Tripp Lite U436-06N-G-C User manual

1
Quick Start Guide
USB 3.1 Gen 1 USB-C™
Gigabit Ethernet Adapter
with Charging
Models: U436-06N-G-C, U436-06N-GB-C
Español 8 • Français 14 • Русский 20
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate
peace of mind. You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
USB Type-C and USB-C are trademarks of USB Implementers Forum
17-10-218-933749.indb 1 10/23/2017 10:47:51 AM

2
Product Features
• Add Gigabit Ethernet and USB-C charging via the
USB-C port on your smartphone, laptop, tablet or
other device
• Plug and play with no software or drivers required
• USB 3.1 Gen 1 supports true 10/100/1000 Mbps
network speeds
• USB-C charging port for charging your device,
supporting up to 20V 3A (60W) of power input
• Compliant with IEEE 802.3, 802.3u, 802.3ab and
802.3az (Energy Efficient Ethernet)
• Supports Wake-on-LAN
• Compatible with Windows®, Mac®and Chromium™
operating systems
17-10-218-933749.indb 2 10/23/2017 10:47:51 AM

3
Package Includes
• U436-06N-G-C (White) or U436-06N-GB-C (Black)
• Quick Start Guide
Installation
Note: When the unit is connected to the USB-C port on your
computer and to a network via Cat5e/6 cabling, a network
connection will be automatically established. If no connection
is made, you can manually establish one by going to your
computer’s network settings page. For example, on a Mac
navigate to the Network section found in System Preferences,
click the ‘Assist Me’ button to get to the Network Setup
Assistant, then follow the prompts to establish a connection.
1. Connect the adapter’s USB Type-C connector
to the USB-C port on your smartphone, tablet,
Ultrabook™ or computer.
2. Connect the adapter’s RJ45 port to a network
using a UTP cable (such as Tripp Lite’s N201-
Series Cat6 cables).
3. Charge your device by connecting a USB-C cable
between the USB-C port on the adapter and the
charger or external power supply that came with
your device.
17-10-218-933749.indb 3 10/23/2017 10:47:51 AM

4
Connectors
USB USB-C Male
Ethernet RJ45 Female
Charging USB-C Female
Environmental
Operating Temperature 32° to 158° F
(0° to 70° C)
Operating Humidity 10% to 85% RH,
Non-Condensing
Storage Temperature 14° to 158° F
(-10° to 70° C)
Storage Humidity 5% to 90% RH,
Non-Condensing
Power Requirements
USB-C Charging Port Supports up to 20V 3A
(60W) Input
Specifications
17-10-218-933749.indb 4 10/23/2017 10:47:51 AM

5
Warranty and Product Registration
3-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials
and workmanship for a period of three (3) years from the date of
initial purchase. TRIPP LITE’s obligation under this warranty is limited
to repairing or replacing (at its sole option) any such defective
products. To obtain service under this warranty, you must obtain a
Returned Material Authorization (RMA) number from TRIPP LITE or
an authorized TRIPP LITE service center. Products must be returned
to TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by a brief
description of the problem encountered and proof of date and place
of purchase. This warranty does not apply to equipment, which has
been damaged by accident, negligence or misapplication or has
been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied
warranties; therefore, the aforesaid limitation(s) or exclusion(s) may
not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as
lost profits or revenue, loss of equipment, loss of use of equipment,
loss of software, loss of data, costs of substitutes, claims by third
parties, or otherwise.
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite
product. You’ll be automatically entered into a drawing for a chance
to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions
apply. See website for details.
17-10-218-933749.indb 5 10/23/2017 10:47:51 AM

6
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to operate this
equipment.
Warranty and Product Registration
17-10-218-933749.indb 6 10/23/2017 10:47:51 AM

7
Warranty and Product Registration
WEEE Compliance Information for Tripp Lite Customers and
Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations, when
customers buy new electrical and electronic equipment
from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one,
like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this
ultimately becomes waste
Use of this equipment in life support applications where failure of
this equipment can reasonably be expected to cause the failure
of the life support equipment or to significantly affect its safety or
effectiveness is not recommended. Do not use this equipment in
the presence of a flammable anesthetic mixture with air, oxygen or
nitrous oxide.
Tripp Lite has a policy of continuous improvement. Specifications are
subject to change without notice.
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
17-10-218-933749.indb 7 10/23/2017 10:47:51 AM

8
Guía de Inicio Rápido
Adaptador USB 3.1 Gen 1
USB-C Gigabit Ethernet
con Carga
Modelos: U436-06N-G-C, U436-06N-GB-C
English 1 • Français 14 • Русский 20
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2017 Tripp Lite.
Todos los derechos reservados.
USB Type-C y USB-C™ son marcas comerciales registradas del USB
Implementers Forum
17-10-218-933749.indb 8 10/23/2017 10:47:51 AM

9
Características del Producto
• Agregue Gigabit Ethernet y USB-C de carga
mediante el puerto USB-C en su smartphone,
laptop, tableta u otro dispositivo.
• Conectar y usar—No requiere software ni
controladores
• El USB 3.1 Gen 1 soporta velocidades reales de
red de 10/100/1000 Mbps
• Puerto de carga USB-C para cargar su dispositivo,
permitiendo hasta 20V 3A (60W) de potencia de
entrada
• Compatible con IEEE 802.3, 802.3u, 802.3ab y
802.3az (Consumo eficiente de energía en redes
Ethernet)
• Soporta Wake-on-LAN
• Compatible con Sistemas Operativos Windows®,
Mac®y Chromium™
17-10-218-933749.indb 9 10/23/2017 10:47:51 AM

10
Contenido del Empaque
• U436-06N-G-C (Blanco) o U436-06N-GB-C
(Negro)
• Guía de Inicio Rápido
Instalación
Nota: Cuando la unidad esté conectada al puerto USB-C en
su computadora y a una red mediante cableado Cat5e / Cat6,
automáticamente se establecerá una conexión de red. Si no
se realiza una conexión, puede establecer una manualmente
en la página de configuración de red de su computadora.
Por ejemplo, en una Mac, navegue a la sección de Red que
se encuentra en Preferencias del Sistema, haga click en el
botón “Assist me” [Ayúdame] para acceder al Asistente de
Configuración de Red, después siga las indicaciones para
establecer una conexión.
1. Conecte el conector USB Type-C del adaptador
en su smartphone, tableta, Ultrabook™ o
computadora.
2. Conecte el puerto RJ45 del adaptador a una red
usando un cable UTP, como los cables Cat6 de la
serie N201 de Tripp Lite
3. Cargue su dispositivo conectando un cable
USB-C entre el puerto USB-C en el adaptador y
el cargador o fuente de alimentación externa que
viene con su dispositivo.
17-10-218-933749.indb 10 10/23/2017 10:47:51 AM
