Travis Industries ProBuilder 36CF GSB2 User manual

ProBuilder 36/42CF Blower Kit (MV / GSB2)
SKU# 99000199

Page 1 of 8 17602032 - Printed 8/20/18 © Travis Industries, Inc.
Compatibility
 ProBuilder 36CF GSB2
 ProBuilder 42CF GSB2
 ProBuilder 36CF MV
 ProBuilder 42CF MV
Packing List
 Left and Right Blower Assemblies  (5) 8-32 KEPS nuts (use 11/32” wrench)
 Rheostat Assembly  Wiring Harness
 Snap Disc
Tools Required
 11/32” Nutdriver/Wrench
 1/4“ Nutdriver/Wrench
 Philips Screw Driver

ProBuilder 36/42CF Blower Kit (MV / GSB2)
SKU# 99000199

Page 2 of 8 17602032 - Printed 8/20/18 © Travis Industries, Inc.
Installation Notes
Install The Blower First
The blower is best installed by removing the rear access plate. This must be done before the fireplace is
installed. If the fireplace has already been installed, the blowers may be installed by removing the burner
then removing the access plates on the firebox floor.
WARNING: Disable power to the fireplace while installing the blower (disable the service breaker). Do not
activate power to the fireplace until the blower kit is fully installed and grounded.
Do not connect 110-120 VAC to the gas control valve or wiring system of this appliance.
If installing the blowers prior to installing the fireplace (RECOMMENDED) skip the to the
“Installation” section on page 4.
Installing the Blower from Inside Firebox (not recommended)
The fireplace is equip with a removable valve tray assembly that allows for installation and service of the
blower after the fireplace has been installed. To access the lower portion of the appliance:
 Turn the gas off to the fireplace.
 Disable AC power to the fireplace (turn off breaker)
 Remove the glass assembly and logs (see manual).
 Remove the burners (see manual).
 Remove the media tray skirt.
 Remove the (2) ¼” screws that secure the media tray to the grate assembly and remove the media tray.
 Remove the (4) ¼” screws that secure the grate to the firebox (2 on the back of the firebox and 2 to the
floor – see below).
Remove
MediaSkirt

ProBuilder 36/42CF Blower Kit (MV / GSB2)
SKU# 99000199

Page 3 of 8 17602032 - Printed 8/20/18 © Travis Industries, Inc.
 Loosen the (2) screws that secure the rear log support to the back wall of the firebox (see below). The
support has keyholes so lift the part upward to disengage from the screws and pull forward to remove
from the firebox.
 Remove the optional Ember-Glo light bracket (if applicable).
 Use a ¼” nut driver to remove the (12) screws that secure the valve tray (see below).
 Disconnect the gas line from the service shutoff valve below the firebox (see below).
 Disconnect electrical connections to the valve tray (IFC wires, pilot connections, AC wiring, etc.)
 Carefullyliftthevalvetrayupandremoveitfromthefireplace(takecarenottodamagethegasket).
 Followtheinstallationstepsoutlinedinthisinstructionsheet
 Returnthefireplacetoitsoriginalconfigurationafterinstallation.
Remove
screwswith
¼”nutdriver
Disconnect
gas
ViewofFireboxFloor
Loosentoremovelogsupport
Loosento
removegrate

ProBuilder 36/42CF Blower Kit (MV / GSB2)
SKU# 99000199

Page 4 of 8 17602032 - Printed 8/20/18 © Travis Industries, Inc.
Installation
1. Disable power to the fireplace (turn the service breaker off).
2. Remove the access panel from the rear of the fireplace by removing the (8) screws. Use a ¼” nut driver.
Set the access cover and screws aside for reinstallation. Locate the blower mounting studs on the bottom
of floor of the fireplace (see below).
3. Attach the wire harness to the blower assemblies. The BLUE connectors will attach to the left blower and
the RED will attach to the right (see below.)
NOTE: Left and Right are in relation to facing the front of the appliance.
4. Locate the wires labeled “Snap Disc”. Attach the wires to the electrical posts of the included snap disc
(polarity doesn’t matter).
5. Look through the access hole in the back of the fireplace and locate the snap disc bracket. Slide the snap
disc into the bracket as shown below.
MountingStuds
Rearoffireplace
Removescrews
andplate
GroundingStud
L
R

ProBuilder 36/42CF Blower Kit (MV / GSB2)
SKU# 99000199

Page 5 of 8 17602032 - Printed 8/20/18 © Travis Industries, Inc.
6. Take the (2) green wires connected to the blower brackets and place them both over the center stud in the
cavity under the fireplace. Use (1) of the 8-32 KEPS nuts to secure the wires to the stud.

ProBuilder 36/42CF Blower Kit (MV / GSB2)
SKU# 99000199

Page 6 of 8 17602032 - Printed 8/20/18 © Travis Industries, Inc.
7. Guide the remaining wire harness into the fireplace and direct it toward the right front corner of the fireplace.
Insert the blower assemblies into the cavity. The rubber grommets fit over the studs and then use (2) of the
8-32 KEPS nuts to secure the blower assemblies (do not overtighten). The blower assemblies should be
oriented so the motors are in the middle (see picture below).
8. The portion of the installation that is performed through the rear access panel is now complete. Reinstall
the cover plate and screws removed in step 2.
9. Detach the dashboard from the front of the fireplace and set the dashboard face down (do not disconnect
any wires). Set the (4) screws aside for reinstallation.
Motorsfaceto
theinside
Placegrommet
overstud
Placegrommet
overstud Securewithnut Repeatwithleftblower

ProBuilder 36/42CF Blower Kit (MV / GSB2)
SKU# 99000199

Page 7 of 8 17602032 - Printed 8/20/18 © Travis Industries, Inc.
10. Attach the rheostat asembly to the back of the dashboard as shown below. Secure using (2) of the 8-32
KEPS nuts
11. Find the wires maked “Rheostat on the wire harness and attach them to the two electrical leads from the
rheostat (polarity doesn’t matter).

ProBuilder 36/42CF Blower Kit (MV / GSB2)
SKU# 99000199

Page 8 of 8 17602032 - Printed 8/20/18 © Travis Industries, Inc.
12. Locate the “power in” wire harness on the right side. Find the connector labeled “Fan”. Remove the
dummy connector from the power in harness as shown below and connect the power connector from the
fan harness in its place
13. Reinstall the dashboard removed in step 9.
If you are installing an Ember-Glo light kit leave the dashboard uninstalled and proceed with the
Ember-Glo instructions.
