Triumph Daytona 675 2014 User guide

Owner’s Handbook
Daytona 675, Daytona 675 R, Street Triple,
Street Triple R and Street Triple Rx
1
This handbook contains information on the Triumph Daytona 675, Daytona 675 R,
Street Triple, Street Triple R and Street Triple Rx motorcycles. Always store this
Owner's Handbook with the motorcycle and refer to it for information whenever
necessary.
The information contained in this publication is based on the latest information
available at the time of printing. Triumph reserves the right to make changes at any
time without prior notice, or obligation.
Not to be reproduced wholly or in part without the written permission of
Triumph Motorcycles America Limited.
© Copyright 09.2014 Triumph Motorcycles America Limited.
Publication part number 3854145-US issue 1.
chtq_4

2
Table of Contents
This handbook contains a number of different sections. The table of contents below
will help you find the beginning of each section where, in the case of the major
sections, a further table of contents will help you find the specific subject required.
Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warning Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Parts Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Serial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
How to Ride the Motorcycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Accessories, Loading and Passengers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Maintenance and Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Foreword
3
FOREWORD
Owner's Handbook
Thank you for choosing a Triumph
motorcycle. This motorcycle is the
product of Triumph's use of proven
engineering, exhaustive testing, and
continuous striving for superior
reliability, safety and performance.
Please read this Owner's Handbook
before riding in order to become
thoroughly familiar with the correct
operation of your motorcycle's controls,
its features, capabilities and limitations.
This handbook includes safe riding tips,
but does not contain all the techniques
and skills necessary to ride a motorcycle
safely.
Triumph strongly recommends that all
riders undertake a safety course
approved by the Motorcycle Safety
Foundation to ensure safe operation of
this motorcycle. Information about the
nearest Motorcycle Safety Foundation
course to you can be obtained by calling
the following nationwide toll free
number: 800-447-4700, or by writing to
the Motorcycle Safety Foundation at: 2,
Jenner Street, Irvine, California 92718. To
ensure a long and trouble free life for
your motorcycle, maintenance should be
carried out as described in this manual
by an authorized Triumph dealer.
This handbook is also available from your
local dealer in:
•Brazilian
•Dutch
•French
•German
•Italian
• Japanese
•Spanish
•Swedish.
Warning
This Owner's Handbook, and all other
instructions that are supplied with
your motorcycle, should be considered
a permanent part of your motorcycle
and should remain with it even if your
motorcycle is subsequently sold.
All riders must read this Owner's
Handbook and all other instructions
which are supplied with your
motorcycle, before riding, in order to
become thoroughly familiar with the
correct operation of your motorcycle's
controls, its features, capabilities and
limitations. Do not lend your
motorcycle to others as riding when
not familiar with your motorcycle's
controls, features, capabilities and
limitations can lead to an accident.

Foreword
4
Talk to Triumph
Our relationship with you does not end
with the purchase of your Triumph. Your
feedback on the buying and ownership
experience is very important in helping
us develop our products and services for
you. Please help us by ensuring your
dealership has your email address and
registers this with us. You will then
receive an online customer satisfaction
survey invitation to your email address
where you can give us this feedback.
Your Triumph Team.
Warnings, Cautions and
Notes
Throughout this Owner's Handbook
particularly important information is
presented in the following form:
Note:
•Thisnotesymbolindicates points of
particular interest for more efficient
and convenient operation.
Warning Labels
At certain areas of the
motorcycle, the symbol
(left) can be seen. The
symbol means 'CAUTION:
REFER TO THE HANDBOOK'
and will be followed by a
pictorial representation of
the subject concerned.
Never attempt to ride the motorcycle or
make any adjustments without
reference to the relevant instructions
contained in this handbook.
See page 12 for the location of all labels
bearing this symbol. Where necessary,
this symbol will also appear on the pages
containing the relevant information.
Maintenance
To ensure a long, safe and trouble free
life for your motorcycle, maintenance
should only be carried out by an
authorized Triumph dealer. Only an
authorized Triumph dealer will have the
necessary knowledge, equipment and
skills to maintain your Triumph
motorcycle correctly.
To locate your nearest Triumph dealer,
visit the Triumph website at
www.triumph.co.uk or telephone
Triumph Motorcycles America Limited on
[phone].
Warning
This warning symbol identifies special
instructions or procedures, which if
not correctly followed could result in
personal injury, or loss of life.
Caution
This caution symbol identifies special
instructions or procedures, which, if
not strictly observed, could result in
damage to, or destruction of,
equipment.

