TRAXX DBM-AK49H V Series User manual

74060 7/2015 Ver 3
DBM-AK49H V SERIES
HYDRAULIC CORE DRILL
OPERATIONS MANUAL
Safety, Operation and Maintenance
Unit 4/1 Rocklea Drive
Port Melbourne Vic 3207
1300 109 108
www.traxxcp.com.au

SAFETY SYMBOLS ..................................................................................................................................................4
SAFETY PRECAUTIONS..........................................................................................................................................5
TOOL STICKERS & TAGS ........................................................................................................................................7
HOSE TYPES............................................................................................................................................................8
HOSE RECOMMENDATIONS ..................................................................................................................................9
FIGURE 1. TYPICAL HOSE CONNECTIONS .......................................................................................................9
HTMA REQUIREMENTS .........................................................................................................................................10
OPERATION ............................................................................................................................................................11
TOOL PROTECTION & CARE ................................................................................................................................12
TROUBLESHOOTING ............................................................................................................................................13
SPECIFICATIONS ...................................................................................................................................................14
DBM-AK49H PARTS ILLUSTRATION ...................................................................................................................16
DBM-AK49H PARTS LIST .......................................................................................................................................17
SERVICING: This manual contains safety, operation, and routine maintenance instructions. Traxx
recommends that servicing of hydraulic tools, other than routine maintenance, must be performed by an authorized
WARNING
SERIOUS INJURY OR DEATH COULD RESULT FROM THE IMPROPER REPAIR OR
SERVICE OF THIS TOOL.
REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN
AUTHORIZED AND CERTIFIED DEALER.
TABLE OF CONTENTS
DBM-AK49H Operations Manual | 1
IMPORTANT
call Traxx Construction Products on 1300 109 108
(NOTE: The warranty Validation record must be submitted to validate the warranty).

Always observe safety symbols. They are included for your safety and for the protection of the tool.
LOCAL SAFETY REGULATIONS
Enter any local safety regulations here. Keep these instructions in an area accessible to the operator and mainte-
nance personnel.
Safety symbols and signal words, as shown below, are used to emphasize all operator, maintenance and repair ac-
tions which, if not strictly followed, could result in a life-threatening situation, bodily injury or damage to equipment.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible
injury or death.
DANGER
This safety alert and signal word indicate an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING
This safety alert and signal word indicate a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CA UTION
This safety alert and signal word indicate a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CA UTION
This signal word indicates a potentially hazardous situation which, if not avoid-
ed, may result in property damage.
NO TICE
This signal word indicates a situation which, if not avoided, will result in damage
to the equipment.
IMPORT ANT
This signal word indicates a situation which, if not avoided, may result in dam-
age to the equipment.
SAFETY SYMBOLS
DBM-AK49H Operations Manual | 2

