Tripp Lite U442-DOCK20BINT User manual

1
Owner’s Manual
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2022 Tripp Lite. All rights reserved.
USB-C®Dual Display Docking Station
with International Power Supply
Model: U442-DOCK20BINT
USB Type-C and USB-C are registered trademarks of USB Implementers Forum
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
Español 12 • Français 22 • Русский 32 • Deutsch 42

2
Product Features
• Dual-display capability lets you extend across up to three
screens (including the host computer) at resolutions up to
1920 x 1080p @ 60 Hz when connecting up to two HDMI
displays
• Single-monitor installations support resolutions up to
2560 x 1440 @ 50 Hz
• USB-C PD 3.0 charging port provides up to 85W of power to
the connected source
• RJ45 Ethernet port supports true 10/100/1000 Mbps network
speeds, providing 1 Gbps connectivity for when Wi-Fi signals
are weak or unavailable
• Read, write and transfer data at up to 5 Gbps via the docking
station’s three USB 3.2 Gen1 ports, or connect other USB
peripherals, such as a keyboard and mouse
• Dedicated USB 3.2 Type-A charging port provides up to 5V
1.5A (7.5W) of fast charging power to mobile devices and 2.4A
to Apple devices
• Multi-mount design provides an all-in-one desktop solution to
help create a clutter-free work environment

3
Package Includes
Optional Accessories
System Requirements
• U442-DOCK20BINT
• USB 3.2 Gen2 C-to-C Cable with C-to-A Adapter – 1 m
• External Power Supply with BS 1363 UK and CEE 7/8 EU
Power Cords
• Owner’s Manual
• P569-Series High Speed HDMI Cables
• N201-Series Cat6 Gigabit Snagless Patch Cables
• U038-0XX-GY-MAX Heavy-Duty USB A-to-C Cables
• M100-Series USB A-to-Lightning Cables
• Windows or Mac Operating System

4
Product Overview
Front:
Back:
Sides:
ABCD
E F G
K
J
J
J
J
HI

5
Product Overview
Bottom:
Item Description
AAudio In/Out Jack
BUSB 3.2 Gen1 Type-A Port, BC 1.2-Compliant
CUSB Type-C Port with PD 3.0 Charging
DLED Indicator - Illuminates blue when powered,
green when active
EPower On/Off Button
FDC Power In Jack
GRJ45 Ethernet Port
HUSB 3.2 Gen1 Type-A Ports
IHDMI Ports
JMounting Screw Holes
KK-Lock for Securing Device
J J

6
Installation
Prior to Installation -
for Windows operating systems only:
DisplayLink drivers are required for both video and audio functions
when using Windows OS. The drivers can be downloaded and
installed from www.displaylink.com/downloads. Once the drivers
are successfully installed, restart the host computer.
Notes:
• The U442-DOCK20BINT is able to recognize USB peripherals such as
a mouse, keyboard or flash drive, without DisplayLink drivers installed
on the host PC or laptop running Windows.
• Mac operating systems do not require the drivers. In the event a Mac
OS driver is needed, the drivers can be downloaded from
www.displaylink.com/downloads.
Installation
1
2
33
45
6
7
7

7
Installation
1. Connect the host computer or laptop to the U442-
DOCK20BINT using the included USB-C to C cable. Use the
USB-A to C adapter if necessary.
Note: Your source device will only charge when using a USB-C to C cable.
2. Connect up to two HDMI-compliant displays to the
U442-DOCK20BINT using Tripp Lite’s P569-Series cable
(sold separately).
Note: Up to three screens can be extended in a multi-monitor
configuration. Manipulate the orientation or mode of the displays
(mirror or extend) through the host computer’s display settings.
3. Connect up to three USB peripherals such as a keyboard,
mouse, flash drive or smartphone.
Note: The front panel USB port labeled with a charging symbol
supports fast charging up to 1.5A and Apple Charge up to 2.4A.
4. Connect to a wired Gigabit LAN using Tripp Lite’s N201-Series
Cat6 Cable (sold separately) if Wi-Fi signals are weak or
unavailable.
5. Connect headphones to the available 3.5 mm port.
Note: If no sound is output, the audio output source must be
changed to USB audio.
6. (Optional) Lock and secure your U442-DOCK20BINT docking
station to your desk using the K-LOCK port located on the side
of the unit.
7. Connect the included power supply to the docking station and
power on the unit using the power button located to the left
of the DC port.