Foreword
5
Noise Control System
Tampering with the Noise Control
System is Prohibited.
Owners are warned that the law may
prohibit:
• the removal or rendering inoperative
by any person other than for
purposes of maintenance, repair or
replacement, of any device or
element of design incorporated into
any new vehicle for the purpose of
noise control prior to its sale or
delivery to the ultimate purchaser or
while it is in use and,
• the use of the vehicle after such
device or element of design has been
removed or rendered inoperative by
any person.
Immobilizer and Tire Pressure
Monitoring System
This device complies with part 15 of the
FCC Rules.
Operation is subject to the following two
conditions:
• This device may not cause harmful
interference.
• This device must accept any
interference received, including
interference that may cause
undesired operation.
Changes or modifications to the device
could void the user's authority to
operate the equipment.
Tires
With reference to the Pneumatic Tires and
Tubes for Automotive Vehicles (Quality
Control) Order, 2009, Cl. No. 3 (c), it is
declared by M/s. Triumph Motorcycles Ltd.
that the tires mounted on this
motorcycle meet the requirements of
IS15627: 2005 and comply with the
requirements under Central Motor
Vehicle Rules (CMVR), 1989.

Foreword - Safety First
6
FOREWORD - SAFETY FIRST
The Motorcycle Fuel and Exhaust Fumes
Warning
This motorcycle is designed for
on-road use only. It is not suitable for
off-road use.
Off-road operation could lead to loss
of control of the motorcycle resulting
in an accident causing injury or loss of
life.
Warning
This motorcycle is not designed to tow
a trailer or have a sidecar installed.
Installing a sidecar and/or a trailer
may result in loss of control and an
accident.
Warning
This motorcycle is designed for use as
a two-wheeled vehicle capable of
carrying a rider on his/her own, or a
rider and one passenger (subject to a
passenger seat being installed).
The total weight of the rider, and any
passenger, accessories and luggage
must not exceed the maximum load
limit of 195 kg.
Warning
GASOLINE IS HIGHLY FLAMMABLE:
Always turn off the engine when
refueling.
Do not refuel or open the fuel filler cap
while smoking or in the vicinity of any
open (naked) flame.
Take care not to spill any gasoline on
the engine, exhaust pipes or mufflers
when refueling.
If gasoline is swallowed, inhaled or
allowed to get into the eyes, seek
immediate medical attention.
Spillage on the skin should be
immediately washed off with soap and
water and clothing contaminated with
gasoline should immediately be
removed.
Burns and other serious skin
conditions may result from contact
with gasoline.
Warning
Never start your engine or let it run
for any length of time in a closed area.
The exhaust fumes are poisonous and
may cause loss of consciousness and
death within a short time. Always
operate your motorcycle in the open-
air or in an area with adequate
ventilation.

