Trane TZON1050AC52ZAA User manual

One System.
Limitless Potential.
Complete Control.
32-5093-03
ComfortLink™ II XL1050
Model TZON1050AC52ZAA
WITH

page 2 XL1050 User Guide
Thank you for choosing the XL1050 Smart
Control. The intuitive interface and powerful
features incorporated into this large color touch
screen control represent the latest in climate
control technology from the industry’s leader in
residential heating and air conditioning systems.
This guide will introduce you to many of the
XL1050’s features and get you started using your
Smart Control right away.
To enjoy the full benet of your XL1050 Smart
Control, it should be connected to a Nexia™
Smart Home System account. Nexia is a cloud
based platform that helps the smart products in
your home work together in a single, convenient
application. The XL1050 ships ready to serve as
the central hub of an entire network of home
automation devices. When connected to Nexia
smart home system you can control your home’s
heating and cooling system and over 200 Z-Wave
devices from a web enabled smart phone, PC or
tablet.
For online user guide support, go to www.
mynexia.com, scroll to the bottom of the page
and select Help.
Features Include:
• Wi-Fi or Ethernet Connectivity
• Nexia™ climate service
• Built in Nexia Bridge
• Weather Forecast, Radar and Alerts
• Home Screen Widget Options
• Allergy Clean/Quick Clean Cycles
• Screen Lock & Guest Access Security
• Ten Year Registered Warranty
• User Setup Wizard
• Self Guided Scheduling
• One Touch Presets
• Runtime History
• System Alerts
• Screen Saver
• Clean Screen
• Color Themes
Congratulations!

32-5093-03 page 3
Navigation Overview ..................................... 4
Home Screen .............................................................5
Menu Screen..............................................................6
Settings Screen.........................................................7
Home Screen Customization ......................... 8
Default .........................................................................8
Default + Presets......................................................9
Adding Widgets..................................................... 10
User Setup Wizard ........................................ 11
Display ...................................................................... 12
Screen Layout......................................................... 13
Scheduling .............................................................. 14
Network Setup....................................................... 16
Nexia Registration................................................. 17
Weather Setup ....................................................... 19
Manual Scheduling....................................... 20
Changing the Schedule ...................................... 21
Adding Periods ...................................................... 23
Deleting Periods.................................................... 24
Screen Lock and Guest Access ..................... 25
Screen Lock and Guess Access......................... 25
Nexia™ smart home system ......................... 26
Adding/Removing Z-Wave Devices (via 1050) .......... 27
Adding Z-Wave Devices (via mobile app) .................. 28
Advanced Z-Wave Settings................................ 29
Other Features .............................................. 30
Quiet Mode ............................................................. 30
Notices
FCC & IC NOTICE .................................................... 31
Contents
Nexia Remote Climate Access is included with the purchase of Trane smart connected controls. Up to four Trane smart controls, of any
combination, may be connected to a Nexia smart home system account without a monthly service fee. Additional smart controls and home
automation devices may require a monthly subscription for remote access via most web-enabled smartphones, tablets and computers.
Internet service and Nexia registration required. Ask your Trane dealer for details.
This product is compatible with Honeywell’s Enviracom® 2.0 protocol. Enviracom® is a registered trademark of Honeywell.
Nexia™ Benets
The XL1050 is designed to work in concert
with Nexia smart home systems to provide the
convenience and advantages of a Smart Home.
Voice Control
Control your XL1050, lights and small appliances
by voice command with
Amazon Echo.
• Adjust the thermostat by saying, “Alexa, set the
<thermostat name> to 68 degrees.”
• Turn lights on or o with simple commands such
as, “Alexa, turn on the front porch light.”
• Set custom lighting settings such as, “Alexa, set
the dining room light to 50 percent.”
• Activate small appliances using a plug-in module
such as, “Alexa, turn on the coee pot.”
Simplied Scheduling
Log into the Nexia smart home website. Simply
point and click and your customized schedule is
set straight away.
Runtime History
Keep track of your system by downloading the cooling
and heating system runtime history from Nexia.
Nexia Diagnostics
With your approval, Nexia Diagnostics allows
your local dealer to remotely monitor your
home’s heating and cooling system using real-
time performance data, ensuring you receive the
highest possible level of Customer Service from
Trane and your Trane Dealer. Ask your dealer
about Nexia Diagnostics.
Automations
By connecting additional devices to the XL1050’s
builtinbridge,youwillunleashthefullcapabilities
of Nexia smart home systems with automations.
Automations allow your smart devices to operate
automatically based on specic conditions or
time of day. For example, with the addition
of a compatible touchpad door lock, you can
automatically change your thermostat to your
preferred temperature setting when entering
your home. To reduce energy usage, you can also
add window and door sensors to automatically
adjust the XL1050’s temperature setting when a
door or window is left open.

