Tricity Bendix TRD 23 SW User manual

2223 123-53
TRD 23 SW
FRIDGE-FREEZER
OPERATING AND INSTALLATION
INSTRUCTIONS
Tricity Bendix, 55-77 High Street, Slough, Berkshire SL1 1DZ
Consumer care telephone number……0 705 950950
©Electrolux plc 2006

2
IMPORTANT SAFETY INFORMATION
It is most important that this instruction book should be retained with the appliance or uture
re erence. Should the appliance be sold or trans erred to another owner, or should you move house and
leave the appliance, always ensure that the book is le t with the appliance in order that the new owner
can get to know the unctioning o the appliance and the relevant sa ety in ormation.
This in ormation has been provided in the interest o sa ety. You MUST read it care ully be ore installing
or using the appliance.
Installation
• This appliance is heavy. Care should e taken when
moving it.
• It is dangerous to alter the specifications or attempt
to modify this product in any way.
• Care must e taken to ensure that the appliance
does not stand on the electrical supply ca le.
Important: if the supply ca le is damaged, it must
e replaced y a special ca le availa le from your
local Service Force Centre.
• Any electrical work required to install this appliance
should e carried out y a qualified electrician or
competent person.
• Parts which heat up should not e exposed.
Whenever possi le, the ack of the appliance
should e close to a wall ut leaving the required
distance for ventilation as stated in the installation
instructions.
• The appliance should e left for 2 hours after
installation efore it is turned on, in order to allow
the refrigerant to settle.
Child Sa ety
• Do not allow children to tamper with the controls or
play with the product.
• Keep all packaging well away from children.
General Sa ety
• This appliance contains hydrocarbons in its
cooling unit; maintenance and recharging must
there ore only be carried out by authorized
technicians.
• Take utmost care when handling your appliance
so as not to cause any damages to the cooling
unit with consequent possible luid leakages.
•The appliance must not be located close to
cookers, radiators or boilers.
•Avoid prolonged exposure o the appliance to
direct sunlight.
•Do not use other electrical appliances (such as
ice cream makers) inside o re rigerating
appliances.
During Use
• This appliance is designed for domestic use only,
specifically for the storage of edi le foodstuffs.
• Frozen food must NOT e re-frozen once it has
thawed out.
• Do not place car onated or fizzy drinks in the
freezer.
• Do not remove items from the freezer if your
hands are damp/wet, as this could cause skin
a rasions or frost/freezer urns.
• Ice lollies can cause ‘frost/freezer urns’ if
consumed straight from the freezer.
• Manufacturers’ storage recommendations should
e strictly adhered to. Refer to relevant
instructions.
• The cooling plate or refrigerated freezer shelves
in this appliance contain channels through which
the refrigerant passes. If these are punctured this
will cause su stantial damage to the appliance
and result in food loss. DO NOT USE SHARP
INSTRUMENTS to scrape off frost or ice. Under
NO circumstances should solid ice e forced off
the lining or shelves. Solid ice should e allowed
to thaw, when defrosting the appliance. See
Defrost Instructions.
Maintenance and Cleaning
• Switch off and unplug the appliance efore
carrying out any cleaning or maintenance work.
Servicing
• This product should e serviced y an authorised
engineer and only genuine spare parts should e
used.
• Under no circumstances should you attempt to
repair the machine yourself. Repairs carried out
y inexperienced persons may cause injury or
serious malfunctioning. Refer to your local
Service Force Centre and always insist on
genuine spare parts.
At the end o the Appliance
Li e
• When disposing of your appliance, use an
authorised disposal site.
• Remove the plug and ensure that any locks or
catches are removed, to prevent young children
eing trapped inside.
15
Door reversal
1. Disconnect from the electricity supply;
2. Remove all loose items, including food, store food
in a cool place;
3. Gently lay the fridge/freezer on its ack with the
top held away from the floor y 5-8 cm (2-3
inches) of packing;
4. Remove the feet (2-3).
5. Remove ottom hinge (1).
6. Slide out the fridge door from middle hinge (H)
and remove the latter.