Tool operators and maintenance personnel must always
comply with the safety precautions given in this manual
and on the stickers and tags attached to the tool and
hose.
These safety precautions are given for your safety. Re-
view them carefully before operating the tool and before
performing general maintenance or repairs.
Supervising personnel should develop additional pre-
safety regulations. If so, place the added precautions in
the space provided in this manual.
The CDV08 Hydraulic Core Drill will provide safe and
dependable service if operated in accordance with the
instructions given in this manual. Read and understand
this manual and any stickers and tags attached to the
tool and hoses before operation. Failure to do so could
result in personal injury or equipment damage.
•Operator must start in a work area without bystand-
ers. The operator must be familiar with all prohibited
work areas such as excessive slopes and danger-
ous terrain conditions.
•Establish a training program for all operators to en-
sure safe operation.
•Do not operate the tool unless thoroughly trained or
under the supervision of an instructor.
•Always wear safety equipment such as goggles,
gloves, ear, head, and breathing protection, and
safety shoes at all times when operating the tool.
•Do not inspect, carry or clean the tool while the hy-
draulic power source is connected. Accidental en-
gagement of the tool can cause serious injury.
•Supply hoses must have a minimum working pres-
sure rating of 2500 psi/175 bar.
•Be sure all hose connections are tight.
•The hydraulic circuit control valve must be in the
“OFF” position when coupling or uncoupling the tool.
Wipe all couplers clean before connecting. Use only
lint-free cloths. Failure to do so may result in dam-
age to the quick couplers and cause overheating of
the hydraulic system.
•Do not operate the tool at oil temperatures above
140 °F/60 °C. Operation at higher oil temperatures
can cause operator discomfort and may damage the
tool. Never come in contact with the tool bit, the bit
can get hot.
•Do not operate a damaged, improperly adjusted, or
incompletely assembled tool.
•
•To avoid personal injury or equipment damage, all
tool repair, maintenance and service must only be
performed by authorized and properly trained per-
sonnel.
•Do not exceed the rated limits of the tool or use the
tool for applications beyond its design capacity.
•Always keep critical tool markings, such as labels
and warning stickers legible.
•Always replace parts with replacement parts recom-
mended by Traxx.
•Check fastener tightness often and before each use
daily.
•Never operate the tool if you cannot be sure that
underground utilities are not present.
•
tool.
Warning: Use of this tool on certain materials during
demolition could generate dust potentially contain-
ing a variety of hazardous substances such as as-
bestos, silica or lead. Inhalation of dust containing
these or other hazardous substances could result
in serious injury, cancer or death. Protect yourself
and those around you. Research and understand
the materials you are cutting. Follow correct safety
procedures and comply with all applicable national,
state or provisional health and safety regulations
relating to them, including, if appropriate arranging
person.
SAFETY PRECAUTIONS
DBM-AK49H Operations Manual | 3

•Warning:
cause skin injection injury. If you are injured by hy-
•Keep all body parts away from the working tool.
•When handling material or the tool bit, wear your
(PPE) Personal Protection Equipment.
•Be observant of the hydraulic hoses lying about the
work area, they can be a tripping hazard.
•Always de-energize the hydraulic system when
changing a tool bit.
•Take caution when changing a tool bit, tool bits can
get very hot.
•Never use the tool in an explosive atmosphere,
sparks from the breaking process could ignite ex-
plosive gas.
•Use proper lifting techniques when handling the tool,
get help from a co-worker and do not over-reach.
•
keep bystanders at a safe distance.
•
and pressure rating. Rapid failure of the internal
seals may result.
SAFETY PRECAUTIONS
DBM-AK49H Operations Manual | 4

Stickers and Tag for the DBM-AK49H
The safety tag is attached to the tool when shipped from the factory. Read and understand the safety instructions
listed on this tag before removal. We suggest you retain this tag and attach it to the tool when not is use.
CDV08 Name Sticker
P/N-73894
Warning Sticker
P/N-73731
Quality Tag
P/N-73755
TOOL STICKERS & TAGS
DBM-AK49H HAMMER
Traxx Construction products
Unit 4/1 Rocklea Drive,
Port Melbourne, VIC, 3207
DBM-AK49H Operations Manual | 5

