Tripp Lite Thunderbolt MTB3-002-HD User manual

1
Quick Start Guide
Thunderbolt™3 to
Dual HDMI Adapter
Model: MTB3-002-HD
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
Español 8 • Français 14
Русский 20 • Deutsch 26
20-12-306-933C2E-Book.indb 120-12-306-933C2E-Book.indb 1 10/1/2021 1:08:40 PM10/1/2021 1:08:40 PM

2
Product Features
• Compatible with macOS®10.12 and below and
Windows®10 and below
• Supports Ultra High Definition (UHD) 4K x 2K
video resolutions up to 4096 x 2160 (60 Hz),
as specified in HDMI 2.0, when transmitting to
two displays
• Supports up to 36-bit Deep Color (12 bits
per channel)
• Compatible with HDCP 2.2 and previous
HDCP specifications
• Supports chroma subsamplings of YUV 4:4:4,
as well as RGB and YUV 4:2:2
• Plug-and-play adapter—no drivers required
20-12-306-933C2E-Book.indb 220-12-306-933C2E-Book.indb 2 10/1/2021 1:08:40 PM10/1/2021 1:08:40 PM

3
System Requirements
Installation
Package Contents
• Thunderbolt 3-enabled Mac or Windows PC
• HDMI-enabled monitor
1. Connect the adapter’s Thunderbolt 3 connector
to the Thunderbolt 3 port on your Mac or
Windows PC.
2. Connect the adapter’s HDMI port to a monitor
using an HDMI cable (such as Tripp Lite’s
P568-Series cables).
3. The video image will appear on the add-on
monitor. Customize how video is displayed on
the add-on monitor using your device’s
display settings.
• MTB3-002-HD
• Quick Start Guide
20-12-306-933C2E-Book.indb 320-12-306-933C2E-Book.indb 3 10/1/2021 1:08:40 PM10/1/2021 1:08:40 PM

4
Specifications
Connectors
Input Thunderbolt 3 (Male)
Display 2x HDMI (Female)
Video
Maximum Resolutions Dual Monitor: 4096 x 2160
(60 Hz)
Color Depth 36-bit Deep Color Maxium
(12 bits per channel)
Environmental
Operating Temperature 32° to 113°F (0° to 45°C)
Operating Humidity 10% to 85% RH,
Non-Condensing
Storage Temperature 14° to 158°F (-10° to 70°C)
Storage Humidity 10% to 90% RH,
Non-Condensing
Power Requirements
External Power Supply No
20-12-306-933C2E-Book.indb 420-12-306-933C2E-Book.indb 4 10/1/2021 1:08:40 PM10/1/2021 1:08:40 PM

5
Warranty and Product Registration
3-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in
materials and workmanship for a period of three (3) years
from the date of initial purchase. TRIPP LITE’s obligation
under this warranty is limited to repairing or replacing (at its
sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material
Authorization (RMA) number from TRIPP LITE or an authorized
TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by
a brief description of the problem encountered and proof of
date and place of purchase. This warranty does not apply to
equipment which has been damaged by accident, negligence
or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. Some states do not permit limitation
or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any
costs, such as lost profits or revenue, loss of equipment, loss
of use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.
20-12-306-933C2E-Book.indb 520-12-306-933C2E-Book.indb 5 10/1/2021 1:08:40 PM10/1/2021 1:08:40 PM

6
Warranty and Product Registration
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply.
See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
20-12-306-933C2E-Book.indb 620-12-306-933C2E-Book.indb 6 10/1/2021 1:08:40 PM10/1/2021 1:08:40 PM

7
Warranty and Product Registration
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to
operate this equipment.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos
and illustrations may differ slightly from actual products.
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
20-12-306 93-3C2E_RevB
20-12-306-933C2E-Book.indb 720-12-306-933C2E-Book.indb 7 10/1/2021 1:08:41 PM10/1/2021 1:08:41 PM

8
Guía de Inicio Rápido
Adaptador Thunderbolt™3
a HDMI Doble
Modelo: MTB3-002-HD
1111 W. 35th Street, Chicago, IL 60609, EE UU
tripplite.com/support
Copyright © 2021 Tripp Lite. Todos los derechos reservados.
English 1 • Français 14
Русский 20 • Deutsch 26
20-12-306-933C2E-Book.indb 820-12-306-933C2E-Book.indb 8 10/1/2021 1:08:41 PM10/1/2021 1:08:41 PM

9
Características del Producto
• Compatible con MacOS®10.12 y versiones
anteriores y Windows®10 y versiones anteriores
• Soporta resoluciones de video de Ultra Alta
Definición [UHD] 4K x 2K hasta 4096 x 2160
(60 Hz), como se especifica en HDMI 2.0, al
transmitir a dos pantallas
• Soporta Color Verdadero de hasta 36 bits
(12 bits por canal)
• Compatible con especificaciones HDCP 2.2 y
HDCP anteriores
• Soporta submuestreos de crominancia de YUV
4:4:4, así como RGB y YUV 4:2:2
• Adaptador para Conectar y Usar—no se necesitan
controladores
20-12-306-933C2E-Book.indb 920-12-306-933C2E-Book.indb 9 10/1/2021 1:08:41 PM10/1/2021 1:08:41 PM

10
Requisitos del Sistema
Instalación
Contenido del Empaque
• Mac o PC Windows equipada con Thunderbolt 3
• Monitor equipado con HDMI
1. Conecte el conector Thunderbolt 3 del adaptador
al puerto Thunderbolt 3 en su Mac o PC Windows.
2. Conecte el puerto HDMI del adaptador a un
monitor mediante un cable HDMI (como los cables
Serie P568 de Tripp Lite).
3. La imagen de video aparecerá en el monitor
adicional. Personalice la forma cómo se muestra
el video en el monitor agregado utilizando la
configuración de la pantalla de su dispositivo.
• MTB3-002-HD
• Guía de Inicio Rápido
20-12-306-933C2E-Book.indb 1020-12-306-933C2E-Book.indb 10 10/1/2021 1:08:41 PM10/1/2021 1:08:41 PM