8
Specifications
Input USB-C
Output (x2) HDMI
RJ45
(x3) USB 3.2 Gen 1 Type-A
3.5 mm
Video (HDMI) Single: 2560 x 1440 @ 50 Hz
Dual: 1920 x 1080 @ 60 Hz
Audio (3.5 mm) 2.1 Channel Surround Sound
Ethernet (RJ45) 10/100/1000 Mbps
Power Supply Input: 100-240V @ 50/60 Hz, 2A
Output: 20V 5A
HDMI Specification 1.3
BC 1.2 Compliant Yes
Operating Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature -4°F to 158°F (-20°C to 70°C)
PD Charging Specification PD 3.0 up to 85W
(20/15/9/5V 4.25A)
Power In DC 100W (20V 5A)

9
Warranty & Product Registration
3-Year Limited Warranty
Tripp Lite warrants its products to be free from defects in materials and workmanship
for a period of three (3) years from the date of initial purchase. Tripp Lite’s obligation
under this warranty is limited to repairing or replacing (at its sole option) any
such defective products. To obtain service under this warranty, you must obtain a
Returned Material Authorization (RMA) number from Tripp Lite or an authorized
Tripp Lite service center. Products must be returned to Tripp Lite or an authorized
Tripp Lite service center with transportation charges prepaid and must be
accompanied by a brief description of the problem encountered and proof of date
and place of purchase. This warranty does not apply to equipment, which has been
damaged by accident, negligence or misapplication or has been altered or modified
in any way.
EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied
warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the
purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite BE LIABLE FOR DIRECT,
INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT
OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE. Specifically, Tripp Lite is not liable for any costs, such as lost profits or
revenue, loss of equipment, loss of use of equipment, loss of software, loss of data,
costs of substitutes, claims by third parties, or otherwise.
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be
automatically entered into a drawing for a chance to win a FREE Tripp Lite product!
** No purchase necessary. Void where prohibited. Some restrictions apply. Open to U.S. residents
only. See tripplite.com for details.

10
Warranty & Product Registration
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by Tripp Lite
could void the user’s authority to operate this equipment.
WEEE Compliance Information for Tripp Lite Customers and Recyclers
(European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and
implementing regulations, when customers buy new electrical and electronic
equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like basis (this
varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes
waste

11
Warranty & Product Registration
Use of this equipment in life support applications where failure of this equipment
can reasonably be expected to cause the failure of the life support equipment or to
significantly affect its safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specifications are subject to
change without notice. Photos and illustrations may differ slightly from actual
products.
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
21-12-046 934080_RevA

12
Manual del Propietario
1111 W. 35th Street, Chicago, IL 60609, EE. UU. • tripplite.com/support
Copyright © 2022 Tripp Lite. Todos los derechos reservados.
Estación de Conexión USB-C®
para Dos Pantallas con Fuente de
Alimentación Internacional
Modelo: U442-DOCK20BINT
USB Type-C y USB-C son marcas comerciales registradas del USB Implementers
Forum
English 1 • Français 22 • Русский 32 • Deutsch 42

