Setup Instructions
Trane Programmable Thermostat
X13511537-01/BAYSTAT150A/THT02774
SAFETY WARNING
Only qualified personnel should install and service the equipment.The
installation, starting up, and servicing of heating, ventilating, and air-
conditioning equipment can be hazardous and requires specific
knowledge and training. Improperly installed, adjusted or altered
equipment by an unqualified person could result in death or serious
injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the
equipment.
More information:
https://www.trane.com/stat
Time Setup
To change the current time:
1. From the Home screen, press , , , , , .
2. Press , ,or to scroll between hours and minutes.
AM PM
Hours Minutes
1. Press to increase or to decrease the hour or minute.
PM PM
AM PM
Changing Hours Changing Minutes
1. Press and hold for 2 seconds or wait 10 seconds to Save and Exit.
System Mode Setup
To set the system mode:
1. From the operating screen, press , . The current mode flashes.
2. Press or to select a mode.
Emergency
Heat
Cool Auto H/C Off
Heat
OFF
Note: Not all system choices may be available depending on the
system configuration 0130.
3. Press and hold for 2 seconds or wait 10 seconds to Save and Exit.
Fan Mode
The fan mode is displayed only on systems configured with the fan
enabled.
For systems configured with a fan, the fan setting is shown on the
display. In addition, the setting also appears on the display when
pressing , , from the Home screen.
The fan mode setting can be overridden by pressing or when the
fan mode flashes. Press and hold for 2 seconds or wait 10 seconds to
Save and Exit. Refer to the section, “Timed Override (TOV)”.
On Mode:
Arrows Flash
Auto Mode:
Auto Flashes

Important: When this thermostat is configured in
programmable mode (0140=1), then changing the Fan
Mode from the Home screen puts the thermostat into
Timed Override (TOV) and is only temporary.The fan
goes back to the schedule setting after theTOV timer
expires.
Timed Override (TOV)
A timed override can be used to temporarily change the heating setpoint,
cooling setpoint, fan mode, and/or occupancy setting from the
programmed schedule.The override can be set for up to 99 days and up
to 23 hours.
To enter a timed override:
1. From the operating screen, press or 2 times.The thermostat
enters timed override mode with the hourglass and setpoint
flashing.
2. Press or press or to move from either left or right through
the selections. Some of the selections may not be available
depending on the system type.
Cooling
Setpoint
Occupancy
Setting
Hours Heating
Setpoint
Fan
Setting
HOURS
(Days)*
DAYS
3. Press or to change the value of the currently active (flashing)
selections. Repeat steps 2 and 3 for the desired settings.
Note:To reach the DAYS setting, the user must press from the
hours setting.
4. Press and hold for 2 seconds or wait 10 seconds to Save and Exit.
Note: The thermostat will return to the scheduled operation when:
• the override time expires, or
• pressing and holding an for 2 seconds.

Important: When in timed override mode, if the system
selection is changed (EmHeat, Heat, Cool, Auto, OFF), this
change will take the thermostat out ofTOV mode.
Important: Whenever the thermostat is inTOV mode, a
solid hour glass ( ) indicator displays at the bottom of the
screen.


Trane optimizes the performance of homes and buildings around the world. A business of
Ingersoll Rand, the leader in creating and sustaining safe, comfortable and energy efficient
environments, Trane offers a broad portfolio of advanced controls and HVAC systems,
comprehensive building services, and parts. For more information, visit www.IRCO.com.
Trane has a policy of continuous product and product data improvement and reserves the right
to change design and specifications without notice.
© 2012Trane. All rights reserved.
X39641168-01B 13 Mar 2012
Supersedes x39641168-01A 03 Dec
2009
We are committed to using
environmentally conscious
print practices that reduce
waste.
4 5
Create or Edit a Schedule
To create or edit a schedule:
1. Press , , , , .
Note: Each button shown above must be pressed within 10 seconds
of the previous button. Once the user is in Schedule Change Mode,
each button must be pressed within 45 seconds of the previous button
in order to stay in Schedule Change Mode.
2. Press or to select the day(s) and
to continue.
Mo Tu We Th Fr Sa Su
AM
We
AM
We
AM
Auto On
3. Press or to select the period and
to continue.
4. Press or to change the StartTime
and to continue.
5. Press or to change the Heating
Setpoint and to continue.
6. Press or to change the Cooling
Setpoint and to continue.
7. Press or to select the Fan Setting
and to continue.
8. Repeat steps 2 through 7 for each day
(see step 2) and period (see step 3).To
exit Schedule Change Mode, wait 45
seconds or press and hold for 2
seconds to Save and Exit.
Possible Scheduling Configurations (configuration option 0233):
• 1 day [default]; MoTuWeThFrSaSu (all days share a schedule).
• 5+1+1 days; MoTuWeThFr Sa Su (Monday through Friday share
a schedule, Saturday and Sunday are each separate schedules).
• 5+2 days; MoTuWeThFr SaSu (Monday through Friday share a
schedule, Saturday and Sunday share a schedule).
• 7 days; Mo Tu We Th Fr Sa Su (Each day has a separate
schedule).
Note: Use the worksheet on the right for planning or recording schedule
settings. Default settings are ENERGY STAR® compliant.
8:00 am
6:00 am 70
° F (21.0 ° C)
62
° F (16.5 ° C)
70
° F (21.0 ° C)
62
° F (16.5 ° C)
78
° F (25.5 ° C)
85
° F (29.5 ° C)
78
° F (25.5 ° C)
82
° F (28.0 ° C)
10:0 0 pm
6:00 pm
Mo
Tu
We
Th
Fr
Sa
Su
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
4-Period defaults
2-Period defaults
70 ° F (21.0 ° C)
55
° F (13.0 ° C)
78
° F (25.5 ° C)
85
° F (29.5 ° C)
10:0 0 pm
8:00 am
Morning Day Evening Night Time Heat Cool Fan ON
Legend of Symbols