7. Slide out the freezer door from pin (G), unscrew
the latter and then screw it down into the hinge
provided on the opposite side, after having
removed the small plugs which should then e
fitted on the opposite side.
8. Refit the freezer door and the middle hinge on the
opposite side.
9. Refit the fridge door and ottom hinge (1) on the
opposite side.
10.Refit the feet (2-3).
Attention
After completion of the door reversing operation,
check that the door gasket adheres to the ca inet. If
the am ient temperature is cold (i.e. in Winter), the
gasket may not fit perfectly to the ca inet. In that
case, wait for the natural fitting of the gasket or
accelerate this process y heating up the part
involved with a normal hairdryer.
H
G
I
I
I
D715 PIED/M
1
2
3
PR60
A
45°
Rear spacers
The plastic ag containing all relevant
documentation also contains two spacers to e fitted
into special holes in the ack of the appliance. Fit the
spacers into the holes, taking care to ensure that the
arrow (A) is positioned as shown in Fig. Then turn
them through 45° (arrow (A) vertical) until they lock
into place.

3
CONTENTS
Instructions or the User
Important Sa ety In ormation 2
Operation 4
Before use 4
Setting the temperature 4
Freezing fresh food 4
Storage of frozen food 4
Thawing 4
Making ice cu es 5
Fresh food refrigeration 5
Mova le shelves 5
Freezing calendar 5
Hints and Tips 6
Maintenance and Cleaning 7
Internal cleaning 7
External cleaning 7
When the appliance is not in use 7
Changing the light ul 7
Defrosting 7
Something Not Working 9
Service and Spare Parts 10
Customer Care 10
Guarantee Conditions 11
Instructions or the
Installer
Technical Speci ication 12
Installation 13
Positioning 13
Shelf holders 13
Electrical Connection 14
Rear spacers 15
Door Reversal 15
Disposal o old Appliances
The sym ol on the product or on its packaging
indicates that this product may not e treated as
household waste. Instead it shall e handed over to
the applica le collection point for the recycling of
electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the environment
and human health, which could otherwise e caused
y inappropriate waste handling of this product. For
more detailed information a out recycling of this
product, please contact your local city office, your
household waste disposal service or the shop where
you purchased the product.
14
Electrical connections
Any electrical work required to install this appliance
should e carried out y a qualified electrician or
competent person.
WARNING: THIS APPLIANCE MUST BE
EARTHED.
The manu acturer declines any liability should
this sa ety measure not be observed.
If the plug that is fitted to your appliance is not
suita le for your socket outlet, it must e cut off and
the appropriate plug fitted.
Remove the fuse from the cut off plug.
The cut off plug should then e disposed of to
prevent the hazard of shocks in case it should e
plugged into a 13amp socket in another part of your
home.
Important
The wires in the mains lead are coloured in
accordance with the following code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
If you fit your own plug, the colours of the wires in
the mains lead of your appliance may not correspond
with the markings identifying the terminals in your
plug, proceed as follows:
Connect the Green and Yellow (earth) wire to the
terminal in the plug which is marked with the letter
«E» or the earth sym ol or coloured green and
yellow.
Connect the lue (neutral) wire to the terminal in the
plug which is marked with the letter «N» or coloured
lack.
Connect the rown (live) wire to the terminal in the
plug which is marked with the letter «L» or coloured
red.
The plug moulded onto the lead incorporates a fuse.
D207
GREEN & YELLOW 13 AMP. FUSE
BROWN
CORD CLAMP
BLUE
13 AMP
For replacement, use a 13amp BSI362 fuse. Only
ASTA or BSI approved fuses should e used.
The plug must not e used if the fuse cover/carrier is
lost. The cover/carrier is indicated y the coloured
insert at the ase of the plug.
A replacement cover/carrier must e o tained from
your local Service Force Centre.