The rated working pressure of the hydraulic hose must be equal to or higher than the relief valve setting on the hy-
draulic system. There are three types of hydraulic hose that meet this requirement and are authorized for use with
Traxx. They are:
reinforcement, and weather resistant thermoplastic or synthetic rubber cover. Hose labeled
conductive is the only hose authorized for use near electrical conductors.
(conductive) — constructed of synthetic rubber inner tube, single or double wire braid reinforce-
ment, and weather resistant synthetic rubber cover. This hose is conductive and must never be used near
electrical conductors.
-
This
hose is and must never be used near electrical conductors.
HOSE SAFETY TAGS
To help ensure your safety, the following DANGER tags are attached to all hose purchased from Traxx.
DO NOT REMOVE THESE TAGS.
If the information on a tag is illegible because of wear or damage, replace the tag immediately. A new tag may be
obtained from your Traxx Distributor.
(Shown smaller than actual size)
SIDE 1
DANGER
1. FAILURE TO USE HYDRAULIC HOSE LABELED AND CERTIFIED AS NON-CONDUCTIVE
WHEN USING HYDRAULIC TOOLS ON OR NEAR ELECTRIC LINES MAY RESULT IN
DEATH OR SERIOUS INJURY.
FOR PROPER AND SAFE OPERATION MAKE SURE THAT YOU HAVE BEEN PROP-
ERLY TRAINED IN CORRECT PROCEDURES REQUIRED FOR WORK ON OR AROUND
ELECTRIC LINES.
2. BEFORE USING HYDRAULIC HOSE LABELED AND CERTIFIED AS NON-CONDUCTIVE
ON OR NEAR ELECTRIC LINES. WIPE THE ENTIRE LENGTH OF THE HOSE AND FIT-
TING WITH A CLEAN DRY ABSORBENT CLOTH TO REMOVE DIRT AND MOISTURE AND
TEST HOSE FOR MAXIMUM ALLOWABLE CURRENT LEAKAGE IN ACCORDANCE WITH
SAFETY DEPARTMENT INSTRUCTIONS.
SEE OTHER SIDE
SIDE 2
DO NOT REMOVE THIS TAG
3. DO NOT EXCEED HOSE WORKING PRESSURE OR ABUSE HOSE. IMPROPER USE
OR HANDLING OF HOSE COULD RESULT IN BURST OR OTHER HOSE FAILURE.
KEEP HOSE AS FAR AWAY AS POSSIBLE FROM BODY AND DO NOT PERMIT DIRECT
CONTACT DURING USE. CONTACT AT THE BURST CAN CAUSE BODILY INJECTION
AND SEVERE PERSONAL INJURY.
4. HANDLE AND ROUTE HOSE CAREFULLY TO AVOID KINKING, ABRASION, CUTTING, OR
CONTACT WITH HIGH TEMPERATURE SURFACES. DO NOT USE IF KINKED. DO NOT
USE HOSE TO PULL OR LIFT TOOLS, POWER UNITS, ETC.
5. CHECK ENTIRE HOSE FOR CUTS CRACKS LEAKS ABRASIONS, BULGES, OR DAM-
AGE TO COUPLINGS IF ANY OF THESE CONDITIONS EXIST, REPLACE THE HOSE
IMMEDIATELY. NEVER USE TAPE OR ANY DEVICE TO ATTEMPT TO MEND THE HOSE.
6. AFTER EACH USE STORE IN A CLEAN DRY AREA.
SEE OTHER SIDE
DANGER
DO NOT REMOVE THIS TAG
DANGER
(Shown smaller than actual size)
SIDE 2
5. CHECK ENTIRE HOSE FOR CUTS CRACKS LEAKS ABRASIONS, BULGES, OR DAMAGE TO
COUPLINGS IF ANY OF THESE CONDITIONS EXIST, REPLACE THE HOSE IMMEDIATELY.
NEVER USE TAPE OR ANY DEVICE TO ATTEMPT TO MEND THE HOSE.
6. AFTER EACH USE STORE IN A CLEAN DRY AREA.
DANGER
DO NOT REMOVE THIS TAG
DANGER
SIDE 1
1. DO NOT USE THIS HYDRAULIC HOSE ON OR NEAR ELECTRIC LINES. THIS HOSE IS
NOT LABELED OR CERTIFIED AS NON-CONDUCTIVE. USING THIS HOSE ON OR NEAR
ELECTRICAL LINES MAY RESULT IN DEATH OR SERIOUS INJURY.
2. FOR PROPER AND SAFE OPERATION MAKE SURE THAT YOU HAVE BEEN PROPERLY
TRAINED IN CORRECT PROCEDURES REQUIRED FOR WORK ON OR AROUND ELEC-
TRIC LINES.
3. DO NOT EXCEED HOSE WORKING PRESSURE OR ABUSE HOSE. IMPROPER USE OR
HANDLING OF HOSE COULD RESULT IN BURST OR OTHER HOSE FAILURE. KEEP HOSE
AS FAR AWAY AS POSSIBLE FROM BODY AND DO NOT PERMIT DIRECT CONTACT
DURING USE. CONTACT AT THE BURST CAN CAUSE BODILY INJECTION AND SEVERE
PERSONAL INJURY.
4. HANDLE AND ROUTE HOSE CAREFULLY TO AVOID KINKING, CUTTING, OR CONTACT
WITH HIGH TEMPERATURE SURFACES. DO NOT USE IF KINKED. DO NOT USE HOSE TO
PULL OR LIFT TOOLS, POWER UNITS, ETC.
DO NOT REMOVE THIS TAG
DANGER
SEE OTHER SIDE SEE OTHER SIDE
HOSE TYPES
DBM-AK49H Operations Manual | 6

