Tristar Products PowerXL SHL96 User manual

Save These Instructions – For Household Use Only
Owner’s Manual
MODEL: SHL96
When using electrical appliances, basic safety
precautions should always be followed. Do not use
the PowerXL Self Cleaning Juicer™
until you have read this manual thoroughly.
Visit TristarCares.com for
tutorial videos, product details, and more.
Guarantee Information Inside
SELF-CLEANING JUICER

Table of Contents
BEFORE YOU BEGIN
The PowerXL Self-Cleaning Juicer™will provide you
many years of healthy juicing. But before you begin,
it’s very important that you read this entire manual,
making certain that you are totally familiar with this
appliance’s operation and precautions.
PowerXL Self-Cleaning Juicer
IMPORTANT SAFEGUARDS 4
Parts & Accessories 6
Instructions for Use 7
Assembly 8
Disassembly 9
Care & Cleaning 10
Self-Cleaning 10
Juicing Guidelines 12
Juicing Chart 14
Troubleshooting 16
Money-Back Guarantee 18
Model Number Supply Power Rated Power Capacity
SHL96 AC 110V 60Hz 1200W 2 Liters
Appliance Specications

45
When using electrical appliances, basic
safety precautions should always be
followed, including:
1. Read all instructions.
2. NOT FOR USE BY CHILDREN!
Keep out of the reach of children
to avoid injury.
3. The appliance has a polarized
plug. To reduce the risk of electric
shock, this plug will t in an outlet
only one way. If the plug does not
t fully in the outlet, reverse the
plug. If it still does not t, do not
use the appliance and consult an
electrician.
4. DO NOT operate this or any
appliance with a damaged AC cord
or plug.
5. UNPLUG from outlet when not in
use.
6. DO NOT operate if appliance
malfunctions, has been dropped or
appears damaged in any manner.
Never attempt home repairs. Only
a qualied appliance technician
should repair appliance before
re-use.
7. DO NOT USE any attachments
or utensils that were not
recommended or included in the
package. The use of attachments
not recommended or sold by
Tristar Products, Inc. may cause
serious hazardous situations
including re, electric shock or
personal injury.
8. To protect against risk of electrical
shock or injury, never immerse
power cord, plug, or main
appliance in water or other liquids.
9. DO NOT let Power Cord hang over
the edge of table, counter, or come
in direct contact with hot surfaces
such as stoves.
10. Make sure the lid is attached
properly and is securely locked
before operating the appliance
(see the “Assembly” section).
11. Make sure the motor stops
completely and the appliance is
unplugged from the electrical
outlet before disassembling,
assembling or cleaning.
12. Should the appliance suddenly
stop or develop excessive vibration
or unusually loud noise, shut off
and unplug appliance immediately,
wait for blade to stop moving, then
disassemble, clean thoroughly and
reassemble.
IMPORTANT SAFEGUARDS IMPORTANT SAFEGUARDS
WARNING
PREVENT INJURIES! CAREFULLY READ
ALL INSTRUCTIONS BEFORE USE!
13. To avoid risk of personal injury
keep hands and utensils out of
the juicer and away from its sharp
Blade during operation. Use the
Pusher, not ngers or utensils, to
insert food into the juicer.
14. NEVER disengage the Locking Bar
during operation.
ANYONE WHO HAS NOT FULLY READ
AND UNDERSTOOD ALL OPERATING AND
SAFETY INSTRUCTIONS CONTAINED IN
THIS MANUAL IS NOT QUALIFIED TO
OPERATE OR CLEAN THIS APPLIANCE.
SAVE THESE INSTRUCTIONS –
FOR HOUSEHOLD USE ONLY
Safety Features
The juicer was designed with safety in
mind. Two important safety features are:
Built-In Automatic Shut Off System
The juicer is equipped with a special
feature that automatically shuts off the
motor should the appliance become
jammed or overheated during the
juicing process. Prior to shut down,
you will most likely hear the juicer get
louder. This will indicate that something
has caused the motor to strain. Should
this happen, simply turn the Power
Switch off and unplug the appliance.
Follow the Disassembly, Cleaning and
Assembly procedures. Then, allow the
appliance to cool for 10 minutes. The
appliance will reset and you will be able
to resume the juicing process.
The Locking Bar
When in the upright and locked
position, this feature holds the Juicer
Lid/Pulp Guard in place. If the Locking
Bar is not in its proper position, the
motor will not engage and the blade
will not spin.
CAUTION