This appliance complies with the E.E.C. Directive
No. 87/308 o 2.6.87 relative to radio inter erence
suppression.
This appliance complies with the following
E.E.C. Directives:
- 73/23 EEC o 19.2.73 (Low Voltage Directive)
and su sequent modifications;
- 89/336 EEC o 3.5.89 (Electromagnetic
Compati ility Directive) and su sequent
modifications.
Please ensure that when the appliance is
installed it is easily accessible or the engineer in
the event o a breakdown.

4
Thawing
Frozen food, prior to eing used, can e thawed in
the fridge or at room temperature depending on the
time availa le. Small food items may even e cooked
from frozen; in this case cooking will take longer.
Any frozen food which is allowed to thaw accidentally
should either e eaten as soon as possi le or thrown
away. Alternatively, if the food is uncooked and has
not een completely defrosted it can e cooked and
then refrozen.
Meat, fish and fruit should e thawed in the
refrigerator compartment and small pieces of meat
can even e cooked while still frozen, ut you must
ensure that it is thoroughly cooked through.
Vegeta les should e directly immersed in oiling
water; ready-cooked dishes can e placed directly in
the oven in their aluminium wrapping.
A microwave oven is particularly suita le for thawing
any type of frozen food: follow the oven instructions,
particularly regarding the placement of aluminium
wrapping or containers in the oven.
OPERATION
Be ore using
Remove all securing tapes. Wash inside the
appliance with lukewarm water and icar onate of
soda (5 ml to 0.5 litre of water).
Do not use soap or detergent as the smell may
linger. Dry thoroughly.
Setting the temperature
The temperature inside the refrigerator is regulated
y a thermostat with 6 temperature positions and
one «OFF» (O) position.
Position 1 = minimum coldness
Position 6 = maximum coldness
Turn the thermostat dial to the required position.
The intermediate position is usually the most
suitable (3-4).
The thermostat setting can vary as the temperature
inside the refrigeration compartment depends on the
following factors:
– room temperature
– how often the door is opened
– how much food is stored
– position of the appliance
Important
During prolonged periods of a normally hot weather,
if the thermostat is set on too high a num er, the
cooling system may operate continuously and the
fridge cooling plate may not defrost. Turning the kno
to a lower num er will cause the automatic
defrosting to resume.
Storage o rozen ood
When first starting-up or after a period of use, efore
putting the products in the freezer compartment let
the appliance run for at least two hours on the
coldest setting, then turn the thermostat kno to the
normal opertion position.
Do not exceed the storage period indicated y the
manufacturer.
Finally, do not open the door frequently or leave it
open longer than is a solutely necessary.
Important
Do not put car onated liquids, (fizzy drinks etc.), in
the freezer compartment.
Ice Iollies, if consumed immediately after removal
from the freezer, can cause low temperature skin
urns.
Do not remove items from the freezer if your hands
are damp/wet, as this could cause skin a rasions or
“frost/freezer urns”.
The reezer compartment
The four-star freezer compartment is suita le for
storage of commercially frozen food and for freezing
fresh foods.
Freezing resh ood
To freeze fresh foods it is necessary to change the
setting of the thermostat kno .
However, for a quicker freezing operation, turn the
thermostat kno to the coldest setting; ut remem er
that, in this condition the refrigerator compartment
temperature might drop elow 0° C.
If this occurs reset thermostat kno to a warmer
setting.
In any 24 hours you can freeze up to 3 kg. of fresh
food.
Place the food to e frozen on the shelf of the
freezer as this is the coldest part.
Important
In the event of a power cut do not open the door. The
food in the freezer will not e affected if the power
cut is short and if the freezer is full. Should the food
egin to thaw, it must e consumed quickly and must
not e re-frozen.
13
INSTALLATION
Positioning
This appliance should only e installed at a location
where the am ient temperature corresponds to the
climate classification indicated on the rating plate,
which is located at the left on the inside of the
appliance.