Oil Flow Hose Lengths Inside Diameter USE
(Press/Return)
Min. Working Pressure
GPM LPM FEET METERS INCH MM PSI BAR
4-9 15-34 up to 10 up to 3 3/8 10 Both 2250 155 4-6 15-23 up to 25 up to 7.5 3/8 10 Both 2500 175 4-6 15-23 26-100 7.5-30 1/2 13 Both 2500 175
5-10.5 19-40 up to 50 up to 15 1/2 13 Both 2500 175 5-10.5 19-40 51-100 15-30 5/8 16 Both 2500 175
5-10.5 19-40 100-300 30-90 5/8 16 Pressure 2500 175
3/4 19 Return 2500 175
10-13 38-49 up to 50 up to 15 5/8 16 Both 2500 175 10-13 38-49 51-100 15-30 5/8 16 Pressure 2500 175
3/4 19 Return 2500 175
10-13 38-49 100-200 30-60 3/4 19 Pressure 2500 175
1 25.4 Return 2500 175
13-16 49-60 up to 25 up to 8
5/8 16 Pressure 2500 175 3/4 19 Return 2500 175
13-16 49-60 26-100 8-30
3/4 19 Pressure 2500 175
1 25.4 Return 2500 175
Figure 1. Typical Hose Connections
Tool to Hydraulic Circuit Hose Recommendations
The chart to the right shows recommended minimum hose diameters for various hose
lengths based on gallons per minute (gpm)/
liters per minute (lpm). These recommenda-
tions are intended to keep return line pressure (back pressure) to a minimum acceptable lev-
el to ensure maximum tool performance. This chart is intended to be used for hydraulic tool applications only based on Traxx
tool operating requirements and should not be used for any other applications. All hydraulic hose must have at least a rated minimum working pressure equal to the maxi-
mum hydraulic system relief valve setting. All hydraulic hose must meet or exceed
PRESSURE
RETURN
<<< FLOW
FLOW >>>
HOSE RECOMMENDATIONS
DBM-AK49H Operations Manual | 7

