Transcell Technology Neptune-6500 Series User manual

Neptune 6500
NEPTUNE -6500
Series
CHECK WEIGHING SCALE
Operation Manual
Revision 2.6
8-6-03
ã2003 Transcell Technology, Inc.
Contents subject to change without notice.
Transcell Technology, Inc.
975 Deerfield Parkway
Buffalo Grove, IL 60089
Tel [phone]
Fax [phone]
E-mail: [e-mail]
Web: www.transcell.net

Neptune 6500
2
ATTENTION:
To extend the life of your digital scale, do not drop items to be weighed onto the
platform or overload the scale beyond its rated capacity. Shock-loading and
overloading may damage the load cell and void the warranty.
Electromagnetic Compatibility Statement for North America
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/her own
expense.
ã2003 Transcell Technology, Inc.
Contents subject to change without notice.
Transcell Technology, Inc.
975 Deerfield Parkway
Buffalo Grove, IL 60089
Tel [phone]
Fax [phone]
E-mail: [e-mail]
Web: www.transcell.net

Neptune 6500
3
TABLE OF CONTENTS
Page
Chapter 1: Introduction to the Transcell NEPTUNE-6500 Series Check Weighing Scale............. 5
Chapter 2: Getting Started.............................................................................................................. 6
2.1 Installation..................................................................................................................... 6
2.1.1 Stainless steel enclosure (NEPTUNE 6500) ............................................................... 6
2.2 Connecting the weigh platform to the indicator ............................................................ 7
2.3 Connecting the Serial printer, remote display or computer .......................................... 8
2.4 Connecting to the Power Supply .................................................................................. 8
Chapter 3: Basics of Operation ...................................................................................................... 9
3.1 Keyboard....................................................................................................................... 9,10
3.1.1 Light Emitting Diode (LED).............................................................................. 9
3.2 Display.......................................................................................................................... 11
3.3 General Scale Operation .............................................................................................. 12
3.3.1 Weighing an Item............................................................................................. 12
3.3.2 Taring an Item of Unknown Weight................................................................. 12
3.3.3 Taring an Item of Known Weight ..................................................................... 12
3.3.4 Clearing a Tare................................................................................................ 12
3.3.5 Entering a min and max value......................................................................... 12
Chapter 4: Advanced Features and Operation............................................................................... 13
4.1 Item ID Storage............................................................................................................. 13
4.1.1 Adding a New ID.............................................................................................. 13
4.1.2 Recalling an ID Entry....................................................................................... 13
4.1.3 Deleting an Item Entry..................................................................................... 13
4.1.4 Editing an Item Entry ....................................................................................... 14
4.2 TTL Outputs.................................................................................................................. 14
4.2.1 Set point outputs........................................................................................................... 14
Chapter 5: Calibration..................................................................................................................... 16
5.1 Calibration Overview..................................................................................................... 16
5.2 Zero Calibration ........................................................................................................... 16
5.3 Span Calibration ........................................................................................................... 16
5.4 View Calibration ............................................................................................................ 17
5.5 Key-in calibration ........................................................................................................... 18
Chapter 6 Configuration Overview ...................................................................................................... 19
6.1 Configuration overview.................................................................................................. 19
6.2.1 Entering the setup menu................................................................................................ 20
6.2.2 Navigating the setup menu............................................................................................ 19
“F”Configuration menu.................................................................................................. 20
“A”Setup menu............................................................................................................. 23

Neptune 6500
4
LIST OF FIGURES
1-1 NEPTUNE-6500 Series Front Panel ...................................................................................... 5
2-1 NEPTUNE-6500 Main Circuit Board ..................................................................................... 7
2-2 Load cell connections.............................................................................................................. 7
2-3 Pin assignments for load cell.................................................................................................. 7
3-1 NEPTUNE-6500 Keyboard Detail........................................................................................... 9
3-2 Display detail .......................................................................................................................... 11
LIST OF TABLES
1-1 NEPTUNE-6500 Series Product Matrix.................................................................................. 5
2-1 Keypad function ...................................................................................................................... 10
3-1 NEPTUNE-6500 Series Annunciator Definitions.................................................................... 11
6-1 Configuration Sub-Menu Items............................................................................................... 20, 23

