Model #: N316-30M
30M (100-ft.) Duplex MMF 62.5/125 Patch Cable (LC/SC)
Highlights
Premium PVC 62.5/125µm multimode patch cables
Attenuation loss meets or exceeds the latest industry standards
Description
Tripp Lite's 30-meter ( 100ft ) multimode duplex fiber optic SC/LC patch cable is manufactured from 62.5/125 zipcord fiber. The cable has LC to SC
connectors, a PVC jacket and is FDDI and OFNR rated. Duplex multimode fiber is most commonly used in LAN applications.
System Requirements
Any fiber optic hardware or NIC card requiring multimode duplex cable with SC/LC connectors
Package Includes
30 meter ( 100ft ) Duplex MMF Cable LC/SC 62.5/125 Fiber
Features
Manufactured from 62.5/125 duplex (zipcord) fiber
PVC jacket
Length: 30-meter (100ft) Connectors: 2 SC/LC connectors on each end
Insertion loss testing performed on every connector (0.2db typical) and provided with cable
Beveled edge on ends of glass makes insertion of plug a breeze
Fiber made from glass (not a polymer)
Color coded shrouds identify transmit and receive
Specifications
OVERVIEW
Intended Application Computer Networking (Fiber)
INPUT
Cable Length (m) 30
PHYSICAL
Color Orange

Style Fiber Optic
CONNECTIONS
Connector A
LC
Connector B
SC
Number of Connectors 4
CERTIFICATIONS
Certifications ROHS
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
Related Items
Optional Products
Product Type Related Model Description Qty.
Fiber Optic Cables &
Adapters
N316-01M 1M (3-ft.) Duplex MMF 62.5/125 Patch Cable
(LC/SC)
1
Fiber Optic Cables &
Adapters
N316-02M 2M (6-ft.) Duplex MMF 62.5/125 Patch Cable
(LC/SC)
1
Fiber Optic Cables &
Adapters
N316-03M 3M (10-ft.) Duplex MMF 62.5/125 Patch Cable
(LC/SC)
1
