Tripp Lite AG-0548 Series User manual

1
User’s Manual
In-Row Precision
Air Conditioning System
DX Air-Cooled, 300 mm Wide, 60 Hz, UL
Models: SRCOOLDXRW12, SRCOOLDXRW25
(Series Numbers: Indoor Unit: AG-0548, AG-0549; Outdoor Unit: KSF18AN, KSF38AN)
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
Español 17 • Français 33

2
Table Of Contents
1. Important Safety Information
SAVE THESE INSTRUCTIONS
Prior to installation, operation, maintenance or servicing of this equipment, read this manual thoroughly.
Only qualified personnel may install, operate, maintain and service this equipment. The following symbols may appear to warn
of potential danger and hazards.
CAUTION This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of
the appliance by person responsible for their safety. Children should be supervised to ensure that they do not play with the
appliance.
This appliance is classified as APPLIANCE NOT ACCESSIBLE TO THE GENERAL PUBLIC. If the supply cord is damaged, it
must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The appliance
shall be installed in accordance with national wiring regulations
A user-supplied all-pole disconnection device which has at least 0.118 in. (3 mm) separation distance in all-pole and a
residual current device (RCD) with a rating of above 10mA shall be incorporated in the fixed wiring, according to the National
Electrical Code (NEC) standards.
1.1 Explanation of Symbols
The following symbols illustrate messages to warn of potential danger and need for caution and attention.
This symbol indicates that with failure to comply with the instructions, there will be a risk of electric shock resulting in
injury, as noted in the “DANGER” or “WARNING” safety labels.
This is a safety alert symbol used to warn of potential personal injury hazards. Follow all safety information to avoid
personal injury or death that may arise.
1. Important Safety Information 2
1.1 Explanation of Symbols 2
1.2 Handling Information 3
2. Operation and Maintenance 5
2.1 Introduction 5
2.2 Home Screen 6
2.2.1 Settings Menu 7
2.2.2 Maintenance Mode 9
2.3 Data Menus 9
2.4 Graph Menu 10
2.5 Alarm Menu 11
2.6 Regular User Maintenance 12
2.7 Alarms and FAQ 12
3. Warranty and
Product Registration 16
For installation instructions, refer to separate Installation Manual.

3
1. Important Safety Information
DANGER
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
DANGER
Hazard of electric shock, explosion or arc flash
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices.
• This equipment must be installed and serviced by qualified HVAC personnel only.
• Comply with all local and national wiring and safety regulations applicable where unit will be installed, e.g.
National Electric Code (NEC) in the United States.
• Turn off all power supplying this equipment before working on or inside of the equipment.
• Always use a properly rated voltage sensing device to confirm power is off.
• Replace all devices, doors, and covers before turning on power to this equipment.
• Only those who are properly trained or qualified to use this device should do so. Anyone who is not trained or
qualified should not use this device unless it is under the supervision of someone who is properly trained or
qualified to do so.
Failure to observe this warning may result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, can result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, can result in minor or moderate injury.
NOTICE
NOTICE addresses practices not related to physical injury including certain environmental hazards, potential
damage or loss of data.
1.2 Handling Information
Read handling information prior to installing, operating, servicing or maintaining the equipment. Comply with local regulations
and laws when handling refrigerant.

4
1. Important Safety Information
WARNING
Hazard from moving parts
• Keep hands, clothing and jewelry away from moving parts. Check the equipment for foreign objects before
closing the doors and starting the equipment.
Failure to observe this warning may result in death or serious injury.
CAUTION
Hazard to equipment or personnel
• All work must be performed only by qualified personnel.
Failure to observe this warning may result in death or serious injury.
WARNING
Hazard of equipment falling over
• Use two or more persons at all times to move or turn this equipment.
• Always push, pull or turn while facing the front and rear of this equipment. Never push, pull or turn while facing
the sides of this equipment.
• Slowly move this equipment across uneven surfaces or door thresholds.
• Lower leveling feet to floor when this equipment is at rest.
• Lower leveling feet and attach joining brackets to adjacent racks when this equipment is in final position.
Failure to observe this warning may result in serious injury or equipment damage.
CAUTION
Hazard to equipment or personnel
• Make sure no spare parts or tools are in the equipment before handling the equipment.
• Do not operate unit without the air filter. This may cause dust accumulation that can damage the unit.
Failure to observe this warning may result in serious injury or equipment damage.
CAUTION
Refrigerant high pressure and hazard to equipment
• This unit operates under high pressure. Observe proper safety precautions when operation or servicing the unit.
• The equipment is to be charged with R-410A only.
• Copper pipe must support minimum 55bar pressure.
Failure to observe this warning may result in serious injury or equipment damage.