page 4 XL1050 User Guide
4:19 PM
Wed, Jul 13
Cooling
75°
Menu Auto
System Mode
Off
Preset
Auto
Fan Mode
Cool to
Heat to
74°
70°
Menu
Weather
Ventilate
System Info
Runtime
History
Schedules
Humidity
Settings
Nexia
Zones
Service
Home Back
Settings
Home Back
Thermostat Screen Date & Time Network
User Setup
Wizard
Reboot
Reminders
SW Upgrades
1
2
3
Navigation Overview
Home Screen Menu Screen
See Page 5 See Page 6 See Page 7
From Home Screen, Press: MENU
Settings Screen
From Home Screen, Press: MENU>SETTINGS
All of the XL1050 features may be accessed via the Home, Menu, and Settings screens
?
FOR
MORE
DETAILS:

32-5093-03 page 5
4:19 PM
Wed, Jul 13
Cooling
75°
Menu Auto
System Mode
Off
Preset
Auto
Fan Mode
Cool to
Heat to
74°
70°
Notications and System Alerts appear here
Date and
Time appear
here
Press to select
Heating or
Cooling
temperature
adjustment
Press
Menu
for menu
screen
Press to change System Mode
(Auto/ Heating/Cooling/ O/Emergency Heat) Press to change Fan Mode
(Auto/On/ Circulate)
Press to set or congure Presets
(Home, Away, Sleep)
Network
Status
Current
temperature
and status is
displayed
Press arrow to
increase
temperature
Press arrow to
decrease
temperature
Home Screen

page 6 XL1050 User Guide
Menu
Weather
Ventilate
System Info
Runtime
History
Schedules
Humidity
Settings
Nexia
Zones
Service
Home Back
View individual
Zone Temperature
and Temperature
Settings in a
Multi-Zone System
Press to
display your
Dealer’s
contact
information
(Dealer setup
required)
Ventilation Options ( Requires
accessory Ventilation System)
Press to view System Runtime
History
Press to view indoor Humidity and
set a humidity target
Press to access all
user settings (see
Settings Screen)
Press to enable, disable, view or edit
your schedule
Press to view 5-Day Weather
Forecast, Radar and Alerts
(requires Nexia registration)
Press to access Alerts, Notications and
information about the Control
Press to use
Z-Wave Bridge
functions (see
Nexia smart home
section)
Menu Screen

32-5093-03 page 7
Settings Screen
Settings
Home Back
Thermostat Screen Date & Time Network
User Setup
Wizard
Reboot
Reminders
SW Upgrades
1
2
3
Press to connect
to a WiFi
network.
Enable/Disable
wireless
connection,
access Advanced
Setup, Network
Properties and
Diagnostics
Reboot
button
Press to set up system and
accessory maintenance reminders
Guided User
Setup
Software upgrades
occur automatically
when the control is
connected to and
registered with Nexia.
Press to set Temperature Sensor,
features and calibration
Press to set up Display features, Screen Layout,
Clean Screen and Screen Lock/Guest Access
Press to set up Date & Time. Date & Time auto
update when connected/registered with Nexia

page 8 XL1050 User Guide
Home Screen Customization
4:19 PM
Wed, Jul 13
Cooling
75°
Menu Auto
System Mode
Off
Preset
Auto
Fan Mode
Cool to
Heat to
74°
70°
4:19 PM
Wed, Jul 13
Cooling
75°
Menu Auto
System Mode
Off
Preset
Auto
Fan Mode
Cool to
Heat to
74°
70°
Default
(Scheduling is Disabled)
See Page 5 See Page 9 See Page 10
Default + Presets
(Scheduling is Disabled)
Add Optional Widgets
(Scheduling may be
Enabled or Disabled)
In example below, scheduling is Enabled
You may choose to use the Default home screen or customize the interface with the following features.
4:19 PM
Wed, Jul 13
Edit
Apply
Cancel
Home Away Sleep Auto
System Mode
4:19 PM
Wed, Jul 13
Cooling
75°
Menu Off
Permanent Hold
Auto
Fan Mode
Outdoor Temp
Following Schedule
Indoor Humidity
Air Cleaner
Auto
Cool to
Heat to
74°
70°
L.71°
H.85°
84°
50%
Out of the box the XL1050’s home screen is set up
with a basic thermostat interface. Simply adjust
the HEAT TO or COOL TO setting up or down
and the setting remains at that temperature until
you adjust it again. Scheduling is disabled.
Press the SYSTEM or FAN MODE button to
select your preferred operation.
Users may choose to display up to 3 of 7 available
widgets on the home screen.
In addition, you may customize a schedule to
t your needs using the convenient Scheduling
Wizard which guides you through the process.
In the Default conguration, you may also
choose to set up 3 presets. Using presets permits
changing the heating and cooling settings by
pressing one button.
Preset
Home
Preset
Away
Preset
Sleep
123
?
FOR
MORE
DETAILS:

32-5093-03 page 9
75º
70º
Away
Home
Sleep
Heat to
Cool to Press to
increase
the
set point
Press to
decrease
the
set point
Cooling Set Point
(press to change)
Press Away, Home or Sleep
to set Cooling & Heating
setpoints for each preset
Heating Set
Point (press to change)
Status Area
Away Preset
Temperatures
Mode
Indicator
1-Touch Presets provide predetermined Set
Points for Home, Away and Sleep time periods.
Note: 1-Touch Presets requires Scheduling
to be disabled. To disable Scheduling, go to
MENU>SCHEDULES and select DISABLE.
When scheduling is disabled, heating and
cooling set points are maintained indenitely.
When a temperature change is desired, the user
must manually adjust the temperature to the
new setting.
Conguring 1-Touch Preset
1. Press the PRESET button from the home
screen
(If a Preset is not selected it will display OFF) .
Preset
Off
2.
4:19 PM
Wed, Jul 13
Edit
Apply
Cancel
Home Away Sleep
To edit the parameters, press the EDIT
button, and rst, select AWAY.
3. To change the Cooling Set Point, press the
blue COOLING SET POINT to activate the
setting. The current System Mode indicator
will display blue wavy lines.
Use the UP and DOWN Arrows to adjust
the Set Point to the desired
temperature.
4. To change the Heating Set
Point, press the red HEATING
SET POINT area to activate
the setting. The current
System Mode indicator will
display red wavy lines.
Use the UP and DOWN
Arrows to adjust the Set Point
to the desired temperature.
5. Repeat the process for Home
and Sleep settings.
6. When editing is complete,
press APPLY.
7. Choose the desired preset and press
APPLY. The preset temperature settings
will be displayed on the Home Screen. The
selected preset will display at bottom right:
8.
Home
Preset
Default + Presets
2

page 10 XL1050 User Guide
Auto
System Mode
4:19 PM
Wed, Jul 13
Cooling
75°
Menu Off
Permanent Hold
Auto
Fan Mode
Outdoor Temp
Following Schedule
Indoor Humidity
Air Cleaner
Auto
Cool to
Heat to
74°
70°
L.71°
H.85°
84°
50%
To maintain a temperature indenitely, adjust the setpoint to the desired temperature and
press the Permanent Hold button. It will then display ON, and the control will maintain that
temperature setpoint until you manually change it. Press the Permanent Hold button again to
turn Permanent Hold OFF. The Control resumes following the schedule.
In multi-zone
systems, you
can scroll
between
zones by
pressing the
arrow keys
Optionally, up to 3 widgets may be chosen to appear on your
home screen. They can be selected by navigating to Menu>
Settings>Screen > Screen Layout
When scheduling is
enabled, the Preset
button is disabled
and a Permanent
Hold button is
displayed. The
system will follow
the custom schedule
you’ve created. You
may override the
schedule by
adjusting the
temperature
settings with the
up/down arrows at
the right of the
screen. At the next
period change, the
schedule will
resume.
Upstairs
Adding Widgets
3

32-5093-03 page 11
Completed
Pending
Pending
Pending
Pending
Pending
Pending
15%
The User Setup Wizard guides you through the
XL1050’s User congurable settings.
To complete the Setup Wizard and connect the
XL1050 to Nexia Smart Home Systems, you need
the following:
• Internet service
• Your Wi-Fi network name and password
• An internet browser
• A valid email address
To access the User Setup Wizard, select
MENU>SETTINGS>USER SETUP WIZARD.
User Setup
Wizard
Settings
Menu
User Setup Wizard
The User Setup Wizard will guide you through
the following screens:
1. Display
2. Screen Layout
3. Scheduling
4. (A) Guided Schedules OR (B) 1-Touch Presets
5. Network
6. Nexia
7. Weather
Note: You may skip any section of the Wizard by
pressing Cancel. It is not possible to exit or go
back to a completed section after starting the
process.
After each step, the Wizard will show your
progress. Press Next to begin the next section.
Any settings can be changed at a later date
either manually, or by running this Wizard
again.
?
TIP

page 12 XL1050 User Guide
1) Display
User Setup Wizard
Press NEXT and set your preferred display
brightness, backlight, screen saver and color
theme settings.
Select User Setup Wizard to begin.
Begin wizard
From Home Screen, Press:
MENU>SETTINGS > USER SETUP WIZARD
15%
Press NEXT
Settings
Home Back
Thermostat Screen Date & Time Network
User Setup
Wizard
Reboot
Reminders
SW Upgrades
1
2
3

