Tripp Lite U444-06N-MDP-AL User manual

1
Quick Start Guide
USB Type-C™ to
Mini DisplayPort Adapter –
Aluminum
Model: U444-06N-MDP-AL
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
Español 7 • Français 13 • Русский 19
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
www.tripplite.com/warranty
19-02-293-9338CC.indb 1 4/2/2019 11:36:29 AM

2
Product Features
• Supports USB DisplayPort 1.2
Alternate Mode for connecting a Mini
DisplayPort monitor to a USB Type-C™ or
Thunderbolt™3 port
• Supports Ultra High Definition (UHD) 4K x
2K video resolutions up to 3840 x 2160
(60 Hz)
• Supports up to 48-bit Deep Color (16 bits
per channel)
• Supports 4:4:4 chroma subsampling
• Supports per lane data transfer rates of
5.4 Gbps (HBR2), 2.7 Gbps (HBR) and
1.62 Gbps (RBR)
• Compatible with HDCP 2.2
• Compact and lightweight aluminum housing
fits easily into a backpack or laptop bag
• Plug-and-Play adapter—no software or
drivers required
*USB Type-C™ and USB-C™ are trademarks of
USB Implementers Forum
19-02-293-9338CC.indb 2 4/2/2019 11:36:29 AM

3
Package Contents
System Requirements
Installation
• U444-06N-MDP-AL
• Quick Start Guide
• USB Type-C device that supports USB
DisplayPort 1.2 Alternate Mode
• Mini DisplayPort monitor
1. Connect the adapter’s USB Type-C
connector to the USB Type-C or
Thunderbolt 3 port on your smartphone,
tablet, laptop or computer.
Note: The U444-06N-MDP-AL can transfer only
DisplayPort signals and is not compatible with
Thunderbolt 3 or Thunderbolt 2 standards.
2. Using a Mini DisplayPort cable (such as
Tripp Lite P584-Series cables), connect the
adapter’s Mini DisplayPort to a monitor.
3. The video image will appear on the add-on
monitor. Customize how video is displayed
on the add-on monitor using your device’s
display settings.
19-02-293-9338CC.indb 3 4/2/2019 11:36:29 AM

4
Specifications
Connectors
USB USB Type-C (Male)
DisplayPort Mini DisplayPort
(Female)
Video
Maximum Resolution 3840 x 2160 (60 Hz)
Color Depth 48-bit Deep Color
(16 bits per channel)
Environmental
Operating Temperature 32 to 113°F
(0 to 45°C)
Operating Humidity 10% to 85% RH,
Non-Condensing
Storage Temperature 14 to 158°F
(-10 to 70°C)
Storage Humidity 5% to 90% RH,
Non-Condensing
Power Requirements
Power Source Bus Power
19-02-293-9338CC.indb 4 4/2/2019 11:36:29 AM

5
Warranty and
Product Registration
3-Year Limited Warranty
Tripp Lite warrants its products to be free from defects in
materials and workmanship for a period of three (3) years from
the date of initial purchase. Tripp Lite’s obligation under this
warranty is limited to repairing or replacing (at its sole option)
any such defective products. To obtain service under this
warranty, you must obtain a Returned Material Authorization
(RMA) number from Tripp Lite or an authorized Tripp Lite
service center. Products must be returned to Tripp Lite or an
authorized Tripp Lite service center with transportation charges
prepaid and must be accompanied by a brief description of the
problem encountered and proof of date and place of purchase.
This warranty does not apply to equipment, which has been
damaged by accident, negligence or misapplication or has
been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. Some states do not permit limitation or exclusion
of implied warranties; therefore, the aforesaid limitation(s) or
exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE. Specifically, Tripp Lite is not liable for any costs, such
as lost profits or revenue, loss of equipment, loss of use of
equipment, loss of software, loss of data, costs of substitutes,
claims by third parties, or otherwise.
19-02-293-9338CC.indb 5 4/2/2019 11:36:29 AM

6
Warranty and
Product Registration
Product Registration
Visit www.tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some
restrictions apply. See website for details.
Use of this equipment in life support applications where failure
of this equipment can reasonably be expected to cause the
failure of the life support equipment or to significantly affect its
safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
19-02-293 93-38CC_RevC
