Paradigm iDEA+ User manual

iDEA+Docking Station i
i
iD DE EA A+
+
D Do oc ck ki in ng g S St ta at ti io on n
User Manual

Copyright
The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an
information retrieval system, translated into any language, or transmitted in any form or by any means,
mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written
permission.
Trademarks
All product, company, brand names are trademarks or registered trademarks of their respective companies.
They are used for identification purpose only. Specifications are subject to be changed without prior notice.
iDEA+Docking Station i

FCC Radiation Norm
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference , and
(2) this device must accept any interference received, including interferences that may cause
undesired operations.
CE Radiation Norm
This equipment has been tested and found to comply with the limits of the European Council Directive
99/5/EC on the approximation of the law of the member states relating to EN 300 328 V1.7.1 (2006-10), EN
301 489-1 V1.8.1 (2008-04) and EN 301 489-17 V1.3.2 (2008-04) and EN 60950.
FCC & CE Compliance Statement
These limits are designed to provide reasonable protection against radio interference in a residential
environment. This equipment can generates, uses and radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which is found by turning the equipment ON
and OFF, the user is encouraged to try to reduce the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and the receiver
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connect to
•Consult a dealer or an experienced technician for assistance
RF exposure warning
This equipment must be installed and operated in accordance with provided instructions and the antenna(s)
used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons
and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and
installers must be provide with antenna installation instructions and transmitter operating conditions for
satisfying RF exposure compliance.
CAUTION!
Any changes or modifications not expressly approved by the grantee of this device could void the user's
authority to operate the equipment.
iDEA+Docking Station ii

iDEA+Docking Station iii
Contents
Copyright............................................................................................................................................ i
Chapter 1 Introduction .....................................................................................................................1
1.1 Features......................................................................................................................................2
1.2 System Requirement..................................................................................................................3
1.3 Package Contents.......................................................................................................................3
Chapter 2 Knowing Travel AP charger ...........................................................................................4
2.1 LED Indicator............................................................................................................................4
2.2 Ports...........................................................................................................................................4
2.3 Power ON/OFF..........................................................................................................................4
2.4 Hardware Connection................................................................................................................5
2.5 Charging.....................................................................................................................................9
Chapter 3 Configuration via PC.....................................................................................................10
3.1 Setting up the TCP/IP..............................................................................................................11
3.2 Login........................................................................................................................................12
3.3 Wizard......................................................................................................................................14
3.3.1 Gateway Mode..................................................................................................................14
3.3.2 Hotspot Mode ...................................................................................................................17
3.4 Wireless....................................................................................................................................18
3.5 WAN ........................................................................................................................................19
3.6 File Server................................................................................................................................21
3.7 System setting..........................................................................................................................22
3.7.1 Wireless.............................................................................................................................22
3.7.1.1 Basic Settings.............................................................................................................22
3.7.1.2 Active Clients.............................................................................................................23
3.7.1.3 Advanced Setting.......................................................................................................24
3.7.1.4 Security......................................................................................................................26
3.7.1.5 Hotspot Mode ............................................................................................................27
3.7.2 TCP/IP Settings.................................................................................................................28
3.7.2.1 LAN Interface............................................................................................................28
3.7.2.2 WAN Interface...........................................................................................................30
3.8 Management ............................................................................................................................38
3.8.1 Statistics............................................................................................................................39
3.8.2 Time Zone Setting.............................................................................................................40
3.8.3 Log....................................................................................................................................41
3.8.4 Upgrade Firmware............................................................................................................42
3.8.5 Save/Reload Setting..........................................................................................................43
3.8.6 Password...........................................................................................................................44

iDEA+Docking Station iv
3.8.7 Reboot...............................................................................................................................45
3.8.8 Logout...............................................................................................................................46
Chapter 4 Configuration via Smart Phone....................................................................................47
4.1 Install APPs forAndroid Phone...............................................................................................47
4.2 Setting......................................................................................................................................49
4.2.1 Gateway Mode..................................................................................................................49
4.2.2 Hotspot Mode ...................................................................................................................50
4.2.3 Wireless Setting ................................................................................................................53
Appendix A: Troubleshooting.........................................................................................................56