32-5093-03 page 13
User Setup Wizard
Screen Layout Options
• Outdoor Temperature - Displays outdoor
temperature on home screen.1Press widget
to display 5 day weather forecast, alerts and
radar.
• Indoor Humidity – Displays indoor relative
humidity on home screen.
• Dealer Contact – The servicing Trane
dealer’s name will be displayed on the home
screen widget.1, 2 Press the dealer widget for
contact information.
• Runtime History – Displays runtime history
widget on home screen. Press the widget
to display daily and monthly runtime
history with average indoor and outdoor
temperature1,3.
• Air Cleaner – Displays air cleaner widget on
home screen. Press the widget to display
and select air cleaning options:
-Auto – operates whenever system fan is on
-Quick Clean – 3 hour air cleaner power
cycle
-Allergy Clean – 24 hour air cleaner power
cycle
• System Status – The system status widget
is displayed on the home screen. Press
the widget to display cooling or heating,
accessory4and zoning5system status.
• Compressor Speed – Displays Trane’s
TruComfort™ variable speed compressor
speed as a percent of maximum speed.
Select up to 3 widgets from the layout screen
and press Apply .These widgets will be displayed
on the home screen.
1 Requires internet service and registration with Nexia™ smart home system.
2 Requires the servicing Trane dealers code to be entered in the control.
3 Requires weather service to be enabled.
4 Requires accessories to be installed.
5 Requires Trane zoning system to be installed.
2) Screen Layout
29%
Press NEXT

page 14 XL1050 User Guide
User Setup Wizard
3) Scheduling
Scheduling Options in Wizard
• Enabled – Guided Scheduling will begin.
See 4A: Guided Scheduling
• Disabled – 1–Touch Preset Options of
Away, Home and Sleep can be set.
See 4B: 1-Touch Presets
4A) Guided Scheduling
(If Scheduling Enabled Chosen)
After pressing Scheduling Enabled, the welcome
to Guided Scheduling screen is displayed.
Select the days you want to schedule. Press NEXT.
Select STAY HOME or LEAVE. Press NEXT.
Stay Home will set up 2 periods per day, wake
and sleep. Leave will set up four periods: Wake,
Away, Home and Sleep. Each period’s cooling
and heating temperature setting was pre-
programmed at the factory for comfort.
Guided Scheduling is a convenient way to quickly
revise the default schedule and customize
a schedule with your preferred settings for
comfort or energy savings. Press NEXT.
43%
Press NEXT

32-5093-03 page 15
4B) 1-Touch Presets
(If Scheduling Disabled Chosen)
1-Touch Presets provide predetermined Heating
and Cooling Set Points for Home, Away and Sleep
time periods.
See page 9 for detailed instructions how to
congure 1-Touch presets.
User Setup Wizard
Adjust the time you would prefer the Wake Period
to Start using the up and down arrows. Press NEXT.
Adjust the cooling and heating system Wake
Period Temperature setting by adjusting the
UP and DOWN arrows. To change the cooling
setting press the blue COOL TO button. To
change the heating setting press the red HEAT
TO button. Press and follow the onscreen
instructions to complete Guided Scheduling.
58%
Press NEXT

page 16 XL1050 User Guide
5) Network Setup
There are three ways to connect the XL1050
Control to a local network:
1. Wi-Fi connection
2. Wi-Fi connection using WPS
Select your network Enter your SSID, which is the name of the router,
then press NEXT.
Next, select the security type for this network.
If you select None, press Connect.
Press the WPS button on your router, then return
to your XL1050 Control and press the WIFI
PROTECTED SETUP button on the Wireless
Network screen. Press NEXT.
Press“Hidden Network”which will be at the end
of the list of available networks. If there are more
than eight networks, you will need to scroll to
the next page.
Enter your Password then press CONNECT.
3. Wireless Wi-Fi connection using a “hidden
network.
User Setup Wizard

