Transcell Technology WEIGHBLOK Manual instruction

WEIGHBLOKWEIGHBLOK
Digital Scale
Setup & Operation Manual
Revision 0502
4-2-03
ã2001-2002 Transcell Technology, Inc.
Contents subject to change without notice.
Transcell Technology, Inc.
975 Deerfield Parkway
Buffalo Grove, IL 60089
Tel [phone]
Fax [phone]
E-mail: [email protected]
Web: www.transcell.net

Manual- Weighblok Rev 1 4-2-03
2
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
Weighblok Manual
Normal Calibration
Calibration
switch
ON
PRINT
NET
GROSS
OFF
ZERO
TARE
Communica-
tions port
External
power
9 VDC
Alkaline
batteries
The Weighingblock is a robust Scale. It is designed for portable use. When
transported by car between different working places we recommend using of a
protected space or a case. This will extend the interval for service.

Manual- Weighblok Rev 1 4-2-03
3
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
Table of contents Page
Introduction, Keyboard Functions 3
Configuration and Setup Menu. Display 4
Parameters 5,6
Calibration 7
Specifications and Displayed Error Codes 8
Troubleshooting 9
Scale use 10
Communication port 11
Introduction
TranscellnewWeighblokseriesarearuggeddigitalscalecastedinstrongaluminum.Itcomesstandardwithalarge(.75")LCDscreenforeasyreadout.
All setupparametersmaybeenteredviathemembranepanelkeys.TheScalehasan”intelligent”auto power off function and can be operated
with 6 alkaline 1,5 V batteries. If the battery is not good enough to ensure a correct value the scale will turn off.
The scale is developed especially for weighing of refrigerant cylinders, and to control when transferring refrigerants to other cylinders or equipments.
The scales setup parameters are altered through the Setup menu while a few other parameters are altered through the User menu The
configuration section of the manual explains how to use the five front panel keys to maneuver and save settings in both menus.
The Weighblok scale can be used as a Batching Scale or regular weighing scale
The Weighblok is suitable for use in weighingapplications as: refrigeration cylinders, fire protection cylinders, CO2,
cylinders, parcels, persons, etc.
Keyboard functions
The calibration switch is only for calibration.
IndicatorON
Innot EC-type approved version: Sends"Print" data to printer if scale is stable and not in overload.
Not active when "Continuous" option is selected in User Menu.
“Dot”.Extended graduation when pushed and 5 secafterrelease. When pressed and released, theDOT
buttonisthe unit switch key, lb –kg.
TogglesbetweenGrossand Netweight displayonly if a Tare has been established.
Sets scale to display "0" wheninGross mode, and within zero bandrange. When pushedin for3
seconds, the Scaleswitchesoff.
Used to establish a Tare (zero the Scale) while in either Grossmode or
Net mode. Thisoperation cannot be performed at orbelow Grosszero.
ON
PRINT
NET
GROSS
OFF
ZERO
TARE

Manual- Weighblok Rev 1 4-2-03
4
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
Configuration
The Weighblok has two menus.
The Setup menu, containing most of the indicator's functional Setup parameters, consists of 15 separate menu selections, each with its own
sub-menuofchoices.
The User menu, except A5 and A10 containing most of the indicator's serial communication parameters, which not are shown in this
manual.
TO ENTER THE SETUP MENU
1. Turn the power OFF.
2. Put Calibration Switch to the Calibration position.
3. Press the ON key.
4. The display shows "F1" to indicate that the unit is in Setup menu mode.
5. To move to a new “F”heading, use TARE or ON to move up or down.
6. To move to the selection value, press ZERO once.
7. Increase and decrease the value with PRINTand TARE.
8. To save the value, press NET.
9. Press DOT key to go back to parameter number.
10. To go back to normal menu put Calibration Switch to the Normal position.
NOTES ON THE SETUP MENU
There is an F21 sub-menu present that is for FACTORY USE ONLY!
DISPLAY
LCD Enunciator
MEANING
è0ç
Better known as the “Center of Zero”enunciator, this light is active whenever the displayed weight is
within ±0.25 divisions of true zero.
N
Indicates that the indicator is displaying net weight.
G
Indicates that the indicator is displaying gross weight.
T
Indicates that a tare weight has been established in the system.
lb, kg
Indicates the unit of the displayed weight (normally disabled).
bAtt
Indicates a low battery condition. Re-charge the battery or replace if alkaline batteries.
Indicates stable weighing.
Weighblok Enunciator Definitions
ON
PRINT
NET
GROSS
OFF
ZERO
TARE

Manual- Weighblok Rev 1 4-2-03
5
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
PARAMETER DESCRIPTION CODE/VALUE
F1
Graduations
Specifies number of the Weighingblocks graduations. Value should be consistent
with legal requirements and environmental limits on the useful system resolution.
500 1,000 1,500 2,000 2,500 3,000
4,000, 5,000 6,000 8,000 10,000
12,000 13,000 15,000 20,000 30,000
40,000 50,000
F2
Span Gain
Span Gain is related to A/D integration time. The larger the span gain, the higher the
internal resolution, but the slower the update speed.
25 50 75 100 150 200
F3
Zero Track Band
Selects the range within which the scale will automatically zero. Note that the scale
must be in standstill to automatically zero. Selections are in Display Divisions. “d”
= graduation
0d 0.5d 1d 3d 5d
F4
Zero Range
Selects the range within which the scale may be zeroed. Note that the indicator must
be in standstill to zero the scale.
100% 1.9%
2%
F5
Motion Band
Sets the level at which motion is detected by comparing the present display update
with the previous one. If motion is not detected for two seconds or more, scale is in
standstill and can process a Print or Zero command. Maximum value varies
depending on local regulations.
0.25 1d 3d
5d 10d
F6
Digital Filter
Averages weight readings to produce higher accuracy. The higher the filter number,
the greater the accuracy but the slower the response time. Choose 4 or 8 unless a very
fast response is needed.
1 2
48
F7
Overload Limit
Selects the desired formula which determines the point at which the indicator shows
overload ("oooo"). All selections are based on the primary unit selected in F8.
"FS" = Full scale in primary units.
FS FS + 2%
FS + 1d FS+ 9d
F8
Calib. Unit
Selects the primary base unit to be used in the calibration process. Also the default
unit for normal operation. "1" =
primary unit is lb. "2" = primary unit is in kg.
1
2
F9
Display Div.
Determines the desired weight increments. Value should be consistent with legal
requirements.
1
2
5
F10
Decimal Pt.
Determines location of the decimal point.
0
0.0 0.00
0.000 0.0000
F11
Batching function.
Activating Batching function (not be used with “EC”-Scales
0 = OFF
1 = ON
F16
Zero Calibration
Places indicator into the zero calibration routine. Scrolling down with the ZERO key
one level begins the procedure.
Press ZERO key to begin sequence
F17
Span Calibration
Places indicator into the span calibration routine. Scrolling down with the ZEROkey
one level begins the procedure.
Press ZERO key to begin sequence
F18
F19
F20
F21
Factory Reset
This sub-menu will reset all parameters in the “F”and “A”menu to the default
settings. USE WITH CAUTION!
Press the ZERO key twice to execute.
A1
A2
A3
A4
A5
Disable the lb/kg
Key
Allows the lb/kg key to be disabled and allows use of extended graduation.
"0" = Disable the lb/kg key "1" = Enable the lb/kg key
”2”Activate the extended graduation for VB2-100-EC
0
1
2

Manual- Weighblok Rev 1 4-2-03
6
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
F6
F7
F8
F9
A10
Auto Power Off
Period
Selects the auto power off time period in minutes:
“Off”= Disabled (Always ON)
1, 2, 3, 5, 10, 15, 20,30, off