13
Características del Producto
• La capacidad para dos pantallas le permite extender hasta tres
pantallas (incluyendo la computadora anfitrión) a resoluciones
de hasta 1920 x 1080p @ 60 Hz al conectar hasta dos
pantallas HDMI
• Las instalaciones de un solo monitor soportan resoluciones de
hasta 2560 x 1440 @ 50 Hz
• El puerto de carga USB C PD 3.0 proporciona hasta 85W de
potencia al dispositivo conectado
• El puerto Ethernet RJ45 soporta velocidades reales de red de
10Mbps / 100Mbps / 1000Mbps, proporcionando conectividad
de 1 Gbps para cuando las señales de Wi-Fi sean débiles o no
estén disponibles
• Lea, escriba y transfiera datos a hasta 5 Gbps mediante los
tres puertos USB 3.2 Gen1 de la estación de conexión o
conecte otros periféricos USB, como un teclado y mouse.
• Un puerto de carga USB 3.2 Type-A dedicado proporciona
hasta 5V 1.5A (7.5W) de potencia de carga rápida a los
dispositivos móviles y 2.4A a dispositivos Apple
• El diseño para instalación múltiple proporciona una solución
de escritorio todo en uno para ayudar a crear un entorno de
trabajo libre de desorden

14
El Paquete Incluye
Accesorios Opcionales
Requisitos del Sistema
• U442-DOCK20BINT
• Cable USB 3.2 Gen2 C a C con Adaptador C a A – 1 m
• Fuente de Alimentación Externa con Cables de Alimentación
BS 1363 para el Reino Unido y CEE 7/8 para la Unión Europea
• Manual del Propietario
• Cables HDMI de Alta Velocidad de la Serie P569
• Cables Patch Snagless Cat6 Gigabit Serie N201
• Cables USB A a C para Servicio Pesado U038-0XX-GY-MAX
• Cables USB A a Lightning de la Serie M100
• Sistema Operativo Windows o Mac

15
Vista General del Producto
Frente:
Atrás:
Costados:
ABCD
E F G
K
J
J
J
J
HI

16
Vista General del Producto
Parte Inferior:
Rubro Descripción
AEnchufe de Entrada y Salida de Audio
BPuerto USB 3.2 Gen1 Type-A, Compatible con BC 1.2
CPuerto USB Tipo C con Carga PD 3.0
DIndicador LED - Se ilumina en azul cuando se enciende,
verde cuando está activo
EBotón de Encendido y Apagado
FEnchufe de Alimentación CD
GPuerto Ethernet RJ45
HPuertos USB 3.2 Gen1 Type-A
IPuertos HDMI
JOrificios para Tornillos de Instalación
KCerradura K para Asegurar el Dispositivo
J J

17
Instalación
Antes de la Instalación - para sistemas
operativos Windows solamente:
Se requieren controladores de DisplayLink para las funciones
de video y audio al usar Windows. Los controladores pueden
descargarse e instalarse desde www.DisplayLink.com/downloads.
Una vez instalados con éxito los controladores, reinicie la
computadora anfitrión.
Notas:
• El U442-DOCK20BINT es capaz de reconocer periféricos USB como
mouse, teclado o memoria USB, sin controladores de DisplayLink
instalados en la PC anfitrión o laptop operando con Windows.
• Los sistemas operativos Mac no requieren de los controladores. En
caso de necesitar un controlador para Mac OS, los controladores
pueden descargarse desde www.displaylink.com/downloads.
Instalación
1
2
33
45
6
7
7

18
Instalación
1. Conecte la computadora o laptop anfitrión al
U442-DOCK20BINT usando el cable USB-C a C incluido.
Use el adaptador USB A a C si fuera necesario.
Nota: su dispositivo fuente solo se cargará cuando se use un cable
USB C a C.
2. Conecte hasta dos pantallas compatibles con HDMI al
U442-DOCK20BINT usando el cable de la Serie P569 de
Tripp Lite (vendido por separado).
Nota: pueden extenderse hasta tres pantallas en una configuración
de múltiples monitores. Manipule la orientación o modo de las
pantallas (espejo o extendido) a través de los parámetros de pantalla
de la computadora anfitrión.
3. Conecte hasta tres periféricos USB como un teclado, mouse,
memoria USB o smartphone.
Nota: El puerto USB del panel frontal etiquetado con un símbolo de
carga soporta carga rápida de hasta 1.5A y carga de Apple hasta
2.4A.
4. Si las señales de Wi-Fi son débiles o no están disponibles,
conecte a una LAN Gigabit cableada usando un Cable Cat6
de la serie N201 de Tripp Lite (vendido por separado).
5. Conecte los audífonos al puerto de 3.5 mm disponible.
Nota: Si no hay salida de sonido, la fuente de salida de audio debe
cambiarse a audio USB.
6. (Opcional) Bloquee y asegure su estación de conexión
U442-DOCK20BINT a su escritorio usando el puerto K-LOCK
ubicado en el costado de la unidad.