5
2.1 Introduction
Because IT rooms generate high concentrations of heat and operate 24/7 x 365, specially designed cooling systems such as
the SmartRack®Precision In-Row Series provide high-density, predictable and reliable cooling. Each In-Row Cooler (indoors)
connects to a condenser (outdoors). By this method, the In-Row Cooler accumulates heat from IT equipment and rejects it to
the outdoors without the need for ductwork or complex cooling infrastructure.
The SmartRack®In-Row SRCOOLDXRW12 and SRCOOLDXRW25 Cooling Systems are precision, split type, DX, air-cooled
systems. They require copper piping connections to bridge the In-Row Cooler (indoors) and condenser (outdoors). No ductwork
or raised floor is required.
As a result, these are dedicated cooling systems, meaning the design allows them to operate independently of the building’s
HVAC / comfort cooling system.
The system must be installed by a professional HVAC installer.
2. Operation and Maintenance
Hot return air Cold supply air

6
2. Operation and Maintenance
2.2 Home Screen
• Supply Air Temp: The current temperature of the discharge air.
Note: If setting the control mode to Return Air, this setting becomes “Return Air Temp.”
• Humidity: The current relative humidity of the return air.
• Dehumidification: The status of the dehumidification system. It will display “ON” when the return air humidity exceeds the
humidity setting + the humidity band.
• Fan: The current total fan speed expressed as a percent of max cumulative airflow.
Note: If max fan speed is set to 80%, for example, the home screen will only show up to 80%.
• Cooling Operation: The current cooling output as a percent of rated capacity.
• Maintenance Mode: The control button to toggle Maintenance Mode. (Must be enabled in user settings.) Refer to
Maintenance Mode section for more information.
•Unit Cooler On/Off: The control button to turn the In-Row Cooler on or off.
• Unit Status: The current cooling status of the In-Row Cooler, specifically whether the compressor is engaged. The In-Row
Cooler status is on when the compressor is running and is on standby when the compressor is off.
Note: When in standby, the fans may still rotate to help circulate air.
• Language: The language selection for the user interface.

7
2. Operation and Maintenance
2.2.1 Settings Menu
The default password is 4321 for User 1.
• Temp setting: The desired temperature of the discharge air.
Note: If setting the control mode to Return Air, this setting becomes “Return Air Temp.”
• Temp control band: It is recommended to leave this at the default setting of 5.4°F (3.0°C) except for low-load situations.
If the IT load is less than the In-Row Cooler minimum capacity or if the IT load often changes, set a higher band to keep
the room temperature stable. A higher band can help reduce the number of compressor on/off cycles. For this, the
recommended setting is 5.4° to 10°F (3° to 6°C).
If the IT load is greater than the In-Row Cooler minimum capacity or if the room IT load is stable, consider setting the band
to its default or even lower to optimize temperature precision. Recommended setting: 3.6° to 5.4°F (2° to 3°C).
• Humidity setting: The target relative humidity of the dehumidification system.
Note: the In-Row Cooler cannot add humidity to the air.
• Upper humid control band: The allowable range above the humidity setting. For example, a delta of 20% RH at a humidity
setting of 50% RH would mean the dehumidification cycle would initiate when the humidity rises above 70% RH.
• High/low temp alarm band: If the discharge temperature exceeds/falls below this value, an alarm is triggered.
Note: If setting Control Mode to Return Air, you MUST ADJUST this setting to be based off of the return air temperature instead.
• High humid alarm band: If the return air humidity exceeds the humidity setting + the high humid band setting, an alarm is
triggered. For example, if the user humidity setting is 50% and the user wants the high humidity alarm to trigger at 80% RH,
set this to 30%. If dehumidification mode is enabled, a high-humidity alarm will engage dehumidification mode.
• Enable maintenance: Allows the ability to engage Maintenance Mode from the home screen.
Note: this allows Maintenance Mode to be engaged from the home screen without a password.
• Maintenance running time: Maintenance Mode duration. If the user does not turn off Maintenance Mode from the home
screen, the In-Row Cooler will automatically revert to normal operation after this time.

