Trane 2MCC05-C User manual

SAFETY WARNING
Only qualified personnel should install and service the equipment. The installation, starting up and
servicing of heating, ventilating and air-conditioning equipment can be hazardous and requires specific
knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could
result in death or serious injury. When working on the equipment, observe all precautions in the literature
and on the tags, stickers, and labels that are attached to the equipment.
U-Match Systems (R410A)
18,000 to 60,000 BTU/h - 60 Hz
Cooling only: 2MCC05-C / 4TTK05-D Heat Pump: 2MWC05-C / 4TWK05-D
2MCXO5-C / 4TTK05-D 2MX05-C / 4TWK05-D
2MZD05-C / 4TTK05-D 2MZD05-C / 4TWK05-D
February 2018 MS-SVN056C-EN
Installation Manual

© 2018 All rights reserved MS-SVN056C-EN
Warnings, Precautions, Notices
Safety advisories appear throughout this manual are required. Your personal safety and the proper
operation of this machine depend upon the strict observance of these precautions.
The three types of advisories are defined as follows:
Important
Important Environmental Concerns
Scientific research has shown that certain man-made chemicals can affect the earth‘s naturally
occurring stratospheric ozone layer when released to the atmosphere. In particular, several of the
identified chemicals that may affect the ozone layer are refrigerants that contain Chlorine, Fluorine
and Carbon (CFCs) and those containing Hydrogen, Chlorine, Fluorine and Carbon (HCFCs). Not all
refrigerants containing these compounds have the same potential impact to the environment.
Trane advocates the responsible handling of all refrigerants including industry replacements for
CFCs and HCFCs such as saturated or unsaturated CFCs and HCFCs.
Important Responsible Refrigerant Practices
Trane believes that responsible refrigerant practices are important to the environment, our
customers and the air conditioning industry. All technicians who handle refrigerants must be
certified according to local rules. For the USA, the Federal Clean Air Act (Section 608) sets forth the
requirements for handling, reclaiming, recovering and recycling of certain refrigerants and the
equipment that is used in these service procedures. In addition, some states or municipalities may
have additional requirements that must also be adhered to for responsible management of
refrigerants. Know the applicable laws and follow them.
WARNING Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
PRECAUTIONsIndicates a potentially hazardous situation which, if not avoided, could
result in minor or moderate injury. It could also be used to alert against
unsafe practices.
NOTICE: Indicates a situation that could result in equipment or property-damage
only accidents.

MS-SVN056C-EN 3
Warnings, Precautions, Notices
WARNING
Proper Field Wiring and Grounding Required
Failure to follow code could result in death or serious injury. All field wiring must be performed
by qualified personnel. Improperly installed and grounded field wiring poses FIRE and
ELECTROCUTION hazards. To avoid these hazards, you MUST follow requirements for field
wiring installation and grounding as described in NEC and your local/state/national electrical
codes.
WARNING
Personal Protective Equipment (PPE) Required
Failure to wear proper PPE for the job being undertaken could result in death or serious injury.
Technicians, in order to protect themselves from potential electrical, mechanical and chemical
hazards, MUST follow precautions in this manual and on the tags, stickers and labels, as well
as the instructions below:
• Before installing/servicing this unit, technicians MUST put on all PPE required for the work
being undertaken (example: cut-resistant gloves/sleeves, butyl gloves, safety glasses, hard
hat/bump cap, fall protection, electrical PPE and arc flash clothing). ALWAYS refer to
appropriate Material Safety Data Sheets (MSDS)/Safety Data Sheets (SDS) and OSHA
guidelines for proper PPE.
• When working with or around hazardous chemicals, ALWAYS refer to the appropriate MSDS/
SDS and OSHA/GHS (Global Harmonized System of Classification and Labelling of
Chemicals) guidelines for information on allowable personal exposure levels, proper
respiratory protection and handling instructions.
• If there is a risk of energized electrical contact, arc, or flash, technicians MUST put on all PPE
in accordance with OSHA, NFPA 70E, or other country-specific requirements for arc flash
protection, PRIOR to servicing the unit. NEVER PERFORM ANY SWITCHING,
DISCONNECTING OR VOLTAGE TESTING WITHOUT PROPER ELECTRICAL PPE AND ARC
FLASH CLOTHING. ENSURE ELECTRICAL METERS AND EQUIPMENT ARE PROPERLY RATED
FOR INTENDED VOLTAGE.

