TransLite TL-9542B User manual

P a g e | 1
4* CVBS/HDMI/YPbPr/CC DVB-C/DVB-T/ISDB-T/ATSC RF
MPEG2 HD & MPEG4 AVC/H.264 HD Encoding
DISCLAIMER
No part of this document may be reproduced in any form without the written permission of the copyright
owner.
The contents of this document are subject to revision without notice due to continued progress in
methodology, design and manufacturing. TRANSLITE GLOBAL LLC shall have no liability for any error or
damage of any kind resulting from the use of this document.
COPY WARNING
This document includes some confidential information. Its usage is limited to the owners of the
product that it is relevant to. It cannot be copied, modified, or translated in another language
without prior written authorization from TRANSLITE GLOBAL LLC
PRODUCT MODEL NUMBER: TL-9542B
MPEG2/MPEG4 HD 4 in 1 Encoder Modulator
ABOUT THIS MANUAL

P a g e | 2
INDEX
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION...................................................................................................................3
1.1 PRODUCT OVERVIEW........................................................................................................................3
1.2 KEY FEATURES...................................................................................................................................3
1.3 SPECIFICATIONS................................................................................................................................4
1.4 PRINCIPLE CHART.............................................................................................................................7
1.5 APPEARANCE AND DESCRIPTION......................................................................................................8
CHAPTER 2 INSTALLATION......................................................................................................................9
2.1 GENERAL PRECAUTIONS ...................................................................................................................9
2.2 POWER PRECAUTIONS.................................................................................................................... 10
2.3 DEVICE’S INSTALLATION FLOW CHART ILLUSTRATED AS FOLLOWING................................................ 10
2.4 ENVIRONMENT REQUIREMENT....................................................................................................... 10
2.5 GROUNDING REQUIREMENT........................................................................................................... 11
CHAPTER 3 OPERATION........................................................................................................................11
3.1 LCD MENU STRUCTURE...................................................................................................................12
3.2 GENERAL SETTINGS FOR MAIN MENU ............................................................................................. 14
CHAPTER 4 WEB NMS OPERATION....................................................................................................... 22
4.1 LOGIN ............................................................................................................................................22
4.2 OPERATION .................................................................................................................................... 23
CHAPTER 5 OPERATION OF CLOSED CAPTION (CC) ...............................................................................35
CHAPTER 6 LOW DELAY SETTINGS........................................................................................................36
CHAPTER 7 TROUBLESHOOTING........................................................................................................... 38
CHAPTER 8 PACKING LIST..................................................................................................................... 39

P a g e | 3
CHAPTER 1
INTRODUCTION
1.1 PRODUCT OVERVIEW
TL-9542B series products are TRANSLITE’s all-in-one devices which integrate encoding
(MPEG-2, MPEG-4/AVC H.264) and modulation to convert HDMI/YPbPr/CVBS signals etc to
digital RF output.
To meet customers’ various requirements, TL-9542B is also equipped with 1 ASI input, and
output with 2 ASI ports and 1 IP port.
The signals source could be from satellite receivers, closed-circuit television cameras, Blue-ray
players, and antenna etc. Its output signals are to be received by TVs, STB and etc with
corresponding standard.
TRANSLITE TL-9542B series products are wildly used in public places such as metro, market
hall, theatre, hotels, restaurants and etc for advertising, monitoring, training and educating in
company, schools, campuses, hospital… It’s a good choice to offer HD channels and more.
1.2 KEY FEATURES
➢MPEG2 HD & MPEG4 AVC H.264 HD video encoding
➢DD AC3 (2.0), MPEG4-AAC, MPEG2-AAC, MPEG1 Layer II audio encoding
➢Support DD AC3 (2.0/5.1/7.1) passthrough
➢4* HDMI/YPbPr/CVBS channels in
➢1*ASI in for re-mux; 1*RF in for RF mix
➢4* DVB-C RF out optional; ASI out; IP out
➢Support CC (Closed Caption) EIA608, (from CVBS source only)
➢Support Low Delay