The following ta le shows which am ient temperature
is correct for each climate classification:
SN +10°C to + 32°C
N +16°C to + 32°C
ST +18°C to + 38°C
T +18°C to + 43°C
It should e located in a dry atmosphere, out of direct
sunlight and away from extreme temperature e.g. not
next to a oiler or radiator, or in a very cold room e.g.
an outhouse, where the temperatures may fall elow
10°C (50°F). If these temperatures are exceeded i.e.
colder or warmer, then the appliance may not operate
correctly.
You should also ensure that air can circulate freely
around the ack and the top of the ca inet. There
must also e at least 100 mm (4”) distance etween
the top of the ca inet and any overhanging kitchen
furniture (A). Ideally, the appliance should not e
positioned eneath overhanging furniture (B).
There should also e a gap of 25 mm either side of
the appliance. Do not o struct the space underneath.
The ack of the ca inet may e placed close to the
wall ut must not touch it. DO NOT install in places
with restricted ventilation.
Adjust the level of the appliance y screwing out the
adjusta le foot, or feet, at the ottom of the ca inet
using your fingers (see figure).
Shel holders
Your appliance is equipped with shelf retainers that
make it possi le to secure the shelves during
transportation.
To remove them proceed as follows:
Raise the shelf from the ack, push it in the direction
of the arrow until it is freed and remove the retainers.
D200
AB
NP005
100 mm10 mm
10 mm
Warning
IF YOU ARE DISCARDING AN OLD APPLIANCE
THAT HAS A LOCK OR CATCH ON THE DOOR,
YOU MUST ENSURE THAT IT IS MADE
UNUSABLE TO PREVENT YOUNG CHILDREN
BEING TRAPPED INSIDE.
Important
It must e possi le to disconnect the appliance from
the mains power supply; the plug must therefore e
easily accessi le after installation.
Depending upon the position which you choose for
your appliance, you may wish to reverse the way in
which the door opens. To do this, refer to instructions
on “Door reversal directions” paragraph.
A
B

5
Fresh ood re rigeration
To o tain the est performance, do not store warm
food or evaporating liquids in the refrigerator; do
cover or wrap the food, particularly if it has a strong
flavour.
Do not cover the shelves with any protective
material, such as paper, card oard or plastic, which
may o struct the air circulation through them.
To help you use your refrigerator correctly, here are
some more useful hints:
Raw meat (bee , pork, lamb & wild poultry): wrap
in polythene ags and place on top of the salad
drawer.
Meat can only be stored sa ely in this way or
one or two days at the most.
Fruit & vegetables: these should e thoroughly
cleaned and placed in the ottom salad drawers.
Butter & cheese: these should e placed in special
airtight containers or wrapped in aluminium foil or
polythene ags to exclude as much air as possi le.
Milk bottles: these should have a cap and should e
stored in the ottle rack on the door.
Making ice cubes
The appliance is provided with one or more trays for
ice-cu es trays.
Fill the tray(s) 3/4 full to give the ice space to expand
and place them in the freezer compartment.
To release the ice cu es simply give the tray a slight
twist.
Do not use sharp or metallic instruments to remove
the trays from the freezer.
De rosted cooked ood must never be
re rozen.
Movable shelves
The walls of the refrigerator have runners so that
shelves can e positioned as desired.
Positioning the door shelves
To permit storage of food packages of various sizes,
the door shelves can e adjusted in height.
To do this proceed as shown in the diagram:
Gradually pull the shelf in the direction of the arrows
until it comes free, then reposition as required.
D040
Freezing Calendar
10 - 1 210 - 1 210 - 1 210 - 123-63-63-63-63-41-2
The sym ols show different types of frozen goods.
The num ers indicate storage times in months for the appropriate types of frozen goods.Whether the upper or lower
value of the indicated storage time is valid depends on the quality of the foods and pre-treating efore freezing.
