Owner’s Manual
USB Type-C™to HDMI,
DisplayPort, and VGA
Adapter with MST
Model: U444-06N-HVDPW
USB Type-C and USB-C are trademarks of
USB Implementers Forum
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate
peace of mind. You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
Español 9 • Français 16 • Русский 23
18-12-177-933910.indb 1 1/10/2019 6:33:07 PM

2
Product Features
• Connect a VGA, DisplayPort or HDMI monitor
to the USB Type-C or Thunderbolt™ 3 port
on your laptop or computer
• Supports USB DisplayPort Alternate Mode,
allowing you to transmit an audio/video
signal via the USB Type-C port on your
smartphone, tablet, Ultrabook or computer
• VGA port supports video resolutions up to
1920 x 1200, including 1080p @ 60 Hz
• HDMI port supports 4K x 2K Ultra High
Definition (UHD) video resolutions up to
3840 x 2160 @ 30 Hz
• HDMI port is compliant with HDMI 1.4 and
earlier, and HDCP 1.4
• DisplayPort supports single-link 4K x 2K
video resolutions up to 3840 x 2160 @
60 Hz
• Supports DisplayPort SST and MST modes,
and DP++
• DisplayPort is compliant with DP 1.2 and
earlier, and HDCP 2.2
18-12-177-933910.indb 2 1/10/2019 6:33:07 PM

3
Product Features
Package Contents
System Requirements
Optional Accessories
• Low-profile design for easy carrying in laptop
bag or briefcase
• Plug-and-Play—no software or drivers
required
• U444-06N-HVDPW
• Owner’s Manual
• USB Type-C device that supports USB
Displayport Alternate Mode
• Monitor with a VGA, DisplayPort or HDMI
port
• P502-Series High-Resolution VGA Cable with
RGB Coax
• P580-Series DisplayPort Cables
• P569-XXX-CERT Premium High-Speed HDMI
Cables
18-12-177-933910.indb 3 1/10/2019 6:33:07 PM

4
Installation
Notes:
• When used with a Mac, up to three displays can
be used in SST mode to share the same video or
picture content with a maximum display resolution
of 1080p @ 60 Hz.
• Mac OS X does not support MST for NVIDIA and
Intel graphics processors, limiting video display on
the connected monitors to mirror mode.
• When used with a Windows PC, up to three displays
can be used in MST mode to display different
content to each display simultaneously.
1. Connect the USB Type-C connector on the
adapter to the USB Type-C port on your
smartphone, tablet, Ultrabook or computer.
2. Using a VGA cable (such as Tripp Lite’s
P502-Series High-Resolution VGA Cable
with Coax), connect a VGA monitor to the
adapter’s VGA port.
3. Using a DisplayPort cable (such as
Tripp Lite’s P580-Series DisplayPort Cable),
connect a DisplayPort monitor to the
adapter’s DisplayPort.
4. Using an HDMI cable (such as Tripp Lite’s
P569-CERT Series Premium High-Speed
HDMI Cable), connect an HDMI monitor to
the adapter’s HDMI port.
18-12-177-933910.indb 4 1/10/2019 6:33:07 PM

5
Specifications
Input Signal USB Type-C
Output Signal VGA, DisplayPort and HDMI
Maximum HDMI
Resolution
3840 x 2160, UHD 4K, @
30 Hz
Maximum
DisplayPort
Resolution
3840 x 2160 (4K x 2K) @
60 Hz
Maximum VGA
Resolution
1920 x 1200, including
1080p @ 60 Hz
Environmental
Operating
Temperature
32° to 113°F
(0° to 45°C)
Storage
Temperature
14° to 158°F
(-10° to 70°C)
Operating
Humidity
10% to 85% RH,
Non-Condensing
Storage
Humidity
5% to 90% RH,
Non-Condensing
18-12-177-933910.indb 5 1/10/2019 6:33:07 PM

6
Warranty and
Product Registration
3-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in materials
and workmanship for a period of three (3) years from the date of
initial purchase. TRIPP LITE’s obligation under this warranty is limited
to repairing or replacing (at its sole option) any such defective
products. To obtain service under this warranty, you must obtain a
Returned Material Authorization (RMA) number from TRIPP LITE or
an authorized TRIPP LITE service center. Products must be returned
to TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by a brief
description of the problem encountered and proof of date and place
of purchase. This warranty does not apply to equipment, which has
been damaged by accident, negligence or misapplication or has
been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied
warranties; therefore, the aforesaid limitation(s) or exclusion(s) may
not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as
lost profits or revenue, loss of equipment, loss of use of equipment,
loss of software, loss of data, costs of substitutes, claims by third
parties, or otherwise.
18-12-177-933910.indb 6 1/10/2019 6:33:07 PM

7
Warranty and
Product Registration
Product Registration
Visit www.tripplite.com/warranty today to register your new Tripp Lite
product. You’ll be automatically entered into a drawing for a chance
to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions
apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to operate this
equipment.
18-12-177-933910.indb 7 1/10/2019 6:33:07 PM

8
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Warranty and
Product Registration
WEEE Compliance Information for Tripp Lite
Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment (WEEE)
Directive and implementing regulations, when customers buy
new electrical and electronic equipment from Tripp Lite they
are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-
like basis (this varies depending on the country)
• Send the new equipment back for recycling when this
ultimately becomes waste
Use of this equipment in life support applications where failure of
this equipment can reasonably be expected to cause the failure
of the life support equipment or to significantly affect its safety or
effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specifications are
subject to change without notice.
18-12-177-933910.indb 8 1/10/2019 6:33:07 PM

9
Manual del Propietario
Adaptador de USB Type-C™
a HDMI, DisplayPort y
VGA con MST
Modelo: U444-06N-HVDPW
USB Type-C y USB-C son marcas comerciales registradas del
USB Implementers Forum
1111 W. 35th Street, Chicago, IL 60609 EE UU
www.tripplite.com/support
Copyright © 2019 Tripp Lite. Todos los derechos reservados.
English 1 • Français 16 • Русский 23
18-12-177-933910.indb 9 1/10/2019 6:33:08 PM

10
Características del Producto
• Conecte un monitor VGA, DisplayPort o
HDMI al puerto USB Type-C o Thunderbolt™
3 en su laptop o computadora
• Soporta USB DisplayPort Modo Alterno,
permitiéndole transmitir una señal de audio
y video mediante el puerto USB Type-C
en su smartphone, tableta, Ultrabook o
computadora
• El puerto VGA soporta resoluciones de video
hasta 1920 x 1200, incluyendo 1080p
@60 Hz
• El puerto HDMI soporta resoluciones de
video de 4K x 2K Ultra Alta Definición [UHD]
hasta 3840 x 2160 @30 Hz
• El puerto HDMI es compatible con HDMI 1.4
y anteriores y HDCP 1.4
• DisplayPort permite resoluciones de video
4K x 2K de conexión única hasta 3840 x
2160 @60 Hz
• Soporta modos de DisplayPort SST y MST y
DP++
• DisplayPort cumple con DP 1.2 y anteriores
y HDCP 2.2