Neptune 6500
5
CHAPTER 1: INTRODUCTION TO THE TRANSCELL NEPTUNE 6500 SERIES CHECK-
WEIGHER
The Transcell Model NEPTUNE 6500 Series Checkweigher is an easy to use high speed, wash
down, stainless steel bench scale. The main function of the NEPTUNE 6500 is to compare
programmed weight readings to pre-set tolerance limits that define an ACCEPTABLE range. If
the current weight reading is within an ACCEPTABLE weight range the green TARGET LED’s
light. If the current weight reading is less then the ACCEPTABLE range the amber UNDER LED’s
light. If the current weight reading is greater then the ACCEPTABLE range the red OVER LED’s
light.
The NEPTUNE 6500 features a full numeric keyboard, storage for up to 100 individual
OVER/UNDER/TARGET/TARE values with an easy link to individual ID recall. The NEPTUNE
6500 also features a simple programmable print format. Utilizing 3-5volt TTL outputs you can
readily send out check weight results to a PC or control other external devices. The NEPTUNE
6500 is available in two platform sizes and four avoirdupois weight capacities.
If you are an installer, the scale’s installation and wiring instructions are found in Appendix D. The
scale contains two main setup menus: Front panel access is available for simple calibration and
configuration. Prior to installing the scale, please read this manual carefully and completely. Store
the manual in a safe and convenient place so it will be available if you have questions concerning
the setup and operation of the scale.
FIGURE 1-1: Front Panel
MODEL
CAPACITY /
GRADUATION
MODEL
CAPACITY /
GRADUATION
NEPTUNE 6500-5
5lb (2.5kg) 12”W x 12" L
NEPTUNE 6500-30
30lb (15kg) 18”W x 18”L
NEPTUNE 6500-10
10lb (5kg) 12"W x 12" L
NEPTUNE 6500-50A
50lb (25kg) 18”W x 18”L

Neptune 6500
6
NEPTUNE 6500-20
20lb (10kg) 12"W x 12" L
NEPTUNE 6500-100
100lb (50kg) 18”W x 18”L
NEPTUNE 6500-50
50lb (25kg) 12"W x 12" L
NEPTUNE 6500-200
200lb (100kg) 18”W x 18”L
TABLE 1-1: Product Matrix
CHAPTER 2: GETTING STARTED
Step 1. Position the scale in its area of intended use. Observe the following guidelines for
suitable location.
1. Choose a firm, stable floor or table.
2. Do not share an AC outlet with electrical noise producing equipment, such as
refrigeration units. This includes products with electrical motors and/or relays.
3. Do not place the scale in an area with changing ambient temperature and/or high
humidity.
4. Do not place the scale in an area prone to exposure to direct sunlight, wind, or dust.
5. Do not place the scale in an area with vibrating equipment.
Step 2. If applicable, install the serial printer to the COM1 serial port.
Connect the printer to the COM1 port using the optional serial cable. See Appendix B for
cabling requirements
and pin outs.
Configure the communication parameters and select the device type as detailed in
Section?
Configure the formatting parameters for the printer as detailed in Section? .
Set the current Time and Date as detailed in Section?
Step 3. Plug in the three prong connector to a standard 110 Volt A/C outlet, the scale will then
power on to begin use.
2.1 INSTALLATION
2.1.1 STAINLESS STEEL ENCLOSURE (NEPTUNE 6500)
The 6500 is contained in a NEMA 4X stainless steel enclosure, the rear cover must first be
removed to make the appropriate connections to the weigh platform, printer, remote display
and power supply. To remove the rear cover, simply remove the screws that secure it to the
enclosure and set aside.