12
TECHNICAL SPECIFICATIONS
DIMENSIONS
Height 140 cm
Width 55 cm
Depth 60 cm
POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz
TOTAL POWER ABSORBED 150 W
AVERAGE DAILY UNITS ELECTRICITY * 1.068 kWh
GROSS CAPACITY
Fridge 190 l
Freezer 44 l
NET CAPACITY
Fridge 186 l
Freezer 44 l
* This figure is ased on standard test results in accordance with European Standard EN 153.
Actual consumption will depend on how the appliance is used and where it is located.

6
Normal Operating Sounds
• You may hear faint gurgling or u ling sounds
when the refrigerant is pumped through the coils
or tu ing at the rear, to the cooling
plate/evaporator.
• When the compressor is on, the refrigerant is
eing pumped round, and you will hear a whirring
sound or pulsating noise from the compressor.
• A thermostat controls the compressor, and you
will hear a faint ’click’ when the thermostat cuts in
and out.
Food Storage
To o tain the est performance from your fridge-
freezer
• Do not store warm food or evaporating liquids.
• Avoid uying frozen food if you cannot store it
straight away. The use of an insulated container is
advisa le. When you arrive home place the frozen
food in the freezer immediately.
• Keep the time etween uying chilled food and
placing it in your refrigerator as short as possi le.
• Do not push food together too much, try to allow
air to circulate around each item.
• Do not store food uncovered.
• Ensure that food placed in the freezer is dated
and la elled and used in date order to ensure
that food is consumed at its est.
• Remove suspect food from your refrigerator and
clean, refer to Maintenance and Cleaning.
• Lean food keeps etter and longer than fatty food,
salt reduces the storage time.
• Wrap the food in polythene or aluminium freezing
ags or foil so that they adhere to the food and
provide an airtight seal .
• Packaging which is swollen or has traces of
refrozen water droplets on the pack could indicate
that the product has not een kept at a suita le
temperature and that it may have lost its original
quality. Partially thawed food must not e
refrozen, it must e consumed within 24 hours.
Never exceed the storage times indicated y the
manufacturer.
Energy Saving Advice
• Do not install the appliance close to sources of
heat, such as a oiler or radiator.
• Locate the appliance in a cool well ventilated
room and make sure that the air openings of the
appliance are not o structed.
• Avoid unnecessary frosting in the ca inet y
packing all foodstuffs into airtight packages
efore placing them in the freezer.
• Always leave warm food to cool down to room
temperature efore placing in the fridge.
• Food which is to e frozen (when cool) should e
placed in the fridge efore eing transferred to
the freezer.
• Thaw frozen food in the fridge. This will ensure
safer defrosting of foods and reduce the work of
the refrigeration unit.
• Try to avoid keeping the door open for long
periods or opening the door too frequently as
warm air will enter the ca inet and cause the
compressor to switch on unnecessarily often.
• Ensure there are no o structions preventing the
door from closing properly.
In the Event o a Power Failure
If there is a power failure during the storage of frozen
foods, keep the door closed. If the temperature within
your freezer should rise, do not refreeze the food
without checking its condition. The following
guidelines should assist you:
Ice-cream: Once thawed should e discarded.
Fruits & Vegetables: If soft should e cooked and
used up.
Breads & Cakes: Can e refrozen without danger.
Shell ish: Should e refrigerated and used up
quickly.
Cooked Dishes: i. e. casseroles should e
refrigerated and used up.
Large Pieces o Meat: Can e refrozen providing
there are still ice crystals remaining within them.
Small Joints: Should e cooked and can then e
refrozen as cooked dishes.
Chicken: Should also e cooked and refrozen as a
fresh dish.
HINTS AND TIPS
11
Standard guarantee conditions
We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or
any part thereof is proved to e defective y reason only of faulty workmanship or materials, we will, at our
option repair or replace the same FREE OF CHARGE for la our, materials or carriage on condition that:
The appliance has een correctly installed and used only on the electricity supply stated on the rating plate.
