTLE
MIN
ON
CHOKE
OFF
!
!
80055
123
4 5
6 7
8
1
2
3
4
5
6
7
8

CAMON SG30 Stump Grinder
Page 10 SG30 Stump Grinder
Maximumsound
power level (LWA).
Ensuresafetyguardsarein Earproteconmust
place. Machine MUST NOT be worn when the
be operated without guards. machine is in use.
Warning!Rotang
blade. Keep away.
Danger! Moving blades. Do not remove safety guards
whilst engine is running. Keep hands and feet away.
Machineidencaonlabel.Indicatescompliance
with European standards (CE mark). Includes
uniqueserialnumber,machineweight,power
output,andmonthandyearofmanufacture.
ALWAYSwearPersonalProtecveEquipment(PPE):
Eardefenders,eyeandfootprotecon,safetygloves.
Important! Ring
①MUSTbelied
BEFORE moving lever
②.DONOTforce
the lever without
lingtheringrst.
LWA
120
dB
120DB
DO NOT
OPERATE
WITH GUARD
REMOVED.
WARNING
!
90998
Rotating blade
hazard.
!WARNING
80044
80048
V
V
X
V
V
X
80047
V
V
X
V
V
X
TRACMASTER LTD
Units 6-7
Winterpick Business Park
Hurstpierpoint Road
Wineham, Henfield
BN5 9BJ, UK
T: [phone]
Machine Type: SG30 Stump Grinder
Weight: 135kg Year ID: May 2020
Power: 8.7kW Serial No: A08-10000
80043
Pull up ring 1
before moving
brake lever 2
!
80056
It is important that these sckers are in good
condion, are legible, and are in the correct
posions on the SG30 Stump Grinder. If any of
these sckers are missing or damaged then they
must be replaced. They can be obtained from
Tracmaster Ltd.

CAMON SG30 Stump Grinder
SG30 Stump Grinder Page 11
6.0 SafetyInstruconsStarngandOperang
6.1 BeforeStarngtheEngine
Review all of the safety decals that are placed on the machine for your safety and
convenience. See Parts Diagram for aid in locang all decals on the machine.
Make sure that all shields, guards, and curtains are in place, and are in good
condion prior to operang the machine.
Only responsible, properly instructed individuals should operate this machine.
Inexperienced operators must always be carefully supervised.
Check cung wheel for damage or missing teeth and replace as necessary.
Make sure that no-one is working on, underneath, or close to the machine before
starng the engine or beginning to move the machine. Make sure that the area is
free of personnel.
Check stumps to be removed for embedded nails, wire, metal fence posts, and
other metallic objects, and for rocks or other buried impediments which may
become dangerously thrown or cause unexpected machine movements when hit
by the cung wheel.
Ensure that everyone in the vicinity
is aware of the DANGER ZONE
associated with this machine –
this is an 8m radius around the
machine (see g. 4).
You and they must avoid the
DANGER ZONE at all mes when
the machine is in operaon.
The SAFE ZONE for the operator,
subject to the operator wearing
the appropriate safety equipment
(PPE) as outlined in secon 6.4, is
indicated in g. 4.
Make no alteraons or modicaons to your CAMON Stump Grinder unless
requested or recommended by Tracmaster Ltd.
Check with the local ulies for the locaons of buried pipes and cables where
applicable, before operang the machine.
Fig. 4

CAMON SG30 Stump Grinder
Page 12 SG30 Stump Grinder
6.2 To Start the Engine
Using the dipsck provided,
check the engine oil level. Top
up with SAE 10W/30 oil, API SJ
or later, if the dipsck is clear
of oil.
Check the fuel level. Rell as
necessary and as determined
by the fuel tank type – see
diagram.
Lock the le hand wheel by pulling brake lever fully back.
IMPORTANT: Pull up ring ① before moving lever (g. 5).
Squeeze the Operator Presence Control (OPC) lever to
turn the engine on (g. 6).
If engine is cold, move the choke lever to the “ON”
posion (g. 6).
Make sure throle is in “MIN” posion.
Raise the cuer wheel o the ground, approximately 4”
to 5”, by pushing downward on the control handle. Hold
it in that posion.
WARNING: THE NEXT STEP MAY CAUSE THE
CUTTER WHEEL TO ROTATE. KEEP EVERYONE
AWAY!
Pull the starter rope lightly unl resistance is felt, then
pull briskly (g. 7).
Move the choke lever to the “ON” posion (g. 8).
WARNING:THE NEXT STEP CAUSES THE CUTTER
WHEEL TO ROTATE. KEEP EVERYONE AWAY!
Move the throle to “MAX” posion (g. 8).
If the engine is cold, allow the engine to idle (throle set
to “MIN” posion) for a few minutes before cung.
Once the engine is running, move the choke lever to the
“OFF” posion (g 8).
Fig. 5
Fig. 6
Fig. 7
!
!