Neptune 6500
7
2.1 CONNECTING THE WEIGH PLATFORM TO THE INDICATOR
1. Connect your shielded load cell cable (not included) to terminal on the main
board. Connection assignments for the Load Cell Terminal are shown in Figure
2-2.
Figure 2-2: Connection assignments for the Load Cell Terminal
Color
Wire Name
RED
+Excitation
BLK
- Excitation
GRN
+Signal
WHT
- Signal
Figure 2-2: Color Codes for Shielded Load Cell Cable
1. If you do not wish to use the shielded load cell cable, you may use your own,
following the pin assignments shown in Figure 2-3. (A 14-pin Male Centronics-
type connector is required).
Pin Nos.
Pin Name
1/8
+Excitation
3/10
- Excitation
5/12
+Signal
7/14
- Signal
7
1
5
3
14
12
10
8
Figure 2-3: Pin assignments for the Load Cell Port

Neptune 6500
8
2.2 CONNECTING THE SERIAL PRINTER, REMOTE DISPLAY OR COMPUTER
The NEPTUNE 6500 series indicator comes standard with a serial port,
designated COM1 and a second port specified for the TTL outputs designated as
COM2. COM1 is a full duplex, RS-232 port designed for connection to either a
PC or a serial printer. COM2 is a 5 volt TTL port for connection to external relays.
Figure 2-1 shows the serial port connections to the main board.
2.3 CONNECTING THE POWER SUPPLY
1. The indicator ships standard with an internal AC to DC adapter. Simply plug the
AC line cord into a standard wall outlet.
2. Make sure that the AC voltage appearing at the wall outlet matches the input
voltage marked on the AC adapter.

Neptune 6500
9
CHAPTER 3: BASICS OF OPERATION
3.1 DISPLAY
The Model NEPTUNE 6500 scale utilizes a 1”High, Bright Red LED (Light Emitting Diode
Display) capable of being viewed from up to 50’away in brightly or darkly lit areas.
3.1.1 LIGHT EMITTING DIODE DISPLAY (LED)
Figure below shows the display detail of the NEPTUNE 6500 Series. As shown in Figure,
the scale
displays weight information as well as UNDER/TARGET/OVER Bar Graph annunciators.
The table lists the various annunciators you may see and their meanings.
3.2 KEYBOARD
The keyboard is composed of eighteen keys, including 10 multi purpose numeric keys.
Figure 3-1: KEYBOARD DETAIL

Neptune 6500
10
TABLE 2-1: KEYPAD FUNCTIONS
KEYS
MEANING
ZERO
The ZERO key sets the current Gross weight to Zero, provided the amount of weight to be
removed is within the specified Zero range and the scale is not in motion.
UNITS
The UNITS key switches the weight display to an alternate unit. The alternate units can be Lb,
Kg, Oz, Lb-Oz, Gross, Tare.
TARE
The TARE key is used to establish a pushbutton Tare provided the scale is not at or below
Gross Zero.
PRINT
ENT
The PRINT/ENT key has two functions first it can be used to transmit an on demand output
through the serial port to a printer or other peripheral device. Secondly, under the Print is ENT
which represents ENTER. This allows you to store information into an Item ID memory file.
1--
The numeral One key has two functions first it can be used to enter in the value of 1 when
entering in a known Tare or Over/Under/Target value. Secondly, on this key there is an
additional symbol of an upward pointing arrow. The arrow is utilized in the F and A setup menu’s
allowing the operator to toggle through individual parameters.
2¯¯
The numeral Two key has two functions first it can be used to enter in the value of 2 when
entering in a known Tare or Over/Under/Target value. Secondly, on this key there is an
additional symbol of a downward pointing arrow. The arrow is utilized in the F and A setup
menu’s allowing the operator to enter into specific setup parameters.
3
SET
The numeral Three key has three functions first it can be used to enter in the value of 3 when
entering in a known Tare or Over/Under/Target value. Secondly, the SET text on this key acts a
a SAVE command when in the setup parameters or when saving OVER/UNDER/TARGET
values. The third function allows the operator to reset the scale, but only when the scale is in the
Gross weighing mode.
4¬¬
The numeral Four key has two functions first it can be used to enter in the value of 4 when
entering in a known Tare or Over/Under/Target value. Secondly, on this key there is an
additional symbol of a pointing West. The arrow is utilized in the F and A setup menu’s allowing
the operator to toggle backwards through the setup parameters.
5®®
The numeral Five key has two functions first it can be used to enter in the value of 5 when
entering in a known Tare or Over/Under/Target value. Secondly, on this key there is an
additional symbol of a pointing West. The arrow is utilized in the F and A setup menu’s allowing
the operator to toggle backwards through the setup parameters.
6,7,8,9,0
Keys six through nine and zero are used to enter numeric values only.
MIN
The MIN key displays the current “UNDER TOLERENCE”value and allows the operator to enter
in a new UNDER value if desired.
MAX
The MAX key displays the current “OVER TOLERENCE”value and allows the operator to enter
in a new OVER value if desired.
CLEAR
Used to reset the scale to normal weighing operation. Clears current min and max values but
does not affect database information.
TARGET
Used to clear incorrect key input. Backs up one character at a time.