Chapter 1 Introduction
Congratulations on your purchase of this outstanding iDEA+ Docking Station. Great for traveler to
charge iPad/iPhone, mobile devices. Working as an AP router for traveler to access Internet easily by
their iPad, iPhone and Laptop via Wi-Fi. Support any 5V USB chargeable handheld devices including
iPad, iPhone. With extra USB port, connecting a USB hard drive to act as a wireless HDD and support
HTTP file server for iPad/iPhone to browse contents via browser. USB port supports Smartphone or 3G
USB card to share Internet connection. With its Hotspot mode, it will let your network wirelessly and
extend your wireless coverage.
iDEA+Docking Station 1

iDEA+Docking Station 2
1.1 Features
Functions
ySupport Router, hotspot mode.
ySupport Setup Wizard.
ySupport File Server for user to playback Music/Video/Photo
ySupport APP Configuration for Android Phone
ySupport Simple configuration for Smart Phone
Wireless
yIEEE 802.11b/g/n standards compliant.
ySupport data rates up to 150Mbps ( Auto-Rate Capable ).
ySupport WEP/WPA/WPA2 Encryption.
ySupport Wireless hotspot mode.
WAN Ethernet Interface
y1 Port Interface compliant with IEEE 802.3x standards.
yAutomatic MDI/MDIX crossover for 10/100 Base-T port.
yAuto-negotiation and speed-auto-sensing support.
yxDSL/Cable modem support
yWAN Access Type: Static IP,DHCP,PPPoE,3G USB and Android Mobile
Network Management
yWeb-based Management
yRemote Access Control
yFirmware upgrade via HTTP/TFTP
ySystem Log
USB
y5V/2.1A USB port for charging iPad/iPhone and Smartphone
yUSB port for Smart Phone,3G USB card
yUSB port for Flash Drive, USB Hard Drive, USB Card Reader

iDEA+Docking Station 3
1.2 System Requirement
Check and confirm that your system/network meets the following requirements:
Personal computer (PC/Notebook/Tablet PC) or Smartphone.
One IEEE 802.11b/g/n Wireless adapter with installed TCP/IP
Internet Browser.
1.3 Package Contents
The iDEA+Docking Station package contains the following items:
One iDEA+Docking Station
One CD-ROM ( Manual / Quick Setup Guide )
One Quick Setup Guide
If any of the above items are damaged or missing, please contact your dealer immediately.

Chapter 2 Knowing iDEA+Docking Station
2.1 LED Indicator
The iDEA+Docking Station’s LED indicator display information about the device’s status.
Green iDEA+Docking Station access Internet successfully
Orange Flashing when iDEA+Docking Station cannot access Internet
Red iDEA+Docking Station is booting
2.2 Ports
The ports of the iDEA+Docking Station contain WAN Ethernet port, Reset Button, USB data port and
USB only for charging port.
WAN Port for connecting to the cable or DSL modem through Ethernet cable
Reset Reset iDEA+Docking Station to factory default. Press this button for more than 5 secs
USB Connect USB HDD, Flash Drive, 3G USB card and Smartphone
USB
Charging Only for Charging iPad, iPhone and Smartphone
2.3 Power ON/OFF
The Power ON/OFF Button of iDEA+Docking Station.
iDEA+Docking Station 4

