Triple E 2002 Class C User manual

CLASS C
MOTORHOME
OWNERS MANUAL
    
    
  

Production improvement is a continuing process at Triple E
Recreational Vehicles. Thus, we reserve the right to
change specifications, operating instructions, standards
and options on any and all products without prior notice.
Errors and omissions excepted. The diagrams included
were current at the time of printing.
NOTE
PRINTED IN CANADA
ISSUE DATE: JANUARY, 2002
Triple E
Recreational Vehicles
301 Roblin Blvd., Box 1230
Winkler, Manitoba
Canada R6W 4C4
Tel: [phone]
Fax: [phone]
PART NUMBER:
146-4588-JAN02

FORWORD
A WORD TO MOTORHOME OWNERS
Welcome to the growing number of discerning
people who own and operate a Triple E
Motorhome.
Our company takes great pride in the quality and
excellence that the Triple E name represents. We
have sought to anticipate your needs and desires
with respect to safety, convenience, styling, and
engineering.
We appreciate having you as our customer and
have provided this manual and various component
manuals to introduce you to the many features of
your new motorhome. Each person using the
motorhome should take time to read this manual
before operation. It will help you to better under-
stand the many built-in operational features of this
recreation vehicle. Talk to your dealer if you have
any questions about your unit.
We hope you will enjoy your new motorhome, and
we wish you pleasant and carefree driving.
Failure to read the manual completely and
thoroughly may lessen your total enjoyable
experience.
WARNING
IMPORTANT
Modifications that are not approved by Triple E
may void the warranty and transfer responsibil-
ity for the changes to the owner.
This manual is intended to be a guideline. This
manual despite our best efforts should not be
considered comprehensive in all details. We invite
you to use this manual to help you learn the basics
about your vehicle. The component operation will
be in the manual for the fridge, stove, etc..
This vehicle is equipped with the latest systems,
appliances and operational equipment making it
considerably more complicated than a normal
automobile.
The use of three way systems; 120V, 12V and
propane needs careful consideration as the avail-
ability of energy in both the 12V and propane
systems has a limited capacity and volume. Due
caution should be applied and in case of doubt,
clarification from the authorized Triple E dealer or
our factory service department should be obtained.
Do not modify the unit in any way. Unauthor-
ized modification may impair the function or
life of the vehicle and could lead to an accident.
INFORMATION AND SAFETY
Throughout the manual, certain instructions,
procedures and information is emphasized with
the words IMPORTANT, CAUTION and
WARNING. These key words denote the level of
care that each operator should exercise on
mechanical and safety items.

PRINTED IN CANADA PART NUMBER: 146-4588-AUG00
Triple E
Recreational Vehicles
301 Roblin Blvd., Box 1230
Winkler, Manitoba
Canada R6W 4C4
Tel: [phone]
Fax: [phone]