P a g e | 4
➢LCN (Logical Channel Number) support
➢Excellent modulation quality
➢LCD display, Remote control and firmware
➢Web-based NMS management; Updates via web
1.3 SPECIFICATIONS
Encoding Section - Video
Encoding
MPEG2; MPEG4 AVC/H.264
Interface
HDMI*4
Resolution
1920*1080_60P, 1920*1080_50P
(For MPEG 4 AVC/H.264 only),
1920*1080_60i, 1920*1080_50i,
1280*720_60p, 1280*720_50P
Low Delay
Normal, Mode 1, Mode 2
Aspect Ratio
4:3; 16:9
Encoding Section –Audio(HDMI)
Encoding
MPEG1 Layer II; MPEG2-AAC; MPEG4-AAC;
DD AC3 (2.0) optional;
DD AC3 (2.0/5.1/7.1) passthrough
Interface
HDMI*4 /SPDIF*4
Sample rate
48KHz
Bit rate
64/96/128/ 192/256/320kbps
Video (CVBS/YPbPr)
Encoding
MPEG2; MPEG4 AVC/H.264
Interface
CVBS/YPbPr*4 (RCA)
Resolution
CVBS: 720*576_50i, 720*480_60i
YPbPr:1920*1080_60i, 1920*1080_50i;
1280*720_60p, 1280*720_50P

P a g e | 5
Audio(L/R)
Encoding
MPEG1 Layer II; MPEG2-AAC; MPEG4-AAC;
DD AC3 (2.0) Optional
Interface
1*Stereo/2*mono/1*SPDIF per channel
Sample rate
48KHz
Bit rate
64/96/128/ 192/256/320kbps
Modulator Section –DVB-T (option)
Standard
EN300744
FFT mode
2K, 8K
Bandwidth
6M, 7M, 8M
Constellation
QPSK, 16QAM, 64QAM
Guard Interval
1/4, 1/8, 1/16, 1/32
FEC
1/2, 2/3, 3/4, 5/6, 7/8
MER
≥42dB
RF frequency
30~960MHz, 1KHz step
RF out
COFDM DVB-T out (2 carriers combined out)
RF output level
-30~ -10dbm (81~97 dbµV), 0.1db step
Modulator Section –DVB-C
Standard
J.83A (DVB-C), J.83B, J.83C
MER
≥43dB
RF frequency
30~960MHz, 1KHz step
RF output level
-30~ -10dbm (77~97 dbµV), 0.1db step
Symbol rate
5.000~9.000Msps adjustable
RF Out
4*DVB-C adjacent carriers combined output
J.83A
J.83B
J.83C
Constellation
16/32/64/128/ 256
QAM
64/ 256 QAM
64/ 256 QAM
Bandwidth
8M
6M
6M

P a g e | 6
ISDB-T option
Standard
ARIB STD-B31
Constellation
DQPSK,QPSK, 16QAM, 64QAM
Guard Interval
1/32, 1/16, 1/8, 1/4
Transmission Mode
2K, 4K, 8K
Guard Interval
1/32, 1/16, 1/8, 1/4
Code rate
1/2, 3/4, 5/6, 7/8
RF frequency
30~999MHz, 1KHz step
ATSC
Standard
ATSC A/53
Constellation
8 VSB
RF output level
-30~ -10dbm (77~97 dbµV), 0.1db step
MER
≥42dB
RF frequency
30~999MHz, 1KHz step
System
Local interface
LCD + control buttons
Remote
management
Web NMS
Stream Out
2 ASI mirrored out (BNC type, 100M);
IP (4 SPTS+1MPTS) over UDP, RTP/RTSP out,RJ45, 100M (MPTS is available
for DVB-C/ATSC out versions)
NMS interface
RJ45, 100M
Language
English
General
Power supply
AC 100V~240V
Dimensions
482*400*44mm
Weight
4.5 kg
Operation
temperature
0~45℃

P a g e | 7
1.4 PRINCIPLE CHART

P a g e | 8
1.5 APPEARANCE AND DESCRIPTION
Front Panel Illustration
1 2 3 4 5 6 7 8 9
1
LCD Screen
2
NMS Port
3
Data Port
4
Power and Alarm Indicators
5
TS Lock Indicators
6
Up and Down, Left and Right Buttons
7
Enter Mode: For Confirm
8
Menu Button: For Back Step
9
Lock Button: Press to Lock Set
Rear Panel Illustration
1 2 3 4 5 6 7 8 9
10 11 12

