Installation Manual
In-Row Precision
Air Conditioning System
DX Air-Cooled, 300 mm Wide, 60 Hz, UL
Models: SRCOOLDXRW12, SRCOOLDXRW25
Combination Model Indoor Cooling Unit Outdoor Unit/Condenser
SRCOOLDXRW25 SRCOOLDXRW25ID SRCOOLDXRW25OD
Series: AG-0549 Series: KSF38AN
SRCOOLDXRW12 SRCOOLDXRW12ID SRCOOLDXRW12OD
Series: AG-0548 Series: KSF18AN
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Español 25 • Français 49

2
Table Of Contents
1. Important Safety Information
SAVE THESE INSTRUCTIONS
Prior to installation, operation, maintenance or servicing of this equipment, read this manual thoroughly.
Only qualified personnel may install, operate, maintain and service this equipment.
CAUTION This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of
the appliance by person responsible for their safety. Children should be supervised to ensure that they do not play with the
appliance.
This appliance is classified as APPLIANCE NOT ACCESSIBLE TO THE GENERAL PUBLIC. If the supply cord is damaged, it
must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The appliance
shall be installed in accordance with national wiring regulations
The user must install a user-supplied residual current device (RCD) with an all-pole disconnection device with at least
0.118 in. (3 mm) separation distance and a rating of above 10mA into the fixed wiring according to national and local
electrical codes.
1.1 Explanation of Symbols
The following symbols illustrate messages to warn of potential danger and need for caution and attention.
This symbol indicates that with failure to comply with the instructions, there will be a risk of electric shock resulting in
injury, as noted in the “DANGER” or “WARNING” safety labels.
This is a safety alert symbol used to warn of potential personal injury hazards. Follow all safety information to avoid
personal injury or death.
1. Important Safety Information 2
1.1 Explanation of Symbols 2
1.2 Handling Information 3
2. In-Row Cooler Installation 5
2.1 Unpacking 5
2.2 Side Air Discharge 5
2.3 Placement Clearance 6
3. Condenser Installation 7
(Outdoor Unit)
3.1 Condenser Elevation 7
and Distance
3.2 Attach Supplied Lifting Brackets 7
and Screws to Condenser
3.3 Lifting Crane 7
3.4 Condenser Leg Installation 8
3.5 Mounting Clearance 8
3.6 Condenser Pad 11
4. Piping Installation 12
4.1 Recommended Piping 14
Diameters
4.2 Condensate Drainage 15
5. Electrical Installation 16
6. Startup and Commissioning 19
6.1 Pre-Startup Information 19
6.2 Oil Charging 20
6.3 Refrigerant Charging 21
6.4 Post-Startup Information 21
6.5 Commissioning 22

3
1. Important Safety Information
DANGER
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
DANGER
Hazard of electric shock, explosion or arc flash
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices.
• This equipment must be installed and serviced by qualified HVAC personnel only.
• Comply with all local and national wiring and safety regulations applicable where unit will be installed, e.g.
National Electric Code (NEC) in the United States.
• Turn off all power supplying this equipment before working on or inside of the equipment.
• Always use a properly rated voltage sensing device to confirm power is off.
• Replace all devices, doors and covers before turning on power to this equipment.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
Failure to observe this warning may result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, can result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, can result in minor or moderate injury.
NOTICE
NOTICE addresses practices not related to physical injury including certain environmental hazards, potential
damage or loss of data.
1.2 Handling Information
Read handling information prior to installing, operating, servicing or maintaining the equipment. Comply with local regulations
and laws when handling refrigerant.
WARNING
Hazard from moving parts
• Keep hands, clothing, and jewelry away from moving parts. Check the equipment for foreign objects before
closing the doors and starting the equipment.
Failure to observe this warning may result in death or serious injury.