Neptune 6500
11
Figure 3.2: ANNUCIATOR DETAIL
Table 3-1: ANNUNCIATOR DEFINITIONS
Annunciators
MEANING
GROSS
Indicates the scale is displaying the Gross weight.
STABLE
Indicates that the scale is in a stable weight mode condition, and therefore
seeing no motion.
TARE
Indicates that a tare has been established in the system.
C-ZERO
Indicates that the current displayed weight reading is+/- 0.25% displayed division of
the acquired zero.
UNDER
The amber LED segments above the UNDER insignia indicate an underweight
condition in the check weighing mode.
TARGET
The green LED segments above the TARGET insignia indicate an acceptable weight
condition in the check weighing mode.
OVER
The red LED segments above the OVER insignia indicate an overweight condition in
the check weighing mode.
Lb-Oz
Indicates the scale is in the pound-ounce weighing mode.
OZ
Indicates the scale is in the ounce weighing mode.
KG
Indicates the scale is in the kilogram weighing mode.
Lb
Indicates the scale is in the pound weighing mode.

Neptune 6500
12
3.3 GENERAL SCALE OPERATION
3.3.1 WEIGHING AN ITEM
If necessary, press the Zero soft key to obtain a weight reading of zero.
Place the object to be weighed on the scale’s platter and allow the weight indication
to stabilize. If the item weight exceeds the scale’s weight capacity, it displays
“000000”. Read the weight shown on the display. Note: If you wish to change the unit
of measure, press the UNIT key.
3.3.2 TARING AN ITEM OF UNKNOWN WEIGHT
To weigh an item in a container, the weight of that container must first be subtracted from
the overall weight to obtain an accurate weight reading. This is known as a Tare.
1. If necessary, press the ZERO to obtain a weight reading of zero.
2. Place the empty container on the scale’s platter and allow the weight indication to
stabilize.
3. Press the TARE key.
4. The display shows ZERO weight value and turns on the TARE and NET
annunciators.
5. Place the material to be weighed in the container and allow the weight indication to
stabilize.
6. Read the weight shown on the display.
3.3.3 TARING AN ITEM OF KNOWN WEIGHT
If the weight of the container or object is known, you may enter this weight via the
keyboard. This value must be rounded to the nearest scale division. For example, on a 60 x
0.002 lb scale, you must enter the tare weight value to the nearest 0.002 lb.
1. If necessary, press the ZERO to obtain a weight reading of zero.
2. Press the TARE key.
3. Enter the TARE weight using the numeric keys.
4. Press the TARE key.
3. The display shows a negative weight value and turns on the TARE and NET
annunciators.
4. Place the material to be weighed in the container and allow the weight indication
to stabilize.
5. Read the weight shown on the display
3.3.4 CLEARING A TARE
1. Remove all weight from the scale platform. Press the TARE key. The TARE and
NET annunciators disappear and the gross weight is displayed.
3.3.5 ENTERING A MAX AND MIN VALUE
1. Press the MIN button. Enter the minimum values and press the MIN button.
Scale temporarily displays SET.
2. Press the MAX button. Enter the maximum value and press the MAX button.
Scale temporarily displays SET.
3. The scale now operates in the check weigh mode. The amber lights are on when
the weight is < min value, the green lights are on when the weight is >= min but <
max

Neptune 6500
13
3.3.6 ENTERING A SINGLE TARGET VALUE
1. Press the MIN key. Enter the single target value. The under lights are on when
the weight is less than the min value, the target (accept) lights are on when the
weight is equal to the target value and the over lights are on when the weight is
greater than the target value.