8
2. Operation and Maintenance
• Control Mode:
• Supply air (default): The cooling control strategy will be based off the temperature of the discharge air.
• Return air: The cooling control strategy will be based off the temperature of the entering air.
Note: If the load is lower than 30% of rated cooling capacity, which may cause frequent In-Row Cooler on/off cycling, it is
recommended to set Control Mode to “Return Air.” Otherwise, set Control Mode to “Supply Air.”
• Restart delay time: Restart delay after restoring power. If power is lost, the In-Row Cooler will automatically restart after
this delay time.
Set up group control to ensure redundancy if there is a cooling fault or to balance run hours to ensure average run hours
across all In-Row Coolers is similar:
• Standby Unit IP: The IP address of the standby air conditioner. The master In-Row Cooler will send commands to this IP
address. If configured as a standby In-Row Cooler, an IP address is not needed.
• This Unit: Designates whether the In-Row Cooler is a master or standby In-Row Cooler. Each standby In-Row Cooler must
have a corresponding master.
• Master Control: Recommended setting is “Enabled.” When enabled, this means the standby In-Row Cooler will be running
the same control modes as the master to prevent demand fighting. Control modes are: cooling and dehumidifying.
• Rotation Time: Number of days each In-Row Cooler should operate until rotating to the next one.
• Rotation: When enabled, this means after the rotation time expires, the master In-Row Cooler will stand by and the existing
standby In-Row Cooler will resume. This helps balance the run hours between each In-Row Cooler.
Note: In-Row coolers will not rotate if the heat load demands additional cooling.
• Force On: When enabled, if the master In-Row Cooler issues an alarm, it will force the standby In-Row Cooler to function,
regardless of the rotation configuration.
• Group Unit Quantity: Used to set the total size (number of In-Row Coolers) of the group.
• Standby Unit Quantity: Use to set the number of “redundant” In-Row coolers within the group reserved for standby.
• Monitor: This is the In-Row Cooler MODBUS address used for the DCIM.

9
2. Operation and Maintenance
2.2.2 Maintenance Mode
From the home screen, click the Maintenance Mode on/off button. Maintenance Mode temporarily adjusts the cooling output
to 100% to help quickly exhaust heat from the hot aisle to make it more comfortable when servicing IT equipment. No
password is required. The system returns to Auto Mode after 30 minutes. Disable Maintenance Mode in the control menu if
the user wants to prevent use of this feature.
2.3 Data Menus
The data menu enables users and technicians to monitor advanced parameters (read only).

10
2. Operation and Maintenance
2.4 Graph Menu
The graph menu enables users or technicians to view historical trends of the following data points:
• Supply temperature
• Return temperature
• Humidity
• Low (suction) pressure
• High (discharge) pressure

11
2. Operation and Maintenance
2.5 Alarm Menu
Alarms generated are logged in the alarm menu. They will also be displayed in a scrolling banner across the top of the home
screen.
Resolved and/or cleared alarms will be cleared from the current alarm menu and logged into the alarm history. For example, if
a high temperature was detected, but has since dissipated.
For a list of alarms, see section 2.7 Alarms and FAQ.