TABLE OF CONTENTS
SECTION DESCRIPTION PAGE SECTION DESCRIPTION
PAGE
1 Introduction .............................................. 1-1
1.1 Operator's Manuals ....................... 1-1
1.2 Information Kit ............................... 1-1
1.3 Options and Equipment ................ 1-1
1.4 Keys .............................................. 1-1
1.5 Vehicle Certification Label ............ 1-2
1.6 Identification Information ............... 1-4
1.7 Exterior Feature Identification ....... 1-5
1.8 Service Assistance ........................ 1-6
1.9 Reporting Safety Defects .............. 1-6
1.10 Driving Comfort ............................. 1-6
2 Safety ........................................................ 2-1
2.1 General Safety .............................. 2-1
2.2 Driving Safety ................................ 2-2
2.3 Fuel (Motor and LP Gas) .............. 2-2
2.4 Asphyxiation.................................. 2-3
2.5 Formaldehyde ............................... 2-3
2.6 LP Gas Leaks ............................... 2-3
2.7 Alarms ........................................... 2-4
2.8 Electrical ....................................... 2-4
2.9 Loose Components ....................... 2-5
2.10 Maintenance ................................. 2-5
2.11 Emergency Exits ........................... 2-5
3 Preparation ............................................... 3-1
3.1 Vehicle Preparation ....................... 3-1
3.1.1 Keys .............................................. 3-1
3.1.2 Vehicle Loading ............................ 3-1
3.1.3 Trailer Towing ............................... 3-2
3.1.4 Auxiliary Vehicle Towing ............... 3-2
3.1.5 Parking, Levelling and Blocking .... 3-3
4 Controls .................................................... 4-1
4.1 Chassis Controls ........................... 4-1
4.2 Dash Controls ............................... 4-1
4.3 Cab Door ...................................... 4-4
4.4 Driver's/Co-Pilot Seat
(Optional Power Seats) ................. 4-4
4.5 Cocktail Seats ............................... 4-5
4.6 Seat/Shoulder Belts ...................... 4-6
4.7 Side Entry ..................................... 4-8
4.8 Refrigerator ................................... 4-9
4.9 Light Switches ............................. 4-10
4.10 Comfort Control Center ............... 4-11
4.10.1 Heating ....................................... 4-11
4.10.2 Air Conditioner ............................ 4-12
4.11 Power Roof Vent (Optional) ........ 4-13
4.12 Water System ............................. 4-14
4.12.1 Water Heater ............................... 4-14
4.12.2 Water Heater Bypass .................. 4-15
4.12.3 Water Pump ................................ 4-16
4.13.4 Water System Access ................. 4-17
4.13 System Monitor ........................... 4-20
4.14 Converter .................................... 4-21
5 Driving ...................................................... 5-1
5.1 Pre-Trip Inspection ........................ 5-1
5.2 Emergency Equipment Check List 5-2
5.3 Entering Vehicle ............................ 5-2
5.4 Engine Operation .......................... 5-2
5.5 Driving Characteristics .................. 5-3
5.6 Driving Safety Tip .......................... 5-3
5.7 Travel Tips .................................... 5-4
5.8 Quick Loading Check List ............. 5-5
5.9 Severe Weather Information ......... 5-6
6 Safety Equipment Operation ................... 6-1
6.1 Fire Prevention .............................. 6-1
6.1.1 Fire Safety Tips ............................. 6-1
6.1.2 Fire Extinguisher ........................... 6-2
6.2 Emergency Escape ....................... 6-3
6.3 Alarms ........................................... 6-4
6.3.1 LP Gas Alarm ................................ 6-4
6.3.2 Carbon Monoxide Alarm ............... 6-5
6.3.3 Smoke Alarm ................................ 6-6
7 Travelling .................................................. 7-1
7.1 Preparation ................................... 7-1
7.2 Baggage Loading .......................... 7-1
7.2.1 Roof Loading................................. 7-1
7.2.2 Baggage Compartments ............... 7-1
7.3 Vehicle Weight-Loaded ................. 7-2
7.4 Front Axle Tire Alignment.............. 7-2

TABLE OF CONTENTS
SECTION DESCRIPTION PAGE SECTION DESCRIPTION
PAGE
7.5 Maximum Occupancy ................... 7-2
7.6 Seat Belts ...................................... 7-3
7.6.1 Lap Belts ....................................... 7-3
7.6.2 Shoulder/Lap Belts ........................ 7-3
7.6.3 Care and Cleaning ........................ 7-4
7.6.4 Child Restraints ............................. 7-4
7.7 Mirrors ........................................... 7-4
7.8 Refuelling ...................................... 7-5
8 Emergencies While Driving ..................... 8-1
8.1 Hazard Warning Lights ................. 8-1
8.2 Flat Tire ......................................... 8-1
8.3 Towing .......................................... 8-2
8.4 Overheating .................................. 8-2
9 Home Use ................................................. 9-1
9.1 Parking .......................................... 9-1
9.2 Motorhome Levelling System ........ 9-2
9.3 Prolonged Occupancy................... 9-3
10 Electrical Systems ................................. 10-1
10.1 120-Volt AC System .................... 10-1
10.1.1 External Power Cord (Shoreline) 10-1
10.1.2 Power Control Center (Converter)10-2
10.1.3 120-Volt Circuit Breakers ............ 10-3
10.1.4 Ground Fault Circuit Interrupter
(GFCI) ......................................... 10-3
10.2 Auxiliary 120-Volt Generator ....... 10-4
10.2.1 Generator Safety ......................... 10-4
10.2.2 Generator Refueling .................... 10-5
10.2.3 Generator Operation ................... 10-6
10.3 12-Volt DC System ..................... 10-7
10.3.1 Automotive Battery ...................... 10-7
10.3.2 Auxiliary Battery .......................... 10-7
10.3.3 12-Volt Coach Fuses .................. 10-8
10.3.4 Battery Maintenance ................... 10-8
10.3.5 Battery Condition Meter ............ 10-10
10.4 Trailer Wiring Connector ........... 10-10
10.5 Electrical Schematics ................ 10-11
10.6 Fuse Panel ................................ 10-12
10.6.1 Vehicle ...................................... 10-13
11 Liquid Propane Gas System ................. 11-1
11.1 How LP Gas Works ..................... 11-1
11.2 Safe Use of LP Gas .................... 11-1
11.3 Selecting Fuel Types .................. 11-2
11.4 LP Tank System .......................... 11-2
11.5 LP Tank Capacity ........................ 11-2
11.6 Refilling LP Tank ......................... 11-3
11.7 Air in the LP Tank ....................... 11-4
11.8 Travelling LP Gas ....................... 11-4
11.9 Regulator .................................... 11-4
11.10 LP Gas Leaks ............................. 11-5
11.11 LP Gas Detector ......................... 11-5
12 Water/Plumbing System ........................ 12-1
12.1 Fresh Water System ................... 12-1
12.1.1 Fresh Water Tank Filling
Procedure ................................... 12-2
12.1.2 Water Pump ................................ 12-3
12.1.3 Water Pump Switch .................... 12-3
12.1.4 Water Pump Filter ....................... 12-4
12.1.5 Water System Drains .................. 12-4
12.1.6 Water Pump Initial Start-Up ........ 12-4
12.1.7 Water Pump Troubleshooting ..... 12-5
12.1.8 Disinfection of Water Tank .......... 12-5
12.1.9 External Water Supply ................ 12-6
12.2 Waste System ............................. 12-7
12.2.1 Grey Water - Waste Holding Tank12-7
12.2.2 Black Water - Waste Holding
Tank ............................................ 12-7
12.2.3 Dumping Holding Tanks .............. 12-8
12.2.4 Do's And Don'ts Holding Tanks 12-10
12.2.5 Using On-Site Sewer Hook-Ups 12-10
12.2.6 Holding Tank Level Indicators ... 12-11
12.2.7 Tank Capacities ........................ 12-11
12.3 Plumbing System Operation ..... 12-11
12.3.1 Water Heater ............................. 12-11
12.3.2 Toilet ......................................... 12-12
12.3.3 Shower ...................................... 12-12
12.4 Plumbing Specifications ............ 12-13
12.4.1 Tank Capacities ........................ 12-13
12.4.2 Plumbing Schematics ............... 12-13

