Welcome
ThankyouforchoosingTriple+CLM™(CloudLeakManagement)system
designedtodetectWaterleaksandpreventthesubsequentdamages.The
Triple+CLM™systemwillgiveyoupeaceofmindwhileathomeoraway.
Pleasenote
Pleasereadthroughtheinstructionscarefullyandfollowthestepsofthe
system'sinstallation.
Pleasemaintainthisdocumentinasafeplaceforfuturereference.Whenin
anydoubt,contactyourauthorizeddistributororinstaller.

Warning!Thisproductwasdesignedtopreventwaterleaksandassuch
shouldbeusedforwaterfloodsonly.
Triple+CLM™system
TheTriple+CLMTMsystemdetectsandpreventswaterleaks.Whentheleak
isdetected,thesystemdisconnectsthewatersupply,wirelesslyactivating
theshutoffunits.Eachinstallationcanincludemultiplevariousdetectors
andshutoffunitsinstalledonwatersupplypipes.
Thesystemisdesignedtominimizepotentialfloodingdamagesbyshutting
downthewatersupplywhenthesiteisinactiveand/orwhenaflooding
indicationisreceived.

TheTriple+CLM™systemisdesignedforinternaluseandshouldbeinstalled
byanauthorizedtechnician.
Flooddetectorspecification
PartNo.CLM‐FDAMAP‐1‐00,CLM‐FDEMEA‐1‐00
ProductdescriptionTheflooddetectorsaretobeinstalledinplaces
probetowaterfloodsorleaks.Whena
detectordetectswaterflood,awireless
communicationisdispatchedtoinitiateclosure
oftheshutoffunit,shuttingoffthewater
supply.
Dimensions Body98X31X28mm(3.85X1.22X1.1”)
Probe34X16X11mm(1.34X0.63X0.43”)
Cablelength30cm(1ft.)
Weight 110gr(0.24Lbs)
PowersupplyTwoAAAnon‐rechargeablebatteries
Operationvoltage3V
BatterylifespanUptotwoyears
OperatingRF915MHz
TransmissionrangeOpenspace‐ upto230m(750ft.)
Whenawalliswithinthespace‐upto120m
(390ft.)
Toavoiddamagingthewirelesscommunication,
avoidinstallationwithinmetalcabinets.
Workingtemperature‐20to+500C(‐4to+1220F)
CertificationsFCCID:2AFOICLMFLD10
IC:20798‐CLMFLD10






FloodDetectordescription
1. IndicationLED
2. Waterdetector
3. Batteryhousingcover
4. Wallmountbracket
5. Double‐sidedadhesivetapeapplicationlocations(rear)

FloodDetectorinstallation

1. Openthebatteryhousingcoverbypullingittowardsthecable,while
holdingthedetectorbody.
2. Removethecoverandexposethebatteryhousing.
3. Install2AAAbatteriesinthebatteryhousing,pleasenotethepolarity
marking.

4. Closethebatteryhousingcover.
5. Applytheattacheddouble‐sidedadhesivetapestripstothebattery
housingcoverintheplaceddefinedonthepicture.
6. Choosethepositionandheightfromthefloorlevelmostsuitablefor
installation,soduringfloodingdetector’sonlyelectrodeswouldget
wet.Fixbothpartsofthedetectortothewallusingthedoublesided
adhesivetape.Thebottompartmightbefixedusing2screws(not
attached).Ensurethattheboxwillnotbeexposedtowater.Theflood
detectorcontainsanelectroniccircuitandisnotwithinawatertight
casing(thetwoelectrodesaretheonlypartthatshouldcomein
contactwithwater).
7. Aftertheinstallation,makesurethattheindicationLEDisclearly
visible.
ExpectedFloodDetectorLEDbehavior
GREENblinkoncein30seconds–allisOK


TripleplusLtd.|5HamadaSt.,HighTechPark,Yoqneam,2069200,Israel|+972‐(0)72‐2211370|[e-mail]|www.tripleplus.io
REDblinkoncein30seconds–communicationproblems
REDblinkoncein10seconds–ongoingwaterleak
BLUEblinkoncein30seconds–lowbattery
Systeminstallation
Triple+CLM™devicesareinstalledusingtheTriple+CLM™Installermobile
APP(availableonAppStoreorGooglePlay)andshouldbehandledbya
certifiedinstaller.
Placeswherethedetectorshouldnotbepositionedat
•Withinametalcabinetoranywherethatmightinfluencewireless
communications.
•Wheredirtoraforeignobjectmayobstructthevalve'soperation.
•Wherethetemperatureexceedstherangebetween‐20and50
degreescentigrade(‐4to+1220F).
•Wherethereisanapprehensionofbeinghitordamaged.
•Inanexternalplacewhereexposedtorainanddirectsunlightand/or
totheelements.
Insuchacase,theunitshouldbeinstalledinawatertightplastic
casing.
•Wherethereishumidity
Systemcomponentsynchronizationandactivation
Theprocessbeginswhenthebatteryisinstalledwithinthedisconnection
unit.


Warrantyinstructions

























Pleasevisitwww.tripleplus.io/supportforwarranty,technical
support,andself‐solvingtools.