67
IMPORTANT: Your juicer has been shipped with the components shown below.
Check everything carefully before use. If any part is missing or damaged, do not
use this product and contact Customer Service using the contact information
located on the back of this manual.
PUSHER
LID AND PULP GUARD
CHUTE
SELF-CLEANING
BUTTON
PULP COLLECTOR
POWER BASE
CLEANING BRUSH
May be sold separately
RECEPTACLE
BLADE/FILTER
SPOUT
LOCKING
BAR
Parts & Accessories
Before First Use
Ensure that all packing materials
have been removed, including any
clear or plastic lm. Running the
appliance with any of this material
still intact may cause serious damage.
Disassemble the appliance (see the
“Disassembly” section). Clean the
appliance (see the “Care & Cleaning”
section). Dry all parts thoroughly
before use. Assemble the appliance
(see the “Assembly” section).
1. Clean and cut ingredients to
a size that will t in the Chute.
Ensure that all pits and large
stems are removed. Small
seeds and skins should not be a
problem if you wish to use them.
2. Place the appliance on a stable
countertop or table. Plug the
power cord into a 110V outlet.
Select the speed you wish to use
based on the type of food you are
juicing and allow the appliance to
run for a few seconds.
Instructions for Use
FIG. A
3. Before juicing, ensure the Spout is
pointed downward and properly
aligned with your glass or container
(see Fig. A).
4. Use the Pusher to guide the
ingredients into the Chute with a
smooth, steady motion. You should
see the juice beginning to ow into
your glass or container, and the
pulp will begin to collect on the Lid
and in the Pulp Collector.
5. Immediately after use, clean
the appliance (see the “Care &
Cleaning” section).
NOTE: Sometimes, you may need to
remove excess food or pulp when
making large quantities of juice. This
appliance’s self-cleaning function can
be used to clean moderate amounts
of food from the appliance (see the
“Self-Cleaning” section). If there is a
large build-up of food, unplug the
appliance, remove the Lid, and clean
the Blade/Filter and Pulp Chute.

89
IMPORTANT: Before disassembly,
make certain appliance is shut off and
the power cord is unplugged from
the power outlet.
Disassembly
1
3
4
2
5
1. Lift and remove the Pusher
from the Chute.
2. Grasp the Locking Bar
and rotate downward. This
will release all components
for easy disassembly.
3. Lift and remove the Lid and
Pulp Guard.
4. Lift and remove the Receptacle,
which contains the Blade/
Filter. At this point, you can
separate the Blade/Filter from
the Receptacle.
5. NOTE: The Pulp Collector is
now free from the appliance.
1. Align the three tabs on the bottom of
the Receptacle with the matching tabs
on the top of the Power Base and insert
the Receptacle.
2. Insert the Blade/Filter into the
Receptacle and set the Blade/Filter
in place with a slow clockwise
motion. Now, place the Pulp Collector
under the back lip of the Receptacle
(see Fig. B).
3. Place the Lid on the Receptacle so that
the Lid is stable and unable to rotate.
4. Lift the Locking Bar so that it comes
over the top of the Lid and locks,
holding the appliance together.
5. The Pusher must be used to guide
fruits and vegetables through the
Chute.
Match tabs
with Receptacle
Assembly
4
3
FIG. B
2
1
5

