Tribata. FEDERATION F9332 User manual

FEDERATION
exposed floor entry bath & shower set
F9332
Specifications
Features
Recommended Use Domestic, Commercial, Hotel
Material Brass Body
Finishes Satin Chrome, Nickel, Brushed Nickel, Gold, Brass Gold N18, Brushed
Gold N18, Rose Gold, Brushed Rose Gold, Matt Black, Black Sapphire
Brushed Black Sapphire, Gunmetal, Satin Pearl, Copper, Antique Copper
Dimensions
Standards
Handle
WELS Rating
200W x 450D x 2160H mm
AS/NZS 3718
Cross Handle, Lever Handle, Porcelain Lever Handle
Flow Rate: 9L/min, Stars: 3
550mm
2160mm
200mm
450mm
AS/NZS3718 Lic WMKA 26319
WaterMark
TM
Products in this specification manual must by regulation be installed by licensed and registered trade people.
Under our commitment to product development and improvement, we may change product specifications
and dimensions or delete models from the range without prior notification. Dimensions and set-outs listed
are correct at time of publication and could contain dimensions which are approximate due to tolerances in
manufacturing processes. It is important that you thoroughly review the product and check specifications
and dimensions prior to surface preparation, cut-out and installation.
During the installation of the product by a qualified trained personnel, make sure that the entire fastening
surface is even and smooth (no protruding seams or tile oset), that the finish of the wall is suitable to apply
the product and has no weak points. It is recommended that all accessories are secured to timber studs.
Disclaimer:

FEDERATION
exposed floor entry bath & shower set
F9332
Specifications
Specifications
Pressure Rating As per AS/NZS3500 pressure must be limited to 500kPa on any new
home, extension or renovation.
For best performance and longer life we recommend 150-500kPa.
Hot and cold water inlet pressure should be equal.
Temperature Rating 80°C maximum continuous working temperature
Suitable Hot Water Units Storage Tank - Yes
Continuous Flow - Yes
Gravity Feed - Not Suitable
Cleaning Instructions
We recommend the use of soapy water or approved cleaners.
This product should not be cleaned with abrasive materials.
Damage caused by any improper treatment is not covered by the product warranty - refer to our
Warranty Conditions.
Plumbers, please ensure a copy of the installation instructions is left with the end user for future reference
For the Plumber
Check 1. All work should be carried out by a licensed plumber. Responsibility will not be accepted by
Tribata for incorrect installation of this tapware, or any tapware not installed by a Registered Plumber.
Check 2. The water supply lines need to be ‘flushed out’ prior to installation. This will avoid any foreign
materials blocking the flow regulator, damaging the cartridge/valve and reducing the flow of water.
Check 3. Ensure all connections are tight.
Check 4. Turn on the main water supply and check for leaks.
Products in this specification manual must by regulation be installed by licensed and registered trade people.
Under our commitment to product development and improvement, we may change product specifications
and dimensions or delete models from the range without prior notification. Dimensions and set-outs listed
are correct at time of publication and could contain dimensions which are approximate due to tolerances in
manufacturing processes. It is important that you thoroughly review the product and check specifications
and dimensions prior to surface preparation, cut-out and installation.
During the installation of the product by a qualified trained personnel, make sure that the entire fastening
surface is even and smooth (no protruding seams or tile oset), that the finish of the wall is suitable to apply
the product and has no weak points. It is recommended that all accessories are secured to timber studs.
Disclaimer:

FEDERATION
exposed floor entry bath & shower set
F9332
Specifications
Installation Instructions
IMPORTANT INFORMATION, please read before starting installation.
CHECK 1
For packaging purposes, this tapware may come partially assembled.
CHECK 2
Before installation, please ensure that you have checked the assembly of all components and joints.
CHECK 3
Always use plumbers tape or a recommended sealing compound on all threaded joints.
CHECK 4
Please pressure test the tapware prior to installation using recommended testing equipment.
CHECK 5
The installer is responsible for selecting the correct fittings and that the distances are correct
before installation.
INSTALLATION Guideline
1. Breech assembly, 150mm centres. (200 mm centres for the models with hand-held shower)
2. Wall brackets allow for pipework to be approx. 40mm clear of wall.
3. Exposed T connections attached to wall outlets. Cover plates behind exposed T connections.
4. Bib tap assembly.
Products in this specification manual must by regulation be installed by licensed and registered trade people.
Under our commitment to product development and improvement, we may change product specifications
and dimensions or delete models from the range without prior notification. Dimensions and set-outs listed
are correct at time of publication and could contain dimensions which are approximate due to tolerances in
manufacturing processes. It is important that you thoroughly review the product and check specifications
and dimensions prior to surface preparation, cut-out and installation.
During the installation of the product by a qualified trained personnel, make sure that the entire fastening
surface is even and smooth (no protruding seams or tile oset), that the finish of the wall is suitable to apply
the product and has no weak points. It is recommended that all accessories are secured to timber studs.
Disclaimer:
