Tripp Lite U442-DOCK3-B User manual

1
Owner’s Manual
Portable USB 3.2 Gen 1 USB-C®
Docking Station - Black
Model: U442-DOCK3-B
Español 12 • Français 22 • Русский 32
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind. You could also win an
ISOBAR6ULTRA surge protector—a $100 value!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.

2
Optional Accessories
Package Contents
• N201-Series Cat6 Gigabit Snagless Patch Cables
• P502-Series High-Resolution VGA Cables
• P566-Series HDMI to DVI Adapter Cables
• P568-Series High-Speed HDMI Cables
• U322-Series USB 3.2 A/B Device Cables
• U326-Series USB 3.2 Micro-B Device Cables
• U420-003-G2-5A USB 3.2 Gen 2 USB-C M/M
Cable, 3 ft.
• U442-DOCK3-B
• Owner’s Manual
System Requirements
• Computer with USB-C or Thunderbolt™ 3 port
that supports USB DisplayPort Alternate Mode
• VGA, DVI* or HDMI monitor
• Ethernet network with speeds up to
10/100/1000 Mbps
*Requires an adapter, such as Tripp Lite’s P566-Series.
See Optional Accessories.
USB Type-C and USB-C are trademarks of USB
Implementers Forum.

3
Product Features
• Supports USB DisplayPort Alternate Mode for
connecting a VGA or an HDMI monitor via a USB-C
or Thunderbolt 3 port
• Supports connection of DVI monitor via HDMI
to DVI adapter (see Optional Accessories)
• HDMI port supports video resolutions up to
3840 x 2160 (4K x 2K) @ 30 Hz
• VGA port supports video resolutions up to
1920 x 1200, including 1080p @ 60 Hz
• Ethernet port supports true 10/100/1000 Mbps
network speeds
• USB-A hub and Type-C data ports support data
transfer rates up to 5 Gbps
• Dedicated USB-A port provides up to 5V/1.5A of
fast charging power to mobile devices
• USB-C PD charging port for charging your device;
supports power input up to 20V 5A (100W)
• Micro SD and SD/MMC Memory Card Slots
allow external memory access via a USB-C or
Thunderbolt port
• Two USB-A and one Type-C data ports share a
maximum 10W (5V 2A) of power
• Supports PD 3.0 Fast Role Swap to maintain
data and power connection upon removal of
charging power
• Automatically resumes operation from hibernation
and suspend mode

4
Product Features
• IEEE 802.3az (Energy Efficient Ethernet) compliant
• Supports full-duplex and half-duplex operations
• Supports IPv4 and IPv6 pack Checksum Offload
Engine (COE) to reduce CPU loading
• Supports Wake-on-LAN
• Compact design fits easily into your laptop bag
for travel
• Plug-and-play; no software or drivers required

5
Product Overview
1USB-C 3.2 Data Port (Female): connects to
USB-C device
2USB-A Ports (Female): connect up to 2 USB
peripherals
Note: Port located next to the memory card slots provides
charging.
3Micro SD Memory Card Slot: insert Micro SD
Memory Card
4SD/MMC Memory Card Slot: insert SD/MMC
Memory Card
5HDMI Port (Female): connects HDMI monitor
6VGA Port (Female): connects VGA Monitor
7RJ45 Port (Female): connects to 10/100/1000
Mbps network
8USB-C PD Charging Port (Female): connects
device to USB-C charger
1 3
4
2
5 6 7 8

6
Installation
Notes:
• Only one monitor can be connected at a time.
• Only one memory card slot can be used at a time.
• When connected to power through USB-C charging port,
15W of power is dedicated to the docking station and
connected USB peripherals. The rest is used to charge the
connected device.
• See Optional Accessories section for suggested cables.
• When the unit is connected to the USB-C port on your
computer and to a network via Cat5e/6 cabling, a
network connection will be automatically established. If
no connection is made, you can manually establish one
by going to your computer’s network settings page. For
example, on a Mac you would navigate to the Network
section found in System Preferences, click the “Assist Me”
button to get to the Network Setup Assistant and follow the
prompts to establish a connection.