10 11
Self-Cleaning
The self-cleaning function helps
remove pulp build-up, which improves
the performance of the juicer. Using the
self-cleaning function can also make
fully cleaning the juicer easier. To use
the self-cleaning function:
1. Place an empty cup underneath
the Spout.
2. While slowly pouring water into
the Chute, lightly press the Self-
Cleaning Button three times. The
cleaning scraper will scrape off any
excess pulp.
3. Stop pouring water and let the
water drain.
4. Remove the cup with water.
5. After using the self-cleaning
function, you can either continue
juicing or shut off the juicer. If you
shut off the juicer, the juicer should
be fully cleaned (see the “Fully
Cleaning the Juicer” section).
Care & Cleaning
Disassembling
& Cleaning the
Self-Cleaning Scraper
1. Pull down the safety bar.
2. Remove the Lid and Pulp Guard
and look beneath them.
3. Remove the silicone cover from
the hooks on the Self-Cleaning
scraper (see Fig.C).
4. Clean the Self-Cleaning scraper.
Reassembling the
Self-Cleaning Scraper
1. Slide the silicone cover over the
Self-Cleaning scraper’s base.
2. Attach the sides of the cover to
the hooks on the scraper.
Fully Cleaning the Juicer
The juicer will need to be fully
cleaned periodically and when the
self-cleaning function does not
remove all food from the juicer. With
the exception of the Motor Base,
all the components can be put in
your home dishwasher. We
recommend top rack placement.*
1. Turn off the power switch
and wait until the motor stops
completely.
2. With dry hands, unplug the
power cord from electrical outlet.
3. Disassemble the machine (see
the “Disassembly” section).
4. Wipe the outside of the Power
Base with a warm, moist cloth
and mild detergent. Do not
submerge the Power Base in
water. Do not spray with water
or any other liquid. The Power
Base is not dishwasher safe.
IMPORTANT: Do not use
abrasive sponges, cloths, or
cleansers as these can damage
the nish.
5. Hold the Filter/Blade under
warm running water. Use a
cleaning brush to loosen the
leftover bers that may be stuck
to the Filter/Blade before
placing the Filter/Blade in the
dishwasher. Never use a wire
brush. Rinse the Filter/Blade from
the outside under running water.
A sink’s spray hose attachment is
especially effective for loosening
ber from the Filter/Blade.
6. Clean all other parts with a warm,
moist cloth and mild detergent.
Rinse well and dry thoroughly.
7. Dry the components thoroughly,
reassemble the machine (see
the “Assembly” section), and turn
on the power to spin out any
excess water.
8. Ensure the appliance and its
parts are completely dry before
storing in a cool, dry place.
*CAUTION: Some commercial
and foreign-made dishwashers may
reach internal temperatures that
are higher than machines made for
home use by US standards. Do not
use these dishwashers with your
juicer. The higher temperatures may
cause damage to appliance and can
void your guarantee. Check with your
dishwasher manufacturer before using.
Care & Cleaning
FIG. C