DBM-AK49H Operations Manual | 8
Flow Range
Nominal Operating Pressure
(at the power supply outlet)
System relief valve setting
(at the power supply outlet)
Maximum back pressure
(at tool end of the return hose)
(at min. operating temperature)
(at max. expected ambient temperature)
Min. cooling capacity at a temperature
temps
NOTE:
Do not operate the tool at oil temperatures above 140° F (60° C). Operation at higher temperatures can cause operator
discomfort at the tool.
Filter
(For cold temp. startup and max.
dirt-holding capacity)
(premium grade, anti-wear, non-conductive)
Viscosity (at min. and max. operating temps)
NOTE:
xtremes that will be experienced in service determine the
most suitable temperature viscosity characteristics. Hydraul ents
over a wide range of operating temperatures.
*SSU = Saybolt Seconds Universal
4-6 gpm 7-9 gpm 9-10.5 gpm 11-13 gpm
(15-23 lpm) (26-34 lpm) (34-40 lpm) (42-49 lpm)
1500 psi 1500 psi 1500 psi 1500 psi
(103 bar) (103 bar) (103 bar) (103 bar)
2100-2250 psi 2100-2250 psi 2200-2300 psi 2100-2250 psi
(145-155 bar) (145-155 bar) (152-159 bar) (145-155 bar)
250 psi 250 psi 250 psi 250 psi
(17 bar) (17 bar) (17 bar) (17 bar)
400 ssu* 400 ssu* 400 ssu* 400 ssu*
(82 centistokes) (82 centistokes) (82 centistokes) (82 centistokes)
140° F 140° F 140° F 140° F
(60° C) (60° C) (60° C) (60° C)
3 hp 5 hp 6 hp 7 hp
(2.24 kW) (3.73 kW) (5.22 kW) (4.47 kW)
40° F 40° F 40° F 40° F
(22° C) (22° C) (22° C) (22° C)
25 microns 25 microns 25 microns 25 microns
30 gpm 30 gpm 30 gpm 30 gpm
(114 lpm) (114 lpm) (114 lpm) (114 lpm)
100-400 ssu* 100-400 ssu* 100-400 ssu* 100-400 ssu*
(20-82 centistokes)
HTMA
HYDRAULIC SYSTEM REQUIREMENTS
NOTE: These are general hydraulic system requirements. See tool speci
TOOL TYPE
HTMA / EHTMA REQUIREMENTS
TYPE I TYPE II TYPE III
TYPE RR
BCD
3.5-4.3 gpm 4.7-5.8 gpm 7.1-8.7 gpm 9.5-11.6 gpm 11.8-14.5 gpm
(13.5-16.5 lpm) (18-22 lpm) (27-33 lpm) (36-44 lpm) (45-55 lpm)
1870 psi 1500 psi 1500 psi 1500 psi 1500 psi
(129 bar) (103 bar) (103 bar) (103 bar) (103 bar)
EHTMA
HYDRAULIC SYSTEM
REQUIREMENTS
CLASSIFICATION
Flow Range
Nominal Operating Pressure
(at the power supply outlet)
System relief valve setting
(at the power supply outlet) 2495 psi 2000 psi 2000 psi 2000 psi 2000 psi
(172 bar) (138 bar) (138 bar) (138 bar) (138 bar)
HTMA / EHTMA REQUIREMENTS

DBM-AK49H Operations Manual | 9
DRILL BIT INSTALLATION
To install a new core drill use a 32mm open end
wrench to hold the shaft from turning while attaching
the core drill, make sure it is secure.
CHECK THE POWER SOURCE
check that the hydraulic power source develops a
bar.
2. Make sure the hydraulic power source is equipped
with a relief valve set to open at 2100–2250 psi/145–
155 bar.
3. Check that the hydraulic circuit matches the tool
for open-center (OC) operation.
CHECK THE TOOL
1. Make certain all tool accessories are correctly in-
stalled. Failure to install tool accessories properly
can result in damage to the tool or personal injury.
2. Check the equipment for signs of oil leaks. If leaks
are observed, do not use the tool; have the equip-
ment serviced before use.
3. Check fasteners for tightness.
4. Check the tool and hydraulic system for proper op-
eration and performance.
5. If the equipment does not appear to operate prop-
erly, have it serviced before use.
CONNECT HOSES
1. Wipe all hose couplers with a clean lint-free cloth
before making connections.
2. Connect the hoses from the hydraulic power source
it last to eliminate or reduce trapped pressure for easier
NOTE:
If uncoupled hoses are left in the sun, pressure in-
connect. When ever possible, connect the free ends
of hoses together.
The female coupler on the drill is the inlet coupler.
4. Cycle the control valve momentarily. If the drill does
not operate, the hoses might be reversed. Verify
correct connection of the hoses before continuing.
WARNING
Before you start changing the tool bit, make
sure that the tool is disconnected from the
power source in order to avoid unintentional
operation of the tool and injury.
GENERAL OPERATION
1. Open the water supply valve and adjust the water
water as the drill bit advances in the hole.
2. Turn the power source on.
3. Start the core drill by pulling the trigger to the on posi-
tion.
4. Slowly feed the drill into the work surface and begin drill-
ing. Note: when drilling by hand start the drilling at an
angle so only a small portion of the bit is contacting
the surface, then gradually bring the drill up straight
where the whole diameter is contacting the material.
material and turn off the core drill.
6. Turn off the power source and water supply.
When drilling into a structure that might contain
electrical wiring, be sure to know the location of the
wiring and avoid drilling into it. The housing can
carry electrical current from live electrical wires
into which the drill is accidentally drilled resulting in
injury or death.
WARNING
DRILLING A HOLE
OPERATION