P a g e | 9
1
HDMI input port
2
YPbPr/CVBS(Pr) input port
3
CVBS input port for CC only
4
L/R Audio input (Stereo or mono)
5
SPDIF Audio input port
6
ASI Input port
7
ASI Output port 1&2
8
Power switch
9
Power supply slot
10
RFin port
11
RFout port
12
Grounding
CHAPTER 2
INSTALLATION GUIDE
This section is to explain the cautions the users must know in some case that possibly injure
may bring to users when it’s used or installed. For this reason, please read all details here and
make in mind before installing or using the product.
2.1 GENERAL PRECAUTIONS
➢Must be operated and maintained free of dust or dirty.
➢The cover should be securely fastened, do not open the cover of the products
when the power is on.
➢After use, securely stow away all loose cables, external antenna, and others.

P a g e | 10
2.2 POWER PRECAUTIONS
➢When you connect the power source, make sure if it may cause overload.
➢Avoid operating on a wet floor in the open. Make sure the extension cable is in
good condition
➢Make sure the power switch is off before you start to install the device
2.3 DEVICE’S INSTALLATION FLOW CHART
ILLUSTRATED AS FOLLOWING
Connecting
Grouding
Wire and
Power
Cord
Acquisition
Check Installing Device Setting Parameter Running Device
Connecting
Signal
cable
2.4 ENVIRONMENT REQUIREMENT
Item
Requirement
Machine Hall
Space
When user installs machine frame array in one machine hall, the distance
between 2 rows of machine frames should be 1.2~1.5m and the distance
against wall should be no less than 0.8m.
Machine Hall
Floor
Electric Isolation, Dust Free
Volume resistivity of ground anti-static material: 1X107~1X1010，
Grounding current limiting resistance: 1M(Floor bearing should be
greater than 450Kg/㎡)
Environment
Temperature
5~40℃(sustainable)，0~45℃(short time)
installing air-conditioning is recommended
Relative
Humidity
20%~80% sustainable 10%~90% short time
Pressure
86~105KPa

P a g e | 11
Door &
Window
Installing rubber strip for sealing door-gaps and dual level glasses for
window
Wall
It can be covered with wallpaper, or brightness less paint.
Fire
Protection
Fire alarm system and extinguisher
Power
Requiring device power, air-conditioning power and lighting power are
independent toeach other. Devicepower requiresAC 110V±10%, 50/60Hz
or AC 220V±10%, 50/60Hz. Please carefully check before running.
2.5 GROUNDING REQUIREMENT
➢All function modules’ good grounding is the basis of reliability and stability of devices. Also,
they are the most important guarantee of lightning arresting and interference rejection.
Therefore, the system must follow this rule.
➢Grounding conductor must adopt copper conductor in order to reduce high frequency
impedance, and the grounding wire must be as thick and short as possible.
➢Users shouldmake sure the 2 ends of grounding wire well electric conducted and be antirust.
➢It is prohibited to use any other device as part of grounding electric circuit
➢The area of the conduction between grounding wire and device’s frame should be no less
than 25mm2.
CHAPTER 3
OPERATION
The front panel of TL-9542B Encoder Modulator is the user-operating interface and the
equipment can be conveniently operated and managed by user according to the procedures
displayed on the LCD:

P a g e | 12
Keyboard Function Description:
MENU: Cancel current entered value, resume previous setting; Return to previous menu.
ENTER: Activate the parameters which need modifications or confirm the change after
modification.
LEFT/RIGHT: Choose and set the parameters.
UP/DOWN: Modify activated parameter or paging up/down when parameter is inactivated.
LOCK: Lock the screen/cancel the lock state. After pressing the lock key, the LCD will display
the current configuring state.
3.1 LCD MENU STRUCTURE
Switch On
Initializing
General Working
Status
1 Status
2 Input Sets 2.1 Input 1
2.3 Input 3
2.2 Input 2
Program Info
2.3.1 Parse Program
2.3.2 Mux Program
2.1.1 Program 1
2.1.2 Program 2
2.2.1 Program 1
2.2.2 Program 2
(Same content with 2.1.1)
(Same content with 2.1.1)
(Same content with 2.1.1)
Video
Audio

P a g e | 13
3 Modulator 3.1 Output A
3.2 Output B
3.3 Output C
3.4 Output D
3.1.2 Standard
3.1.3 Constellation
3.1.4 Symbol Rate
3.1.5 RF Frequency
3.1.6 RF Level
3.1.1 RF On
3.2.1-3.2.7
(Same content with 3.1.1-3.1.7)
3.3.1-3.3.7
3.4.1-3.4.7
3.1.7 ASI output
4 TS Config 4.1 Output A
4.2 Output B
4.3 Output C
4.4 Output D
4.1.2 ON ID
4.1.1 TS ID
4.2.1-4.2.3
(Same content with 4.1.1-4.1.3)
4.3.1-4.3.3
4.4.1-4.4.3
4.5 Output E 4.5.1-4.5.3
5 Network 5.1 NMS
5.2 IP Stream
5.1.2 Subnet Mask
5.1.3 Gateway
5.1.4 MAC Address
5.1.5 Web NMS Port
5.1.6 Reset Password
5.1.1 NMS IP
5.2.2 Output SPTS2
5.2.3 Output SPTS3
5.2.4 Output SPTS3
5.2.1 Output SPTS1
Output IP
Data Enable
Null PKT Filter
Gateway
Output Port
Subnet Mask
Protocol
(Same content
with 5.2.1)
6 System 6.1 Save Config
6.2 Load Saved CFG
6.3 Factory Reset
6.4 LCD Time-out
6.6 Version
4.1.3 ASI output
5.2.5 Output MPTS

P a g e | 14
Initial Status
After powering on the device，it will take a few seconds to initialize the system It shows as
below:
•DVB-C: to indicate the modulation standard of this device.
•A/B/C/D: to indicate the 4 carrier outputs
•XXX.XX MHz: to indicate the current output frequency (Range: 30~999MHz) of
the 4 carriers output, which shows in turn.
•X.XX Mbps: to indicate the encoding bit rate of each encoding board
respectively.
3.2 GENERAL SETTINGS FOR MAIN MENU
By pressing “Lock”key on the front panel, user can enter the main menu. The LCD will display
the following pages:
User can press UP/DOWN buttons to specify menu item, and then press ENTER to enter the
submenus as below:
1) Status
Start up…
Start OK…
DVB-C A XXX.00MHz
P1 X.XXMbps P2 X.XXMbps
1 Status
2 Input Sets
3 Modulator
4 TS Config
5 Network
6 System

P a g e | 15
Press Enter to enter “Status”and it displays the working time duration of the device. It times
upon power on
2) Input Sets
Under this submenu, the LCD will show “2.1 Input 1”, “2.2 Input 2”and “2.3 Input 3”.
“2.1 Input 1”and “2.2 Input 2”respectively represent the two encoding boards and there are two
programs under each input. User could enter each program to set the interface as per the signal
source and set the related video & audio parameters.
1.1 Uptime
Uptime
2 Days-10:30:20
2.1 Input 1
2.2 Input 2
2.3 Input 3
2.1 Input 1
2.1.1 Program 1
2.1.2 Program 2
Video in status
Interface
Video Format
Low Delay
Video Bitrate
Low Delay
Normal
Interface
CVBS
Video Bit Rate
08.000 Mbps
Video Format
MPEG-2
Video
Audio
Program Info
Video in status
Locked

P a g e | 16
“Interface”: Connect the signal source to the corresponding input channel and select the
interface from the options provided in the submenu (YPbPr, CVBS and HDMI optional). Press
Enter key to confirm and the system will automatically search the signal source.
“Video Format”: the encoding module supports both MPEG2 and MPEG4 AVC/H.264 formats.
Move the triangle mark with LEFT/RIGHT keys to specify the intended format and press ENTER
to confirm.
“Video Bit Rate”: Move the underline with LEFT/RIGHT keys and modify the value of frequency
(1-19Mbps) with UP/DOWN keys, and press ENTER key to save the settings.
“Low Delay”: Normal: not to enable the low delay mode.
NOTE: The different combination of Video Format, Video Bit-rate, Low Delay Mode and the
Resolution of signal source will have an impact on the time latency on receiving side. Please
refer to the Appendix attached for detailed information.
“Audio Format”: MPEG-1 Layer 2, MPEG-2 AAC, MPEG-4 AAC, AC3, AC3 Passthrough
optional.
“Audio Bitrate”:64-320Kbps optional.
“Audio Gain”: 000% to 400% adjustable.
Audio Format
►MPEG-2
AAC
Audio Bitrate
►128Kbps
Video
Audio
Program Info
Audio Format
Audio Bitrate
Audio Gain
Audio Gain
000%