iDEA+Docking Station 5
2.4 Hardware Connection
This section describes the hardware connection mechanism of iDEA+Docking Station connected to the
Internet.
You need to prepare the following items before you can establish an Internet connection through your
iDEA+Docking Station:
1. A notebook/tablet PC which have wireless available.
2. Internet available of any ADSL/Cable modem or 3G USB card/3G Mobile phone.
3. Flash Drive/ USB hard drive.
Install the device
Gateway:
1. Insert one end of the Ethernet cable to the WAN port of iDEA+Docking Station.
2. Insert one end of the Ethernet cable to the LAN port of ADSL/Cable modem which is Internet
available.
3. Insert the flash drive to the USB port of iDEA+Docking Station if you want to share the contents of
flash drive to Wi-Fi devices.
4. Now other Wi-Fi devices can access Internet via your iDEA+Docking Station via wireless.
Hotspot:
1. Wi-Fi devices connect to your iDEA+Docking Station.
2. The iDEA+Docking Station connects to root AP which is Internet available.
3. Configure your iDEA+Docking Station to Hotspot mode.
4. Now the Wi-Fi devices can access Internet via your iDEA+Docking Station and root AP.
3G USB Sharing:
1. Insert your 3G data card to the USB port of iDEA+Docking Station.
2. Configure your iDEA+Docking Station to 3GUSB mode.
3. Now the Wi-Fi devices can access Internet sharing your 3G network.
Android Mobile Sharing:
1. Insert your Android phone to the USB port of iDEA+Docking Station.
2. Enable USB Tethering on your Android phone.
3. Configure your iDEA+Docking Station to Android Mobile mode.
4. Now the Wi-Fi devices can access Internet sharing your 3G network.
Figures show the overall hardware connection mechanism of your iDEA+Docking Station.

iDEA+Docking Station 6

iDEA+Docking Station 7

iDEA+Docking Station 8

2.5 Charging
Support any 5V USB chargeable handheld devices including iPad, iPhone. Connect your iPad/iPhone
or Smartphone to the USB charger port (red circle) of iDEA+Docking Station.
The USB port is only for charging. Do not plug any USB devices to this
charging port.
!
iDEA+Docking Station 9

Chapter 3 Configuration via PC
For your convenience, the web GUI allows you to configure iDEA+Docking Station using web browser. This
chapter will explain all the functions in this Web GUI.
iDEA+Docking Station 10

3.1 Setting up the TCP/IP
iDEA+Docking Station 11
Step 1: Click Start→Control Panel. Step 4:Right click on the Local Area Connection
and select Properties.
1
2
Step 2: Click the View network status and tasks. Step 5:Select Internet Protocol Version 4
(TCP/IPv4) and click Properties.
1
2
Step 3: Click on the Change adapter settings.
Step 6:Go to General icon, select Obtain an IP
address automatically and DNS server
address automatically.
1
2
3

3.2 Login
To access the iDEA+Docking Station configuration screens, follow the following steps will enable you to
log into the iDEA+Docking Station.
1.
Launch your web browser, and enter the iDEA+Docking Station ’s IP Address: “192.168.168.1”
in the address field then press the “Enter” key to login.
iDEA+Docking Station 12
2. Enter the default User name: “admin” and Password: “admin”. Then press “OK” to login.

3. There are Wizard, WAN, System Setting, Wireless and FileServer icon to help you to configure the
iDEA+Docking Station easily.
iDEA+Docking Station 13

3.3 Wizard
Click on “Wizard” and the following screen will pop-up:
Click Next>> button to continue.
Choose Gateway or Hotspot mode.
3.3.1 Gateway Mode
In the Gateway mode, the iDEA+Docking Station connects to Internet through ADSL modem, cable modem,
3G USB card or Android mobile phone.
WAN access type: Static IP, DHCP, PPPoE, USB3G and Android Mobile.
Static IP, DHCP& PPPoE:
Select WAN access type from the drop-down list.
zDHCP: If you are using DHCP client, just click Apply changes to save the setting.
iDEA+Docking Station 14

zStatic IP: Please fill in IP address, subnet mask, Default Gateway, DNS IP address if you are using
Static IP.
zPPPoE: Please enter the username and password if you are using PPPoE connection.
USB3G
Please enter the information of APN service name, PIN code, dial number, account name and password if
you choose USB3G and use 3G USB card to access Internet.
iDEA+Docking Station 15