Foreword - Safety First
7
Riding
Warning
Never ride the motorcycle when
fatigued or under the influence of
alcohol or other drugs.
Riding when under the influence of
alcohol or other drugs is illegal.
Riding when fatigued or under the
influence of alcohol or other drugs
reduces the rider's ability to maintain
control of the motorcycle and may
lead to loss of control and an accident.
Warning
All riders must be licensed to operate
the motorcycle. Operation of the
motorcycle without a license is illegal
and could lead to prosecution.
Operation of the motorcycle without
formal training in the correct riding
techniques that are necessary to
become licensed is dangerous and
may lead to loss of motorcycle control
and an accident.
Warning
Always ride defensively and wear the
protective equipment mentioned
elsewhere in this foreword. Remember,
in an accident, a motorcycle does not
give the same impact protection as a
car.
Warning
This Triumph motorcycle should be
operated within the legal speed limits
for the particular road traveled.
Operating a motorcycle at high speeds
can be potentially dangerous since the
time available to react to given traffic
situations is greatly reduced as road
speed increases. Always reduce speed
in potentially hazardous driving
conditions such as bad weather or
heavy traffic.
Warning
Continually observe and react to
changes in road surface, traffic and
wind conditions. All two-wheeled
vehicles are subject to external forces
which may cause an accident. These
forces include but are not limited to:
• Wind draft from passing vehicles
• Potholes, uneven or damaged road
surfaces
•Badweather
• Rider error.
Always operate the motorcycle at
moderate speed and away from heavy
traffic until you have become
thoroughly familiar with its handling
and operating characteristics. Never
exceed the legal speed limit.

Foreword - Safety First
8
Wobble/Weave
A weave is a relatively slow oscillation of
the rear of the motorcycle, while a
wobble is a rapid, possibly strong
shaking of the handlebar. These are
related but distinct stability problems
usually caused by excessive weight in
the wrong place, or by a mechanical
problem such as worn or loose bearings
or under-inflated or unevenly worn tires.
Your solution to both situations is the
same. Keep a firm hold on the
handlebars without locking arms or
fighting the steering. Smoothly ease off
the throttle to slow gradually. Do not
apply the brakes, and do not accelerate
to try to stop the wobble or weave. In
some cases, it helps to shift your body
weight forward by leaning over the tank.
Copyright © 2005 Motorcycle Safety
Foundation. All rights reserved. Used
with permission.
Helmet and Clothing
Warning
Ensure that you know and respect the
rules of the road. Read and observe
publications such as 'MOTORCYCLE
SAFETY', 'YOU AND YOUR
MOTORCYCLE, RIDING TIPS' and also
read and become familiar with the
contents of the MOTORCYCLE
HANDBOOK for your state.
Caution
This Triumph motorcycle is not
equipped with spark arresters.
Operation in forests, brush or grass
areas may violate state and local laws
and regulations.
Warning
When riding the motorcycle, both rider
and passenger must always wear a
motorcycle helmet, eye protection,
gloves, boots, trousers (close fitting
around the knee and ankle) and a
brightly colored jacket. Brightly
colored clothing will considerably
increase a rider's (or passenger's)
visibility to other operators of road
vehicles. Although full protection is
not possible, wearing correct
protective clothing can reduce the risk
of injury when riding.
Warning
A helmet is one of the most important
pieces of riding gear as it offers
protection against head injuries. You
and your passenger's helmet should
be carefully chosen and should fit you
or your passenger's head comfortably
and securely. A brightly colored
helmet will increase a rider's (or
passenger's) visibility to other
operators of road vehicles.
An open face helmet offers some
protection in an accident though a full
face helmet will offer more.
Always wear a visor or approved
goggles to help vision and to protect
your eyes.
cbma