7
Installation
1. Connect the dock’s USB Type-C connector to the
USB-C or Thunderbolt 3 port on your laptop, tablet
or other device.
2. Connect the dock’s VGA port to the VGA port on a
monitor using a VGA cable.
or
Connect the dock’s HDMI port to the HDMI port on
a monitor using a HDMI cable.
3. Connect up to 2 USB devices to the dock’s USB-A
hub ports.
4. Connect a USB Type-C device to the dock’s Type-C
data port.
5. Connect the adapter’s RJ45 port to a network
using a UTP cable.
6. Insert Micro SD or SD/MMC card into the
corresponding memory card slot to access
external memory.
7. Charge your device by connecting its USB-C
charger to the adapter’s USB-C port.

8
Specifications
Input Connectors
USB USB-C (M)
Charging USB-C (F)
Output Connectors
USB-A (2x) USB-A (F)
USB-C USB 3.2 Type-C Data (F)
10/100/1000 Ethernet RJ45 (F)
VGA VGA (F)
HDMI HDMI (F)
Memory Card Slots Micro SD and SD/MMC
Environmental
Operating Temperature 32° to 113°F (0° to 45°C)
Operating Humidity 10% to 90% RH,
Non-Condensing
Storage Temperature 14° to 158°F
(-10° to 70°C)
Storage Humidity 10% to 90% RH,
Non-Condensing
Power Requirements
USB-C Charging Port Supports up to 20V 5A
(100W) Input

9
Warranty and Product Registration
3-Year Limited Warranty
Tripp Lite warrants its products to be free from defects in
materials and workmanship for a period of three (3) years from
the date of initial purchase. Tripp Lite’s obligation under this
warranty is limited to repairing or replacing (at its sole option)
any such defective products. To obtain service under this
warranty, you must obtain a Returned Material Authorization
(RMA) number from Tripp Lite or an authorized Tripp Lite
service center. Products must be returned to Tripp Lite or an
authorized Tripp Lite service center with transportation charges
prepaid and must be accompanied by a brief description of the
problem encountered and proof of date and place of purchase.
This warranty does not apply to equipment, which has been
damaged by accident, negligence or misapplication or has
been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. Some states do not permit limitation or exclusion
of implied warranties; therefore, the aforesaid limitation(s) or
exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE. Specifically, Tripp Lite is not liable for any costs, such
as lost profits or revenue, loss of equipment, loss of use of
equipment, loss of software, loss of data, costs of substitutes,
claims by third parties, or otherwise.

10
Warranty and Product Registration
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some
restrictions apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.

11
Warranty and Product Registration
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to operate
this equipment.
WEEE Compliance Information for Tripp Lite Customers
and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations,
when customers buy new electrical and electronic
equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one,
like-for-like basis (this varies depending on the
country)
• Send the new equipment back for recycling when
this ultimately becomes waste
Use of this equipment in life support applications where failure
of this equipment can reasonably be expected to cause the
failure of the life support equipment or to significantly affect its
safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
21-08-214 9337B5_RevB

12
Manual del Propietario
Estación de Conexión Portátil
USB 3.2 Gen 1 USB-C®- Negra
Modelo: U442-DOCK3-B
English 1 • Français 22 • Русский 32
1111 W. 35th Street, Chicago, IL 60609 EE UU
tripplite.com/support
Copyright © 2021 Tripp Lite.
Todos los derechos reservados.

13
Accesorios Opcionales
Contenido del Empaque
• Cables Patch Gigabit Snagless Cat6 Serie N201
• Cables VGA de Alta Resolución Serie P502
• Cables adaptadores de HDMI a DVI Serie P566
• Cables HDMI de Alta Velocidad Serie P568
• Cables par Dispositivo USB 3.2 A/B Serie U322
• Cables par Dispositivo USB 3.2 Micro-B Serie U326
• U420-003-G2-5A – Cable USB 3.2 Gen 2 USB-C
M/M, 91 cm [3 pies]
• U442-DOCK3-B
• Manual del Propietario
Requisitos del Sistema
• Computadora con puerto USB-C o Thunderbolt™ 3
que soporte USB DisplayPort Modo Alterno
• Monitor VGA, DVI* o HDMI
• Red Ethernet con velocidades hasta
10Mbps / 100Mbps /1000Mbps
* Requiere un adaptador, como la Serie P566 de Tripp Lite
Ver Accesorios Opcionales.
USB Type-C y USB-C son marcas comerciales registradas del
USB Implementers Forum.

