Trifecte EM200 User manual

NOTE: This has been designed to operate on 110-120 Volt, 50/60 Hz exclusively. Using any other
voltage or Hz will adversely affect performance.
IMPORTANT: Read all instructions thoroughly. Keep this guide for future reference.
WARNING: Be sure to review safety instructions pertaining to a risk of fire, electrical shock
or injury to persons before using disposal.
PLEASE READ THIS MANUAL CAREFULLY BEFORE USE
THE COMPANY RESERVES THE RIGHT TO INTERPRET THE MANUAL
THE ACTUAL PRODUCT APPEARANCE SHALL PREVAIL.
PLEASE KEEP IT TOGETHER WITH THE INVOICE AFTER READING.
THE PRODUCT TECHNOLOGY OR SOFTWARE MAY BE UNGRADED WITHOUT PRIOR NOTICE
MODEL NO.:EM200
CGMD-65
QSD-38
MCD17-T7
USER MANUAL
FOOD WASTE DISPOSER

Please read the manual before use, children shall
operate this product under the guidance of adults,
do not allow children to play with this product.
Do not disassemble, modify or repair the waste
processor
When using, please open the tap first, and then the
disposer; after food waste is grinded, rinse it with
water continuously, so that food waste and
corrosive detergents will not remain in the disposer.
The continuous load operation shall not exceed 10
minutes, and the interval between each use shall be
greater than 30 minutes.
This product is designed to dispose of normal
household food waste;inserting materials other
than food waste into disposer could cause personal
injury and/or property damage.
To reduce the risk of injury and/or property damage,
do not use the sink containing the disposer for
purposes other than food preparation (such as baby
bathing or washing hair).
Turn off the machine and tap only after the food
waste has been grinded and the machine and
running water have been heard.
When not operating a disposer, leave the stopper in
place to reduce the risk of objects falling into the
disposer.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified-persons in order to avoid a hazard.
Do not store or use gasoline or other flammable
vapors and liquids in vicinity of disposer.
Please do not put your hands in the disposer.
LEAK HAZARD: Regularly inspect disposer and
plumbing fittings for leaks, which can cause proper
ty damage and could result in personal injury.
It can handle:Leftovers, vegetables, egg shells,
livestock small bones,tea leaves Fruit skins,small
fruit pits,cooked meat, small corncobs,cereal and
other food waste.
Do not put the following into a disposer: High-
fiber foods,hair, hemp rope, big pork bones,clam or
oyster shells, caustic drain cleaners or similar
products, glass, china, or plastic, metal (such as
bottle caps, steel shot, tin cans, or utensils), hot
grease or other hot liquids.
Note: to prevent water accumulation in the disposer, the water pipe inserted into the wall/
floor drain must be lower than the disposer outlet.
WARNING:WHEN USING ELECTRIC
APPLIANCES, BASIC PRECAUTIONS ARE
ALWAYS TO BE FOLLOWED, INCLUDING
1.INSTALLATION INSTRUCTIONS
1.Sink Plug
2.Stainless Steel Flange
3.Flange Waterproof Rubber
4.Foam Gasket
5.Sink Flange
7.Screws (3)
8.Splash Guard
9.Mounting Ring
10.Dishwasher Inlet
12.Reset Button
6.Backup Ring
11.Dishwasher Valve
(With Rubber Gasket)
13.Water Outlet Gasket
14.Drain Pipe
15.Hex Wrench
16.Dishwasher Connecting
17.Drain Pipe Connecting
(With Rubber Gasket)
1.Dimensions
Model
EM200
CGMD-65
QSD-38
MCD17-T7
12.913in.
13.385in.
12.795in.
13.779in.
3.47in.
3.47in.
3.47in.
3.47in.
3.248in.
3.248in.
3.248in.
3.248in.
4.921in.
5.551in.
4.921in.
5.905in.
7.677in.
7.677in.
7.677in.
7.677in..
Size
① ② ③ ④ ⑤
-1-
MOUNTING ASSEMBLY