DBM-AK49H Operations Manual | 10
•Make sure all couplers are wiped clean before con-
nection.
•The hydraulic circuit control valve must be in the
“OFF” position when coupling or uncoupling hydrau-
lic tools. Failure to do so may result in damage to
the quick couplers and cause overheating of the hy-
draulic system.
•Always store the tool in a clean dry space, safe from
damage or pilferage.
•Make sure the circuit PRESSURE hose (with male
quick disconnect) is connected to the “IN” port. The
circuit RETURN hose (with female quick disconnect)
is connected to the opposite port. Do not reverse cir-
•Always replace hoses, couplings and other parts
with replacement parts recommended by Traxx.
Supply hoses must have a minimum
working pressure rating of 2500 psi/172 bar.
NOTICE
In addition to the Safety Precautions found in
this manual, observe the following for equipment
protection and care.
•
and pressure rating. Rapid failure of the internal
seals may result.
•Always keep critical tool markings, such as warning
stickers and tags legible.
•Tool repair should be performed by experienced
personnel only.
•Make certain that the recommended relief valves
are installed in the pressure side of the system.
•Do not use the tool for applications for which it was
not intended.
TOOL PROTECTION & CARE

DBM-AK49H Operations Manual | 11
PROBLEM CAUSE REMEDY
Tool will not start. Power unit not functioning.
(5 gpm/20 lpm, 800–2175 psi/55–150 bar.
Couplers or hoses blocked. Remove restriction.
Pressure and return line hoses
reversed at ports.
Be sure hoses are connected to their proper
ports.
Jammed motor. See your authorized dealer for service.
Low drilling torque.
(5 gpm/20 lpm, 800–2175 psi/55–150 bar.
Defective quick-disconnect. Check each disconnect separately.
Hydraulic circuit relief set too
low.
Set relief valve at 2250 psi/155 bar.
Fluid restriction in hose or valve.
Excess back-pressure.
Locate and remove obstruction. Check back
pressure, 250 psi max.
Hoses too restrictive. Fluid not warmed up. Preheat system.
Hoses too long for hose ID. Use shorter hose.
Use larger ID hose.
Over-feeding the drill. To much down pressure, do not overload drill
to avoid wear or damage.
Tool runs too fast.
(5 gpm/20 lpm, 800–2175 psi/55–150 bar.
TROUBLESHOOTING

DBM-AK49H Operations Manual | 12
Max Pressure ................................................................................................................................ 2000 psi / 140 bar.
Nominal Pressure.......................................................................................................................... 1500 psi / 103 bar.
Flow Range ...................................................................................................................................4-6 gpm/15-24 lpm
Nominal Flow....................................................................................................................................... 5 gpm / 20 lpm
Maximum Back Pressure......................................................................................................................250 Psi/17 bar
Connect Size & Type ......................................................................................................3/8 in. Male Pipe Hose Ends
Weight ................................................................................................................................................... 22 lbs / 10 kg
Length................................................................................................................................................. 22 in. / 560 mm
Width .............................................................................................................................................. 10.2 in. / 260 mm
Max. Fluid Temperature........................................................................................................................ 140 °F / 60 °C
System Type........................................................................................................................................... Open Center
Port Size.................................................................................................................................................SAE 8 O-ring
Rotational Speed @ 20 lpm / 5 gpm ..............................................................................................................600 rpm
SPECIFICATIONS