32-5093-03 page 17
5) Network Setup (cont.)
If you select WPA or WEP, you will need to
enter a password, then CONNECT.
4. The XL1050 also features an Ethernet jack
and may be connected to a router using CAT5
cable. The control will recognize an Ethernet
connection and the User Wizard will skip the
Wireless setup screens and display the Nexia
Registration screen next.
User Setup Wizard
72%
Press NEXT
6) Nexia Registration
Select SIGN UP NOW to set up an account or
log in to an existing account. Select the ENROLL button for Trane XL824,
XL850 or the XL1050 Control.
Select the THERMOSTATS drop down arrow.
From the Nexia Dashboard select ADD DEVICES.
To control your home climate system from your
web enabled smartphone, tablet or computer
go to www.mynexia.com and set up a Nexia
account. If you already have an account, log in
and select ADD DEVICES.
Your XL1050 comes equipped with remote climate access from Nexia™
Smart Home Systems:
• Control your home climate from your smartphone
• View local weather
• Receive alerts
Go to www.mynexia.com to set up your account before proceeding.

page 18 XL1050 User Guide
User Setup Wizard
Nexia will generate a Pin Code. Record the Pin Code.
Press CONTINUE.
6) Nexia Registration (cont.)
Read the License Agreement, then ACCEPT or DECLINE.
Enter the Pin Code and Press NEXT. Registration successful. Press DONE.
87%
Press NEXT
Return to the XL1050 control and Press NEXT.
Your XL1050 comes equipped with remote climate access from Nexia™
Smart Home Systems:
• Control your home climate from your smartphone
• View local weather
• Receive alerts
Go to www.mynexia.com to set up your account before proceeding.

32-5093-03 page 19
7) Weather Setup
To view your local weather press LOCATION
and enter your Zip Code.
To view the 5 day forecast press FORECAST.
To view the weather map press RADAR.Use the backspace button to delete the current
zip code. Enter the new zip code and press
APPLY.
To view weather warnings press ALERTS
User Setup Wizard
100%
Wizard
is
Complete!

page 20 XL1050 User Guide
Manual Scheduling
Back
Weekly Schedule
Disable
Schedule Guided Schedule
Sleep
75˚ 70˚
Home
75˚ 70˚
Away
75˚ 70˚
Wake
MON
TUE
WED
THU
FRI
SAT
SUN
6:00 8:008:008:008:008:008:008:00
6:006:006:006:006:006:00
6:00
10:0010:0010:0010:0010:0010:0010:00
6:006:006:006:006:006:00
75˚ 70˚
Wake
75˚ 70˚
Wake
75˚ 70˚
Wake
75˚ 70˚
Wake
75˚ 70˚
Wake
75˚ 70˚
Wake
75˚ 70˚
Away
75˚ 70˚
Away
75˚ 70˚
Away
75˚ 70˚
Away
75˚ 70˚
Away
75˚ 70˚
Away
75˚ 70˚
Home
75˚ 70˚
Home
75˚ 70˚
Home
75˚ 70˚
Home
75˚ 70˚
Home
75˚ 70˚
Home
75˚ 70˚
Sleep
75˚ 70˚
Sleep
75˚ 70˚
Sleep
75˚ 70˚
Sleep
75˚ 70˚
Sleep
75˚ 70˚
Sleep
75˚ 70˚
The XL1050 Smart Control is capable of adjusting
the temperature settings throughout the day
according to a user-programmable schedule.
Each day of the week can have its own unique
schedule, and each day can have a maximum
number of four periods.
Periods dene the time of day when the target
temperature is adjusted. Each day can have from
one to four periods, and each day can have a
dierent number of periods. The Scheduling Screen
shows the start time for each Period highlighted
across the top row.
Important: Scheduling must be enabled before a
schedule can be dened. To verify that scheduling
is enabled, navigate to MENU>SCHEDULES and
verify scheduling is enabled. If enabled a Weekly
Schedule will be displayed. If not, a message will
indicate scheduling is disabled..
To Enable Scheduling, select the following:
MENU>SCHEDULES>ENABLE SCHEDULE.
Menu
Schedules
Enable
Schedule
After pressing ENABLE SCHEDULE, the factory
default week-long schedule screen will be displayed.
The schedule displayed is a 7 day schedule with up
to 4 periods per day. The four periods include:Wake,
Away, Home and Sleep. Each period’s cooling and
heating temperature setting was pre-programmed
at the factory.
The schedule can be changed in the following ways:
• Guided Scheduling – See the Guided Scheduling
portion in the User Wizard. A series of screens will
aid you in setting up a schedule.
• Manual Scheduling – To manually schedule, press
anywhere on the Weekly Schedule screen to
begin modifying the schedule. You may modify,
add and delete periods. See the samples on the
following pages.