14
Características del Producto
• Soporta USB DisplayPort Modo Alterno para
conectar monitores VGA y HDMI mediante un
puerto USB-C o Thunderbolt 3
• Soporta la conexión de un monitor DVI mediante
adaptador HDMI a DVI (ver Accesorios Opcionales)
• El puerto HDMI soporta resoluciones de video de
hasta 3840 x 2160 (4K x 2K) @ 30Hz
• El puerto VGA soporta resoluciones de video hasta
1920 x 1200, incluyendo 1080p @ 60Hz
• El puerto Ethernet soporta velocidades reales de
red de 10Mbps / 100Mbps /1000Mbps
• Los puertos de datos del hub USB-A y Type-C
soportan tasas de transferencia de datos hasta
5 Gbps
• El puerto USB-A proporciona hasta 1.5A de
potencia de carga rápida para dispositivos móviles
• Puerto de carga USB-C PD para cargar su
dispositivo; soporta entrada de hasta 20V 5A
(100W)
• Las ranuras para tarjeta de memoria Micro SD y
SD / MMC permiten acceso a memoria externa a
través de un puerto USB-C o Thunderbolt
• Dos puertos de datos USB-A y uno Type-C
comparten una potencia máxima de 10W (5V 2A)
• Soporta Intercambio Rápido de Roles [FRS] PD 3.0
para mantener la conexión de datos y energía una
vez retirada la energía de carga

15
Características del Producto
• Restablece automáticamente la operación desde
los modos de hibernación y suspensión
• Compatible con IEEE 802.3az (Ethernet Eficiente
con la Energía)
• Soporta operaciones Dúplex y Semi-dúplex
• Soporta Checksum Offload Engine [COE] de
módulo IPv4 e IPv6 para reducir la carga del CPU
• Soporta Wake-on-LAN
• Su diseño compacto cabe fácilmente en su
maletín de laptop para viajes
• Conectar y Usar—No requiere software ni
controladores

16
Vista General del Producto
1
Puerto de Datos USB-C 3.2 (Hembra): se conecta
a un dispositivo USB-C
2
Puertos USB-A (Hembra): conecte hasta 2
periféricos USB.
Nota: El puerto ubicado junto a las ranuras para tarjeta de
memoria es para carga.
3
Ranura para Tarjeta de Memoria Micro SD: inserte
una Tarjeta de Memoria Micro SD
4
Ranura para Tarjeta de Memoria SD / MMC:
inserte una Tarjeta de Memoria SD / MMC
5
Puerto HDMI (Hembra): se conecta a un monitor
HDMI
6
Puerto VGA (Hembra): se conecta a un monitor VGA
7
Puerto RJ45 (Hembra): se conecta a una red
10Mbps / 100Mbps /1000Mbps
8
Puerto de Carga PD USB-C (Hembra): conecta un
dispositivo a un cargador USB-C
1 3
4
2
5 6 7 8

17
Instalación
Notas:
• Solo se puede conectar un monitor a la vez.
• Sólo se puede usar una tarjeta de memoria a la vez.
• Cuando se conecta a la energía a través de un puerto de
carga USB-C, 15W de potencia se dedican a la estación de
conexión y los periféricos USB conectados. El resto se usa
para cargar el dispositivo conectado.
• Para consultar los cables sugeridos, vea la sección de
accesorios opcionales.
• Cuando la unidad esté conectada al puerto USB-C en
su computadora y a una red mediante cableado Cat5e /
Cat6, se establecerá automáticamente una conexión de
red. Si no se realiza una conexión, se puede establecer
una manualmente yendo a la página de configuración de
red de la computadora. Por ejemplo, en una Mac tendría
que desplazarse a la sección de red en preferencias del
sistema, hacer click en "Ayúdame" para llegar al asistente
de configuración de red y seguir las instrucciones para
establecer una conexión.