CAMON SG30 Stump Grinder
SG30 Stump Grinder Page 13
6.3 To Stop the Engine
Tilt the stump grinder to raise the teeth into the air.
Move the throle lever to the “MIN” posion (g. 9).
Release the operator presence lever (g. 10).
Ensure the blades have stopped rotang prior to moving
the machine.
Turn the fuel tap lever to the “OFF” posion.
WARNING:THEEXHAUSTCOVERMAYBEHOT–
DO NOT TOUCH.
6.4 Safety Equipment
The SG30 operator must be wearing:
• Ear Defenders
• Gloves
• Protecve Footwear
• Safety Glasses
• Forestry Helmet (recommended)
6.5 Operaon-RemovingStumps
Before grinding a stump the area must be cleared of
any objects such as stones or metal that would damage
the grinder or be picked up and thrown by the rotang
blades.
WARNING: REMOVE ALL HARD OBJECTS SUCH AS GRAVEL, ROCKS AND
STONES TO REDUCE THE LIKELIHOOD OF THESE OBJECTS BEING THROWN
BY THE STUMP GRINDER.
Remove all loose pieces of wood, stones, wire and
other debris from the work area before beginning
stump removal.
Wind direcon should be considered, as it inuences
the direcon in which dust and wood chips will be
directed.
Never operate the machine aer dark. Night-me operaon will not allow the
operator to see the stump and danger zone adequately enough for safe operaon.
Always allow a cold engine me to warm up before cung a stump.
Only the poron of cung wheel within the 80o area shown in g. 11 should engage
the stump.
Never undercut the stump or use the boom of the cung wheel for cung
purposes.
Fig. 9
Fig. 10
Fig. 8
!
!Fig. 11

CAMON SG30 Stump Grinder
Page 14 SG30 Stump Grinder
6.6 ProcedureforCungtheStump
PosiontheStumpGrinder(g. 12).
Place the machine into posion with the cung
wheel near the top edge of the stump.
Removenearbyrootsrst(g. 13).
Conduct the pre-starng inspecon if not already
done and start the engine as per the operang
instrucons above. Allow the engine to “warm
up” for 30 seconds with the engine revs set to
the MIN posion prior to starng to remove the
stump.
Lock the brake by pulling back the brake lever.
Make sure the throle is set to “MAX”. The cuer
wheel is thus accelerated to cung speed.
Swing the cung wheel to one side, then lower it
approximately 1” into the nearside roots that are
buried at the foot of the stump.
Swing the cung wheel across the roots, back
and forth, lowering cung wheel approximately
1” before each sweep, unl the roots are
suciently removed.
Raise the cung wheel unl the centre of the
cung wheel is just above the top of the stump.
Allow the cuer wheel to stop rotang, release the brake, and reposion the
machine. Lock the brake again.
Remove the main part of the stump (g. 14).
Make sure the throle is set to “MAX”. The cuer wheel is thus accelerated to
cung speed.
Direct the cuer wheel against the stump, beginning with the nearside top corner
of the stump, and steadily sweep it across the stump le and right, cung away 1”
of wood with each sweep.
Raise and lower the cuer wheel, between sweeps as needed, by lowering and
raising the control handle.
Roll the machine forward and back by pushing and pulling on the control handle,
between sweeps as needed, in order to progress into the stump. To do this, release
the brake. Relock it when the machine has been reposioned, and connue cung.
Shut o the engine by releasing the Operator Presence Control (OPC) lever.
Fig. 12
Fig. 13
Fig. 14

CAMON SG30 Stump Grinder
SG30 Stump Grinder Page 15
HelpfulpsforoperangtheStumpGrinder
Use smooth, comfortable movements while operang.
When it is desired to cut smaller roots, it may be more eecve to do so before,
rather than aer, cung the stump.
Should the chip build-up become excessive when cung, shut o the machine,
wait for the cung wheel to stop rotang, retract the machine from the stump,
and rake away chips.
On larger stumps, when cung from one side, eventually a tyre may tend to roll
into the hole. This may be prevented by moving the machine to another side of the
stump to connue removal, or by lling the hole with chips before connuing.
WARNING: NEVER USE THE STUMP GRINDER IN POOR LIGHT OR AT NIGHT.
6.7 ProcedureforUnexpectedShutDown
Release the Operator Presence Control (OPC) lever.
Push down on the handlebars to raise the teeth into the air.
Ensure the rotor sha and blades have stopped rotang prior to moving the
machine.
6.8 Residual Risks of the SG30 Stump Grinder
The rotor sha will connue to rotate for several seconds once the operang lever
has been released. Ensure that the blades have stopped rotang prior to moving or
lng the machine.
The SG30 Stump Grinder is designed to be pushed by the operator both during
transportaon and operaon. The SG30 is ed with a wheel brake on the le hand
wheel that may be used to hold the machine on sloped areas.
!