12 13
Juicing is a quick way to get many
of the health benets you need from
fresh food, including antioxidants
and nutrients.
We recommend juicing produce
items that you would normally
consume. Before juicing any produce,
it is important to wash it thoroughly
to remove all contaminants, including
soil and pesticides.
Skins, Stems, and Seeds
Skins: Juicing with the skins on
is a personal preference with
most produce.
Stems: The only stems that are
benecial to process are grape
stems. All others should be removed.
Seeds: Removing seeds is
discretionary due to certain health
risks associated with certain produce.
Carrots
Due to the irregular size and shape
of carrots, care must be taken when
juicing. Do not overll the chute.
Allow room for the carrots to move
and be pushed into the juicer. Use
the Pusher to guide the carrots and
prevent them from bouncing out of
the chute.
Citrus Fruits
We recommend the removal of
the skin from citrus fruits. The skin will
provide a tart avor to the juice. The
skin can also be difcult to process.
Juicing with or without the skin is a
personal preference.
Mangoes, Apricots, and Peaches
Important: Always remove large pits.
Do not put any produce in the juicer
with large pits. Pits will damage the
blade and possibly seize the motor.
Juicing Guidelines Juicing Guidelines
Ginger
Ginger is brous, juice small pieces
of ginger and do not juice more than
1 cup at a time.
Pomegranates and Cherries
These wonder fruits can absolutely
be juiced. When juicing cherries,
remove the pits. When juicing
pomegranates, only the seeds may
be used. You must remove the
outer skin and the inner membrane.
Pineapple and Melons
Although the juicer can process
the rind from these items, we
recommend removing the rind.
Pineapple is stringy in nature and
can cause a blockage at the opening
of the Spout. Monitor juice ow and
juicing progress to avoid blockages,
which can cause the Receptacle
to overow.
Berries and Small Fruits
When juicing berries (except
cranberries), you need to add other
juicier fruits (such as apples or
oranges) that produce more juice to
push the juice through the juicer. For
example, rst process the berries (you
may not see a lot of juice). Then, add
an apple or an orange – something
that will increase the volume of juice.
Keep the Pulp Collector Clean
When juicing, be sure to monitor the
Pulp Collector and empty it before
it is full. If the Pulp Collector lls and
pulp backs up into the lter, the
motor will shut off. The pulp can be
used for recipes or thrown away. You
can place a plastic bag in the Pulp
Collector to aid with clean-up.
The Benets of Juicing

14 15
Harder Fruits & Vegetables Ideal For Juicing
Apples
Asparagus
Brussels sprouts
Cabbages
Cantaloupe
Celery
Cherries (pitted)
Clementines
Cranberries
Cucumber
Fennel
Garlic
Ginger
Grapefruits
Grapes
Guava
Honeydew Melon
Horseradish
Jicama
Kiwi
Kohlrabi
Lemon
Lettuces
Lime
Nectarines
Onion
Oranges
Parsnip
Peaches (harder)
Pears (harder)
Peppers
Pineapple
Pomegranate seeds
Potatoes
Pumpkin
Radicchio
Radishes
Squashes
Strawberries
Tangerines
Tomatoes
Watermelon
Softer Fruits & Vegetables More Challenging For Juicing
Apricot
Basil
Beets
Blackberries
Blueberries
Broccoli
Carrots
Cauliower
Collard greens
Dandelion greens
Endive
Green beans
Green peas
Kale
Kiwi (very ripe)
Leafy greens
Leeks
Mango
Mint
Mushroom
Mustard greens
Nectarines (very ripe)
Okra (skin removed)
Papaya
Parsley
Passion fruit
Peaches (very ripe)
Pears (very ripe)
Peppermint
Pineapple (very ripe)
Plums
Raspberries
Spinach
Swiss chard
Tomatoes (very ripe)
Turnip
Watercress
Wheat grass
Fruits & Vegetables With High Juice Content
Apples
Cantaloupe
Celery
Clementines
Cranberries
Cucumber
Grapefruits
Grapes
Honeydew Melon
Lemon
Lime
Oranges
Peppers
Pineapple
Tangerines
Tomatoes
Watermelon
Juicing Chart Juicing Chart
Some varieties of produce are more
difcult to juice than others. The
amount of juice you process depends
on which fruits and vegetables you
select. Produce such as oranges,
apples, melons, and cucumbers tend
to yield more juice and should be
mixed with those that yield less juice.
The Juicing Chart can help take the
guesswork out of juicing.
DO NOT JUICE avocados, bananas,
or coconuts because they do not
contain juice. Rhubarb juice can be
used on its own or mixed with other
fresh juices. Wash the rhubarb bunch
thoroughly, removing the leaves,
because they are poisonous and not
safe for consumption. Rhubarb stalks
are very brous and may become
caught in the juicer.
Get the Most from Your Juicer