19
Instalación
Especificaciones
Entrada USB C
Salida (x2) HDMI
RJ45
(x3) USB 3.2 Gen 1 Type-A
3.5 mm
Video (HDMI) Uno: 2560 x 1440 @ 50 Hz
Dos: 1920 x 1080 @ 60 Hz
Audio (3.5 mm) Sonido Envolvente de 2.1 Canales
Ethernet (RJ45) 10/100/1000 Mbps
Fuente de Alimentación Entrada: 100V ~ 240V @ 50Hz /
60Hz, 2A
Salida: 20V 5A
Especificación HDMI 1.3
Cumple con BC 1.2 Sí
Temperatura de Operación 0 °C a 40 °C [32 °F a 104 °F]
Temperatura de
Almacenamiento -20 °C a 70 °C [-4 °F a 158 °F]
Especificación de
Carga PD PD 3.0 hasta 85W
(20V / 15V / 9V / 5V @ 4.25A)
Entrada de Potencia 100W CD (20V 5A)
7. Conecte la fuente de alimentación incluida a la estación de
conexión y encienda la unidad usando el botón de encendido
ubicado a la izquierda del puerto de CD.

20
Garantía
Garantía Limitada de 3 años
Tripp Lite garantiza durante un período de tres (3) años a partir de la fecha de
compra inicial que este producto no presenta defectos de materiales ni de mano de
obra. La obligación de Tripp Lite bajo esta garantía está limitada a la reparación o
reemplazo (a su entera discreción) de cualquier producto defectuoso. Para obtener
servicio bajo esta garantía, debe obtener un número de Autorización de Devolución
de Mercancía [RMA] de Tripp Lite o de un
centro de servicio autorizado de Tripp Lite. Los productos deben devolverse a
Tripp Lite o a un centro de servicio autorizado de Tripp Lite con los cargos de
transporte prepagados y deben acompañarse con una breve descripción del
problema y un comprobante de la fecha y el lugar de compra. Esta garantía no se
aplica a equipos que hayan sido dañados por accidente, negligencia o mal uso o
hayan sido alterados o modificados de alguna manera.
EXCEPTO COMO SE INDICA EN EL PRESENTE, TRIPP LITE NO OTORGA GARANTÍAS
EXPRESAS O IMPLÍCITAS, INCLUIDAS LAS GARANTÍAS DE COMERCIABILIDAD Y
ADECUACIÓN PARA UN DETERMINADO PROPÓSITO. Algunos estados no permiten
la limitación o exclusión de garantías implícitas; por lo tanto, las limitaciones o
exclusiones antes mencionadas pueden no aplicarse al comprador.
EXCEPTO COMO SE INDICA ANTERIORMENTE, EN NINGÚN CASO TRIPP LITE SERÁ
RESPONSABLE POR DAÑOS DIRECTOS, INDIRECTOS, ESPECIALES, INCIDENTALES
O CONSECUENTES QUE SURJAN DEL USO DE ESTE PRODUCTO, INCLUSO SI SE
ADVIERTE SOBRE LA POSIBILIDAD DE TAL DAÑO. Específicamente, Tripp Lite no es
responsable por ningún costo, como pérdida de ganancias o ingresos, pérdida de
equipos, pérdida del uso de equipos, pérdida de software, pérdida de datos, costos
de sustituciones, reclamaciones de terceros o de cualquier otra forma.