4
The SRCOOLDXRW12 and SRCOOLDXRW25 In-Row Air Conditioning Systems are precision, split type, DX, air-cooled systems.
They require copper piping connections to bridge the In-Row Cooler (indoor) with the condenser (outdoor). No ductwork
or raised floor is required. As a result, these are dedicated cooling systems, meaning the design enables them to operate
independently of the building’s HVAC/comfort cooling system.
The system requires charging with R-410A refrigerant.
Notes:
• These are cooling-only devices with no heating capability.
• In-Row Coolers shall be spaced properly to provide coverage across all rack enclosures. Ensure the total number and placement of all
coolers adheres to the redundancy model required as per customer design. Typical redundancy is n+1.
• Install the In-Row Cooler either on a solid surface or a raised floor. Ensure the floor is level.
• The In-Row Cooler design is for data centers and other cleanroom applications. It is not intended for harsh or dirty environments.
1. Important Safety Information
CAUTION
Hazard to equipment or personnel
• All work must be performed only by qualified personnel.
Failure to observe this warning may result in death or serious injury.
WARNING
Hazard of equipment falling over
• Use two or more persons at all times to move or turn this equipment.
• Always push, pull, or turn while facing the front and rear of this equipment. Never push pull, or turn while facing
the sides of this equipment.
• Slowly move this equipment across uneven surfaces or door thresholds.
• Lower leveling feet to floor when this equipment is at rest.
• Lower leveling feet and attach joining brackets to adjacent racks when this equipment is in final position.
Failure to observe this warning may result in serious injury or equipment damage.
CAUTION
Hazard to equipment or personnel
• Make sure no spare parts or tools are in the equipment before handling the equipment.
• Do not operate unit without the air filter. This may cause dust accumulation that can damage the unit.
Failure to observe this warning may result in serious injury or equipment damage.
CAUTION
Refrigerant high pressure and hazard to equipment
• This unit operates under high pressure. Observe proper safety precautions when operating or servicing the unit.
• The equipment is to be charged with R-410A refrigerant only.
• Copper pipe must support minimum 55 bar pressure.
Failure to observe this warning may result in serious injury or equipment damage.

5
2. In-Row Cooler Installation
• For maximum cooling performance in humid environments, install vapor barriers on walls and floors to ensure the cooler is generating the
highest amount of sensible vs. latent cooling.
• This product is rated for 64.0 to 98.6°F (17.7 to 37°C), 20 to 80% RH indoor temperature and 14 to 95°F (-10 to 35°C) outdoor
temperature. The system continues operating when the outdoor temperature is up to 113°F (45°C), but at reduced cooling capacity and
efficiency. The system is protected for temperatures above 113°F (45°C). Contact the manufacturer if over range.
Minimum/maximum air temperature test was conducted at 55°F (12.8°C) indoor temperature and 5°F (-15°C) outdoor temperature /
116.6°F (47°C) indoor temperature and113°F (45°C) outdoor temperature for cooling mode.
• GWP for R410A (R32/125: 50/50): 2087.5.
2.1 Unpacking
Refer to the unpacking guide attached to the outside of the In-Row Cooler container.
Note: Retain the shipping brackets attached to the In-Row Cooler if installation will be anchored to the floor.
2.2 Side Air Discharge
CAUTION: Remove front airblock (if installed flush) or install perforated side panels (if installed protruded)
before turning on the In-Row Cooler. Failure to do so will result in damage to the In-Row Cooler.
The In-Row Cooler ships with both the solid front door airblock and the solid side discharge panels pre-installed. Configure the
air discharge according the following table.
Table: Air Discharge Configurations
Front of In-Row Cooler Alignment Front Door Airblock Side Airblock Type
Flush, front-only discharge Removed Solid panels
Protruded, side-only discharge Installed Perforated panels
Protruded, front and side discharge Removed Perforated panels
Figure 2-1: Perforated side panels installed, front airblock installed. Figure 2-2: Solid side panels installed, front airblock removed.

6
2. In-Row Cooler Installation
2.3 Placement Clearance
Using its casters, install the In-Row Cooler beside a rack enclosure. Ensure the installation area has sufficient clearance for
both airflow and maintenance and repair. Refer to Figure 2-3: Installation Clearance Requirements below.
Figure 2-3: Installation Clearance Requirements
If installing the cooling unit at the end of a row, a minimum of 19 in. (460 mm) clearance is needed on the side for servicing.
Adjust the leveling feet to ensure the entire unit is level for proper condensate drainage.
Secure the unit directly to the adjacent rack enclosure using baying brackets. For installation next to Tripp Lite racks, use the
Z-shaped baying brackets included with the cooler. Refer to Protruded (left) and Flush (right) installation diagram below.
Figure 2-4: Protruded (left) and Flush (right) installation
39.4 in.
(1000 mm)
48 in.
(1200 mm)