18
Instalación
1. Conecte el conector USB Type-C de la estación de
conexión al puerto USB-C o Thunderbolt 3 en su
laptop, tableta u otro dispositivo.
2. Conecte el puerto VGA de la estación de conexión
al puerto VGA de un monitor usando un cable VGA.
O
Conecte el puerto HDMI de la estación de
conexión al puerto HDMI de un monitor usando un
cable HDMI.
3. Conecte hasta 2 dispositivos USB a los puertos
USB-A del hub de la estación de conexión.
4. Conecte un dispositivo USB Type-C al puerto de
datos Type-C de la estación de conexión.
5. Conecte el puerto RJ45 del adaptador a una red
mediante un cable UTP.
6. Inserte una tarjeta Micro SD o SD / MMC en la
ranura correspondiente para tarjeta de memoria
para acceder a la memoria externa.
7. Cargue su dispositivo conectando su cargador
USB-C al puerto USB-C del adaptador.

19
Especificaciones
Conectores de Entrada
USB USB-C (M)
Carga USB-C (F)
Conectores de Salida
USB-A (2x) USB-A (H)
USB-C Datos USB 3.2 Type-C (H)
Ethernet 10Mbps /
100Mbps / 1000Mbps
RJ45 (H)
VGA VGA (H)
HDMI HDMI (H)
Ranuras para Tarjeta de
Memoria
Micro SD y SD / MMC
Ambiental
Temperatura de
Operación
0 °C a 45 °C
[32 °F a 113 °F]
Humedad de Operación De 10% a 90% de HR,
Sin Condensación
Temperatura de
Almacenamiento
-10 °C a 70 °C
[14 °F a 158 °F]
Humedad de
Almacenamiento
De 10% a 90% de HR,
Sin Condensación
Requerimientos de Energía
Puerto de Carga USB-C Soporta hasta 20V 5A
(100W) de Entrada

20
Garantía
Garantía Limitada de 3 años.
Tripp Lite garantiza durante un período de tres (3) años
a partir de la fecha de compra inicial que este producto
no tiene defectos de materiales ni de mano de obra. La
obligación de Tripp Lite bajo esta garantía está limitada a la
reparación o reemplazo (A su entera discreción) de cualquier
producto defectuoso. Para obtener servicio bajo esta garantía,
debe obtener un número de Autorización de Devolución de
Mercancía (RMA) de Tripp Lite o de un centro de servicio
autorizado de Tripp Lite. Los productos deben ser regresados a
Tripp Lite o a un centro de servicio autorizado de Tripp Lite con
los cargos de transporte prepagados y deben acompañarse
con una breve descripción del problema y un comprobante
de la fecha y el lugar de compra. Esta garantía no se aplica a
equipos que hayan sido dañados por accidente, negligencia
o mal uso, o hayan sido alterados o modificados de alguna
manera.
EXCEPTO COMO SE INDICA EN EL PRESENTE, TRIPP LITE
NO HACE GARANTÍAS EXPRESAS O IMPLÍCITAS, INCLUIDAS
GARANTÍAS DE COMERCIABILIDAD Y ADECUACIÓN PARA UN
PROPÓSITO PARTICULAR. Algunos estados no permiten la
limitación o exclusión de garantías implícitas; por lo tanto,
las limitaciones o exclusiones antes mencionadas pueden no
aplicarse al comprador.
EXCEPTO COMO SE INDICA ANTERIORMENTE, EN NINGÚN
CASO TRIPP LITE SERÁ RESPONSABLE POR DAÑOS DIRECTOS,
INDIRECTOS, ESPECIALES, INCIDENTALES O CONSECUENTES
QUE SURJAN DEL USO DE ESTE PRODUCTO, INCLUSO
SI SE ADVIERTE SOBRE LA POSIBILIDAD DE TAL DAÑO.
Específicamente, Tripp Lite no es responsable por ningún
costo, como pérdida de ganancia o ingresos, pérdida de
equipos, pérdida del uso de equipos, pérdida de software,
pérdida de datos, costos de sustituciones, reclamaciones de
terceros o de cualquier otra forma.