Neptune 6500
14
CHAPTER 4: ADVANCED FEATURES AND OPERATION
4.1 ITEM ID STORAGE
Your scale can store UNDER/OVER//TARE/UNIT information for up to 100 items. These
items are stored and retrieved under a Product ID number. The ID numbers are assigned
by the scale operator. Each ID record may contain:
·UNDER tolerance value
·OVER tolerance value
·TARE value
·Product ID number –up to 6 numeric characters
4.1.1 ADDING A NEW ITEM ENTRY
Make sure the scale is in the weighing mode and does not have a max or min value
entered. To clear any old information, press and hold the 0/CLR key for three
seconds. Press the MIN key, enter a minimum weight value and press MIN.
Press the MAX key, enter a maximum weight value and press MAX.
If keyboard tare is required, press the TARE key, enter the tare value and press
TARE. If known tare is available, place object on scale and press TARE.
Enter an ID number up to 6 digits and press ID KEY to store item record. Scale
displays SET while storing information and then displays the number of records
stored. If you make any key in errors, press the TARGET key to back up one
character. To return to weighing only mode, press and hold the 0/CLR key for three
seconds.
4.1.2 RECALLING AN EXISTING ID ITEM ENTRY
Enter a stored ID number and press ID key.
The scale automatically recalls the stored information.
NOTE: If you do not know the Product ID number, press the 0 key and the ID
key. The scale displays the
first item ID stored. You can view the min, max and tare values by press the
5(right arrow) key. To select another stored item, press the 2(down arrow) key.
When the desired ID is found, press ENT key to activate that ID and begin
check weighing.
4.1.3 DELETING AN EXISTING ID ITEM ENTRY
Press and hold the SET key. The scale displays DEL 1 d.
Enter the Product ID number to delete. Press and hold the ID key for 2 second’s.
Scale displays del and the item record is deleted from memory.
4.1.4 EDITING AN EXISTING ITEM ID
1. Enter an existing Product ID and press ID key.
2. Enter a new min, max or tare value or change unit of measure. (lb/kg/oz)
3. Enter the Product ID number and press ID to save changes.

Neptune 6500
15
4.2 TTL SET POINT OUTPUTS
This function works utilizing three 5Volt TTL outputs and allows your scale to work within a
specialized system. This is useful if you are filling individual containers to a pre-determined
TARGET weight value, or if you are check weighing individual portions, you can utilize the
set points to activate an internal buzzer that will sound when the TARGET set point is
reached.
Each output is an open-collector circuit, capable of sinking 250mA when ON. All logic levels
are active low. The circuits include +-5 V resistors to drive TTL or 5 V CMOS logic without
additional hardware.
4.2.1 SETPOINT OUTPUTS
The Neptune 6500 has three annunciators on the front display to indicate UNDER,
ACCEPT or OVER. If you want to use an external device to signal the check weigh
condition, use the external TTL outputs. The same condition that drives the internal
annunciators will drive the external device. Setup step F15 allows control over external set
point number 2. A value of 0 (zero) will cause the set point to remain high when the
condition is met. You may enter a value of 1/10s of a second to cause SP2 to alternate high
and low when the condition is met. An common example of how this delay is used would be
to flash a light on and off when the accept condition is met. Over and under would show a
steady light.
SP1 SP2 SP3
On if < Min value On if >= Min value & < Max On if >= Max value
See F15 for always on or delay time
Only one set point is active at a time. When a set point is active, the others are not.