Foreword - Safety First
9
When choosing a helmet, always look for
a DOT (Department of Transport) sticker
indicating that the helmet has DOT
approval. Do not buy a helmet without
DOT approval.
Handlebars and Footrests
Warning
The rider must maintain control of the
vehicle by keeping hands on the
handlebars at all times.
The handling and stability of a
motorcycle will be adversely affected if
the rider removes his hands from the
handlebars, resulting in loss of
motorcycle control and an accident.
Warning
The rider and passenger must always
use the footrests provided, during
operation of the vehicle.
By using the footrests, both rider and
passenger will reduce the risk of
inadvertent contact with any
motorcycle components and will also
reduce the risk of injury from
entrapment of clothing.
Warning
When banking and the bank angle
indicator, attached to the rider's
footrest, makes contact with the
ground, the motorcycle is nearing its
bank angle limit. A further increase of
the banking angle is unsafe. Banking
to an unsafe angle may cause
instability, loss of motorcycle control
and an accident.
Warning
The bank angle indicators must not be
used as a guide to how far the
motorcycle may be safely banked. This
depends on many various conditions
including, but not limited to, road
surface, tire condition and weather.
Banking to an unsafe angle may cause
instability, loss of motorcycle control
and an accident.
Warning
Use of a motorcycle with bank angle
indicators worn beyond the maximum
limit will allow the motorcycle to be
banked to an unsafe angle.
The bank angle indicators have
reached the maximum wear limit and
should be replaced when they have
worn down to a length of:
•15mm(StreetTriple)
• 5 mm (Daytona 675, Daytona 675 R,
Street Triple R and Street Triple Rx).
Banking to an unsafe angle may cause
instability, loss of motorcycle control
and an accident.
1. Bank angle indicator
2. Wear limit measurement
1
2

Foreword - Safety First
10
Parking Parts and Accessories
Triumph does not accept any liability
whatsoever for defects caused by the
installation of non-approved parts,
accessories or conversions or the
installation of any approved parts,
accessories or conversions by
non-approved personnel.
Warning
Always turn off the engine and
remove the ignition key before leaving
the motorcycle unattended. By
removing the key, the risk of use of
the motorcycle by unauthorized or
untrained persons is reduced.
When parking the motorcycle, always
remember the following:
Engage first gear to help prevent the
motorcycle from rolling off the stand.
The engine and exhaust system will be
hot after riding. DO NOT park where
pedestrians, animals and/or children
are likely to touch the motorcycle.
Do not park on soft ground or on a
steeply inclined surface. Parking
under these conditions may cause the
motorcycle to fall over.
For further details, please refer to the
How to Ride the Motorcycle section of
this Owner's Handbook.
Warning
Owners should be aware that the only
approved parts, accessories and
conversions for any Triumph
motorcycle are those which carry
official Triumph approval and are
mounted to the motorcycle by an
authorized dealer.
In particular, it is extremely hazardous
to install or replace parts or
accessories whose installation requires
the dismantling of, or addition to, either
the electrical or fuel systems and any
such modification could cause a safety
hazard.
The installation of any non-approved
parts, accessories or conversions may
adversely affect the handling, stability
or other aspect of the motorcycle’s
operation that may result in an
accident causing injury or death.

Foreword - Safety First
11
Maintenance/Equipment
Warning
Consult your authorized Triumph
dealer whenever there is doubt as to
the correct or safe operation of this
Triumph motorcycle.
Remember that continued operation
of an incorrectly performing
motorcycle may aggravate a fault and
may also compromize safety.
Warning
Ensure all equipment that is required
by law is installed and functioning
correctly. The removal or alteration of
the motorcycle's lights, mufflers,
emission or noise control systems can
violate the law. Incorrect or improper
modification may adversely affect the
handling, stability or other aspect of
the motorcycle’s operation, which may
result in an accident causing injury or
death.
Warning
If the motorcycle is involved in an
accident, collision or fall, it must be
taken to an authorized Triumph dealer
for inspection and repair. Any accident
can cause damage to the motorcycle
that, if not correctly repaired, may
cause a second accident that may
result in injury or death.