CAMON SG30 Stump Grinder
Page 16 SG30 Stump Grinder
7.0 Maintenance
IMPORTANT! BEFORE UNDERTAKING ANY MAINTENANCE ENSURE
THAT THE ENGINE IS OFF AND THE FUEL TAP IS OFF.
7.1 Schedule
Operaon Daily
Every
Week
Every
Month
Engine Check engine oil level SAE 10W/30 API SJ or later
See separate engine manual X X
Machine
Check condion of teeth X
Check belt condion X
Check operang lever and cable X
Check rotor sha bearings X
Lubricate wheel bearings X
Tighten all nuts and bolts X
7.2 Basic Maintenance
Check that all guards are ed securely.
Ensure the cable connecng the operang lever to the engine is securely fastened
at both ends and shows no sign of wear.
Check the pressure of pneumac tyres and ensure that they do not show any
indentaons or signicant wear and tear.
Ensure the wheels are held securely and the bolts that hold the wheels onto the
axles are in place.
Check the wheels rotate smoothly and without hindrance.
Grease the cuer sha bearings daily.
7.3 Advanced Maintenance
We strongly recommend that an Authorised Representave is consulted prior to
any major machine maintenance projects.
7.3.1 RotangTeeth
InspeconCheck:
A tooth that has become rounded on its
leading edge (g. 15a) can be rotated to
an unworn posion facing forwards so that
the SG30 Stump Grinder can connue to
funcon properly.
!
Rounded tooth Sharp tooth
Fig. 15a Fig. 15b

CAMON SG30 Stump Grinder
SG30 Stump Grinder Page 17
To Rotate Teeth:
To rotate a tooth, rst loosen the locknut
that holds the tooth in its holder on the
tooth pocket.
Li and rotate the tooth to the next
indexed posion so a sharp edge is facing
forwards on the machine.
Re-ghten the nut to 27Nm to secure the
tooth ghtly in posion.
7.3.2 Replacing Teeth
InspeconCheck:
Blades that have been worn so that they have become rounded must be
changed for the SG30 Grinder to funcon properly (g. 15a).
To Replace Teeth:
Loosen and remove the locknut and spacer that hold the tooth in its holder
on the tooth pocket.
Slide the worn tooth out of the tooth pocket.
Insert a new tooth with sharp carbide edges and re-t the spacer. Ensure
that the spacer is installed with the chamfered
edge facing downwards so that it ts inside the
tooth holder (g. 16).
Tighten the lock nut that holds the tooth in the
tooth holder securely to 27Nm.
7.3.3 Changing the Teeth Holder
InspeconCheck:
Teeth holders that are damaged or which can
move whilst the bolts are fully ghtened must
be replaced to ensure the safe retenon of the
teeth.
To Replace Teeth Holders:
There are two types of teeth holder on the
cung disc, a straight tooth holder and an
angled tooth holder (g. 17). There a four of
each type, eight in total, and they are ed in
pairs, one of each type either side of the cung
disc.
Fig. 16
Locknut
Spacer
Tooth
Holder
Fig. 17
Angled
holder Straight holder
Angled
holder
Straight
holder

CAMON SG30 Stump Grinder
Page 18 SG30 Stump Grinder
The holders must be ed alternately, eg, the rst pair would be a straight
holder and an angled holder, then the second pair would be an angled holder
and a straight holder, and so on.
When changing the teeth holders it is essenal that a similar type of holder
is posioned in the same posion as the holder that was removed.
WARNING: INCORRECT FITTING OF TEETH HOLDERS ONTO THE
ROTATING CUTTING DISC CAN SERIOUSLY AFFECT PERFORMANCE
AND MAY DAMAGE YOUR MACHINE.
Loosen and remove the two bolts used to clamp the two teeth holders either
side of the rotang cung disc.
Replace the tooth holders with a similar tooth holder type and reposion
and ghten the bolts to hold them in place (g. 18).
The tooth holders are reversible; each holder has one threaded hole and
one counter-bored hole which allow the tooth holder bolts to feed into the
wheel from opposite sides to ensure a strong secure setup.
The tooth holder bolts must be ghtened to a torque seng of 244Nm if
using anseize (copper slip) or 325Nm dry.
7.4 Engine
7.4.1 Check Engine Oil Level
This is to be checked prior to each use and every 8 hours during operaon.
Check only when the engine is o and in a horizontal posion.
Clean the oil ller plug and its surrounding parts.
Remove the oil ller plug. Clean the dipsck with a clean cloth and put the
oil ller plug all the way back into the engine. Remove the oil ller plug and
check the oil level.
Rell the oil if indicator shows more is required. For the Honda GX160 the
recommended oil is SAE 10W/30 API SJ or equivalent.
7.4.2 Change Engine Oil
Refer to the engine manufacturer’s manual for locaon of components and
more detailed assistance.
Do not change the oil if the engine is hot.
The rst oil change is aer 50 hours of work.
Subsequent oil changes should be made aer each 100 hours of work.
At extreme temperatures or condions change the oil aer every 50 hours.
!