7
3. Condenser Installation (Outdoor Unit)
Note: Avoid installing the condenser in areas with excess heat, dust or debris. Refer to local codes and regulations for proper reinforcement
for high wind areas. The maximum outdoor operating temperature is 110ºF (43ºC).
3.1 Condenser Elevation and Distance
Confirm that the vertical distance between the condenser and In-Row Cooler is within the range listed in the Condenser
Elevation Installation Limits table.
Take measurements from the bottom surface (excluding legs) of the condenser to the bottom surface of the In-Row Cooler.
Table: Condenser Elevation Installation Limits
Type Vertical height value
Positive (condenser higher than indoor unit) Max: +65 ft. (20 m), bottom-to-bottom
Negative (condenser lower than indoor unit) Max: -16 ft. (-5 m)
3.2 Attach Supplied Lifting Brackets and Screws to Condenser
Figure 3-1: Attach Supplied Lifting Brackets and Screws to Condenser
Note: After removing the lifting brackets, save the screws; they will be used to attach the condenser’s legs at a later time (refer to section
3.4 Condenser Leg Installation for more information).
3.3 Lifting Crane
If the condenser will be installed on a rooftop, a lifting crane may be required.
Figure 3-2: Example of Lifting the Condenser

8
3. Condenser Installation (Outdoor Unit)
3.4 Condenser Leg Installation
If necessary, install the mounting support legs (SRCOOLDXRW25 horizontal mount only).
Figure 3-3: Condenser Leg Installation
3.5 Mounting Clearance
Place the condenser on its base and into position. Ensure the installation area has sufficient clearance for both airflow and
maintenance and repair. Refer to following Figures 3-4A and 3-4B.
Figure 3-4A: Installation Clearance Requirements - Condenser (SRCOOLDXRW12)
49 in.49 in.
(1240 mm)(1240 mm)
31.5 in.31.5 in.
(800 mm)(800 mm)
19.7 in.19.7 in.
(500 mm)(500 mm)
31.5 in.31.5 in.
(800 mm)(800 mm)
118 in.118 in.
(3000 mm)(3000 mm)

9
3. Condenser Installation (Outdoor Unit)
Figure 3-4B: Installation Clearance Requirements – Condenser (SRCOOLDXRW25)
40 in.40 in.
(1016 mm)(1016 mm)
20 in.20 in.
(498 mm)(498 mm)
31 in.31 in.
(788 mm)(788 mm)
40 in.40 in.
(1016 mm)(1016 mm)
31 in.31 in.
(788 mm)(788 mm)

10
3. Condenser Installation (Outdoor Unit)
Anchor the condenser using expansion bolts according to the hole locations shown in the “Condenser Mounting Interface”
figures below.
Figure 3-5: Condenser Mounting Interface (bottom view looking up), SRCOOLDXRW12
Figure 3-6: Condenser Mounting Interface (condenser inlet side looking up), SRCOOLDXRW25 (horizontal installation)
17.6 in.
(447 mm)
23.6 in.
(599.4 mm)
31.5 in.
(800.1 mm)
12.8 in.
(325.1 mm)
13.3 in.
(337.8 mm)
3.9 in.
(99.1 mm)
3.9 in.
(99.1 mm)
44.3 in.
(1125.2 mm)
33 in.
(838.2 mm)
37.1 in.
(924.3 mm)
48.5 in.
(1231.9 mm)

11
3. Condenser Installation (Outdoor Unit)
Figure 3-7: Condenser Mounting Interface (side mounted, bottom view looking up), SRCOOLDXRW25 (vertical installation)
3.6 Condenser Pad
If installing the condenser on the ground, provide a cement pad that extends at least 2 in. (50 mm) from all sides of the
condenser.
Note: For colder weather installations, make sure to keep the condenser off of the ground.
Refer to local codes for pad height and other condenser pad requirements.
48.8 in.
(1240 mm)
9.8 in.
(250 mm)

