TRESPASS HT-198 Quick guide

Trespass Rechargeable pump
Read following instructions and warnings
before use -
Please keep for future reference
Read following instructions and warnings
before use -
Please keep for future reference
IMPORTANT
USE INSTRUCTIONS
For quickly inflating the item with screw valve, unscrew
the safe bolt to deflate directly.
*
*
Technical Data
Model No
Material
Power
Input Volt
Pressure
Airflow
HT-198
ABS
42W (max)
AC 230V - 240V or DC 12V
0.5PSI (When fully charged)
250L/Min (When fully charged)
Where possible recycle unwanted materials instead of disposing
of them as waste. All parts and packaging should be sorted, taken
to a recycling center and disposed of in an environmentally friendly
manner.
Guarantor: Argos Limited
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
The vavle of inflatable item should not be obstructed.
Otherwise, it could overheat and damage the pump.
switch off for stop.(the symbol “-”on the switch means
“ON”, “O” means “OFF”)
1. Read these instructions carefully
and familiarise yourself with the
procedure before assembling the
unit.
2. Check that you have all the
component parts following the
list on the next page and
familiarise yourself with each
part before proceeding.
E13

IMPORTANT SAFETY INSTRUCTIONS
Read all instruction before use and keep for future reference.
1
*
*
*
*
This pump is intended to inflatable/deflatable items. Such as inflatable toys, air
mattress etc. This pump is not designed for continuous use.
Keep the air pump out of the reach of children.
Do not obstruct the inflation/deflation port and keep them ventilated all the time.
For fast inflation and shorten the motor’s working time, always use the suitable
adapter according to the size of valve of inflatable item.
Running time 10 minutes(inflate Tresp ass double airbed two times),
once fully charged.
IMPORTANT
2WARNING
T
o reduce the risk, contact qualified electrician to repair or replace the damaged
cord immediately.
Carefully follow the instructions on inflatable item when inflating. Never exceed
recommended pressure, otherwise, serious injury might be caused by the
bursting item.
Never leave pump unattended while the pump in use .
Do not keep/use the pump in wet condition.
Never allow sands, small rocks, etc.to be sucked into inflation /deflation port when
using the pump.
Never look inside or point the inflation/deflation port toward your eyes when the
pump is working.
Please charge pump with its original AC/DC charger, otherwise will destroy the
pump.
*
*
*
*
*
*
*
3TO CHARGE BATTERY
USE INSTRUCTIONS
*
*
Before charging in the initial use,make sure that the battery has been fully discharged.
- For use with the transformer
1. Connect the transformer to the pump.(See Fig.1)
2. Insert the tansformer into a home socket.
3. It will takes about 10-15 hours to full charge the
battery (The battery should be charged for 16
hours for initial use)
- For use with the DC power cord.
1. Insert thc DC power cord into the pump’s socket.
(See Fig.2)
2. Insert the plug into a car cigarette lighter.
3.
*
*
NOTE
:
Make sure the switch is off before inserting the transformer into socket.
When charging the pump power supply must be 230-240Volt AC or automobile
Fig.1
Fig.2
4TO INFLATE ITEMS
*
*
*
*
Use the pump directly in which the battery has been
fully charged.
Join adapter to inflation port, then hold pump against
valve of inflatable item and switch on for inflation/
switch off for stop. (The symbol “-” on the switch
means “ON”, “O” means “OFF”)
The valve of inflatable item should not be obstructed.
Otherwise, it could overheat and damage the pump.
On large items like inflatable boat, king-size air
mattress, the pump should fit directly to the valve of inflatable item for fast inflation.
Use the appropriate adapter for small valve, such as single-size air mattress, etc.
5TO DEFLATE ITEMS
Open the valve of inflatable item.
Join adapter to deflation port, then insert it in the valve and switch on for deflation/
*
*
*
cigarette lighter 12Volt DC.
DEFLATION PORT
INFLATION PORT
ADAPTER
CHARGER
CAR CHARGER
SWITCH
It will take 2 hours to charge with DC power source.
Never use the pump when it is being charged.
The battery should be recharged immediately after it is discharged.Please do not
lay the pump aside without power for a long time.
Please take the R E D charger stopper out from the pump before charging and using.