Neptune 6500
16
CHAPTER 5: CALIBRATION
5.1 CALIBRATION OVERVIEW
The indicator is calibrated by following the procedures embedded in F16 (Zero) and F17
(Span) of the Setup Menu. Each procedure enters a value into the indicator's non-volatile
memory - F16 the zero value (deadweight) and F17 the span value (test weight). The
minimum test weight that can be used is 1% of full-scale capacity. After the two calibration
procedures are executed successfully, you should record both calibration values in Table
6-1 using the F18 View procedure.
In the unlikely event that either value is lost while in the field, the setup menu makes
provisions for re-entering these values via F19 and F20, thus eliminating the need for re-
calibration with test weights.
NOTE: This chapter assumes that the indicator is in Setup (“F”) Menu mode. If the indicator
is not in Setup Menu mode, refer to Chapter 3 for instructions.
5.2 ZERO CALIBRATION (F16)
1. While in the Setup mode, scroll to "F 16", then scroll down once using the DOWN
ARROW (2) key to enter zero calibration menu. The display will momentarily show "C
0" followed by a value. This value is the internal A/D count and can prove useful when
trying to troubleshoot setup problems. Record this value where you can find it again.
2. After making sure that there is no weight on the platform, press the ZERO key to zero
out the displayed value.
3. Press the SET key to save the zero point value. The display will show “SAVE”then
“EndC0" momentarily, then revert back up to F16. At this time, proceed to the F17
span calibration to complete indicator calibration.
5.3 SPAN CALIBRATION (F17)
1. While in the Setup mode, scroll to "F 17", then scroll down once using the DOWN
ARROW (2) key to enter span calibration menu.
2. The display will momentarily show "C 1" for the span calibration, followed by a value
with one flashing digit. This value will be zero with the Decimal Point parameter
selected in F10. Place the test weight on the scale platform.
3. Use the four directional keys (shown in Figure 6-1 below) to adjust the displayed value
to the actual test weight value. Increase the flashing digit by pressing the UP ARROW
(1) key. Decrease the flashing digit by pressing the DOWN ARROW (2) key. Pressing
the LEFT ARROW (4) key or the RIGHT ARROW (5) key will change the position of
the flashing digit.
4. Place the test weight on the scale and press the SET key.
5. If the calibration was successful, the display will show SAVE, then "EndC1"
momentarily. You can now end the calibration process or proceed through a three point
calibration.
For three point calibration - the scale will momentarily show "C 2". See steps 3, 4 and
5. The scale displays C 3. See steps 3, 4 and 5.
To end as a single point calibration, press the SET key at C 2 and again at C 3. The
scale returns to F17.

Neptune 6500
17
6. If the calibration was not successful, one of the error messages below will appear. Take
the indicated action to correct the problem, then perform a new calibration.
"Err0" - The calibration test weight or the adjusted keyed-in weight is larger than the full
capacity of the scale. Change the calibration test weight or check the input data.
"Err1" - The calibration test weight or the adjusted keyed-in weight is smaller than 1%
of the full capacity of the scale. Change the calibration test weight or check the input
data.
"Err2" - The internal resolution of the scale is not high enough to accept the calibration
value. Select a larger parameter for the Span Gain (F2). SEE APPENDIX C FOR
MORE INFORMATION.
5.4 VIEW CALIBRATION VALUES (F18)
Note: The values displayed in this procedure are valid only after a successful calibration
has been performed using F16 and F17.
1. While in the Setup mode, scroll to "F 18", then scroll down once using the DOWN
ARROW (2) key to enter View calibration menu.
2. The display will momentarily show "CAL 0" followed by a value. This value is the zero
calibration value and should be recorded in the table below.
3. Press DOWN ARROW (2) again. Scale will momentarily show "CAL 1" followed by
another value. This value is the span calibration value and should also be recorded in
the table below. Press the up arrow key to return to upper level (F18).
INDICATOR
ZERO CALIBRATIONVALUE
SPANCALIBRATIONVALUE
S/N:
Table 6-1: Calibration Value Table
5.5 KEY-IN ZERO CALIBRATION VALUE (F19)
Note: This procedure is intended for emergency use only in the case of non-volatile
memory loss. A valid zero calibration value, obtained from a successful F16
calibration procedure, must be used.
1. While in the Setup mode, scroll using the right or left arrow keys to "F 19", then scroll
down once using the DOWN ARROW (2) key.
2. The display will momentarily show "CAL 0", followed by a flashing zero. Use the four
directional keys (shown in Figure 6-1) to adjust the displayed value to the zero
calibration value.
3. After setting the exact value, press the ENT key to save the value.
4. The display will show "E CAL 0" momentarily, then revert back up to F19.