12
Note: The cooling system shall be installed by a professional HVAC installer and in accordance with local codes and regulation.
The In-Row Cooler accepts either top or bottom connections.
Table: Unit Connections
Model SRCOOLDXRW12 SRCOOLDXRW25
Refrigerant Discharge 5/8 in. (16 mm) 5/8 in. (16 mm)
Refrigerant Liquid 1/2 in. (12 mm) 5/8 in. (16 mm)
Notes:
• It is good practice to install isolation valves near the In-Row Cooler on both the discharge and liquid piping for easy removal. Isolation
valves are not included with the system.
• For outdoor operating temperatures less than -4°F (-20°C), install the Low Temperature Kit (SRCOOLDXRWLTKIT) according to the
instructions provided with the kit.
Figure 4-1: Piping Examples
4. Piping Installation
Condenser
Check Valves
Condenser (Positive Elevation)
Liquid & Gas Pipe
(Heat Insulation)
Oil Traps
Indoor Ball Valves
Heat Shield
Condensate Drain (Incline)
Maximum Height 65 ft. (20 m)
20 ft. (6 m)
Floor
Indoor
Unit
Gas Pipe
(Incline)
AC
Indoor Check Valves
Indoor
Unit
AC
Heat Shield
Condensate Drain (Incline)
Floor Gas Pipe
(Incline)
Condenser
(Negative
Elevation)
Maximum 16 ft. (5 m)
Condenser Check Valves
Liquid &
Gas Pipe
(Heat Insulation)
1 in. per 10 ft.
(10 mm per 1 m)
1 in. per 10 ft.
(10 mm per 1 m)
1 in. per 10 ft.
(10 mm per 1 m) 1 in. per 10 ft.
(10 mm per 1 m)

13
• Pitch the discharge piping down and away from the In-Row Cooler at a decline of 1 in. per 10 ft. (10 mm per 1 m).
• Use Type L ACR copper tubing.
• Install tube supports where necessary.
• When passing piping through a wall or other obstacle, use a brass cushion to prevent direct contact with the wall when
vibration occurs.
• Insulate the liquid line to prevent exposure to direct sunlight.
Notice the trap locations in Figure 4-2: Piping Trap Examples below. Traps installed in the discharge and liquid piping prevent
liquid backflow to the In-Row Cooler and help retain compressor oil when in standby or powered off.
P-Trap S-Trap Inverted-Trap
Figure 4-2: Piping Trap Examples
Whenever the condenser is located above the In-Row Cooler:
• Install a P-trap at the lowest pitched point of the horizontal discharge piping.
• Install inverted traps or check valves at the condenser inlet and outlet.
• Install an S-trap every 20 ft. (6 m) of vertical height of the discharge piping when the installation vertical height is over 30 ft.
(10 m). Refer to the Vertical Discharge Piping S-Traps table.
Table: Vertical Discharge Piping S-Traps
Vertical Distance Number of Traps
Less than 30 ft. (10 m) 0
30 to 40 ft. (10 to 12 m) 1
40 to 60 ft. (12 to 18 m) 2
60 to 65 ft. (18 to 20 m) 3
Note: Calculate the number of inverted traps from the total vertical height, not per individual vertical run. For example, two vertical runs of
18 ft. each is a total of 36 ft., which requires one inverted trap.
Using the Equivalent Length of the Sub-Assembly table, multiply the equivalent length of each elbow type by the total
quantity of each elbow, based off Table: Recommended Piping Diameters.
4. Piping Installation

14
4. Piping Installation
4.1 Recommended Piping Diameters
Based on the proposed piping layout and the actual locations of both the In-Row Cooler and the condenser, calculate the total
equivalent piping distance, including bends and traps, to determine the necessary piping diameters.
Note: For equivalent piping length longer than 100 ft. (30 m), use the long piping kit (SRCOOLLONGPKIT).
Look up the recommended piping diameters for both the discharge and liquid piping using the Table: Recommended Piping
Diameters.
Table: Recommended Piping Diameters (Use Type L ACR Copper Tubing)
Discharge horizontal Discharge vertical Liquid line
Equivalent length 0 to 32.5 ft. (0 to 10 m)
SRCOOLDXRW12 5/8" 5/8" 1/2"
SRCOOLDXRW25 7/8" 7/8" 1/2"
Equivalent length 32.5 to 65 ft. (10 to 20 m)
SRCOOLDXRW12 5/8" 5/8" 1/2"
SRCOOLDXRW25 7/8" 7/8" 1/2"
Equivalent length 65 to 100 ft. (20 to 30 m)
SRCOOLDXRW12 3/4" 5/8" 1/2"
SRCOOLDXRW25 7/8" 3/4" 5/8"
Note: Installations at distances greater than 30 m (100 ft.) require using the Long Pipe Kit (SRCOOLLONGPKIT).
Equivalent length 100 to 130 ft. (30 to 40 m)
SRCOOLDXRW12 3/4" 5/8" 5/8"
SRCOOLDXRW25 1" 7/8" 5/8"
Equivalent length 130 to 165 ft. (40 to 50 m)
SRCOOLDXRW12 7/8" 3/4" 5/8"
SRCOOLDXRW25 1" 7/8" 5/8"
Maximum equivalent length 165 to 200 ft. (50 to 60 m)
SRCOOLDXRW12 7/8" 3/4" 5/8"
SRCOOLDXRW25 1" 7/8" 3/4"
Note: For equivalent distance greater than 32.5 ft., the vertical discharge piping is generally one size smaller than the horizontal to improve
velocity.