DBM-AK49H Operations Manual | 13
DBM-AK49H PARTS ILLUSTRATION
7
19
14
15
21
17
10
41
47
53
57
56
59
25
27
28
8
3
2
5
24
29
38
40
44
52
51
50
54
55
49
13
12
11
34
35
16
20
37
36
42
46
43
45
39
9
6
18
1
58
26
4
48
33
32
31
60
63
64
65
66
61
62
22
23
30

Plate Compactor MS50/MS60/MS90/MS100
DBM-AK49H Operations Manual | 14
DBM-AK49H PARTS LIST
ITEM # PART # DESCRIPTION QTY
1 73873 SCREW M8*130 2
2 73874 SAFETY LATCH HANDLE 1
3 73875 SAFETY LATCH SLEEVE 1
4 73876 COMPRESSION SPRING 1
5 73877 SAFETY KEY 1
6 73878 SPRING PIN 1
7 73879 HANDLE 1
8 73880 TRIGGER LEVER 1
9 73881 FLANGE BOLTS M8*12 2
10 73882 MOUNTING PLATE 1
11 73883 PIPE PLUG 1/8-27NPT 7
12 73884 COMPRESSION SPRING 1
13 73885 STEEL BALL 1
14 73886 BANJO BOLT 1
15 73887 BANJO BOLT 1
16 73888 SEAL RING 4
17 73889 PRESSURE RELIEF VALVE 1
18 73890 CYLIDER PIN 4
19 73891 VALVE HOUSING 1
20 73892 O-RING 2
21 73893 MOTOR 1
22 73731 WARNING STICKERS 1
23 73894 CDV08 NAME STICKERS 1
24 73895 PLASTIC COVER 1
25 73896 HANDLE RING W/BUSHING 1
26 73897 RETAINING RING 1
27 73898 SUPPORTING HANDLE 1
28 73899 HANDLE GRIP 1
29 73900 FITTING 2
30 73755 CERTIFICATE OF QUALITY 1
31 73509 3-8 MALE COUPLER 1
32 73508 3-8 FEMALE COUPLER 1
33 73901 HOSE ASSY 2
34 73839 ORIFICE PLUG 1
35 73902 PIPE PLUG 1
36 73903 COMPRESSION SPRING 1
37 73904 LOCKNUT 8.8,M6 1
38 73905 TRIGGER PISTON 1
39 73906 SPRING WASHER 1
40 73907 TRIGGER 1
ITEM # PART # DESCRIPTION QTY
41 73908 WASHER 1
42 73909 SEAL 1
43 73910 O-RING 1
44 73911 SEAL HOUSING 1
45 73912 O-RING 1
46 73913 SEAL 1
47 73914 MOTOR ADAPTOR 1
48 73915 CAPSCREW M6*16 3
49 73916 RETAINING RING 1
50 73917 COMPRESSION SPRING 2
51 73918 DISTANCE RING 1
52 73919 BEARING 2
53 73920 BEARING HOUSING 1
54 73921 O-RING 2
55 73922 SEAL 2
56 73923 SEAL HOUSING 1
57 73924 SHAFT 1
58 73925 SEAL 1
59 73926 FRONT ADAPTOR 1
60 73927 PAGODA JOINT(OUTSIDE ) 2
61 73928 HOSE CLAMP 4
62 73929 WATER HOSE 2
63 73930 WATER SWITCH 1
64 73931 COPPER PAGODA
JOINT(INSIDE) 1
65 73932 COPPER CONNECTORS
( MALE ) 1
66 73933 COPPER CONNECTORS
( FEMALE ) 1

Traxx Constructions Products Operations Manual – Plate Compactor MS50/MS60/MS90/MS100 18
Unit 4/1 Rocklea Drive
Port Melbourne Vic 3207
1300 109 108
www.traxxcp.com.au