16
Troubleshooting
Symptom Possible Cause/Solution
Appliance does not run
when switched on
Check to see if the appliance is plugged in.
Locking bar is not locked in place properly.
Check if all parts are assembled.
Check if there is any residue left between the blade and the receptacle.
Make sure you wait 5–10 minutes to restart if the appliance
automatically shuts down.
Motor is unusually
loud and vibrating
Check that all parts are assembled properly and in the correct position.
Juicing brous items can create a lot of pulp and clog the Blade/Filter.
Turn off the appliance and clean the Blade/Filter.
The motor overheats
causing the power to
automatically shut off
Applying too much pressure with the Pusher while processing can cause
the motor to overheat, which activates the built-in thermal cut-off switch.
The motor will stop working for approximately 10 minutes to cool down
(see the “Safety Features” section).
The fruits and vegetables may be soft or overripe.
There may be too much pulp in the lter. Turn the appliance off
and clean the lter.
No juice is coming
out of the Spout
Make sure the Spout is facing downward while juicing.If the Spout
is facing upward, juice will not come out of the Spout and may overow
out of the receptacle.
Some produce, such as berries, may not be juicy enough.Add juicier
produce, such as apples and oranges, to the juicer to help push the juice
through the juicer.
SELF-CLEANING JUICER

18 19
Return Policy
If, for any reason, you would like to replace or return the product
under the money-back guarantee, your order number can be used
as the return merchandise authorization number (RMA). If the
product was purchased in a retail store, return the product to the
store or use “RETAIL” as the RMA. Return your product to the address
provided below for a replacement, which will incur no additional
processing and handling fees, or for the refund of your purchase
price, less processing and handling. You are responsible for the cost
of returning the product. You can locate your order number at
www.customerstatus.com. You can call customer service at 973-287-5150
or email [e-mail] for any additional questions.
Pack the product carefully and include in the package a note with
(1) your name, (2) mailing address, (3) phone number, (4) email address,
(5) reason for return, and (6) proof of purchase or order number,
and (7) specify on the note whether you are requesting a refund or
replacement. Write the RMA on the outside of the package.
Send the product to the following return address:
PowerXL Self-Cleaning Juicer
Tristar Products
500 Returns Road
Wallingford, CT 06495
If the replacement or refund request has not been acknowledged after
two weeks, please contact Customer Service at 973-287-5150.
Refund
Refunds requested within the money-back guarantee timeframe will
be issued to the payment method used at purchase if the item was
purchased directly from Tristar. If the item was purchased from an
authorized retailer, proof of purchase is required, and a check will be
issued for the item and sales tax amount. Processing and handling fees
are non-refundable.
60-Day Money-Back Guarantee
The PowerXL Self-Cleaning Juicer is covered by a 60-day
money-back guarantee. If you are not 100% satised with your
product, return the product and request a replacement product
or refund. Proof of purchase is required. Refunds will include the
purchase price, less processing and handling. Follow the instructions
in the Return Policy below to request a replacement or refund.
Replacement Guarantee Policy
Our products, when purchased from an authorized retailer, include
a 1-year replacement guarantee if your product or component part
does not perform as expected, the guarantee extends only to the
original purchaser and is not transferable.
If you experience an issue with one of our products within
1 year of purchase, return the product or the component part for
replacement with a functionally equivalent new product or part. The
original proof of purchase is required, and you are responsible to pay
to return the unit to us. In the event
a replacement unit is issued, the guarantee coverage ends
six (6) months following the receipt date of the replacement unit or
the remainder of the existing guarantee, whichever is later. Tristar
reserves the right to replace the unit with one of equal or greater
value.
SELF-CLEANING JUICER

Distributed by:
Tristar Products, Inc.
Faireld, NJ 07004
© 2020 Tristar Products, Inc.
Made in China
PXL-SCJ_IB_TP_ENG_V1_200702
We are very proud of
the design and quality of our
PowerXL Self-Cleaning Juicer.
This product has been manufactured
to the highest standards. Should you have any questions,
our friendly customer service staff is here to help you.
Visit us at www.TristarCares.com,
email us at [e-mail],
or call us at 973-287-5150.
SELF-CLEANING JUICER