4MS-SVN056C-EN
Content
Warnings, Precautions y Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Model Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Security Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
System Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Indoor unit (Cassette) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
System Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Indoor unit (Concealed) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
System Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Indoor unit (Convertible) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cassette Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Concealed Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Convertible Unt Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Outdoor Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Piping connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Drain pipe connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Maintenance recommendations......... . . . . . . . . . . . . . . . . . . 42
Electrical Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Wiring connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Operation test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Power Specificationsa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Cassette unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Concealed unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Convertible unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

MS-SVN056C-EN 5
Wired Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Installation procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Accessories provided for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Cassette unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Concealed unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Convertible unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
U-Match Unit interconnection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

6MS-SVN056C-EN
General Information
General
These instructions are offered as guidelines for the proper installation, start-up and operation for
universal coupling systems 2MX/2MW. However, these do not contain all fully required procedures
for a continued operation free of obstacles. Therefore, it is important to contract a professional
service agency for such matters. Read these instructions carefully before installing the equipment.
Warranty
Warranty is based upon general terms and conditions of the manufacturer. Warranty may be
nullified if the equipment were to be modified or repaired without the express approval of the
manufacturer, or if operation limitations were to be exceeded, or if electrical wiring of the system
were to be altered. Any damage to the equipment as a result of bad use of same, or lack of
maintenance, or non-compliance with instructions offered by the manufacturer, will not be covered
by the warranty. Warranty will be automatically cancelled if the user does not adhere to the rules
described in this manual.
Reception
Upon arrival, inspect the unit before signing approval of delivery. Specify any damages observed
at the time of delivery and report same in writing to the transportation company, within 72 hours
of delivery. At the same time, notify your local sales representative of these damages. Inspect the
unit within the first 7 days of delivery. If any concealed damage is detected, advise of same in
writing to the transportation company within 7 days of delivery, as well as to your local sales
representative.
About the Unit
Before shipping, the unit covered in this manual are assembled, dehydrated, charged and leak
tested. This document contains information related to the units of Universal Coupling.
Refrigerant
Refrigerant provided by the manufacturer complies with all Trane unit requirements. When using
recycled or reprocessed refrigerant, it is recommended to ensure that the quality is equivalent to
new refrigerant. To do this, it will be necessary to order an analysis of said refrigerant by a
specialized laboratory. Any action contrary to this measure, will compel the manufacturer to anull
the warranty.
IMPORTANT:
The unit must be installed in accordance with national regulations for electrical installations.
These instructions do not cover all variations in the system, nor do they foresee all possible
contingency. If further information were to be required or if problems should arise which are not
covered sufficiently in this manual, the matter should be turned over to the local Trane Sales Office.

MS-SVN056C-EN 7
Model Numbers
Model Numbers
U-Match Systems R410-A - 60 Hz
18,000 to 60,000 BTU/Hr
Single split system, cooling only, fixed speed
Heat pump, fixed speed
Indoor Unit Outdoor Unit
Cassette 2MCC05-C 4TTK05-D
Concealed 2MCZ05-C 4TTK05-D
Convertible 2MCX05-C 4TTK05-D
Indoor Unit Outdoor Unit
Cassette 2MWC05-C 4TWK05-D
Concealed 2MZD05-C 4TWK05-D
Convertible 2MWX05-C 4TWK05-D

