TRENDnet's TEW-204UB 11Mbps Wireless USB Network
Adapter is today's creation to wire-free access to networking
resources. Compiling with IEEE 802.11b standard, this USB
Wireless Adapter implements four high-extensive data rates
of 1, 2, 5.5 and 11Mbps with automatic rate selection for fast
and reliable wireless data communication. Designed for
desktop PC's and Laptops with USB support, TRENDnet's
TEW-204UB is fully mobile and seamless roams from Access
Point to Access Point, allowing users to create wireless LAN
or connect to the wired Ethernet network at home or at the
office - with coverage up to 300 meters!!
TEW-204UB
11Mbps Wireless USB Network Adapter
Low interference and high susceptibility guarantee reliable
performance
Delivers data rate up to 11Mbps
Dynamically shifts between 11, 5.5, 2 and 1 Mbps network
speed (based on signal strength), for maximum availability and
reliability of connection
Allows users to move between Access Points without resetting
their connection reconfiguration.
Antenna is built into the adapter with LED's indicating Power
and Link
Uses 2.4 GHz frequency band, which complies with worldwide
requirement
Supports Ad-Hoc (peer-to-peer) mode and Infrastructure mode
network architecture
Provides drivers supporting Windows 98/ME/2000/XP
Ensures great security by providing 64/128-bit Wired Equivalent
Privacy (WEP) defined in the IEEE 802.11b standard
Distance coverage 30 to100 meters indoor, 100 to 300 meters
outdoors
3 years Warranty
BENEFITSFEATURES
Integration Friendly:
Economical:
Flexible:
Cost Effective:
Performance:
Easy installation with plug-and play
and Hot-Swappable USB interface.
With Wireless network, users can
save time, labor, and material for
network cable installation.
Creates wireless peer-to-peer network
in Ad-Hoc mode or connects to
Ethernet LAN in Infrastructure mode
using Wireless Access Point.
Supports IEEE 802.11b wireless
standard, user can connect to any
IEEE 802.11b wireless network.
Connects at a speed up to 11Mbps,
wirelessly!
TEW-204UB (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking

PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TEW-201PC 11Mbps Wireless PCMCIA Network Adapter
TEW-202CF:11Mbps Wireless CompactFlash Network Adapter
TEW-203PI: 11Mbps Wireless PCI Network Adapter
TEW-204UB: 11Mbps Wireless USB Network Adapter
TEW-210APB: 11Mbps Wireless Access Point + Bridge
TEW-211BRP: 11Mbps Wireless Broadband Router + Access Point
TEW-PS3: 3-port Wireless Ethernet Print Server
TEW-IA04O: 4.0 dBi 2.4GHz ISM Band Omni Directional Antenna (with Reverse
SMA Connector)
TEW-IA06D: 6.0 dBi 2.4GHz ISM Band Patch Antenna (with Reverse SMA Connector)
TEW-OA14D: 14dBi Directional Antenna (outdoor) for IEEE 802.11b 2.4 GHz ISM Band
TEW-2000F: N-Type Male to Reverse SMA Female Antenna Cable (2 meters)
for Outdoor Antenna
NETWORKING SOLUTIONS
SPECIFICATIONS
Adapter Type:
USB Specification 1.0
Standards:
IEEE 802.11b
Data Rate:
11Mbps, 5.5Mbps, 2Mbps, 1Mbps
Module Technique:
Direct Sequence Spread Spectrum
(DSSS), CCK, DQPSK, DBPSK
Antenna:
Sleeved Dipole Antenna
Media Access Protocol:
CSMA/CA with ACK
LED Indicator:
Power, Link
•
•
•
•
•
•
•
Frequency:
2.4 to 2.4835GHz (Industrial Scientific
Medical Band)
Output Power:
15dBm (typical)
Receiving Sensitivity:
10-5 BER @ -81 dbm (11Mbps) min.
Power Consumption:
5V, 240mA (typical), 300mA max.
Channels:
11 Channels (US & Canada)
Dimensions:
102 x 71 x 20 mm (4.0 x 2.8 x 0.8 inch)
Weight:
70g (2.47oz.)
•
•
•
•
•
•
•
Temperature:
Operating: 0° ~ 55° C (32° ~ 131° F)
Storage: -20° ~ 65° C (-4° ~ 149° F)
Humidity:
Max. 95% (Non-condensing)
Certification:
FCC, CE
•
•
•
•
TEW-204UB
11Mbps Wireless USB Network Adapter
TEW-204UB
11Mbps Wireless USB Network Adapter