12
2. Operation and Maintenance
2.6 Regular User Maintenance
• Ensure In-Row Cooler is meeting the setpoint.
• Clean/replace filters every 6 months or when needed.
• Check the alarm log.
• Check for water leaks in or around the In-Row Cooler.
• Ensure working rotation schedule by observing which In-Row Cooler(s) are in standby each week.
2.7 Alarms and FAQ
Alarm/Fault Reason Action(s)
Compressor Fault
Excessive refrigerant in system Remove excess refrigerant
Refrigerant backflow/migration
Check that ambient temperature is above rated condition
(install low ambient kit if necessary)
Ensure necessary piping valves and bends
Ensure condenser height is not above the maximum limit
Inverter fault Refer to inverter fault section
Seized due to oil loss
Ensure proper trapping and pitching of refrigerant lines
Ensure condenser height is not above the maximum limit
Replace compressor
Thermal overload Check integrity of overall system to ensure compressor is
not generating excessive heat
Supply voltage value Check for voltage instability
EEV Fault
High liquid head pressure Ensure condenser vertical height is not higher than
maximum limit
Loss of sub-cooling Ensure sufficient insulation
Ensure condenser elevation is not too low
Inverter Fault
Excessive refrigerant in system Remove excess charge so as to remove liquid refrigerant
from compressor
Power boot sequence fault Reboot system
Unstable power Check for voltage instability
Unstable Cooling Operation
Refrigerant contamination/
overcharge/undercharge Check sight glass to determine quality of refrigerant
Environmental factors Ensure system is installed and configured within
specification
High Supply Air Temperature
(continued on following page)
Invalid upper temperature
threshold Adjust cooling setpoint and thresholds appropriately
Outdoor temperature too hot (if
outdoor ambient temperature is
too hot, the condenser cannot
effectively reject enough heat
and therefore derates the total
system capacity)
When and where possible, turn on additional cooling In-
Row Coolers
Attempt to set the supply air temp and high temp
threshold settings higher (temporarily) to allow the system
to run a bit warmer while allowing the alarm to clear

13
Alarm/Fault Reason Action(s)
High Supply Air Temperature
Heat load exceeds cooling
capacity limit
Adjust airflow limit in factory menu to highest value
Add more cooling devices
Move heat-generating equipment closer to cooling In-Row
Cooler
Add aisle containment or attempt to redirect airflow
Cooling In-Row Cooler will not
come out of standby Ensure group connection is set up properly
Low refrigerant Check for refrigerant leaks, replace necessary components
Add more refrigerant
Issues with directional airflow
configuration
Ensure front and/or side discharge airflow vents do not
have obstructions and are configured properly
Compressor/fan speed is set to
fixed
Raise the upper limit of the temperature band or reset
compressor/fan speed to auto
Condenser signal wiring
disconnected
Ensure condenser signal wiring is still intact
If none of these solutions work, check for component
failure within the refrigeration circuit
Low Supply Air Temperature
Low load (minimum cooling
capacity exceeds the heat load
in the room)
If multiple cooling In-Row Coolers are on, turn off
additional cooling In-Row Coolers by either ensuring group
control is configured properly or manually putting In-Row
Cooler(s) into standby.
Add more thermal load by adding more equipment or
artificial heat (heat banks)
If none of these solutions work, check for component
failure within the refrigeration circuit
Compressor/fan speed is set to
fixed
Lower the lower limit of the temperature band or reset
compressor/fan speed to auto
Condenser signal wiring
disconnected
Ensure condenser signal wiring is still intact
If none of these solutions work, check for component
failure within the refrigeration circuit
High Humidity
High humidity environment Install vapor barrier
Or wait for high humidity conditions to pass
Cooling In-Row Cooler not
dehumidifying Ensure condensate management system is operational
Low Humidity
Dry environment
Add humidification in the IT space
Or adjust the lower humidity limit and wait for the dry
humidity conditions to pass
Cooling In-Row Cooler
dehumidifying
Check that In-Row Cooler is not cooling below the
setpoint.
Report any issues if yes.
Leakage/Water Overflow
Leak in drain pan Repair
Leak in condensate connection
or drainage tube Repair
Fan blowing moisture off
evaporator coil
Record the evaporator fan speed at the time of
occurrence and report any issues
Leak from adjacent equipment/
room Check origin of the leak
Drain pan overflow Ensure drain pan floats are operational
Displaced evaporator Repair
2. Operation and Maintenance