13 Appliances And Interior Features ........ 13-1
13.1 Refrigerator ................................. 13-1
13.1.1 Operating Instructions ................. 13-1
13.1.2 Operating Tips ............................ 13-1
13.1.3 Exterior Refrigerator
Compartment .............................. 13-2
13.2 Range And Oven ........................ 13-2
13.2.1 Lighting Burners .......................... 13-2
13.2.2 Safety Tips .................................. 13-3
13.2.3 Range Hood ................................ 13-3
13.2.4 Lighting Oven Pilot ...................... 13-3
13.2.5 Operating Oven Control .............. 13-4
13.2.6 Shut Down Instructions ............... 13-4
13.3 Optional Microwave Oven ........... 13-4
13.4 Monitor Panel .............................. 13-5
13.5 Water Heater Bypass Valve ........ 13-5
13.6 LP Gas Furnace .......................... 13-6
13.7 Roof Air Conditioners .................. 13-7
13.8 Cable TV Hook-Ups .................... 13-8
13.9
DC-AC Electrical Voltage Inverter ... 13-8
13.10 Sleeping Facilities ....................... 13-8
13.11 Seats ........................................... 13-9
13.12 Seat/Shoulder Belts .................. 13-10
13.13 Fresh Water Toilet .................... 13-10
13.14 Optional Electric Step
(XL Only) ................................... 13-11
13.15 Screen Windows ....................... 13-12
13.16 Standard Quartz Clock.............. 13-12
13.17 Power Roof Vent (Optional) ...... 13-12
13.18 Suspension Air System
(Optional) .................................. 13-13
14 Care And Maintenance .......................... 14-1
14.1 Exterior ........................................ 14-1
14.2 Interior ......................................... 14-2
15 Motorhome Maintenance ....................... 15-1
15.1 Chassis Customer Service .......... 15-1
15.2 Engine Access ............................ 15-1
15.2.1 Engine Hood ............................... 15-1
15.3 Engine Cooling System ............... 15-2
15.4 AC And Oil Coolers ..................... 15-2
15.5 Tires ............................................ 15-2
16 Storing Your RV ..................................... 16-1
17 Winterization .......................................... 17-1
17.1 Cold Temperature Operation ...... 17-1
17.1.1 Chassis ....................................... 17-1
17.1.2 LP Gas ........................................ 17-1
17.1.3 Furnace ....................................... 17-1
17.1.4 Waste System ............................. 17-1
17.1.5 Fresh Water System ................... 17-1
17.2 Cold Temperature Storage ......... 17-2
17.2.1 Water System Winterization ........ 17-2
17.2.2 De-Winterize Water Systems ...... 17-2
18 Warranty Policy .....................................18-1
19 Index .................................................... 19-1
TABLE OF CONTENTS
SECTION DESCRIPTION PAGE SECTION DESCRIPTION
PAGE

