Triton AX Pro User manual
Precision Gaming Headset
3D Directional Gaming Headset Utilizing True Dolby Digital 5.1 Technology
.com
TRITTONUSA
.com
TRITTONUSA
True Dolby Digital 5.1
technologies
AX Pro
Register your product at Trittonusa.com to
receive news, updates and promotional deals.
Visit us on the web for more information and support:
trittonusa.com
Custom earcap covers, and pad sets will be available as well, check
the site for more information.Tritton Support is available Monday thru
Friday, 8am to 5pm PST
Call us at 800-431-1176
CONFIGURING AUDIO CONTROLLER
(Advanced) Package Contents
Remove
protective
caps before
installing.
Images not to scale.
FRONT
REAR
CENTER
SUB
The default settings of the audio controller are pre-optimized but can
be modified for user customization.
VOL/PL
Move the selector to the VOL/PL position
Button will select Pro Logic on/off
Button and will adjust volume up and down
(Pro Logic) When Dolby Pro Logic is “on” with an audio source
that is 2 channel, the audio will then be converted to 5.1 channel
sound. When Dolby Pro Logic is “off” with an audio source that is 2
channel, the audio will remain 2 channel stereo.
(Volume up/down) Pressing the volume up/down one time will adjust
the volume 1dB in either direction. Press and hold the volume up
to increase the volume to the maximum level. Press and hold the
volume down to decrease the volume to the minimum level (mute).
TD/DRC (Time Delay, Dynamic Range Control)
Move the selector to the TD/DRC position
Button now becomes DRC (Dynamic Range
Compression) on/off
TD/DRC (Continued)
Button and will now increase or decrease
the Time-Delay
- Toggle to change the time delay between the front channel and
the center channel, or the front channel and rear channels
Time Delay – Some users add time delay to the surround channels
to make the 3d effect more dramatic. To do this, set the switches as
shown.
Then press the + key about 10 times, this will set the time delay to
max for the “Surround” channels. You can also adjust the time delay to
the center channel, simply switch the left switch to the left, however
for gaming, this typically is less commonly used.
You can also use the time delay settings if you plug auxiliary speakers
into the side outputs, and use our device to output 5.1 to them.
v1: Volume Adjustment Switch
v2: Master Mute
v3: Mic Mute
v4: Chat Voice Volume Knob
v5: Individual Sound Field Switches
v6: Xbox Live Connection
Volume Control
To adjust the Master Volume, move the “Volume Adjustment Switch”(v1)
one way or the other. To mute the master volume, press inward on the
toggle switch (v2)
To adjust the volume of each channel individually, first press one of
the “Individual Sound Field Switches”(v5) and then adjust the Volume
Adjustment Switch(v1). The color will change based upon the volume
level. See back of controller for key.
Repeat this for all sound fields you wish to adjust.
To adjust master volume after this, you must wait 3 seconds for all the
channels to illuminate.
To reset the volume of all channels to the same level, simply adjust the
master volume level, all the way to the
lowest level, then turn it back up again.
Voice Communication Settings
To adjust the volume of the voices of
other players, use the “Chat Voice Volume Knob” (v4).
To Mute your voice so others cannot
hear you, toggle the “Mic Mute”(v3) switch.
controller and Xbox360 controller
to ensure “Dolby Digital” light on audio controller illuminates
Connect to
Xbox 360 Connect to
PS3 Connect to
PC with Optical
model.
ensure “Dolby Digital” light on audio controller illuminates
Connect to
PC with Analog
Connect to
DVD Player
Connect to
5.1 Speakers
Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, and the double-D symbol are registered trademarks of Dolby
Laboratories, all rights reserved.
©2008 Microsoft Corporation. All Rights Reserved. Xbox, Xbox Live, the Live Logo, and the Xbox logos are registered trademarks or trademarks of
Microsoft Corp.
©2008 Sony Computer Entertainment America Inc. All Rights Reserved. “PlayStation”, “PLAYSTATION”, “PS” Family logo and “PSP” are registered
trademarks of Sony Computer Entertainment Inc.
XBox360
HD Audio Dongle (Required) ships
with XBox360 Elite/Premium.
XBox Arcade sold separately.
FRONT
REAR
CENTER
SUB
Basic 4 Step Setup for All Optical Connections
CONNECTING YOUR AX PRO
Front of PS3
If you experience issues, visit us on
the web at TRITTONUSA.com, or call
us at 800.431.1176
1 Year Limited Warranty
TRITTON Technologies warrants that this product will be free from defects in materials and workmanship for a period of 1 year from the
date of purchase. If a product proves to be defective during this warranty period, TRITTON Technologies, at its option, either will repair the
defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product. In order to obtain
service under this warranty, you the Customer, must notify TRITTON Technologies of the defect before the expiration of the warranty period
and make suitable arrangements for the performance of service. The Customer shall be responsible for packaging and shipping the defective
product to a designated service center nominated by TRITTON Technologies. Customer shall be responsible for paying all shipping charges,
insurance, duties, taxes, and any other charges for products returned to us for any reason. This warranty shall not apply to any defect, failure
or damage caused by improper use or improper or inadequate maintenance and care. TRITTON Technologies shall not be obligated to furnish
service under this warranty: a) to repair damage resulting from attempts by personal other than TRITTON Technologies representatives to
install, repair or service the product, b) to repair damage resulting from improper use or connection to incompatible equipment, c) to repair any
damage or malfunction caused by the use of non TRITTON Technologies parts or supplies, or d) to service a product that has been modified or
integrated with other products when the effect of such a modification or integration increases the time or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TRITTON TECHNOLOGIES IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. TRITTON TECHNOLOGIES AND
ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TRITTON TECHNOLOGIES
RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE WHOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR
ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WETHER TRITTON TECHNOLOGIES OR THE VENDOR
HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES. TRITTON TECHNOLOGIES IS NOT LIABLE FOR ANY ILLEGAL USE OF EQUIPMENT
BY CUSTOMER. TRITTON TECHNOLOGIES IS NOT LIABLE FOR ANY DAMAGES RESULTING FROM USE OF THIS PRODUCT. USER OPERATES THIS
PRODUCT AT OWN RISK.
Permanent hearing loss may occur if headphones are used at high volume. Set the volume at a safe level and discontinue use if you
experience ringing in your ears or muffled speech.
FRONT
REAR
CENTER
SUB
v1
v2
v3
v4
v5
v6
To remove top head rail pad, hold headset
upside down, with microphone side of headset
close to your chest. Slide the pad away from
your body, and towards the “R” emblem on the
head rail. Once it pulls up a little, pull the pad
off. Installation is reverse of removal.
Slide
Pad
Removing Headrail Pad
Remove
protective
caps before
installing!
