Tripp Lite U444-06N-DP-C User manual

1
Owner’s Manual
USB 3.1 Gen 1 USB-C™ to
DisplayPort Adapter with
Charging
Model: U444-06N-DP-C
USB Type-C and USB-C are trademarks of USB Implementers Forum
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate
peace of mind. You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
Este manual esta disponible en español en la página de
Tripp Lite: www.tripplite.com
Ce manuel est disponible en français sur le site Web de
Tripp Lite : www.tripplite.com
Русскоязычная версия настоящего руководства представлена
на веб-сайте компании Tripp Lite по адресу: www.tripplite.com
17-10-006-933559-EN.indd 1 10/4/2017 5:27:07 PM

2
Package Contents
Product Features
• U444-06N-DP-C
• Owner’s Manual
• Supports USB DisplayPort Alternate Mode for
connecting a DisplayPort monitor via a USB-C port
• Supports 4K x 2K Ultra High Definition (UHD)
resolutions up to 3840 x 2160 (60 Hz)
• USB-C Power Delivery (PD) charging port charges
your device
• USB-C port supports power input up to 20V 3A
(60W)
• Plug and play; no software or drivers required
Optional Accessories
• P580-Series DisplayPort Cables
• U420-003 USB 3.1 Gen 1 USB-C Male/Male
Cable – 3 ft.
17-10-006-933559-EN.indd 2 10/4/2017 5:27:07 PM

3
Installation
1. Connect the adapter’s USB-C connector to
the USB-C port on your laptop, tablet or other
compatible device.
2. Connect the adapter’s DisplayPort to the monitor’s
DisplayPort using a DisplayPort cable (such as
Tripp Lite’s P580-Series DisplayPort cables).
3. Charge your device by connecting its USB-C charger
to the adapter’s USB-C port.
Input Connectors
USB USB-C (Male)
PD Charging USB-C (Female)
Output Connectors
DisplayPort DisplayPort (Female)
Environmental
Operating Temperature 32°F to 113°F (0°C to 45°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature 14°F to 158°F (-10°C to 70°C)
Storage Humidity 5% to 90% RH, Non-Condensing
Power Requirements
USB-C PD Charging Port Supports up to 20V 3A (60W) Input
Specifications
17-10-006-933559-EN.indd 3 10/4/2017 5:27:07 PM