14
Alarm/Fault Reason Action(s)
High Discharge Pressure / HP/
HD Switch Alarm
Dirty condenser coil Clean coil with water
Condenser fan malfunction
Check fan coil and replace if necessary
Ensure fan spins freely
Measure motor amperage and ensure it is not higher than
nameplate
Refrigerant overcharged Remove excess refrigerant; the high pressure in the
control should be between 2.3 to 2.8 MPa
Expansion valve is set too
“loose”
Appropriately adjust the opening degree of the expansion
valve
Expansion valve failure Replace expansion valve
Contaminated refrigerant Check the sight glass for refrigerant quality and level
Replace refrigerant if necessary
Not enough airflow Ensure proper airflow clearances
Condenser signal wiring
disconnected Ensure condenser signal wiring is still intact
Low Suction Pressure
Low heat load (minimum
cooling capacity exceeds the
heat load in the room)
If multiple cooling In-Row Coolers are on, turn off
additional cooling In-Row Coolers by either ensuring group
control is configured properly or manually putting In-Row
Cooler(s) into standby
Dirty filter Replace filter
Refrigerant undercharged Add charge; shall be 9-10 bar, depending on room
temperature
Expansion valve excess
superheat Recalibrate expansion valve
Expansion valve malfunction,
replace
Filter drier plugged
Ensure temp drop across is less than 2°F
Replace if necessary
Kinked liquid line Identify and repair
Low airflow across evaporator Replace filter
Check for obstructions
Condenser signal wiring
disconnected Ensure condenser signal wiring is still intact
In-Row Cooler Maintenance
Time
In-Row Cooler service interval
has expired Perform preventative maintenance, then reset timer
Indoor Fan Maintenance Time
Compressor Maintenance
Time
Outdoor Fan Maintenance
Time
Filter Maintenance Needed
2. Operation and Maintenance

15
2. Operation and Maintenance
Alarm/Fault Reason Action(s)
Suction Temperature Sensor
Failure
Variable causes (ensure
condenser signal wiring is
intact)
Replace as necessary
Supply Temperature Sensor
Failure
Suction Pressure Sensor
Failure
Discharge Pressure Sensor
Failure
Return Temperature Sensor
Failure
Return Humidity Sensor
Failure
Liquid Pipe Temperature
Sensor Failure
Heater Fault (if equipped)
FAQ
Symptom Reason Action(s)
Water Leak Condensate management system leak Consider powering off the cooler and
turning on a different one until the leak
can be diagnosed
Leak detected from another source If leak detection is installed, check to
see if it is triggered by another source
Cooler Discharging Warm Air Excessive heat, not enough cooling Turn on additional In-Row Coolers
Cooling system in standby Fans may rotate while In-Row Cooler
is in standby. If the other coolers are
operational, no action is required
Refrigerant leak / compressor failure Contact technician to diagnose
Cooler Not Responding / Not Turning On Boot sequence Wait for system to finish boot sequence
Initializing Sometimes it takes a while for the
system to initialize; wait a minute or two
and check again
Loss of Cooling Group control not set up properly Configure group control (see group
control section)

