Triumph Trophy User manual

1
Foreword
FOREWORD
This handbook contains information on the Triumph Trophy and Trophy SE motorcycles. Always
store this owner's handbook with the motorcycle and refer to it for information whenever
necessary.
Warnings, Cautions and
Notes
Throughout this owner's handbook
particularly important information is
presented in the following form:
Note:
• This note symbol indicates points of
particular interest for more efficient
and convenient operation.
Warning
This warning symbol identifies special
instructions or procedures, which if not
correctly followed could result in personal
injury, or loss of life.
Caution
This caution symbol identifies special
instructions or procedures, which, if not
strictly observed, could result in damage to,
or destruction of, equipment.

2
Foreword
Warning Labels
At certain areas of the
motorcycle, the symbol (left)
can be seen. The symbol
means 'CAUTION: REFER TO
THE HANDBOOK' and will
be followed by a pictorial
representation of the subject
concerned.
Never attempt to ride the motorcycle or
make any adjustments without reference to
the relevant instructions contained in this
handbook.
See page 12 for the location of all labels
bearing this symbol. Where necessary, this
symbol will also appear on the pages
containing the relevant information.
Maintenance
To ensure a long, safe and trouble free life for
your motorcycle, maintenance should only be
carried out by an authorized Triumph dealer.
Only an authorized Triumph dealer will have
the necessary knowledge, equipment and
skills to maintain your Triumph motorcycle
correctly.
To locate your nearest Triumph dealer, visit
the Triumph web-site at www.triumph.co.uk
or telephone Triumph Motorcycles America
Limited on [phone].
Noise Control System
Tampering with the Noise Control System is
Prohibited.
Owners are warned that the law may
prohibit:
• The removal or rendering inoperative by
any person other than for purposes of
maintenance, repair or replacement, of
any device or element of design
incorporated into any new vehicle for the
purpose of noise control prior to its sale
or delivery to the ultimate purchaser or
while it is in use and,
• the use of the vehicle after such device or
element of design has been removed or
rendered inoperative by any person.
Immobilizer and Tire
Pressure Monitoring System
This device complies with part 15 of the FCC
Rules.
Operation is subject to the following two
conditions:
• This device may not cause harmful
interference;
• This device must accept any interference
received, including interference that may
cause undesired operation.
Changes or modifications to the device could
void the user's authority to operate the
equipment.

3
Foreword
Owner's Handbook
Thank you for choosing a Triumph
motorcycle. This motorcycle is the product of
Triumph's use of proven engineering,
exhaustive testing, and continuous striving for
superior reliability, safety and performance.
Please read this owner's handbook before
riding in order to become thoroughly familiar
with the correct operation of your
motorcycle's controls, its features, capabilities
and limitations.
This handbook includes safe riding tips, but
does not contain all the techniques and skills
necessary to ride a motorcycle safely.
Triumph strongly recommends that all riders
undertake a safety course approved by the
Motorcycle Safety Foundation to ensure safe
operation of this motorcycle. Information about
the nearest Motorcycle Safety Foundation
course to you can be obtained by calling the
following nationwide toll free number:
800-447-4700, or by writing to the Motorcycle
Safety Foundation at: 2, Jenner Street, Irvine,
California 92718. To ensure a long and trouble
free life for your motorcycle, maintenance
should be carried out as described in this
manual by an authorized Triumph dealer.
This handbook is also available from your
local dealer in:
•Dutch;
• French;
•German;
•Italian;
• Japanese;
• Spanish;
•Swedish.
Talk to Triumph
Our relationship with you does not end with
the purchase of your Triumph. Your feedback
on the buying and ownership experience is
very important in helping us develop our
products and services for you. Please help us
by ensuring your dealership has your E-mail
address and registers this with us. You will
then receive an online customer satisfaction
survey invitation to your E-mail address
where you can give us this feedback.
You r Tri um ph Te am .
Warning
This owner's handbook, and all other
instructions that are supplied with your
motorcycle, should be considered a
permanent part of your motorcycle and
should remain with it even if your
motorcycle is subsequently sold.
All riders must read this owner's handbook
and all other instructions which are
supplied with your motorcycle, before
riding, in order to become thoroughly
familiar with the correct operation of your
motorcycle's controls, its features,
capabilities and limitations. Do not lend
your motorcycle to others as riding when
not familiar with your motorcycle's
controls, features, capabilities and
limitations can lead to an accident.