15
4. Piping Installation
Table: Equivalent Length of the Sub-Assembly with the Following Piping Turns/Angles
Piping Diameter (in.)
Equivalent Length
Elbow 90° Elbow 45° T-Piece
3/8 0.7 ft. (0.21 m) 0.3 ft. (0.1 m) 2.5 ft. (0.76 m)
1/2 0.8 ft. (0.24 m) 0.4 ft. (0.12 m) 2.5 ft. (0.76 m)
5/8 0.9 ft. (0.27 m) 0.5 ft. (0.15 m) 2.5 ft. (0.76 m)
3/4 1 ft. (0.3 m) 0.6 ft. (0.18 m) 2.5 ft. (0.76 m)
7/8 1.4 ft. (0.44 m) 0.8 ft. (0.24 m) 3.6 ft. (1.1 m)
1 1.6 ft. (0.5 m) 0.9 ft. (0.27 m) 4.1 ft. (1.25 m)
1-1/8 1.8 ft. (0.56 m) 1 ft. (0.3 m) 4.6 ft. (1.4 m)
4.2 Condensate Drainage
Ensure there is access to a nearby water drain for the condensate management system.
The In-Row Cooler comes preinstalled with a condensate management system and ships with condensate tubing.
Connect the drain tube to the In-Row Cooler (see Table: Drain connection information) from either the top or the bottom.
Table: Drain connection information – SRCOOLDXRW12, SRCOOLDXRW25
Connection Size 1/4 in.
Drain Tube Length 13 ft. (4 m)
Max Flow 2.4 gal/h (9 L/h)
Maximum Lift 26.5 ft. (8 m)*
Maximum Distance 150 ft. (45 m)*
*Note: 1 foot of lift equals 10 feet of distance.
• Pitch the discharge piping down and away from the In-Row Cooler at a decline of 1 in. per 10 ft. (10 mm per 1 m)
• Ensure not to expose the drain tube to freezing temperatures
• Perform a test with water to ensure the drainage system is working properly

16
5. Electrical Installation
Notes:
• All electrical connections shall be performed by a qualified electrician and must comply with local codes and regulations.
• The In-Row Cooler supplies power to the condenser.
• The In-Row Cooler accepts both delta and wye connections.
Disconnect power at the source prior to making electrical connections.
Supply power to the In-Row Cooler according to its nameplate.
Cable size should meet the electrical requirements.
Table: In-Row Cooler Nameplate Power Information
Model
SRCOOLDXRW12:
In-Row Cooler + Condenser
SRCOOLOXRW25:
In-Row Cooler + Condenser
Voltage 208V 208V
Phase 3ph 3ph
Frequency 60 Hz 60 Hz
MCA (Minimum Current Ampacity) 19A 33A
MOP (Maximum Overcurrent Protection) 25A 50A
Model
SRCOOLDXRW12:
Condenser Only
SRCOOLOXRW25:
Condenser Only
Voltage 208V 208V
Phase 1ph 1ph
Frequency 60 Hz 60 Hz
Table: Motor Protection Information
Model SRCOOLDXRW12 SRCOOLOXRW25
Main breaker 63A 3-poles 63A 3-poles
Compressor fuse 15A 15A
Compressor breaker 32A 3-poles 20A 3-poles
Indoor fan breaker 20A 2-poles 20A 2-poles
Outdoor fan fuse — S505-5-R (5A)
Outdoor fan breaker 20A 2-poles (location indoor unit) 20A 3-poles