The appliance has een used for normal domestic purposes only, and in accordance with the manufacturer’s
instructions.
The appliance has not een serviced, maintained, repaired, taken apart or tampered with y any person not
authorised y us.
All service work under this guarantee must e undertaken y a Tricity Bendix Service Force Centre. Any
appliance or defective part replaced shall ecome the Company’s property.
This guarantee is in addition to your statutory and other legal rights.
Home visits are made etween 8.30am and 5.30pm Monday to Friday. Visits may e availa le outside these
hours in which case a premium will e charged.
Exclusions
This guarantee does not cover:
Damage or calls resulting from transportation, improper use or neglect, the replacement of any light ul s or
remova le parts of glass or plastic.
Costs incurred for calls to put right an appliance which is improperly installed or calls to appliances outside the
European Community (EC) or European Free Trade Area.
Appliances found to e in use within a commercial environment, plus those which are su ject to rental
agreements.
Products of Tricity Bendix manufacture which are not marketed y Tricity Bendix.
European Guarantee
The standard one year guarantee is or the same period and the same extent or labour and parts as
exists in the new country o use or this brand or range o products.
Customer Care Centre:
Ireland Dublin 353-1-4090752
If you should move to another country within Europe then your guarantee moves with you to your new home
su ject to the following qualifications:
The guarantee starts from the date you first purchased your product.
The guarantee is for the same period and to the same extent for la our and parts as exists in the new country of
use for this rand or range of products.
This guarantee relates to you and cannot e transferred to another user.
Your new home is within the European Community (EC) or European Free Trade Area.
The product is installed and used in accordance with our instructions and is only used domestically, i.e. a
normal household.
The product is installed taking into account regulations in your new country.
Before you move please contact your nearest Customer Care centre, listed elow, to give them details of your
new home. They will then ensure that the local Service Organisation is aware of your move and a le to look
after you and your appliances.
France Senlis [phone]
Germany Nürn erg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Luton [phone]
GUARANTEE CONDITIONS

7
De rosting
Re rigerator
The refrigerator automatically defrosts every time the
compressor stops. The water is discharged, via the
pipe, into a tray located at the ack of the appliance
a ove the compressor, where it evaporates.
Important
To avoid defrost water overflowing into the fridge,
periodically clean the water discharge hole in the
centre of the V shaped drip collector at the ack of
the refrigerator compartment ehind the fruit and
vegeta le drawer. Use the defrost cleaner provided
which you will find already inserted into the
discharge hole.
D037
MAINTENANCE AND CLEANING
External cleaning
Many proprietary kitchen sur ace cleaners
contain chemicals that can attack/damage the
plastics used in this appliance. For this reason it
is recommended that the outer casing o this
appliance is only cleaned with warm water with a
little washing-up liquid added.
An accumulation of dust will affect the performance
of the appliance and cause excessive electricity
consumption.
You MUST ensure that the appliance is switched
OFF.
Once or twice a year dust the condenser ( lack grill)
and the compressor at the ack of the appliance,
with a rush or vacuum cleaner, see figure.
PR259
Before any maintenance or cleaning work is carried
out, DISCONNECT the appliance from the
ELECTRICITY supply.
Internal cleaning
Clean the inside and accessories with warm water
and icar onate of soda (5ml to 0.5 litre of water).
Rinse and dry thoroughly.
NEVER USE DETERGENTS, ABRASIVE
POWDERS, HIGHLY PERFUMED
CLEANING PRODUCTS OR WAX
POLISHES, TO CLEAN THE INTERIOR AS
THESE WILL DAMAGE THE SURFACE AND
LEAVE A STRONG SMELL.
When the appliance is not in use
When the appliance is not in use for long periods,
disconnect from the electricity supply, empty all
foods and clean the appliance, leaving the doors ajar
to prevent unpleasant smells.