Foreword
4
Information
The information contained in this publication is based on the latest information available at the
time of printing. Triumph reserves the right to make changes at any time without prior notice, or
obligation.
Not to be reproduced wholly or in part without the written permission of Triumph Motorcycles
America Limited.
© Copyright 09.2012 Triumph Motorcycles America Limited.
Publication part number 3853706 issue 1.
Table of Contents
This handbook contains a number of different sections. The table of contents below will help
you find the beginning of each section where, in the case of the major sections, a further table
of contents will help you find the specific subject required.
Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warning Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Parts Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Serial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
How to Ride the Motorcycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Accessories, Loading and Passengers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Maintenance and Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 9

5
Foreword - Safety First
FOREWORD - SAFETY FIRST
The Motorcycle
Warning
This motorcycle is designed for on-road
use only. It is not suitable for off-road use.
Off-road operation could lead to loss of
control of the motorcycle resulting in an
accident causing injury or loss of life.
Warning
This motorcycle is not designed to tow a
trailer or be installed with a sidecar.
Installing a sidecar and/or a trailer may
result in loss of control and an accident.
Warning
This motorcycle is designed for use as a
two-wheeled vehicle capable of carrying a
rider on his/her own, or a rider and one
passenger.
The total weight of the rider, and any
passenger, accessories and luggage must
not exceed the maximum load limit of
526 lbs (239 kg).
Warning
This motorcycle is installed with a catalytic
converter below the engine, which along
with the exhaust system reaches very high
temperature during engine operation.
Flammable materials such as grass,
hay/straw, leaves, clothing and luggage etc.
could ignite if allowed to come into contact
with any part of the exhaust system and
catalytic converter; always ensure
flammable materials are not allowed to
contact the exhaust system or catalytic
converter.

6
Foreword - Safety First
Fuel and Exhaust Fumes
Warning
Use of a motorcycle with the bank angle
indicator worn beyond the maximum limit
(when 0.2 in (5 mm) of the bank angle
indicator remains) will allow the motorcycle
to be banked to an unsafe angle.
Banking to an unsafe angle may cause
instability, loss of motorcycle control and
an accident.
1. Bank angle indicator
1
Warning
GASOLINE IS HIGHLY FLAMMABLE:
Always turn off the engine when refuelling.
Do not refuel or open the fuel filler cap
while smoking or in the vicinity of any
open (naked) flame.
Take care not to spill any gasoline on the
engine, exhaust pipes or mufflers when
refuelling.
If gasoline is swallowed, inhaled or allowed
to get into the eyes, seek immediate
medical attention.
Spillage on the skin should be immediately
washed off with soap and water and
clothing contaminated with gasoline
should immediately be removed.
Burns and other serious skin conditions
may result from contact with gasoline.
Warning
Never start your engine or let it run for any
length of time in a closed area. The
exhaust fumes are poisonous and may
cause loss of consciousness and death
within a short time. Always operate your
motorcycle in the open-air or in an area
with adequate ventilation.

7
Foreword - Safety First
Safety Helmet and Clothing
When choosing a helmet, always look for a
DOT (Department of Transport) sticker
indicating that the helmet has DOT approval.
Do not buy a helmet without DOT approval.
Parking
Warning
When riding the motorcycle, both rider and
passenger must always wear a motorcycle
helmet, eye protection, gloves, boots,
trousers (close fitting around the knee and
ankle) and a brightly colored jacket.
Brightly colored clothing will considerably
increase a rider's (or passenger's) visibility
to other operators of road vehicles.
Although full protection is not possible,
wearing correct protective clothing can
reduce the risk of injury when riding.
Warning
A helmet is one of the most important
pieces of riding gear as it offers protection
against head injuries. You and your
passenger's helmet should be carefully
chosen and should fit you or your
passenger's head comfortably and
securely. A brightly colored helmet will
increase a rider's (or passenger's) visibility
to other operators of road vehicles.
An open face helmet offers some
protection in an accident though a full face
helmet will offer more.
Always wear a visor or approved goggles
to help vision and to protect your eyes.
Warning
Always turn off the engine and remove the
ignition key before leaving the motorcycle
unattended. By removing the key, the risk
of use of the motorcycle by unauthorized
or untrained persons is reduced.
When parking the motorcycle, always
remember the following:
Engage first gear to help prevent the
motorcycle from rolling off the stand.
The engine and exhaust system will be hot
after riding. DO NOT park where
pedestrians, animals and/or children are
likely to touch the motorcycle.
Do not park on soft ground or on a steeply
inclined surface. Parking under these
conditions may cause the motorcycle to fall
over.
For further details, please refer to the 'How
to Ride the Motorcycle' section of this
owner's handbook.

8
Foreword - Safety First
Parts and Accessories
Triumph does not accept any liability
whatsoever for defects caused by the
installation of non-approved parts, accessories
or conversions or the installation of any
approved parts, accessories or conversions by
non-approved personnel.
Maintenance/Equipment
Warning
Owners should be aware that the only
approved parts, accessories and
conversions for any Triumph motorcycle
are those which carry official Triumph
approval and are mounted to the
motorcycle by an authorized dealer.
In particular, it is extremely hazardous to
mount or replace parts or accessories
whose installation requires the dismantling
of, or addition to, either the electrical or
fuel systems and any such modification
could cause a safety hazard.
The installation of any non-approved parts,
accessories or conversions may adversely
affect the handling, stability or other aspect
of the motorcycle operation that may result
in an accident causing injury or death.
Warning
Consult your authorized Triumph dealer
whenever there is doubt as to the correct
or safe operation of this Triumph
motorcycle.
Remember that continued operation of an
incorrectly performing motorcycle may
aggravate a fault and may also
compromise safety.
Warning
Ensure all equipment that is required by
law is installed and functioning correctly.
The removal or alteration of the
motorcycle's lights, mufflers, emission or
noise control systems can violate the law.
Incorrect or improper modification may
adversely affect the handling, stability or
other aspect of the motorcycle operation,
which may result in an accident causing
injury or death.
Warning
If the motorcycle is involved in an accident,
collision or fall, it must be taken to an
authorized Triumph dealer for inspection
and repair. Any accident can cause
damage to the motorcycle that, if not
correctly repaired, may cause a second
accident that may result in injury or death.

9
Foreword - Safety First
Riding
Warning
Never ride the motorcycle when fatigued
or under the influence of alcohol or other
drugs.
Riding when under the influence of alcohol
or other drugs is illegal.
Riding when fatigued or under the
influence of alcohol or other drugs reduces
the rider's ability to maintain control of the
motorcycle and may lead to loss of control
and an accident.
Warning
All riders must be licensed to operate the
motorcycle. Operation of the motorcycle
without a license is illegal and could lead to
prosecution.
Operation of the motorcycle without
formal training in the correct riding
techniques that are necessary to become
licensed is dangerous and may lead to loss
of motorcycle control and an accident.
Warning
Always ride defensively and wear the
protective equipment mentioned
elsewhere in this foreword. Remember, in
an accident, a motorcycle does not give the
same impact protection as a car.
Warning
This Triumph motorcycle should be
operated within the legal speed limits for
the particular road travelled. Operating a
motorcycle at high speeds can be
potentially dangerous since the time
available to react to given traffic situations
is greatly reduced as road speed increases.
Always reduce speed in potentially
hazardous driving conditions such as bad
weather or heavy traffic.

10
Foreword - Safety First
Warning
Continually observe and react to changes
in road surface, traffic and wind conditions.
All two-wheeled vehicles are subject to
external forces which may cause an
accident. These forces include but are not
limited to:
• Wind draft from passing vehicles;
• Potholes, uneven or damaged road
surfaces;
• Bad weather;
• Rider error.
Always operate the motorcycle at
moderate speed and away from heavy
traffic until you have become thoroughly
familiar with its handling and operating
characteristics. Never exceed the legal
speed limit.
Warning
Banking to an unsafe angle may cause
instability, loss of motorcycle control and
an accident.
Warning
Ensure that you know and respect the rules
of the road. Read and observe publications
such as 'MOTORCYCLE SAFETY', 'YOU
AND YOUR MOTORCYCLE, RIDING
TIPS' and also read and become familiar
with the contents of the MOTORCYCLE
HANDBOOK for your state.
Caution
This Triumph motorcycle is not mounted
with spark arresters. Operation in forests,
brush or grass areas may violate state and
local laws and regulations.

11
Foreword - Safety First
Wobble/Weave
A weave is a relatively slow oscillation of the
rear of the motorcycle, while a wobble is a
rapid, possibly strong shaking of the
handlebar. These are related but distinct
stability problems usually caused by excessive
weight in the wrong place, or by a
mechanical problem such as worn or loose
bearings or under-inflated or unevenly worn
tires.
Your solution to both situations is the same.
Keep a firm hold on the handlebars without
locking arms or fighting the steering.
Smoothly ease off the throttle to slow
gradually. Do not apply the brakes, and do
not accelerate to try to stop the wobble or
weave. In some cases, it helps to shift your
body weight forward by leaning over the
tank.
Copyright © 2005 Motorcycle Safety
Foundation. All rights reserved. Used with
permission.
Handlebars and Footrests
Warning
The rider must maintain control of the
vehicle by keeping hands on the
handlebars at all times.
The handling and stability of a motorcycle
will be adversely affected if the rider
removes his hands from the handlebars,
resulting in loss of motorcycle control and
an accident.
Warning
The rider and passenger must always use
the footrests provided, during operation of
the vehicle.
By using the footrests, both rider and
passenger will reduce the risk of
inadvertent contact with any motorcycle
components and will also reduce the risk of
injury from entrapment of clothing.

Warning Labels
12
WARNING LABELS
The labels detailed on this and the following pages draw your attention to important safety
information in this handbook. Before riding, ensure that all riders have understood and
complied with all the information to which these labels relate.
Warning Label Locations - Trophy and Trophy SE
chqw
R.P.M.
Coolant
(page 12 7 )
Tires
(page 14 3 )
Tire Pressure Monitoring
(if equipped) (page 52)
Windshield
(page 16 4 )
Cockpit
Stowage
(page 113 )
Helmet
(page 7)

Warning Labels
13
Warning Label Locations - Trophy and Trophy SE (continued)
Caution
All warning labels and decals, with the exception of the Breaking-in label, are mounted to the
motorcycle using a strong adhesive. In some cases, labels are installed prior to an application
of paint lacquer. Therefore, any attempt to remove the warning labels will cause damage to
the paintwork or bodywork.
chqt
P
b
X
X
R.P.M.
Daily Safety Checks
(page 96)
Unleaded Fuel
(page 70)
Engine Oil
(page 12 4 )
Cockpit Stowage
(page 113 )
Breaking-In
(page 95)

14
Parts Identification
PARTS IDENTIFICATION
1. Headlight
2. Front turn signal
3. Accessory socket
4. Front heated seat switch (if
equipped)
5. Fuse boxes
6. Tool kit/Accessory U-lock storage
location
7. Accessory socket (if equipped)
8. Accessory socket (if top box
equipped)
9. Seat lock
10. Rear brake caliper
11. C e n t e r s t a n d
12. Rear suspension spring rebound
damping adjuster (models without
Triumph Electronic Suspension (TES))
13. Gear-change pedal
14 . S i d e s t a n d
15. Coolant expansion tank
16. Front brake caliper
17. Front brake disc
chqw
12468
111213151617 14 910
37
5

15
Parts Identification
18. Rear heated seat switch (if
equipped)
19. Rear brake fluid reservoir
20. Relays (both sides)
21. Fuel tank and fuel filler cap
22. Front fork rebound damping
adjuster (models without Triumph
Electronic Suspension (TES))
23. Battery and main fuse
24. Radio antenna (models fitted with
audio system)
25. Front fork
26. Engine oil level sight glass
27. Oil filler cap
28. Rear brake pedal
29. Rear suspension spring pre-load
adjuster (models without Triumph
Electronic Suspension (TES))
30. Muffler
31. Rear brake disc
32. Rear turn signal/brake/tail light
assembly
chqt
18 19
27
22 23 24
282931 30
20
2526
21
32

16
Parts Identification
Parts Identification (continued)
1. C l u t c h l e v e r
2. Passing button
3. Headlight dimmer switch
4. Instrument's scroll button
5. Clutch fluid reservoir
6. Speedometer
7. H a z a r d w a r n i n g light button
8. Multi-function display screen
9. Tachometer
10. Front brake fluid reservoir
11. R e a r v i e w m i r r o r
12. Front brake lever
13. Engine stop switch
14. Starter button
15. Cruise control adjust button
16. Cruise control ON/OFF button
17. Ignition switch
18. Fuel filler cap
19. Audio controls (models fitted with
audio system)
20. Windshield adjustment switch
21. Heated grip switch
22. Instrument's select button
23. Direction turn signal switch
24. Horn button
chsc
2 3 4 5 6 7 8 9 10 11
13
14151617182021222324 19
121

17
Serial Numbers
SERIAL NUMBERS
Vehicle Identification
Number (VIN)
1. V I N n u m b e r
The Vehicle Identification Number (VIN) is
stamped into the steering head area of the
frame. In addition, it is displayed on a label
which is also adjacent to the steering head.
Record the vehicle identification number in
the space provided below.
Engine Serial Number
1. Engine serial number
The engine serial number is stamped on the
engine crankcase, immediately below the
gearbox.
Record the engine serial number in the space
provided below.
chsk
1
chsm
1

Serial Numbers
18
This page intentionally left blank

19
General Information
GENERAL INFORMATION
Table of Contents
Instrument Panel Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Multi-function Display Screen Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Tachometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Multi-function Display Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Warning Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Direction Turn Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
High Beam. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Low Fuel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Neutral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Low Oil Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
High Coolant Temperature Warning Light. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Engine Management System Malfunction Indicator Light . . . . . . . . . . . . . . . . . . . . . . . . 27
Battery Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Alarm/Immobilizer Indicator Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Tire Pressure Warning Light (if TPMS is fitted) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Triumph Electronic Suspension (TES) Warning Light
(if electronic suspension is fitted) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Frost Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Traction Control Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Cruise Control Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Multi-function Display Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Ambient Air Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Gear Position Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Fuel Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Heated Seats (if equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Heated Grips (if equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Service Interval Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Low Battery Warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

20
General Information
Central Display Area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Trip Computer 1 and 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Trip Computer Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Settings Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Profile 1 and 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Adjustment Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Trip Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Bike Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Lower Message Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Automatic Self-Cancelling Turn Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Units of Measure (Imperial, US or Metric) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Tire Pressure Monitoring System (TPMS) (if equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
TPMS Sensor ID Number. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
System Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Sensor Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
TPMS Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Tire Pressures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Replacement Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Triumph Traction Control (TTC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Triumph Traction Control Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Triumph Electronic Suspension (TES) (if equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Activating Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Deactivating Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Resuming the Cruise Control Set Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Increasing Speed while in Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Decreasing Speed while in Cruise Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Ignition Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Ignition Switch/Steering Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Engine Immobilizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Ignition Switch Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