17
5. Electrical Installation
L3L2
L1
NP E
M ain P o w er
L2
L1
P E
0
YC o n d e n ser
P o w er
C o n d e n ser
S ig n al
L2L1
H eater
P o w e r fo r
Lo w Te m p L2
L1
So len o id
P o w e r fo r
Lo w Te m p
W eb card
M o d b u s
TC P
L2L1
So len o id
P o w e r fo r
Exten sio n
P ip e
P E
Figure 5-1a: Electrical Connections, SRCOOLDXRW12
L3L2
L1
NP E
M ain P o w er
L3L2
L1
P E
0
YC o n d e n ser
P o w er
C o n d e n ser
S ig n al
L2
L1
H eater
P o w er fo r
Lo w Te m p L2
L1
So len o id
P o w er fo r
Lo w Te m p
L2
L1
So len o id
P o w er fo r
Exten sio n
P ip e
P E
W eb card
M o d b us
TC P
Figure 5-1b: Electrical Connections, SRCOOLDXRW25
Condenser
Signal
Modbus
TCP
Webcard Heater
Power for
Low Temp
Solenoid
Power for
Low Temp
Solenoid
Power for
Extension
Pipe
Condenser
Power Main Power
Condenser
Signal
Modbus
TCP
Webcard Heater
Power for
Low Temp
Solenoid
Power for
Low Temp
Solenoid
Power for
Extension
Pipe
Condenser
Power Main Power

18
5. Electrical Installation
Apply strain relief per Figures 5-2A and 5-2B:
Figure 5-2A: Strain Relief from Above Figure 5-2B: Strain Relief from Below
Figure 5-3A: Electrical Connections, Figure 5-3B: Electrical Connections,
SRCOOLDXRW12 Condenser (Outdoor Unit) SRCOOLDXRW25 Condenser (Outdoor Unit)
Main
Power
Main
Power
Fan
Signal
Fan
Signal

19
6. Startup and Commissioning
6.1 Pre-Startup Information
Contact your service organization for official pre-startup checklist
Review the installation procedure and ensure all steps are completed properly. Ensure the room has proper vapor barrier in
place.
❏ q Visual safety inspection done ________________________________________
❏ q Service clearances (In-Row and condensers) checked __________________
❏ q Isolation valves installed (if specified by customer) ______________________
❏ q All accessories installed ___________________________
Review the electrical wiring and connections and ensure it is safe, done properly and compliant to code.
❏ q In-Row power is within range of nameplate ______V _____ Ph _____ Hz
❏ q Outdoor power input is within range of nameplate ______V _____ Ph _____ Hz
❏ q Circuit breaker/fuse sizes _______________________________________
❏ q Condenser control wiring connected _______________________
Check proper sizing and installation (including hangers and supports) of the refrigerant piping. Check for missing panels or
other items and ensure professional appearance for the customer.
❏ q Number of bends and traps recorded _________________________________
❏ q Condenser elevation (above In-Row Cooler) recorded ___________________________________
❏ q Piping diameters recorded ______________________________________
❏ q Pitching of horizontal lines ___________________________________
❏ q Piping clamps, cushioning and insulation present _________________________________
❏ q Long piping kit is present _________________________________
❏ q Condensate drain line routed properly _____________________________

20
6. Startup and Commissioning
6.2 Oil Charging
Use RL68H synthetic oils (or equivalent with the same viscosity). Calculate the additional amount according to the following
formula:
For pipe length up to but not exceeding 33 ft. (10 m):
Liquid Pipe Diameter (in.) Length Ratio (lb/ft)
3/8 0.039
1/2 0.075
5/8 0.122
3/4 0.145
7/8 0.243
Note: For installations where the pipe to the condenser unit exceeds 33 ft. (10 m), the use of the SRCOOLLONGPKIT is required.
Instructions for oil changing and additional refrigerant are included with the SRCOOLLONGPKIT.
Additional amount (lb.) if same as long pipe kit = Length ratio
R (kg) =
( )
lb.
ft.
Amounttotal
2.2
x Liquid line length (ft.)
