TrippNT Core SP Series User manual

Thank you for choosing TrippNT for your storage and organiza-
tion needs. Please check to make sure you received your cart in
good shape and all the necessary components are included. This
guide will show you step by step how to assemble your
Core SP™Space Saving Cart (51142).
Assembly Guide (v.3.0)
Core SP™Cart (51142)
Included Components
If you need any assistance please call TrippNT at 1.800.874.7768 or email us at
[e-mail]. Also check out the video assembly guide
online at http://TrippNT.com/AssemblyAssistance
Cart BodyA.
Caster w/ Brake
x4
B.
Clips
x4
G.
Lock Washer
x4
F.
Top Drawer
x1
D.
Propel Nut
x4
E.
Cart Top
x1
H. Set of 2 keys
x1
I.
White Plastic Spacer
x4
C.

Core SP™Cart (51142)
12
A
A
I
I
Locate the keys (I)taped to the
second drawer.
Unlock sliding door with keys (I).
Slide door up.
Unpacking the Cart
Unpack components and inspect
with the included component
list to insure all items have been
included.
34
Bottom of
Cart (A)
Gently lay cart body (A) on its
back with the drawers and door
facing up towards the ceiling.
Front of
Cart (A)
Care Instructions for your Cart
This product can be cleaned with a solution of water or with a mild organic
solvent . Use of strong solvents is not recommended.
Accessories and Replacement Parts
A variety of accessories and replacement parts are available at:
TrippNT.com/CartAccessories or from your normal TrippNT Distributor

Core SP™Cart (51142)
Installing the Casters
Front of Cart (A)
Bottom of Cart (A)
5
C
A
F
E
IMPORTANT CASTER INSTALLATION INSTRUCTIONS
Casters must be assembled correctly. The caster will stay on
tight if installed correctly.
B
Lock Washer - Should be between the
propel nut and the bottom of the cart.
Bottom of Cart
White Plastic Spacer - The grove in the
caster cover should fit snuggly to the hex
shape on the stem of the caster.
Caster
Propel Nut - Hand tighten propel nut
to the stem of the caster with shown
components in between. Nut should
be completely flush with surface
when adequately tightened. This does
require significant torque.
Lock the brake of
the caster so that the
wheel does not move
and the top of the
caster does not swivel.
Securely tighten the
caster in a clockwise
direction until the
caster is snug.
First disassemble each caster assembly.
Caster (B)
White Plastic
Sapcer (C)

8
G
Slide metal clips (G) into
position to secure the cart top
(H) to the cart body (A).
H
A
9
D
Align the tracks of the top
drawer (D) with the tracks on
the inside of the cart body.
Press the top drawer complete-
ly in to the cart to snap it into
place.
A
Core SP™Cart (51142)
6
Return cart to upright position.
Lock the brake on the front
casters to prevent movement
while assembling.
Assembling the Cart
Lock the brake on
these casters
7
H
A
Install the cart top (H) using the
plastic quick fittings. The fittings
will snap when the cart top is in
place. Please note the side of
the cart top with the groove for
the door should face towards
the front of the cart.

Congratulations, your Core SP Space Saving Cart is now complete and
ready for your use. Thank you again for selecting TrippNT and please
enjoy your cart.