Manual- Weighblok Rev 1 4-2-03
7
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
Calibration
We recommend the scale to be calibrated at periodic intervals with the frequency based on usage.
The minimum test weight that can be used is 70% of full-scale capacity.
To adjust the zero point using the F16 zero adjust procedure:
1. Turn the power OFF
2. Put Calibration Switch to the Calibration position.
3. Press the ON key.
4. Scroll to "F 16". Use TARE or ON to move up or down.
5. Press ZERO. The display will momentarily show "C 0" followed by a value. (If you want, press Dot
to go back to parameter number.)
6. After making sure that there are no weights on the platform, press ZERO to zero out the displayed
value.
7. Press NET to save the zero point value. The display will show "EndC0"momentarily, and then revert
back up to F16. At this time, proceed to the F17 span calibration to complete indicator calibration.
To adjust the max point using the F17 span adjusts procedure:
1. Scroll to "F17",then press ZERO to enter spancalibration menu.
2. The display will momentarily show "C 1" for the span calibration, followed by a value with one flashing digit. This
value will be zero. Place the test weight on the Scale.
3. Pressing TARE or ON will change the position of the flashing digit.
4. Increase the flashing digit by pressing Dot. Decrease the flashing digit by pressing ZERO.
5. After setting the exact value, press NETto save the value.
6. Ifthe adjustmentwassuccessful, the displaywill show"EndC1" momentarily, and thenrevert back up to F17.
"Err0"–The calibration test weight or the adjusted keyed-in weight is larger than the full capacity of
the scale. Change the calibration test weight orcheck the input data.
"Err1"–Change the calibration test weight or check the input data.
"Err2"–The internal resolution of the scale is not highenough to accept the calibration value.
Select a larger parameter for the Span Gain (F2).
7. Put the Calibration Switch to the normal mode.
8. Check the Scale.
ON
PRINT
NET
GROSS
OFF
ZERO
TARE

Manual- Weighblok Rev 1 4-2-03
8
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
Specifications and displayed error codes.
General
Model
Capacity /
Graduation
Weight kg
Dimension mm
Battery
Weighblok
Max 100 kg / 50 g
Not approved version
4,5
260 x 345 x 55
6 of alk. 1,5 V batteries LR6/AA for 15 hours operation.
OPERATORINTERFACE
Display
0.75" (19 mm) 7-segment, Liquid Crystal, 6-Digit
Additional Symbols
Net, Gross, Stable, Tare, lb, kg, Zero
Keyboard
5-key flat membrane panel
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Displayed error codes.
CODE
MODE
MEANING / POSSIBLE SOLUTION
rrrrrr
Normal Operating
Mode
Gross Overload. A weight greater than the rated capacity has been applied to the scale. Remove the weight
from the platter or try re-calibrating the scale. Otherwise, check for a bad load cell connection or possible
load cell damage due to overloading.
bAtt
Normal Operating
Mode
Indicates a low battery condition. Re-charge the battery or replace if alkaline batteries.
Err 0
Span Calibration
Mode (F17)
Keyed-in weight value is larger than full-scalecapacity. Use a smaller test weight or check keyed-in value.
Err 1
Span Calibration
Mode (F17)
Keyed-in weight value is less than 1% of full-scale capacity. Use a larger test weight or check keyed-in
value.
Err 2
Span Calibration
Mode (F17)
There is not enough load cell signal to produce the internal counts necessary to properly calibrate the scale.
First check all load connections. Use F16 mode to view internal counts. See Appendix C for more
information.
Err 3
All Modes
Non-volatile memory read error. One or more setup parameters have been lost.
Err 4
All Modes
Non-volatile memory writes error. Indicator needs service.
Err 5
Key-in Span
Calibration Mode
(F20)
You have attempted to enter a zero value for C1. Enter a known calibration value greater than zero.
Err 7
Initialization
No reading from the ADC. Make sure there is a load cell(s) connected to the indicator at start-up.
Err 9
Normal Operating
Mode
Span calibration value has been lost. Re-calibrate the Scale.

