Transrotor Avorio User manual

Transrotor
Avorio
Instruction Manual
RÄKE HIFI/VERTRIEB GMBH, IRLENFELDER WEG 43, D-51467 BERG. GLADBACH
Tele on 02202/31046 Tele ax 02202/36844

Our turntables are precise mechanical master-pieces, expressing a
consequent handicra t.
It is our goal to manu acture a turntable or our customers which sounds
excellent, is com ortable and logically to handle, made only o best material,
unctions or decades and later o ers an easy service.
DELIVERY EXTENT (Standard) (LIEFERUMFANG)
Be ore building up the turntable please check i all parts are enclosed.
Motor
Power-supply-unit
3 Turntable eet
Belt
Platter
One pair o cotton gloves
Bag o tonearm-accessories and instruction manual
(Cartridge-accessories & instruction manual)

ONSTRU TION (AUFBAU)
Please start to build-up the turntable at its inal place, because o di icult
transport a ter construction. To avoid ingerprints on perspex and polished
parts please put on the enclosed gloves.
1. Arrange the three turntable eet in a triangle- orm (two in the ront and
one midst in the back).
2. Lay the turntable chassis on the eet.
3. Place the motor as shown on the drawing. The motor can be placed
around the platter, the distance o 5 mm between platter and motor
must be kept.
4. Fix the belt around the -platter and the motor-pully. The inner-platter has
one separate groove, the motor-pully has two grooves:
upper groove (small diameter) = 33 1/3 U/min
lower groove (big diameter) = 45 U/min
5. Take the platter out o the packing and set it on to the mainbearing.
6. Put the plug o the motor-cable into the power-supply-unit. Connect the
power-supply-unit with the circuit. Basically the power-supply-unit can
remain plugged-in as the power consumption with switched-o motor is

quite insigni icant. Disconnect the power-supply-unit only in case o
longer no-usage.
7. Connect the tonarm-cable with both plugs at the phono-entrance o
your empli yer:
red = right channel
black = left channel
8. Please take in ormation regarding the tonearm-adjustment rom the
special tonearm instruction-manual.
9. Please take in ormation and dates regarding the installation o the
cartridge rom the special cartridge-manual.
USAGE
Always switch-o the motor be ore laying a record on the platter.
Listening of records
1. Lay a record on the platter.
2. I a platter-weight is available, set it on the platter-spindle, so even slight
wavy records can be played with accuracy and a high quality standard.
3. Move the tonearm over the irst groove o the record and then lower it
with the tonearm-li t.

SPE IALITIES
•The mainbearing-oil has to be checked once a year. It has to be ex-
changed in case o discolouration or i dirt particles are discovered.
•
ARE-INDI ATION
Your Transrotor-turntable is manu actured only o very best material. All parts
are sturdy, easy-care and made or a longlasting use. Please pay attention to
the ollowing indications to keep your turntable in a brilliant state.
Dustcover, chassis and platter
Always use a moisty leather or normal cleaning. Never use a dry leather as
scratches on the sur ace increase. You achieve the best result by using the
cleaning-lotion Laser lean and the so t Laser Cloth. In addition the cleaned
parts are mostly ree o statical loading. Oil or grease stains can be removed
easily by using benzine (pharmacy).
Aluminum and metal parts
Also here, oil and grease stains can be removed with benzine. Slight scratches
can be removed with a special aluminium-polish. Please do not use any other
polish or cleaning agent.
Belt
Rub the belt every once in a while in talcum. Remove loose talcum with a dry
cloth be ore ixing the belt at the platter.
The careset contains:
-Aluminium-polish
-Laser Clean
-Laser Cloth
-One pair o cotton gloves
-(can be ordered through your dealer or via our service-number)

ADDITIONAL DATA
Avorio
Measurements: (w x d x h)
44cm x 33cmx 17cm (depends on placing o motor)
Weight:
approx. 20 kg
In case you have further questions regarding your turntable, accessory
or service parts please ask your dealer or contact us via telephone.
Service-number:
Monday – Thursday from 15.00 to 16.00pm, Tel: ++49-2202-31046
This turntable is expressively subject to any technical alterations, errors
and omissions.