Neptune 6500
18
5.6 KEY-IN SPAN CALIBRATION VALUE (F20)
Note: This procedure is intended for emergency use only in the case of non-volatile
memory loss. A valid span calibration value, obtained from a successful F17
calibration procedure, must be used.
5.6 KEY-IN CALIBRATION VALUE (F20)
Note: This procedure is intended for emergency use only in the case of non-volatile
memory loss. A valid span calibration value, obtained from a successful F17
calibration procedure, must be used.
1. While in the Setup mode, scroll to "F 20", then scroll down once using the DOWN
ARROW key.
2. The display will momentarily show "ET C1", followed by the right digit flashing. Use
the numeric keyboard to adjust the displayed value to the original calibration value.
3. After setting the exact value, press the ENT key to save the value.
4. If the entered value is greater than zero, the display will show "E E C1" momentarily,
then displays “E T C2”. Press ENT key and the display will show "E E C3"
momentarily, then displays “E T C3”. Press ENT key and the scale then displays "E E
C3" and goes back to F20.
If a value of zero is entered, the indicator will briefly show "Err 5", then revert back to the
screen described above in Step # 2..

Neptune 6500
19
CHAPTER 6: CONFIGURATION
6.1 CONFIGURATION OVERVIEW
The indicator contains two main setup menus: The Setup (“F”) menu which configures the indicator to
your weigh platform and the User (“A”) menu which configures the serial communication port and
enables some user options. TheSetupandUsermenusconsistofseveralmenuselections,eachwithitsown
sub-menuofchoices.
Tosetuptheindicator,youmustfirstentertheappropriatemenumode.Oncethere,fourofthefrontpanelkeys
becomedirectionalnavigatorstomovearoundinthemenus,andonekeyisusedtosaveorSETtheselections.
6.2 SETUP (“F”) MENU & “A”MENU
6.2.1 ENTERING/EXITING THE SETUP MENU
1. Power off the indicator by unplugging the power source.
2. Remove two screws holding the small cover plate
3. Slide the switch to the left
4. Power on the indicator by plugging in the power source. The indicator shows ”F
1”to indicate that you are in Setup Menu mode. The “A”menu follows the “F”
menu. Press the right arrow key to step through all the “F”parameters to get to
the “A”menu.
5. After completing changes in the setup menu slide the switch to its original
position, this will return the indicator to normal weighing mode. There is no need
to power down the indicator after returning the switch to the original position.
6.2.2 NAVIGATING IN THE SETUP MENU
Use the directional keys shown in Figure 6-1 to move around in the Setup Menu Chart
shown in Figure 6-3 on the following page.
1. To move to a new “F”or “A”heading, use the 4 (left) or 5 (right) arrow key to
move right or left in the Setup Menu Chart.
2. To move to the selection level, press the 2 (down) arrow key once. The
current saved selection is shown or the selected process will begin.
3. To view the available selections for the current “F”or “A”heading, use the 4
(left) or 5 (right) arrow key to move through the selection field.
4. To save a new selection, press the 3 (Set) key followed by the 1(up) arrow
key. To exit without saving, press the 1 (up) arrow key to return to the current
“F”or “A”heading.
5. Repeat Steps 1 through 4 until the Setup Menu is programmed.

Neptune 6500
20
Figure 6-1: “F”CONFIGURATION MENU
F1
Grads
F2
Span Gain
F3
Zero Track
F4
Zero Range
F5
Mot Band
F6
Dig Filter
F7
Ovld Limit
F10
Dec Point
F9
Disp Div
F8
Cal Unit
0D
0.5D
1D
D
3D
5D
1D
D
3D
5D
10D
0D
D
2%
1D
9D
D
50
D
75
100
200
D
100%
D
1.9%
8
12
16
24
25
D
32
64
lb
kg
F12
N/A
F11
N/A
F14
N/A
F13
N/A
F15
N/A
F17
Span Calib
F16
Zero Calib
F19
Key-in
Zero
F18
Cal &
SpanView
F21
Fac Dflt
F20
Key-in Span
F22
N/A
F23
Scale Cap
1
2
5
0
0.0
0.00
0.000
0.0000
1000
D
1500
2000
2500
500
D
3500
4000
5000
10000
3000
20000
30000
40000
50000
12000
00
10
25
50
100
5
500
250
150
D
7D
10D
Down
arrow key
to begin
Down
arrow key
to begin
Down
arrow key
to begin
Down
arrow key
to begin
Down
arrow key
to begin
Down
arrow key
to begin
1000
2.5
0
Enter
Value