Changing the light bulb
Should the interior light fail to work, first switch off
the appliance and disconnect from the electricity
supply, then replace the ul as follows;
Unscrew the light cover and then pull it outward y
pressing as shown in the figure. Unscrew the ul
and replace it with one of the same power (the
maximum power is shown on the light diffuser)
availa le from your nearest Service Force Centre.
Replace the light cover y sliding it into its original
position and replacing the screw.
D411
10
CUSTOMER CARE DEPARTMENT
In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local
Tricity Bendix Service Force Centre y telephoning:-
0870 5 929929
Your telephone call will e automatically routed to the Service Force Centre covering your post code area.
For the address of your local Service Force Centre and further information a out Service Force, please visit the
we site at www.serviceforce.co.uk
Before calling out an engineer, please ensure you have read the details under the heading ‘Something Not
Working?
When you contact the Service Force Centre you will need to give the following details:
1. Your name, address and post code
2. Your telephone num er
3. Clear and concise details of the fault
4. The model and serial num er of the appliance (found on the rating plate)
5. The purchase date
For service in the Republic o Ireland contact
Tricity Bendix
Long Mile Road
Du lin 12
Telephone : [phone]
Please note that a valid purchase receipt or guarantee documentation is required or in-guarantee
service calls.
For general enquiries concerning your Tricity Bendix appliance or for further information on Tricity Bendix
products, please contact our Customer Care Department y letter or telephone as follows:-
Customer Care Department
Tricity Bendix Major Appliances
Addington Way
Luton
Bedfordshire
LU4 9QQ
08705 950 950 *
* calls to this num er may e recorded for training purposes.
SERVICE AND SPARE PARTS

8
Remem er to wash the defrost cleaner in hot soapy
water at regular intervals. Dry throughly efore
replacing.
Freezer
When the frost has reached a thickness of up to
4mm it can e removed using a plastic scraper.
During this operation it is not necessary to
disconnect the appliance from the mains and remove
the food. Never use metal tools for this operation.
For complete defrosting (once or twice a year)
proceed as follows:
- turn the thermostat dial to the «OFF» position (O)
or disconnect the appliance from the mains.
- Remove any food from inside the freezer and
fridge, wrap it in several sheets of newspaper and
store in a cool,dry place.
- Leave the door open.
- Clean and dry thoroughly.
- Reconnect the appliance to the mains or reset
the thermostat to a functioning position.
- After letting the appliance run for a least half an
hour, replace the previously removed food into
the compartment.
Important
When defrosting the freezer, the fridge is also
controlled y the thermostat and will not e
operational during this period. A temperature rise of
the frozen food packs, during defrosting, may
shorten their safe storage life.
9
SOMETHING NOT WORKING
Symptom
No power to the appliance
The light does not come on
The temperature in the fridge or freezer section is
too high
The freezer door will not open
The compressor runs continously
Excessive frost and ice has uilt up
Noise
Water under the salad in
Solution
Check there is power at the socket.
Check there is not a power cut y checking the
household lights.
Check the fuse has not lown.
Ensure that the ul is correctly fitted.
Replace the ul if it has lown.
Check the door light switch is not jammed.
Check the thermostat control kno in the fridge is
turned to the correct setting relative to am ient
conditions.
Check the am ient temperature is within the
appliance’s operating limits, please refer to the
installation section in this instruction ook.
Relocate the appliance if necessary.
Has door just een opened? If so leave for a few
minutes to allow the air pressure to equalise.
Adjust the thermostat control kno to give correct
temperature control. See “Setting the temperature”.
Check that the doors are closed.
Large quantities of food have recently een placed in
the ca inet and/or door is frequently opened.
Check that air ventilation is not o structed.
Ensure the doors are not left open.
Check that nothing is preventing the doors from
closing.
Is the door gasket intact and clean.
Has advised periodic defrosting een carried out.
Refer to normal operating sounds.
Check the drain hole is not locked. (see
Maintenance and Cleaning).
Important: If the appliance is not working correctly, please carry out the following checks efore calling out an
engineer.
