Triton CHR P-7039 88400003 User manual

Installers please note these InstructIons are to be left wIth the user
2180706H - September 2016
Installation and
operating
instructions
Fixed riser
rail kit
88400003 CHR P-7039
*Mixer, showerhead, hose & handset are for illustration purposes only and not supplied.

2
FITTING
1
2
Ref. Description
1. Rigid riser rail pipe
2. Handset holder
3. Fixed spray arm
4. Arm mounting plate
5. Collar & outlet assembly
MAIN COMPONENTS
Fig.1
2
3
4

1
FITTING
150mm
1040mm approx
Datum
Hot
inlet
Cold
inlet
Bracket
mounting point
FITTING THE RISER PIPE/FIXED HEAD
• Mark the centre hole for the fixed head
mounting bracket at a height of 1040mm
(approx) from the inlet datum (fig.2).
Note: The elongated hole in the mounting
bracket allows for a small amount of adjustment.
• Drill and plug the wall. (An appropriate drill bit
should be used. If the wall is brick, plasterboard
or a soft building block, appropriate wall plugs
and screws should be fitted).
Fig.2

2
FITTING
• Secure the arm mounting plate to the wall
(fig.3).
• If the handset holder is required, depress the
button on the handset holder (fig.4), slide
the holder onto the pipe. The threaded
section of the riser pipe should be at the top.
• Screw the fixed showerhead arm to the top
of the riser pipe.
• Install the adaptor into the top outlet of the
mixer. Slide the base of the riser pipe into
the adaptor (fig.5), making sure the sealing
washer and locking collar are in place. Do
not fully tighten the collar at this time.
• Fit the rear section of the fixed arm over the
mounting plate, but do not fully tighten the
grub screw at this time. (fig.6).
• Adjust the riser pipe position to suit.
• Once correctly positioned, lock the diverter
collar. Finger tight should be sufficient.
Note: There is a small amount of depth
adjustment within the collar. Adjust the depth
of the bracket before securing in place to the
mounting plate.
• Using a suitable allen key, secure the fixed
arm in place by tightening the locking screw.
WARNING!
Check there are no hidden cables or
pipes before drilling holes for wall
plugs. Use great care when using power
tools near water. The use of a residual
current device (RCD) is recommended.
Fig.5
Fig.4
Fig.3
Riser pipe (threaded
section at the top)
Handset holder
Press button
and hold
to unlock
mechanism
Riser pipe
Collar
Seal
Adaptor
Angled section
facing down

3
FITTING
*Fitting the fixed showerhead (not supplied)
• Screw the fixed head (fig.7) to the fixed
spray arm. Make sure the sealing washer is in
place and screw tight to seal the joint.
*Fitting the hose and handset (not supplied)
• Connect the one end of the flexible hose
to the bottom outlet connector (fig.8) on
the mixer valve and the other end to the
handset, making sure that the seals are in
place. Carry out a Leak Test.
IMPORTANT: It is the conical end of the hose
which grips into the holder. The showerhead will
not fit in the holder without the hose attached.
LEAK TESTING
Fit the hose to the outlet and direct it to waste.
Open the supplies and test for leaks in the valve
connections. Remedy any leaks if necessary
CAUTION: Exposed metal surfaces may become
hot during use.
CLEANING
It is recommended that all products are cleaned
using warm, soapy water.
DO NOT use abrasive or aggressive
chemical cleaning products as this may
affect the product surface finish and
invalidate your guarantee. Fig.8
Fig.7
Fig.6
Seal
Seal
Seal

4
FITTING
Ref. Description Part No.
-Kit complete ........................... 88400003
1. Handset holder ....................... 83308810
2. Collar & outlet assembly......... 83311520
SPARE PARTS
1
2

5
FITTING
DIMENSIONS
65mm
G1/2B
361mm 75-90mm
ø20.6mm
1040mm
All dimensions listed in this tting book regarding the product and installation are approximate.
Illustration not to scale.

6
FITTING
Please refer to shower installation and operating instructions for service details.