1-1
CLASS C MOTORHOME
1 INTRODUCTION
Congratulations on your choice of a Triple E built Motorhome for your travelling and touring comfort and
enjoyment. It utilizes the latest design features and manufacturing techniques to insure safe, efficient
and trouble-free operation at all times.
1.1 OPERATOR'S MANUALS
All owners/operators should read, understand and
follow all instructions in this the motorhome manual,
chassis manual and manuals for all auxiliary systems
and appliances. A few minutes spent reading the
appropriate manual will pay rich dividends in
providing safe, efficient and trouble-free operation.
Refer to the chassis manufacturer's operator's
Manual for detailed information on the chassis. Refer
to the appropriate manual supplied for auxiliary
equipment and appliances as required.
This manual covers all the systems, controls and
operation unique to this vehicle. Always keep the
information kit of manuals and information with the
vehicle for easy reference. Pass the kit on to new
operators or owners as appropriate for their
information as well. Use the Table of Contents or
Index to find specific information.
If more information is required or you do not
understand something, please contact:
Your Triple E dealer or
Triple E Recreational Vehicles
301 Roblin Blvd., Box 1230
Winkler, Manitoba Canada
R6W 4C4
Tel: [phone]
Fax: [phone]
Chassis: Ford US 1-800-392-3673
Ford CAN 1-800-565-3673
1.2 INFORMATION KIT
An information kit is provided with each vehicle and
includes specific information on specific systems,
features and appliances including:
1. Chassis
2. Air Conditioning
3. Generator (If equipped)
4. Furnace
5. General Operation
6. Entertainment System
7. Water Heater
8. Safety
9. Flooring and Counter Tops
10. Fridge
11. Plumbing Fixtures
12. Roof and Side Walls
13. Appliances
14. Converter
1.3 OPTIONS AND EQUIPMENT
Your motorhome is available in various sizes, models
and floor plans. The equipment, accessories and
components described in this manual may not
necessarily apply to your vehicle. Refer to the
material provided in the information kit for the
detailed instructions unique to your unit.
1.4 KEYS
It is a good idea to keep a record of all key code
numbers and keep them in a safe place - not in your
vehicle. Use the charts at the front of this manual but
make a duplicate copy to be stored elsewhere.

1-2
CLASS C MOTORHOME
1.5 VEHICLE CERTIFICATION LABEL
This label contains vehicle identification and other important reference information. The vehicle certifica-
tion label is located on the driver's door frame. Never remove or destroy this label.
Reference Number Code:
1. Chassis manufacturer.
2. Chassis manufacture date.
3. Month and year of manufacture at Triple E
Recreational Vehicles.
4. Gross Vehicle Weight Rating:
Total permissible weight of the vehicle, including
driver, passengers, total cargo carried (including
all liquids) and equipped with all options.
5. Gross Axle Weight Rating:
Total permissible weight allowed for the front,
and rear axles (listed in pounds and kilograms).
6. Suitable Tire Choice:
Tires recommended to meet handling, loading
and safety requirements. When replacing any of
the tires, the new tires must meet these specifi-
cations.
7. Suitable Rim Choice:
Wheel rims recommended to meet handling and
safety requirements. When replacing any of the
rims on the vehicle ensure that the new rims meet
these specifications.
8. Cold Inflation Pressure:
Inflation pressures recommended (while cold)
for the tires originally equipped on your vehicle.
These pressure levels must be maintained to
assure proper handling, safety and fuel
economy.
9. Rear Axle Wheel Configuration:
Single axle/Dual wheels.
10. Serial Number:
This is the serial number assigned to the
completed vehicle by Triple E Recreational
Vehicles.
11. Vehicle Identification Number (VIN):
This number identifies the chassis on which the
motorhome is built.
12. Type:
States the NHTSA designated usage classifica-
tion for your motorhome. MPV signifies a Multi-
purpose Passenger Vehicle.
13. Model:
Lists the Triple E product model number of your
vehicle.
14. Color:
Signifies the color code number of the decor
used throughout the vehicle. This number is
necessary for ordering replacement cushions,
curtains, carpet, etc. It also is found in the
wardrobe.
NOTE
The specifications sheet is located in
the wardrobe. Beneath the specifica-
tion sheet are the exterior color codes.
All Triple E motorhomes are built
according to CSA and RVIA stand-
ards.
Fig. 1-1 REFERENCE NUMBER CODE

1-3
CLASS C MOTORHOME
Fig. 1-2 VEHICLE LABELS
Fig. 1-3 IDENTIFICATION INFORMATION (LABEL LOCATION)
U.S.