8MS-SVN056C-EN
Security Recommendations
Security Recommendations
The following recommendations will help to obtain the best performance of your air-conditioning
unit:
• Do not leave doors and windows open for a long period of time while the unit is in operation
as it will reduce the unit’s air-conditioning capacity.
•Do not place heat sources near the air conditioner as it will reduce the unit’s air-conditioning capacity.
• When the unit is not used for an extended period of time, disconnect incoming power to the
unit.
• If some smell of burning or smoke is detected, immediately disconnect all power supply to the
unit and alert your authorized service agency of the situation. If this condition persists, it could
be due to damages found in the unit which could possibly lead to electric shock or fire.
• Make sure the unit is not close to any type of fuel sprays (at least 1 meter in distance) in order
to avoid fire or explosion hazards.
• Never try to repair the air conditioning unit by yourselves. An erroneous repair could lead to
electrocution or fire. Always call your service agency for all repairs.
• Never splice or join electrical wiring, and never use an extension cord. This practice could lead
to super-heating or fire.
• Electrical power supply should be of appropriate rated amperage and conform to all local
codes.
• In order to prevent electric shock or fire, do not cut or damage power or control cords. If any
of these cords are found to be damaged, request their replacement only to qualified personnel.
• Do not operate the unit without air filters installed. Otherwise, the penetration of debris or dirt
could damage the unit. Filters must be removed and cleaned periodically to ensure their
maximum efficiency.
NOTICE:
Air Flow Restriction
Ascertain that system incoming air flow and outgoing air flow is free of all obstructions.
Otherwise, it could prevent the unit’s good performance and could provoke damages to the
equipment.

MS-SVN056C-EN 9
System Appearance
System Appearance
Indoor Unit (Cassette)
Note: All pictures in this manual are merely representative of their image since they may differ from the actual unit acquired
by the customer.
UN. INTERIOR
UN. EXTERIOR
3
9
10
11
11
12
1
5
7
8
2
4
6
RESET
TIMEON
TIMEOFF
CLOCK
SWING
AIRDIRECTION
OK
ECO
SWING
MODEFAN
SPEED
LOCK
C/H
AUTO
COOL
DRY
HEAT
FAN
TEMP
SET
CLOCK
SET
HOUR
FANSPEED
Indoor Unit Outdoor Unit
(1) Air flow louver (outgoing air) (7) Incoming air vents
(2) Drain pump (condensing water) (8) Panel
(3) Drain pipe (9) Remote controller
(4) Outgoing air (10) Refrigerant piping
(5) Air filter (incoming air louvers) (11) Incoming air
(6) Incoming air (12) Outgoing air

10 MS-SVN056C-EN
System Appearance
System Appearance
Indoor Unit (Concealed)
Note: All pictures in this manual are merely representative of their image since they may differ from the actual unit acquired
by the customer.
Indoor Unit Outdoor Unit (A, B, C)
(1) Outgoing air (7) Connecting piping
(2) Incoming air (8) Incoming air
(3) Air filter (9) Incoming air (sideways)
(4) Electric control cabinet (10) Outgoing air
(5) Wired controller (in some models)
(6) Drain pipe
UN. INTERIOR UN. EXTERIOR
1
2
3
4
5
6
7
8
9
10

MS-SVN056C-EN 11
System Appearance
System Appearance
Indoor Unit (Convertible)
Note: All pictures in this manual are merely representative of their image since they may differ from the actual unit acquired
by the customer.
Indoor Unit Outdoor Unit (A, B, C)
(1) Outgoing air (7) Connecting piping
(2) Mesh filter (nylon) (8) Incoming air
(3) Unit support (9) Outgoing air
(4) Electrical control cabinet
(5) Wired controller (in some models)
(6) Drain pipe

12 MS-SVN056C-EN
Cassette Unit Installation
Cassette Unit Installation
Location
The unit must be installed in a place that complies with the following requirements:
•Fullclearanceforinstallation and maintenance procedures
• Unobstructed inlets and outlets and also free of outdoor air currents
• Appropriate capacity to allow the flow of air to reach the space designated for air conditioning
• Easy removal of all connecting and draining piping
• Space devoid of radiation and heat sources
Note: Keep the unit at a distance of at least 1 meter away from TV sets and radios to
avoid interference from sound and images coming from these devices.
Piping connection Drain pipe connection
threaded rods)
Body)
Connecting entry for drain pipe
Connecting entry for refrigerant line
(liquid side)
Connecting entry for refrigerant line
(gas side)
Ground
Ceiling
Outgoing Ingoing
ceiling hole)