16
3. Warranty and Product Registration
1-YEAR LIMITED WARRANTY
Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and
workmanship for a period of 1 year from the date of initial purchase. If the product should prove defective in material or workmanship within
that period, Seller will repair or replace the product, in its sole discretion. Service under this Warranty can only be obtained by your delivering
or shipping the product (with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W. 35th Street, Chicago, IL 60609 USA. Seller will
pay return shipping charges.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER
MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION
TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL
DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This Warranty gives you
specific legal rights, and you may have other rights which vary from jurisdiction to jurisdiction).
WARNING: The individual user should determine prior to use whether this device is suitable, adequate or safe for the use intended. Since
individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or fitness of
this device for any specific application.
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a
FREE Tripp Lite product!
** No purchase necessary. Void where prohibited. Some restrictions apply. Open to U.S. residents only. See tripplite.com for details.
Regulatory Compliance Identification Numbers
For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique series
number. The series number can be found on the product nameplate label, along with all required approval markings and information. When
requesting compliance information for this product, always refer to the series number. The series number should not be confused with the
marking name or model number of the product.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ
slightly from actual products.
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
20-09-020 93-3CC8_RevB

17
Manual del Usuario
Sistema Aire Acondicionado
de Precisión en Hileras
DX Enfriado por Aire, 300 mm de Ancho, 60 Hz, UL
Modelos: SRCOOLDXRW12, SRCOOLDXRW25
(Números de Serie: Unidad Interior: AG-0548, AG-0549; Unidad Exterior: KSF18AN, KSF38AN)
1111 W. 35th Street, Chicago, IL 60609, EE UU • tripplite.com/support
Copyright © 2021 Tripp Lite. Todos los derechos reservados.
English 1 • Françaís 33

18
Índice
1. Información de Seguridad Importante
CONSERVE ESTAS INSTRUCCIONES
Antes de la instalación, operación, mantenimiento o servicio de este equipo, lea cuidadosamente este manual.
Solo personal calificado puede instalar, operar, mantener y dar servicio a este equipo. Los siguientes símbolos pueden
aparecer para advertir de peligros y riesgos potenciales.
PRECAUCIÓN Solo deben usar este dispositivo las personas debidamente capacitadas o calificadas para hacerlo. Cualquier
persona que no esté capacitada o calificada no debe usar este dispositivo a menos que esté bajo la supervisión de alguien
que esté debidamente capacitado o calificado para hacerlo. Los niños deben ser supervisados para asegurarse de que no
usen el dispositivo como juguete.
Este aparato se clasifica como APARATO NO ACCESIBLE PARA EL PÚBLICO EN GENERAL. Si el cable de alimentación está
dañado, debe ser reemplazado por el fabricante, su agente de servicio o personal con calificación similar a fin de evitar un
riesgo. El aparato se instalará de acuerdo con los reglamentos nacionales de cableado.
El usuario debe instalar un dispositivo de corriente residual (RCD) provisto por el usuario con un dispositivo de desconexión de
todo el poste con al menos 3 mm [0.118”] de distancia de separación y una especificación superior a 10 mA en el cableado
fijo de acuerdo con los códigos eléctricos nacionales y locales.
1.1 Explicación de los Símbolos
Los siguientes símbolos ilustran mensajes para advertir sobre el peligro potencial y la necesidad de precaución y atención.
Este símbolo indica que, al no cumplir con las instrucciones, habrá un riesgo de descarga eléctrica que resultará en
lesiones, como se señala en las etiquetas de seguridad de “PELIGRO” o “ADVERTENCIA”.
Este es un símbolo de alerta de seguridad usado para advertir sobre posibles riesgos de lesiones personales. Siga
toda la información de seguridad para evitar la ocurrencia de lesiones personales o la muerte.
1. Información de Seguridad 18
Importante
1.1 Explicación de los Símbolos 18
1.2 Manejo de la Información 19
2. Operación y Mantenimiento 21
2.1 Introducción 21
2.2 Pantalla de Inicio 22
2.2.1 Menú de Configuración 23
2.2.2 Modo de Mantenimiento 25
2.3 Menús de Datos 25
2.4 Menú Gráfico 26
2.5 Menú de Alarma 27
2.6 Mantenimiento Regular 28
del Usuario
2.7 Alarmas y Preguntas y 28
Respuestas Frecuentes
3. Garantía 32
Para obtener instrucciones de instalación, consulte el Manual de Instalación
específico.

