Owner’s Manual
USB 3.0 to SATA / IDE
Adapter with
Built-in Cable
Model: U338-06N
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be automatically entered
to win an ISOBAR surge protector in our monthly drawing!
tripplite.com/warranty
Español 9 • Français 17

2
Package Contents
Product Features
• U338-06N USB 3.0 to SATA / IDE Adapter
• 7-Pin SATA Data Cable
• 15-Pin SATA Power Cable
• 4-Pin Molex Power Cable
• Power Supply Adapter
• External Power Supply (Input: 100-240V,
50/60 Hz, 1.5A; Output: 12V 2A)
• Owner’s Manual
• Supports USB 3.0 SuperSpeed specification;
backward compatible with USB 2.0 and 1.1
• Allows easy hard drive access without having
to connect the drive internally
• Features SATA, 40-Pin and 44-Pin
connectors for use with 2.5", 3.5" or 5.25"
drives
• Compatible with Windows®, Mac®, and
Linux® operating systems
• Plug-and-Play—no software or drivers
required

3
System Requirements
Installation
• Computer with an available USB port; a
USB 3.0 port is required to achieve USB 3.0
data transfer rates
• 2.5" / 3.5" / 5.25" SATA or IDE drive
Notes:
• Hard drives are sensitive to static electricity and
must be handled properly to prevent data loss.
Always handle your hard drive with caution. Wear
an anti-static strap (such as the Tripp Lite
P999-000) when transporting it, or touch a
grounded metal surface to discharge yourself of
static electricity before picking up the drive.
• If your drive has not been formatted, you must
format it using your computer’s Disk Management
utility before you can copy and access files.
• For all IDE devices, set the Jumper setting on the
drive to Master Single drive mode. For Jumper
settings, refer to your hard drive manufacturer’s
documentation.
• Before unplugging the adapter, make sure to
properly eject the drive from your computer to
avoid any potential data loss.

4
Installation
1. Connect the external power supply to the
included power supply adapter and plug it
into an appropriate power source.
SATA Drive (For IDE drives, skip to Step 4)
2. Insert one end of the provided 7-Pin SATA
data cable into the SATA port on the
U338-06N and the other end to the SATA
data port on the SATA hard drive.
3. Connect the included 15-Pin SATA Power
Cable between the included power supply
adapter and the SATA power port on the
SATA hard drive. Go to Step 6.
IDE Drive
4. Align the IDE drive interface on the hard
drive with the appropriate port on the
U338-06N, then gently but firmly insert the
IDE drive interface into it. Be sure the drive
is firmly connected.
5. Connect the included 4-Pin Molex Power
Cable between the included power supply
adapter and the power port on the IDE
hard drive.

5
Installation
6. Insert the built-in USB cable on the U338-
06N into an available USB port on your
computer. The LEDs on the U338-06N
will illuminate if all devices are connected
properly.
Note: The two LEDs will illuminate solid blue to
indicate the unit is powered on. They will blink
when transmitting data.
7. The hard drive should be automatically
detected by your computer’s operating
system.

6
Warranty and
Product Registration
3-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in
materials and workmanship for a period of three (3) years
from the date of initial purchase. TRIPP LITE’s obligation
under this warranty is limited to repairing or replacing (at its
sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material
Authorization (RMA) number from TRIPP LITE or an authorized
TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by
a brief description of the problem encountered and proof of
date and place of purchase. This warranty does not apply to
equipment, which has been damaged by accident, negligence
or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
Some states do not permit limitation or exclusion of implied
warranties; therefore, the aforesaid limitation(s) or exclusion(s)
may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any
costs, such as lost profits or revenue, loss of equipment, loss
of use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.

7
Warranty and
Product Registration
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited.
Some restrictions apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.

8
Warranty and
Product Registration
• Consult the dealer or an experienced radio/TV technician
for help.
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to operate
this equipment.
WEEE Compliance Information for Tripp Lite Customers
and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations,
when customers buy new electrical and electronic
equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one,
like-for-like basis (this varies depending on the
country)
• Send the new equipment back for recycling when
this ultimately becomes waste
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
19-11-162 93-3B9A_RevA

9
MÁS DE
AÑOS
Manual del Propietario
Adaptador USB 3.0 a
SATA / IDE con
Cable USB Integrado
Modelo: U338-06N
1111 W. 35th Street, Chicago, IL 60609, EE. UU.
tripplite.com/support
Copyright © 2019 Tripp Lite. Todos los derechos reservados.
English 1 • Français 17

10
Contenido del Empaque
Características del Producto
• U338-06N – Adaptador USB 3.0 a SATA / IDE
• Cable de Datos SATA de 7 Pines
• Cable de Alimentación SATA de 15 Pines
• Cable de Alimentación Molex de 4 Pines
• Adaptador de Corriente
• Fuente de Alimentación Externa (Entrada: 100V
~ 240V, 50Hz / 60Hz, 1.5A; Salida: 12V, 2A)
• Manual del Propietario
• Soporta la especificación USB 3.0 SuperSpeed;
compatible con versiones anteriores de USB 2.0
y 1.1
• Permite el fácil acceso al disco duro sin tener
que conectar el disco internamente.
• Cuenta con conectores SATA de 40 pines y 44
pines para usar con discos de 2.5", 3.5" o 5.25"
• Compatible con sistemas operativos Windows
®
,
Mac
®
y Linux
®
• Conectar y Usar—No requiere software ni
controladores