1.Tape measure
2.Wire cutters
3.flashlight
4.wire strippers
5.flathead screwdriver
6.Phillips screwdriver
7.Adjustable pliers
PERSONAL INJURY
Wearing safety glasses is recommended
during the installation of the food waste disposer.
1. Loosen nut (1) at top of trap (4) with pipe wrench .
2. Loosen nut (2) at top of extension pipe. Remove extension pipe..
3. Loosen nut (3) at base of sink flange4.
4. Push sink flange up through sink hole and remove it
5. Clean sink flange area of any putty or other debris.
Remove flange mounting assembly from machine,turn mounting
assembly over,Use Hex wrench to loosen three mounting screws ,
Mounting assembly will now come apart.
Note: the diameter of the disposer flange (GB) is 4.331in.
① Ensure there is no debris around the sink drain hole, mount the upper
seal ring on the flange, and put the flange into the sink drain hole. You
may need to place a heavy object in the sink or hold it down by hand to
keep the flange in place (place a towel under the object to prevent
scratching).
② Under the sink, mount the lower seal ring and upper buckle (flat side
up) on the flange in order.
③ Put the upper buckle of the lower seal ring in place, and mount the
middle buckle on the flange to hold the upper buckle.
④ When the upper and middle buckle of lower seal ting hold the sink
bottom tightly, tighten the three hex socket screws at the same time
until the mounting component is firmly installed on the sink, improper
operation will cause water leakage
Note: the flange is designed with convex points. When the flange is
connected with the middle buckle, the convex points shall be stuck in the
middle of the middle buckle to prevent the equipment from falling due to
vibration.
2.HELPFUL TOOLS
3.DISCONNECT SINK DRAIN
CAUTION
4.SEPARATE COMPONENTS BEFORE CONNECTION OF
DISPOSER AND SINK
5.CONNECT FLANGE MOUNTING ASSEMBLY TO SINK
For safety and ease of garbage disposal installation, we recommends
the use of these helpful tools
-2-
1 2 3 4
5 6 7

Failure to clean sink waste pipe line
may result in waste pipe blockage.
1. Remove trap.
2. With drain auger, clear away all
hardened waste material in
horizontal drain line running from
drain trap to main pipe.
PERSONAL INJURY
To avoid personal injury, do not position your head or body under
disposer; the unit could fall during installation.
Clear any objects from inside the disposer grind chamber before
mounting the disposer to the sink.
1. Position disposer with three mounting tabs(1) aligned in position to
slideover mounting tracks (2).
2.Lift disposer, insert top end (mounting gasket) into mounting assembly,
and turn lower mounting ring to right (with wrenchette or adjustable
pliers)until mounting tabs lock over ridges (3) on mounting ring
tracks.Make sure all three mounting tabs are locked over ridges.
Disposer will now hang by itself.
3. Run water into sink, then check for leaks.
4. When installing this product, please make sure the reset switch can be
easily touched, and there is no object block which may affect the later
operation
8.DISHWASHER CONNECTION
NOTE: If the dishwasher connection is made without removing the plug.
the dishwasher may overflow. (Connections must comply with local plum
bing codes.)
① Remove the connecting plug(A) of dish washer, and replace the
dishwasher connecting(B).
② Connect the dish washer drain pipe to the dishwasher connecting
If you have a sink overflow, it should be connected to the overflow
inlet on the tailpipe .
Install the drain pipe connecting(A) on
to the disposer,put the rubber
gasket(B) into the drain pipe(C). After
that, install the discharge tube on to
the drain pipe connecting(A).
If you are not thoroughly familiar with electric power,contact a qualified
electrician to connect disposer to electrical circuit.
If three-prong, earth (grounded)plug is used,plug must be inserted into
three-hole, earth (grounded) receptacle.
Do not modify plug provided with unit (if applicable).
Improper connection of equipment earth (grounded) conductor can
result in electric shock.
All wiring must comply with local electrical codes.
Do not attach earth wire (ground wire) to gas supply pipe.
Do not reconnect electrical current at main service panel until proper
earth (grounded) outlets are installed.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified-persons in order to
avoid a hazard.
9.ATTACH DISCHARGE TUBE TO WASTE DRAIN PIPE
6.CLEAN SINK WASTE PIPE
7.CONNECT DISPOSER TO MOUNTING ASSEMBLY
CAUTION
ELECTRICAL SHOCK
To avoid electrical shock, disconnect power before installing or servicing
disposer.
DANGER
10.CONNECT DISPOSER TO ELECTRICAL SUPPLY
-3-
AB