12
Warning Labels
WARNING LABELS
The labels detailed on this and the following pages draw your attention to important
safety information in this handbook. Before riding, ensure that all riders have
understood and complied with all the information to which these labels relate.
Warning Label Locations - Daytona 675 and Daytona 675 R
chtr
R.P.M.
6
5
4
3
2
N
1
Gear Position
(page 68)
Windshield
(page 147)
Drive Chain
(page 102)
Tires
(page 126)
Tire Pressure
Monitoring (if equipped)
(page 128)
Breaking-in
(page 63)
Headlights
(page 137)

13
Warning Labels
Warning Label Locations - Daytona 675 and Daytona 675 R
(continued)
Caution
All warning labels and decals, with the exception of the Breaking-in label, are
mounted to the motorcycle using a strong adhesive. In some cases, labels are
installed prior to an application of paint lacquer. Therefore, any attempt to remove
the warning labels will cause damage to the paintwork or bodywork.
chtq
P
b
Engine Oil
(page 89)
Daily Safety Checks
(page 64)
Unleaded Fuel
(page 56)Helmet
(page 8)
Coolant
(page 94)

14
Warning Labels
Warning Label Locations - Street Triple, Street Triple R and
Street Triple Rx
chrb
R.P.M.
6
5
4
3
2
N
1
Gear Position
(page 68)
Breaking-in
(page 63)Coolant
(page 97)
Tires
(page 126)
Tire Pressure
Monitoring (if equipped)
(page 128)
Drive Chain
(page 102)
Headlights
(page 137)

15
Warning Labels
Warning Label Locations - Street Triple, Street Triple R and
Street Triple Rx (continued)
Caution
All warning labels and decals, with the exception of the Breaking-in label, are
mounted to the motorcycle using a strong adhesive. In some cases, labels are
installed prior to an application of paint lacquer. Therefore, any attempt to remove
the warning labels will cause damage to the paintwork or bodywork.
P
b
Engine Oil
(page 89)
Daily Safety Checks
(page 64)
Unleaded Fuel
(page 56)
Helmet
(page 8)

Parts Identification
16
PARTS IDENTIFICATION
Daytona 675 and Daytona 675 R
1. Headlight
2. Fuel filler cap
3. Fuel tank
4. Rear suspension unit
5. Battery
6. Seat lock
7. Brake light
8. Drive chain
9. Gear shift pedal
10. Side stand
11. Oil cooler/Heat exchanger
12. Front turn signal
13. Front brake caliper
14. Front brake disc
chtr
2 3 4 6 7
12 11 10 9 814 13
51

Parts Identification
17
Daytona 675 and Daytona 675 R (continued)
15. Rear turn signal
16. Tool kit
17. Rear brake fluid reservoir
18. Radiator/Coolant pressure cap
19. Front fork
20. Coolant expansion tank
21. Clutch cable
22. Dipstick
23. Oil filler cap
24. Rear brake pedal
25. Muffler
26. Rear brake disc
27. Rear brake caliper
chtq
17 1918
24 22 2127 26 25
16
23 20
15

Parts Identification
18
Daytona 675 and Daytona 675 R (continued)
1. Clutch lever
2. Passing button
3. Headlight dimmer switch
4. Trip computer display
5. Speedometer
6. Tachometer
7. Front brake fluid reservoir
8. Engine stop switch
9. Front brake lever
10. Starter button
11. Ignition switch
12. Horn button
13. Turn signal switch
chts
10
13 1112
54612 3 7 98

Parts Identification
19
Street Triple, Street Triple R and Street Triple Rx
1. Clutch lever
2. Passing button
3. Headlight dimmer switch
4. Trip computer display
5. Speedometer
6. Tachometer
7. Front brake fluid reservoir
8. Engine stop switch
9. Front brake lever
10. Starter button
11. Ignition switch
12. Turn signal switch
13. Horn button
chro
13 12 11 10
1 2 3 4 5 6 7 8 9

Parts Identification
20
Street Triple, Street Triple R and Street Triple Rx (continued)
1. Headlight
2. Fuel filler cap
3. Fuel tank
4. Rear suspension unit
5. Seat lock
6. Brake light
7. D r i v e c h a i n
8. Coolant expansion tank
9. Gear shift pedal
10. Side stand
11. Oil cooler/Heat exchanger
12. Front turn signal
13. Front brake caliper
14. Front brake disc
chrb_1
2 3 4 5 6
12 11 10 9 714 13
1
8
