1
USB 3.1 Gen 1 to
HDMI Alternate Mode
Adapter
Models:
U444-06N-HD-AM, U444-06N-HDB-AM
Español 7 • Français 12 • Русский 17
Quick Start Guide
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate
peace of mind. You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2018 Tripp Lite. All rights reserved.
17-03-281-933753-EN-NEW.indd 1 3/26/2018 1:41:06 PM

2
Product Features
System Requirements
Package Contents
• USB-C or Thunderbolt™ 3 device that supports
USB DisplayPort Alternate Mode
• HDMI-enabled monitor
• U444-06N-HD-AM (White) or U444-06N-HDB-AM
(Black)
• Quick Start Guide
• Supports USB DisplayPort Alternate Mode for
displaying audio/video signals on an HDMI monitor
or projector via your computer, tablet, laptop or
smartphone’s USB-C™ or Thunderbolt™ 3 port
• Supports Ultra High Definition (UHD) 4K x 2K
video resolutions up to 3840 x 2160 (@ 30 Hz)
• Supports 36-bit Deep Color (12 bits per channel)
• Supports per-lane transfer rates of 5.4 Gbps
(HBR2), 2.7 Gbps (HBR) and 1.62 Gbps (RBR)
• Supports USB 3.1 Gen 1 data transfer rates up to
5 Gbps
• No external power supply or drivers required
USB Type-C™ and USB-C™ are trademarks of USB
Implementers Forum.
17-03-281-933753-EN-NEW.indd 2 3/26/2018 1:41:06 PM

3
Installation
1. Connect the adapter’s USB Type-C connector to
the USB Type-C port on your computer, tablet,
laptop or smartphone.
2. Connect the adapter’s HDMI port to a monitor
using an HDMI cable (such as Tripp Lite’s
P568-Series cables).
3. The video image will appear on the add-on
monitor. Use your device’s display settings to
customize how video is displayed on the add-on
monitor.
Specifications
Connectors
USB USB Type-C (Male)
Display HDMI (Female)
Video
Maximum Resolutions 3840 x 2160 (30 Hz)
Color Depth 36-bit Deep Color
(12 bits per channel)
Environmental
Operating Temperature 32° to 113°F (0° to 45°C)
Operating Humidity 10% to 85% RH,
Non-Condensing
Storage Temperature 14° to 158°F (-10° to 70°C)
Storage Humidity 5% to 90% RH,
Non-Condensing
Power Requirements
External Power Supply No
17-03-281-933753-EN-NEW.indd 3 3/26/2018 1:41:06 PM

4
Warranty and Product Registration
3-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in
materials and workmanship for a period of three (3) years
from the date of initial purchase. TRIPP LITE’s obligation
under this warranty is limited to repairing or replacing (at its
sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material
Authorization (RMA) number from TRIPP LITE or an authorized
TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by
a brief description of the problem encountered and proof of
date and place of purchase. This warranty does not apply to
equipment which has been damaged by accident, negligence
or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. Some states do not permit limitation
or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any
costs, such as lost profits or revenue, loss of equipment, loss
of use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.
17-03-281-933753-EN-NEW.indd 4 3/26/2018 1:41:06 PM

5
Warranty and Product Registration
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply.
See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
17-03-281-933753-EN-NEW.indd 5 3/26/2018 1:41:06 PM

6
Warranty and Product Registration
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to
operate this equipment.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
17-03-281-933753-EN-NEW.indd 6 3/26/2018 1:41:06 PM

7
Adaptador USB 3.1
Gen 1 a HDMI de Modo
Alterno
Modelos:
U444-06N-HD-AM, U444-06N-HDB-AM
English 1 • Français 12 • Русский 19
Guía de Inicio Rápido
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2018 Tripp Lite. Todos los derechos reservados.
18-03-281-933753-ES.indd 7 3/26/2018 1:41:23 PM

8
Contenido del Empaque
• U444-06N-HD-AM (Blanco) o U444-06N-HD-AM
(Negro)
• Guía de Inicio Rápido
Características del Producto
• Soporta el USB DisplayPort Modo Alterno para
mostrar señales de audio y video en un monitor
o proyector HDMI mediante el puerto USB-C o
Thunderbolt™ 3 de su computadora, tableta,
laptop o smartphone.
• Soporta resoluciones de video de Ultra Alta
Definición (UHD) 4K x 2K hasta 3840 x 2160
(@ 30 Hz)
• Soporta Color Verdadero de 36 bits (12 bits por
canal)
• Soporta velocidades de transferencia por línea de
5.4 Gbps (HBR2), 2.7 Gbps (HBR) y 1.62 Gbps
(RBR)
• El USB 3.1 Gen 1 soporta tasas de transferencia
de datos hasta 5 Gbps
• No se necesita alimentación externa o
controladores
USB Type-C™ y USB-C™ son marcas comerciales registradas
del USB Implementers Forum.
18-03-281-933753-ES.indd 8 3/26/2018 1:41:23 PM

9
Requisitos del Sistema
Instalación
• Dispositivo USB-C o Thunderbolt™ 3 que soporte
USB DisplayPort Modo Alterno
• Monitor equipado con HDMI
1. Conecte el conector USB Type-C del adaptador al
puerto USB Type-C en su computadora, tableta,
laptop o smartphone.
2. Conecte el puerto HDMI del adaptador a un
monitor usando un cable HDMI (Como los cables
Serie P568 de Tripp Lite).
3. La imagen de video aparecerá en el monitor
añadido Use los parámetros de pantalla de su
dispositivo para personalizar como se muestra el
video en el monitor agregado.
18-03-281-933753-ES.indd 9 3/26/2018 1:41:23 PM

10
Garantía
Garantía limitada por 3 años
TRIPP LITE garantiza por tres (3) años desde la fecha de
compra inicial que este producto no tiene defectos de
materiales ni de mano de obra. La obligación TRIPP LITE bajo
esta garantía está limitada a la reparación o reemplazo (A su
entera discreción) de cualquier producto defectuoso. Para
obtener servicio bajo esta garantía, debe obtener un número de
Autorización de Devolución de Mercancía (RMA) de TRIPP LITE
o de un centro de servicio autorizado de TRIPP LITE.
Especificaciones
Conectores
USB USB Type-C (Macho)
Pantalla HDMI (Hembra)
Video
Resoluciones Máximas 3840 x 2160 (30 Hz)
Profundidad de Color Color Verdadero de 36 bits
(12 bits por canal)
Ambiental
Temperatura de Operación 0 °C a 45 °C
Humedad de Operación De 10% a 85% de HR,
Sin Condensación
Temperatura de
Almacenamiento
-10 °C a 70 °C
Humedad de
Almacenamiento
Del 5% a 90% de HR,
Sin Condensación
Requerimientos de Energía
Fuente de Alimentación
Externa
No
18-03-281-933753-ES.indd 10 3/26/2018 1:41:23 PM
