TRENDnet TEW-687GA User manual

wireless
Features
• 1 x 10/100/1000Mbps Auto-MDIX LAN port
• 1 x Wi-Fi Protected Setup (WPS) button
• 1 x Reset button
• Diagnostic LEDs
• High performance wireless data rates of up to 450Mbps
• Wi-Fi compliant with the IEEE 802.11n standard
• Backwards compatible with IEEE 802.11g/b devices
• Supports 64/128-bit WEP, WPA-PSK, and WPA2-PSK wireless security
• Power Save mode conserves electricity
• Supports Multiple Input Multiple Output (MIMO) antenna technology
• Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization
• One-touch wireless security setup using the Wi-Fi Protected Setup (WPS) button when connecting to a WPS supported device
• Maximum reliability, throughput and connectivity with automatic data rate switching
• Easy user setup wizard and intuitive Web browser configuration
• Coverage of up to 50 meters indoor, 100 meters outdoor *
• 3-year limited warranty
* Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending
on interference, network traffic, building materials and other conditions.
TEW-687GA
rev:12.22.2011
TEW-687GA(V1.0R)
450Mbps Wireless N Gaming Adapter
TRENDnet's 450Mbps Wireless N Gaming Adapter, model TEW-687GA,
networks gaming consoles, televisions, and DVRs to the Internet with an
ultra-high performance 450Mbps wireless connection.
Setup is quick and simple, with no drivers to install and a Gigabit Ethernet
port transfers wired data fast.
Advanced Multiple Input Multiple Output (MIMO) antenna technology with
three spatial streams per antenna generates a maximum theoretical wireless
throughput of 450Mbps. Connect to a router at the touch of a button with Wi-
Fi Protected Setup (WPS). WMM® Quality of Service (QoS) technology
prioritizes gaming, Internet calls, and video streams. LEDs on the front of the
adapter convey device status. Cut your cables and start winning with ultra-
high performance 450Mbps wireless n.

SPECIFICATIONS
Standards
Interface
LED Indicator
• IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n
• 153 g (5.4 oz.)
• Storage: -20° ~ 60° C (-4° ~ 140° F)
• 1 x 10/100/1000Mbps Auto-MDIX LAN ports
• 60 x 118 x 135 mm (2.4 x 4.6 x 5.3 in.)
• Power, LAN, Wireless, WPS
• WPS button – enables WPS function
Weight
Hardware
SPECIFICATIONS
• Operating: 0° ~ 40° C (32° ~ 104° F)
Temperature
• Max. 90% (non-condensing)
Humidity
• CE, FCC
Certifications
Dimensions (LxWxH)
Button
Frequency
Data Rate (auto fallback)
• 2.412 ~ 2.472 GHz
• 802.11b: up to 11Mbps
Wireless
• 802.11g:up to 54Mbps
Encryption
Channels
• 802.11b: -84dBm (typical)
Receiving Sensitivity
• 1~ 11 (FCC), 1~13 (ETSI)
• 802.11n: up to 450Mbps
• 64/128-bit WEP , WPA/WPA2-PSK
• Reset button – restores factory default settings
Power • 12V DC 0.5A power adapter
• 4.5 watts (max)
Power Consumption
• 802.11g: -72dBm (typical) • 802.11n: -69dBm (typical)
Output Power • 802.11n : 13dBm (typical)
• 802.11g: 15dBm (typical)
• 802.11b: 18dBm (typical)
1-888-326-6061
CONTACT INFORMATION
RELATED PRODUCTS
PACKAGE CONTENTS
NETWORKING SOLUTIONS
• Multi-Language Quick Installation Guide
• 1 x Cat. 5 Ethernet cable (0.6 m / 2 ft.)
• TEW-687GA
• CD-ROM (Utility and User’s Guide)
TEW-691GR
TEW-690AP
TEW-640MB 300Mbps Wireless N 4-Port Media Bridge
450Mbps Wireless N Gigabit Router
450Mbps Wireless N Access Point
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
• Power adapter (12V DC, 0.5A)