First cover the sink plug, open the tap and fill half of the sink, then
remove the plug, wipe the body, flange assembly, pipe connections with
paper towels, if there is leakage, please timely adjust and reinstall.
NOTE:You must have access to an earth (grounded) wall socket.Any
additional socket should be fitted by a qualified electrician and properly
earthed(grounded).The disposer is fitted with a molded plug and cable.
1. Remove stopper from sink opening and run cold water.
2. Turn on wall switch to start disposer.
3. Slowly insert food waste into disposer. WARNING! Position stopper to
minimize possible ejection of material while grinding.
4. After grinding is complete, turn disposer off and run water for a few
seconds to flush drain line.
In the daily use of waste disposer, the following problems may occur. You can quickly solve them with the corresponding methods. Enjoy the
cleanliness and convenience brought by waste disposer:
Problem
Loud noises
Slow sewage discharge
Disposer water leakage
Possible Causes
Silverware, bottle cap or other
foreign object has fallen into the
Part pf the drain pipe is blocked
What To Do
Disconnect the power and water flow switch of the disposer first, and wait for
the disposer to stop working， check for an object lodged between the
turntable and the grind ring. Dislodge the object by moving the turntable with
a broom handle. Then remove the object.
A solution is to use a plumber or a special elastic rod tape to be cleared.
Check whether the rubber seal ring is installed in place and tighten the three
fastening screws on the buckle at the same time or replace the rubber seal
ring.
The sink and disposer flange are not connected in place;
the middle buckle screw is not tightened;rubber seal ring
is not installed in place
If the water leaks from the disposer outlet, the screws may
be loose or the water pipe may be broken
Check whether the outlet is normal, tighten the screws or replace the drain
pipe.
Foreign bodies fall in, block the machine and overheating
protection is enabled
Remove the power plug, check whether the plug and power cable are in
good condition, if any damage, please replace in time
If the motor still does not work, please contact the maintenance department
designated by the manufacturer.
11.CHECKING OPERATING INSTRUCTIONS
TROUBLE SHOOTING TIPS
Motor stops when the
disposer is working
The motor does not work The plug contact is poor
Remove the disposer plug
Check the grinding chamber, take out the foreign bodies with long clip or
tweezers
Insert the provided internal hex wrench into the base plate axis hole, rotate
clockwise and anti-clockwise 360°
Turn on the reset switch, connect the power, and the disposer can work
normally.
-4-

The Warranty card is to be completed, signed by the dealer immediately
on purchase.
The Customer shall carry the Waste disposer to the nearest Company
Regional Service Centre or Authorized Service Centre or purchased
Dealer point as his/her own cost and risk.
The company shall make all endeavors/ attempts to carry out the
service/replacement under this warranty at the earliest, but shall not be
obliged to do so within any specified time.
The warranty will continue and remain in force only for the unexpired
period of the original warranty, in regards to the Repair/Replacement of
parts of the Waste Disposer.
The Waste Disposer shall be used strictly for domestic purpose in
accordance with the user's manual.
The Company shall not be held liable for any accident,loss or
damage(director indirect)
To person or property caused by reason of:
Overloading/Misuse/abuse and negligence on the part of the person
using the Waste Disposer. Defects causes by improper/reckless fittings
and usages. Use of chemicals, spurious spares or old, non-genuine
FROM THE DATE OF ORIGINAL PURCHASE, SUBJECT TO THE FOLLOWING
TERMS AND CONDITIONS.
SCHEMATIC CIRCUIT DIAGRAM
NAME OF DEALER
BILL NO: & DATE
PRODUCT & MODEL NAME
CUSTOMER'S NAME
ADDRESS & TEL NOS
DEALER'S ADDRESS & STAMP
INSTALLED BY NAME
INSTALLED DATE & REG .NO
WARRANTY CARD
spares .
Failure to company with any safety precaution or maintenance tip
suggested by the company Original serial number is deleted/defected or
altered.
In case the warranty is void due to any of the reasons listed above, the
customer shall be liable to pay the cost of all the spares and service
charges.
The warranty does not cover damages due to negligence
mishandling,breakage of glass/Abs body,dents of body and
breakage/fuse of lighting parts.
The company shall not be responsible for any special consequential
damages or loss arising directly or indirectly for any delay in the
performance of this warranty.
The company reserves the right to retain any part or component at the
regional service centre/branches or authorized service centre or at its
workshop and shall effect repairs/ replacement of parts or components
at its sole discretion.
This warranty shall not in any case extent towards payment or any
monetary consideration whatsoever, and shall be limited to the product
replacement only.
Electrical appliances are prone to voltage fluctuation risks,therefore
precaution should be taken before every use. Company shall not be
responsible for any damage to electrical parts viz.coil, motor etc.arising
out of this problem.
The decision of the company is final in all cases of complaints.
The company will not be responsible for delay in service of the appliance
or complaint resolution if it is due to reasons beyond its control.
These products are not for use by children. The company is not liable for
any damages or physical injury arising out of improper use, modification
or alteration of the product or due to unauthorized spares use and poor
maintenance of this product.
What we will charged or not covered during warranty period:
Incidental or consequential damage caused by possible defects with this
appliance.
Failure of the product if it is abused. misused. or used for other than the
intended purpose or used commercially.
Product not accessible to provide required service.
If the leak is at the top, it may be caused by:
1. Improper seating of sink flange (gasket choice, putty or tightening).
2. Support ring not tightened properly.
3. Defective cushion mount.
If the leak is at the discharge elbow,leak may be caused by improper
tightening of elbow flange screws.
DISPOSER LEAKS
WARRANTY TERMS
This warranty is for a period of 3 years against manufacturing defects
from the date of original purchase, Subject to the following terms and
conditions
-5-