19
1. Información de Seguridad Importante
PELIGRO
PELIGRO indica una situación de peligro inminente que, de no evitarse, causará lesiones graves o fatales.
PELIGRO
Peligro de descarga eléctrica, explosión o de arco eléctrico
• Ocupe el equipo de protección personal [PPE] apropiado y siga prácticas eléctricas seguras.
• Este equipo debe ser instalado y atendido solamente por personal calificado de HVAC.
• Cumpla con todos los reglamentos de cableado y seguridad aplicables, nacionales y locales, en donde se vaya
a instalar la unidad, p.e. el Código Eléctrico Nacional {NEC] en los Estados Unidos.
• Apague todo el suministro de energía a este equipo antes de trabajar en él o dentro de él.
• Use siempre un dispositivo de detección de voltaje correctamente especificado para confirmar que la energía
está apagada.
• Reemplace todos los dispositivos, puertas y tapas antes de encender este equipo.
• Solo deben usar este dispositivo aquellos que estén debidamente capacitados o calificados para hacerlo.
Cualquier persona que no esté capacitada o calificada no debe usar este dispositivo a menos que esté bajo la
supervisión de alguien que esté debidamente capacitado o calificado para hacerlo.
El incumplimiento de esta advertencia puede ocasionar lesiones graves o fatales.
ADVERTENCIA
ADVERTENCIA indica una situación potencialmente peligrosa que, si no se evita, puede causar lesiones graves o
fatales.
PRECAUCIÓN
PRECAUCIÓN indica una situación potencialmente peligrosa que, si no se evita, puede resultar en lesiones
menores o moderadas.
AVISO
AVISO aborda prácticas no relacionadas con lesiones físicas, incluyendo ciertos riesgos ambientales, daño
potencial o pérdida de datos.
1.2 Manejo de la Información
Antes de instalar, operar, dar mantenimiento o servicio al equipo, lea la información de manejo. Cumpla con los reglamentos y
leyes locales al manejar el refrigerante.

20
1. Información de Seguridad Importante
ADVERTENCIA
Riesgo por piezas móviles
• Mantenga las manos, la ropa y las joyas alejadas de las partes móviles. Revise el equipo para detectar objetos
extraños antes de cerrar las puertas y arrancar el equipo.
El incumplimiento de esta advertencia puede ocasionar lesiones graves o fatales.
PRECAUCIÓN
Riesgo para el equipo o el personal
• Todo el trabajo debe ser realizado solamente por personal calificado.
El incumplimiento de esta advertencia puede ocasionar lesiones graves o fatales.
ADVERTENCIA
Riesgo de caída del equipo
• Use dos o más personas en todo momento para mover o girar este equipo.
• Siempre empuje, jale o gire viendo hacia el frente y la parte posterior de este equipo. Nunca empuje, jale o gire
viendo hacia los lados de este equipo.
• Mueva lentamente este equipo a través de superficies o umbrales de puerta desnivelados.
• Baje las patas niveladoras al piso cuando este equipo esté en reposo.
• Baje las patas niveladoras y fije los soportes de unión a los racks adyacentes cuando este equipo esté en su
posición final.
El incumplimiento de esta advertencia puede causar lesiones graves o daños al equipo.
PRECAUCIÓN
Riesgo para el equipo o el personal
• Asegúrese de que no haya piezas de repuesto o herramientas en el equipo antes de manipularlo.
• No opere la unidad sin el filtro de aire. Esto puede causar acumulación de polvo que puede dañar la unidad.
El incumplimiento de esta advertencia puede causar lesiones graves o daños al equipo.
PRECAUCIÓN
Alta presión de refrigerante y riesgo para el equipo
• Esta unidad opera bajo alta presión. Observe las precauciones de seguridad adecuadas durante la operación o
mantenimiento de la unidad.
• El equipo debe cargarse solamente con R-410A.
• La tubería de cobre debe soportar un mínimo de presión de 55 bar.
El incumplimiento de esta advertencia puede causar lesiones graves o daños al equipo.