Manual- Weighblok Rev 1 4-2-03
9
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
Troubleshooting
If the Weighblok to power up.
1. Change to new alkaline batteries.
2. Check to see if AC adapter is plugged in.
If thescale startsbut the display showswrong.
1. Adjust and Calibrate the Scale.
Bottom plate removal
1. Remove the two screwsfrom the bottom plate ofthe Weighblok.. Be careful with the keyboard connection.
2. Check the inside of the Scale visually. Look for bad cables and connections.
If the Scale shows F1
1. Check the position of the Calibration Switch.
2. Reset to normal mode.
Loadcell Connections
Check the Loadcellwith a universal voltmeter, see table. The left pin is number 1.
Terminal J1
Description
Colours Loadcell
AG
Colours Loadcell 1042
E+ (1)
Out +5 VDC*
Brown
Green
S+ (2)
In +
Yellow
Red
E- (3)
Out 0 VDC
Green
Black
S- (4)
In -
White
White
1. Check the excitation voltage (E+ and E-) from the Indicator. Should be 5,0* (+-0,4) VDC.
2. Check the input to the Indicator (S+ and S-). The output from the Loadcell S+ and S- (pin 2 and 4)
will increase from aprox. 0 to 10 mV analogue to the capacity range (100 or 30 kg). Note S+ is plus
and S- is minus. The polarity is important.
3. If the input is wrong, <0 mV or > +10 mV with unloaded Scale check the Loadcell. Do have only
E+ and E- connected (or probably an external Power 5 VDC) and checks the output from the
Loadcells direct on the wires. Should be 0 mV to +10 mV depending on the load.

Manual- Weighblok Rev 1 4-2-03
10
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
LCD
Enunciator
MEANING
è0ç
Better known as the “Center of Zero”enunciator, this light is active
whenever the displayed weight is within ±0.25 divisions of true zero.
N
Indicates that the indicator is displaying net weight.
G
Indicates that the indicator is displaying gross weight.
T
Indicates that a tare weight has been established in the system.
lb, kg
Indicates the unit of the displayed weight (normally disabled).
bAtt
Indicates a low battery condition. Re-charge the battery or replace if alkaline
batteries.
Indicates stable weighing.
Weighblok Enunciator Definitions. Shown above is the LCD display. Before readingthe value the stable indicator must be ”on”.
Ifnot, wait a few secondsuntil it appears.
Basic scale use
1. Press ON to start the scale.
2. If necessary, press ZERO to obtain a weight reading of zero.
3. Press OFF to switch off the scale. Hold 3 seconds.
4. The scale switches off automatically after 10 minutes when not in use
Weighing (e.g. a cylinder with liquid)
1. Unload scale and press ZERO.
2. Place the object (cylinder, container, etc) on the scale’s platter and allow the weight indication to stabilize. If the item
weight exceeds the scale’s weight capacity, it displays “rrrrrr”. Press TARE to zero the Scale. The display
shows zero weight and turns the NET enunciator on.
3. NET/GROSS toggles between Gross and Net weight display only if a Tare has been established.
4. “Dot”.Extended graduation.
General advice
When the Scale is not in use and is transported between different working places, we recommend usage of a case or any
other protection against vibrations and other hard environmental conditions. Protect the scale with a plastic bag if there is
any risk of working in a wet environment.
ON
PRINT
NET
GROSS
OFF
ZERO
TARE

Manual- Weighblok Rev 1 4-2-03
11
975 Deerfield Parkway 800-503-9180 www.transcell.net
Buffalo Grove, IL 60089 847-419-1515 [e-mail]
Communication Port
The Weighblok has a Communication Port standard. It is possible to connect different accessories such as a Printer,
PC/Notebook or external relay.
Printer for the weight value.
Manyprinters in the market can be connected. For more information, contact Transcell.
PC/Notebook
The Scale canbe connected to a PC/Notebook. For more information, contact Transcell.
External Relay
The scale can be connected to an external relay. A 5 V output is available to actuate a relay for cut-off control when filling or
discharging.
One time set up: F11 must be “1”and A5 must be “2”(normally done when delivered)
RS-232
PIN NUMBER
PIN NAME
2
RXD
3
TXD
5
GND
7
TARGET
TTL(+5V/OV)
8
TTL +5V
Set the target weight value:
1. To set the Target Weight:
2. Press, ”Dot”for 5 seconds, displayshows 0,0 (flashing).
3. Press ON until the first relevant digit flashes.
4. Change to the desired value with ”Dot”.
5. Press ON until the next relevant digit flash.
6. Change to the desired value with ”Dot”.
7. When the Scale shows desired value, save with NET
8. Press ZERO it the Scale not shows zero and put the object on the Scale. The Scale shows the gross weight.
9. Batching: Press TARE. The Scale shows zero and the process begins.
10. When the weight difference on the Scale is same as Batching Weight the process stops.
11. The Scale shows the Batching Weight. Press NET/GROSS for gross weight.