MS-SVN056C-EN 13
Cassette Unit Installation
Drilling a hole in existing ceiling (horizontal)
1. Drill a 880 x 880mm hole following the outline indicated on the mounting template.
•The center of the hole must be placed in the same position corresponding to the body of the
air-conditioning unit.
•Determine the lengths and outlets of connecting piping, drain piping, and wiring cables.
•In order to balance the installation in the ceiling and also to avoid vibrations, install wedges
as may be deemed necessary.
2. Determine the position of the support rods following perforations for rods indicated on the
mounting template.
•Drill four holes of 12mm dia. and 45-50mm in depth at the places indicated on the ceiling.
Insert expansible anchors.
•Place the hollow side of the rods towards the expansible anchor. Determine the length of
installation rods based on the height of the ceiling. Cut away any remaining and
unnecessary extension. If ceiling height is taller, determine the length of installation rods
according to the space available for installation.
3. Apply equal torque to hex nuts on all four hanging rods to ensure the correct balance of the unit.
•Place the drain pipe in the right direction to allow it to adjust to the movement of the water
level controller.
•Center the unit in a manner that may ensure uniform spacing between the body of the unit
and the four sides of the ceiling. The lower side of the body of the unit must penetrate the
ceiling in approximately 10 to12 mm.
•In general, the L distance represents half of the length of the installation rod.
•Once the unit has been installed, apply final torque to all nuts.
Drilling a hole in a ceiling of new construction
1. In the case of new construction, hanging rods may be inserted in advance (see point No. 2 in
section above). Rods must have the capacity to support the weight of the indoor unit and must
be unable to become loose due to the effects derived from concrete compression.
2. After installing the body of the unit, install the mounting template over the air conditioning unit
using M6 x 12 screws in order to determine in advance the sizes and positions of ceiling holes.
•Before the installation, make sure the ceiling maintains proper leveling.
•Refer to point No. 1.
3. See point No. 3 in section above
4. Remove the installation template.
Note: In order to install the body of the unit, adjust all four screws (M6 x 12) to the air
conditioning unit to ensure its grounding.

14 MS-SVN056C-EN
Cassette Unit Installation
Panel Installation
Note: Never place the panel face down on the floor or against a wall or heavy object.
Protect it from being hit or being scratched.
1. Air grill removal
•Slide both sliding bars simultaneously towards the center and then lift them.
•Lift the air grill at an angle of 45 degrees and remove it.
2. Remove the 4 corner installation panels.
•Remove the screws, loosen the cable/wiring from the four corner panels, and proceed to
remove panels.
Body
Ceiling
Body Center hole
Carton template
Sliding bars
air grille

MS-SVN056C-EN 15
Cassette Unit Installation
3. Panel placement
•Align panel’s swing motor with the refrigerant connections on the body of the unit.
•Insert panel hooks into the swing motor and the opposite sides to the hooks of the
corresponding water deposit. Hang the other two panel hooks to the corresponding sections
on the body of the unit.
Note: Do not entangle the swing motor cable inside the insulation sponge material.
•Adjust all four panel hanging rods to horizontal position; adjust them equally until they reach
the ceiling.
•Place the panel following the arrows in order to center it to the opening on the ceiling. Make
sure that all four corner hooks are adjusted correctly.
•Tighten the screws below the panel hooks until the width of the sponge between the body
and panel outlet is reduced to approximately 4 to 6 mm. The edge of the panel must touch
the ceiling. Failure in the operation of the unit may be due to inappropriate adjustment of
the panel screw.
•If after adjustment of the installation screws a spacing can be observed between the panel
and the ceiling, the height of the indoor unit must be modified once more.
•Modification of the unit’s height can be done through the openings at the four corners of the
panel, provided that the adjustment of the indoor unit and the drain pipe will not be affected.
4. Install the air grill inside the panel. Connect power leads to the swing motor and control box
at their corresponding terminals.
5. Reinstall the air grille inverting the procedure employed to dismount it.
6. Reinstall the corner covers on the panel.
•Connect the panel cable to the screw on same panel.
•Carefully press the corner cover inside the panel.
Piping connection
water drain
Support anchor
Swing motor
Hook
screw
Refrigeration connection
(líquid and suction)
Water deposit (internal)
Phillips screwdriver

16 MS-SVN056C-EN
Cassette Unit Installation
sponge seal
(insulation)
body
ceiling
panel
foam rubber
on panel 1 outgoing air
fan foam rubber on panel 2
4-mm6
foam rubber on the outlet
Leak
Ceiling
Contamination
Condensation leaking
Loosen top screw
Adjust lower screw
Spacing forbidden
Tapping screw on
corner cover panel Slide all four bars in the
corresponding channel
when installing the cover panel