P a g e | 17
“2.3 Input 3”represents the ASI input. User could parse and select program(s) to mux out.
“Parse Program” is for checking the quantity of input programs from the corresponding Tuner
input.
“Mux Program” is for selecting programs from the ASI IN to output via corresponding carrier
output or ASI output (A, B, C, D, E optional). Move the triangle mark to specify the program and
press RIGHT/LEFT keys to shift the mark between “√” and “X”. (“√”: to output the corresponding
program; “X”: not to output the corresponding program)
►1 GXTV √
2 SZTV X
Parse Program
Get 3 programs
2.3.1 Parse Program
2.3.2 Mux Program
2.3 Input 3
Program Output
Program Name
Service Provider
Program ID
PMT PID
PCR PID
Video PID
Audio PID
Video
Audio
Program Info
►Output A Mux
Output B Mux

P a g e | 18
3) Modulator Setting
When entering “Modulator” submenu, user can configure the modulating parameters for the 4
carrier output separately:
As the TL9542B (ATSC Modulating) is with 4 carrier outputs, “3.1”-“3.4”represent the “Carrier
A”, “Carrier B”, “Carrier C”, and “Carrier D”respectively. User can enter “3.1”/“3.2”/“3.4”/“3.4”to
set the corresponding modulating parameters. Submenus (taking “3.1”as an example) are as
below:
➢RF On
This interface is to decide whether to enable the RF (carrier A) output or not.
OFF: to disable programs to output through carrier A.
ON: to enable programs to output through carrier A.
3.1 Output A
3.2 Output B
3.3 Output C
3.4 Output D
3.1 Output A
3.1.1 RF On
3.1.2 Standard
3.1.3 RF On
3.1.4 ASI output
RF On
Off On

P a g e | 19
➢RF Frequency
The RF output frequency range is from 30 to 999MHz with 1K stepping. After entering
the RF frequency setting submenu, users the can press LEFT, RIGHT, UP, and DOWN
buttons to adjust the frequency and confirm by press ENTER button.
➢RF level
The RF attenuation range is from -30~-10dbm (81~97dbµV) with 0.1db step. After
entering this setting submenu, user can shift UP/DOWN/LEFT/RIGHT key to set the
output level and press ENTER to confirm.
➢ASI Output:
TL-9542B encoder & modulator (DVB-C Modulating) is with quad-carrier output A, B, C,
D and 1 ASI output E.
Output A: the ASI output programs are same as carrier output A.
Output B: the ASI output programs are same as carrier output B.
Output C: the ASI output programs are same as carrier output C.
Output D: the ASI output programs are same as carrier output D.
Output E: the ASI output programs are set separately.
ASI Output
Output A
RF Frequency
750.000 MHz
RF Level
-10.0 dbm

P a g e | 20
NOTE: The setting principle of “3.2”, “3.3”, and “3.4”are the same with “3.1”explained above.
4) TS Config
Enter each menu to configure the TS ID and Original Network ID for the 4 carriers and ASI
output.
5) Network
Network contains “5.1 NMS”and “5.2 IP Stream”.
“5.1 NMS”is for setting the network parameters for the connection between the device and PC.
“IP Stream”is for configuring the 4 SPTS and 1 MPTS output respectively.
4.1 Output A
4.2 Output B
4.3 Output C
4.4 Output D
5.1.5 Web NMS Port
5.1.6 Reset Password
5.1.3 Gateway
5.1.4 MAC Address
5.1.1 NMS IP
5.1.2 Subnet Mask
5.1 NMS
5.2 IP Stream
5.2.1Output SPTS1
5.2.2Output SPTS2
5.2.3 Output SPTS3
5.2.4 Output SPTS4
4.5 Output E
