Trivum RP321 User manual

Quick Installation Guide
RP321
AN: 301023
Connection example:
Connection examples with trivum Audio Extenders:
🛒 All trivum products are available in our online shop www.trivum.com
Article Numbers:
Technical Data
Required components for installation:
• 24 V DC power supply, at least 4A (e.g. PS24/100 4.2A by trivum AN: 500023)
• ethernet cable
• network with DHCP capable router
• Browser (PC / Mac) or trivum App
• speakers with 4 or 8 Ohms impedance
1. RP321: 301023
2. XT:LINE: 500041
3. XR:LINE: 500042
4. REG PS 24/100 (4.2A): 500023
5. Audio Extender PS 15V: 500049
6. TouchPad 7": 600013
We reserve the right to make misprints, mistakes and changes in the case of product progress, even without prior
notice. 01/2022
Zones 2 Zones
Expandable to up to 64 zones
Source 2x Streaming
1x DAB+/FM Tuner
2x analog Line Input
Streaming 2x up to 192kHz 24Bit
Radio DAB+/FM
External Sources 2x Line In analog via 3.5 Jack
Music Formats MP3, AAC, FLAC, M4A, WMA, ALAC
Connections 1x Network (RJ45 Socket)
2x Speaker Stereo (4-Pin connector)
2x Analog Line Input
1x Antenna (2-pin connector)
1x Power (2-pin connector)
Amplier Class D, 4x 30W @ 4 Ohm
Power Supply 24V, 4A (192 W) 2-pin connector
Casing REG 8 units (142mm)
Weight 0,170 kg
LAN
DHCP
NAS
(optional)
trivum TouchPad
(optional)
DHCP
Browser or App
wireless
Power 24V / 4A
Line In
TV, Bluetooth receiver, etc
Speakers
Network SpeakersDAB+/FM
Radio
RP321
2x Streaming
1x DAB+ / FM Tuner
2x Line-In with Trigger
4x 30 Watt
2-Zone SoundSystem
24V DC
Antenna
Output 1
Left Right
Left Right
Output 2
Analog Out
RCA
XT:LINE
Bluetooth receiver
Power 15V
XR:LINE
Analog Line InCAT 5/6/7 RP321
2x Streaming
1x DAB+ / FM Tuner
2x Line-In with Trigger
4x 30 Watt
2-Zone SoundSystem
24V DC
Antenna
Output 1
Left Right
Left Right
Output 2

1. Mounting and connection
1.1 Mount the RP321 on a 35 mm DIN-rail.
1.2 Connect cables to audio speakers (check polarity), Ethernet network and power supply.
⚠ Warning: Wrong polarity may damage the device! Double check power cable polarity before connecting!
2. Conguration
The trivum RP321 has to be congured via web browser. We recommend you to use the trivum Apps or trivum ServerAdmin Tool.
The trivum Apps and ServerAdmin Tool will scan and list all trivum devices and their IP addresses in your network.
Using trivum App (iOS or Android)
2.1 Please scan QR Code to download the trivum iOS App or Android App. You can also visit -> https://trivum.de/apps
2.2 Start the App and tap on the button "Select trivum system" .
Then all trivum devices in your network, their IP addresses and serial numbers will be listed..
Using trivum ServerAdminTool (Windows)
2.3 Please download and install the ServerAdmin Tool. -> https://trivum.de/admin-tool
2.4 Start the ServerAdmin Tool.
2.5 Double-click on the device (RP321) to open the Music Center WebCong (main cong site).
ℹ Note: If you are not sure about the assignment of the listed devices, you can compare the serial number in the list with the
serial number on your device.
2.6 If you need static IP instead of DHCP: click "Network".
2.7 Select "Use static IP address".
2.8 Enter your IP settings and Restart to apply changes.
3. Adding a network share
The trivum RP321 can play audio les which are stored on network shares. If you want to use a shared directory, make sure that it
supports the media sharing service Samba service (smb). To add a network share (e.g. NAS):
3.1 Open the Music Center WebCong.
3.2 Click: "Music on NAS -> Setup music library -> Add network share".
3.3 Set the network path and user/password if required.
3.4 Click "Save as new share".
3.5 Click "Refresh" your music index now.
4. Adding your Online streaming service account
4.1 Open the Music Center WebCong.
4.2 Click "Streaming".
4.3 Click "Add Service".
4.4 Select your favorite service and enter your user account.
4.5 Click Create the streaming service given account.
ℹ Note: trivum supports only paid accounts.
💡 Tip: The RP321 is AirPlay ready, so it’s easy to stream every kind of music to the specic zone (with Apple devices).
Backup your conguration
Once you have completed the setup, we recommend you to make a backup of your conguration:
• Open the Music Center WebCong.
• Click "Backup/Restore -> Export/import conguration".
• Follow the instructions.
For easy operation of your RP321, we recommend our trivum TouchPad.
How to use a trivum TouchPad?
• Make sure your TouchPad is running software v2.35 or later.
• Wait a few seconds until the TouchPad has booted.
• On the starting screen press "Pair TouchPad with Audio System".
• Press "Select..." and select your preferred trivum MusicCenter from the pop-up menu.
How to use KNX?
The KNX programming of RP321 is done via the web browser. No need for extra KNX software.
• Open the Music Center WebCong.
• Click "KNX->Setup KNX communication" and enable "use KNX / IP".
• Follow the instructions.
You nd further informations for KNX on:
https://trivum.de/knx-setup
Further documentation and troubleshooting
To nd helpful log les in support cases:
• Open the Music Center WebCong.
• Click "Logs & Warnings".
Please visit also our website for the latest documentation, videos and information:
https://www.trivum.com
https://service.trivum.com
If support is needed
Please contact your local trivum dealer or write to:
[email protected]
Download links:
trivum ServerAdmin Tool (Windows):
https://trivum.de/admin-tool
trivum Apps (iOS, Android, Web):
https://trivum.de/apps