MS-SVN056C-EN 17
Cassette Unit Installation
Drain test
Verify the integrity of the drain pipe. In cases of new construction, we recommend testing the drain
before cementing the ceiling.
Units with water pump
1. Remove the testing port cover and pour 2000ml of water in the drain pan.
2. Operate the unit in cooling mode. The operation of the pump will be heard during testing. Verify
that water drains correctly (1 minute delay, depending upon the length of the drain tube).
Confirm that all pipe fittings are leak-free.
3. Shut the unit down and replace the testing port cover.
<500mm
mm057<
1-1.5m
Testing port cover
C
L
O
S
E
D
O
P
E
N
C
L
O
S
E
D
O
P
E
N
Water deposit
Body
Testing port
Pump connection
Testing port cover
Feeding tube (water)
Draining port cover
Inclination 1/50
Support bracket for pump tube

18 MS-SVN056C-EN
Cassette Unit Installation
Distribution ductwork installation
Model 18 to 24 Series A = 160mm; Series B = 75mm
Model 36 to 60 Series A = 160mm; Series B = 95mm
Single duct connection
Ductwork air volume is approximately 300-360m3/h - Model 18 to 24
Ductwork air volume is approximately 400-640m3/h - Model 36 to 60
Maximum duct length is 2m.
In the case of double duct connection, the original opening for outgoing air with the same piping direction, must
be sealed.
Double duct connection
Ductwork air volume is approximately 200-260m3/h - Model 18 to 24
Ductwork air volume is approximately 300-500m3/h - Model 36 to 60
Maximum duct length is 1.5m for a single duct.
The original opening for outgoing air with the same piping direction, must be sealed.
80mm
80mm
Ø75mm
MODLE (18-60)
Fresh air
intake
Distribution duct
Distribution
duct
Distribution
duct
Distribution duct
Fresh air
One way
Two ways

MS-SVN056C-EN 19
Concealed Unit Installation
Concealed Unit Installation
Location
The unit must be installed in a place that complies with the following requirements:
•Fullclearanceforinstallation and maintenance procedures
• Unobstructed inlets and outlets and also free of outdoor air currents
• Appropriate capacity to allow the flow of air to reach the space designated for air conditioning
• Easy removal of all connecting and draining piping
• Space devoid of radiation and heat sources
Note: Keep the unit at a distance of at least 1 meter away from TV sets and radios to
avoid interference from sound and images coming from these devices.
Clearance for maintenance procedures
Hanging rods installation (4)
• Consult the following diagrams to determine the distance in between hanging rods. Use
threaded rods of 10mm dia. / 0.394 in.
• Hanging ceiling rods/supports will vary according to each individual construction. Always
maintain supports/rods perfectly leveled and reinforce them with wedges in order to prevent
vibrations.
• Cut hanging supports/rods as deemed necessary and reinforce the cutting points.
• Install piping system after installing the body of the unit. Determine the direction of the piping
with outlet towards the outside of the suspended ceiling. Before installing the machine,
determine connecting points for refrigerant lines, drain piping, and indoor and outdoor unit
lines.
Note: Confirm that minimum draining pitch is of 1/100 or more.

20 MS-SVN056C-EN
Concealed Unit Installation
Wooden construction ceilings
Place a wooden cross-member over the plafond ceiling support. Insert hanging rods as is shown
below.
New concrete brick ceilings
Insertion or embedding of threaded hanging rods (with butterfly type rawl plugs)
Original concrete brick ceilings
Use threaded rod, eye-bolt or reinforced lug
Steel beam ceilings
Install using a steel support angle
Hanging the unit
•Hang the unit from the threaded rods and fasten it with the corresponding nuts.
•Level the unit with the use of a level gauge
Wooden cross-member over
the support beam/rafter
Anchor bolt
Ceiling beam
Plafond ceiling
Vertical insertion
Sliding insertion
Steel bar
Hanging rod
(Pipe and hanging rod)
Anchor bolt
Steel support rafter
Hanging rod
Washer
Hanging rod
Nut
Clamping ring for hanging
