KODAK Portable Power Station
PPS500
User Manual
Please read this manual carefully before operating the product.
Please keep this manual with you for further reference.
PPS500
1. SET INCLUDES 3
2. INTRODUCTION 4
3. SAFETY INSTRUCTIONS 5
4. TRANSPORTATION 9
5. GET TO KNOW YOUR KODAK PPS500 10
6. CHARGING 11
6.1. PV SOLAR PANEL CHARGING 11
6.2. DISPLAY 11
7. TECHNICAL SPECIFICATIONS 12
8. USING THE KODAK PPS500 13
9. TROUBLESHOOTING 14
10. FREQUENTLY ASKED QUESTIONS FAQ 15
11. STORAGE AND DOWNTIME MAINTENANCE 16
12. SERVICE LIFE OF LITHIUM ION BATTERIES 16
13. DISPOSAL AND RECYCLING 17
14. WARRANTY AND CUSTOMER SERVICE 18
CONTENTS
3
1. SET INCLUDES
No. Item Quantity
1 KODAK Portable Power Station PPS500 1
2 AC charger (2 parts) 1
3 User manual 1
1
2 3
Portable
Power Station
PPS500
User Manual
4
Congratulations on purchasing KODAK Portable Power Station PPS500, a plug-and-play power supply for
outdoor use (IP21). With 500 watt-hours of stored energy, you can keep appliances, or electronic devices
running for hours.
The KODAK PPS500 Portable Power Station is designed to keep you powered up while travelling in your
RV, during emergencies involving power outages, or camping with the family at the lake.
Note the following points while reading through this instruction manual:
• This manual was prepared with care and to the best of our knowledge.
Contact us should you have any questions relating to the product.
• This manual may not be copied or duplicated, except for personal use.
Disclaimer
• Our company cannot be held liable for damages caused by ire, earthquake, use by a third party, other
accidents, intentional misconduct on the part of the customer, abuse or other abnormal conditions.
• Do not repair any damage to the AC plug or power supply on your own.
• The warranty covers all terms and conditions of the warranty. Contents that are not speciied in the
warranty terms and conditions are beyond our responsibility.
• Our company assumes no liability for damages caused by incorrect use or non-compliance with this
instruction manual.
• This instruction manual, as well as other language versions can be downloaded as a PDF ile on our
website: www.portable-power-stations.com.
• Intended use: Our product is not suitable to be used with equipment that relates to one‘s own per-
sonal safety or which relies heavily on electricity, such as medical devices, equipment for nuclear
facilities, the manufacture of air and spacecraft, etc. We therefore assume no liability for accidents
involving personal safety, ires or machine failures caused by using our product with the aforementi-
oned devices.
2. INTRODUCTION
5
2. SAFETY INSTRUCTIONS
Observe these instructions to ensure safe usage.
Explanation of symbols
This symbol together with
DANGER means
Noncompliance may very likely lead
to serious injury or death.
This symbol together with
WARNING means
Noncompliance may lead
to serious injury or death.
This symbol together with
CAUTION means
Noncompliance may lead
to injuries and/or property damage.
This symbol together with
ATTENTION means Noncompliance may damage the unit.
• Serious injuries include blindness, burns, electric shock, fractures, poisoning, etc., which can lead to
complications, hospitalization or permanent treatment.
• Injuries include burns, electric shock, etc., which usually do not lead to hospitalization or permanent
treatment.
• Property damage: includes buildings, belongings and pets, etc.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
twoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemust
accept any interference received, including interference that may cause undesired
operation.
6
Do NOT disassemble, repair or modify the unit or the battery.
Doing so may result in electric shock, ire, etc.
Do NOT place the unit close to or in a ire or expose it to heat. Keep out of direct sunlight.
Doing so may result in ire or injuries.
Do NOT charge, use or store the unit in a bathroom or in an area exposed to rain or moisture.
Doing so may result in electric shock, ire, etc.
Only use the output socket to power external devices. Never connect the output to mains power
under any circumstances.
Connecting to the mains may lead to electric shock, injuries or ire.
Do NOT touch the unit or the plug-in points if your hands are wet.
Doing so may result in electric shock.
Do NOT connect any metallic objects to the AC input or output.
Doing so may result in electric shock, ire, etc.
Do NOT rub your eyes if luid from inside the unit should get in your eyes.
If this should occur, lush eyes with water and seek medical attention immediately.
This can lead to blindness.
Do NOT dispose the unit together with household waste.
Follow the local law to dispose the unit.
Do NOT use any inappropriate power cords.
Doing so may result in electric shock, ire, etc.
Do NOT operate the unit above the speciied input voltage.
Doing so may result in electric shock, ire, etc.
Do NOT use the unit if it is not functioning correctly.
Doing so may result in electric shock, ire, damage to the unit, etc.
Do NOT move the unit if it is recharging or in use.
Doing so may result in electric shock, damage to the unit or other injuries.
DANGER
7
WARNING
Use and store the unit only in a clean and dry environment. Do not use and store in dusty and wet
environment.
Failure to do so may result in a short circuit, smoke or ire if metal dust or small metallic parts come in
contact with the connections.
Check the unit prior to every use. Do not use the unit if it is damaged, broken.
If you notice that the unit has any damage or cracks, is broken, or has other abnormalities, do NOT cont-
inue to use the unit and contact your dealer or our customer service center.
Do not use the unit if the power cord is damaged or broken.
Keep the unit away from children. Do NOT let children use the power supply unit.
Doing so may result in an accident or injuries. This unit must not be used by children. The unit and its
connection cables must be kept out of reach of children. Children must not play with the unit.
This unit may only be used by persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they are monitored or have been instructed in how to safely use the unit
and understand the resulting risks.
Keep this product away from pets.
Do NOT use or store the unit in an area or environment with high temperature.
Doing so may cause the unit to deform or overheat.
Should luid from inside of the unit come in contact with your skin or clothing, wash the aected
areas with tap water.
Contact with the luid may result in injuries.
In a storm, unplug the power cord from the socket.
A storm may result in an overcurrent coming from the socket, resulting in overheating, ire or other acci-
dents.
Do NOT charge the unit via power supply systems that operate outside of 100240V.
That may otherwise result in overheating, ire, etc.
Do NOT place the unit on its side or upside down while in use or storage.
Doing so may result in leakage or cause the unit to overheat leading to other accidents.
8
If rust, peculiar odors, overheating or other abnormal circumstances are observed, stop using the unit
immediately and contact the dealer or our customer service center.
The unit complies with all legal requirements for transport of dangerous goods.
The capacity of the lithium battery pack in the unit exceeds 100 Wh.
Based on international standards: If this unit is to be sent by airplane, it must be transported in accordan-
ce with IATA standard packaging. IATA instructions and labelling requirements and the relevant declara-
tions must be completed.
Make sure that the unit is properly secured when transporting it in a motor vehicle.
Failure to do so may result in damage to the unit, electric shock, overheating, ire and other accidents.
Only charge and use the unit within an ambient temperature of 0 to 40 °C (32-104 °F).
Operating the unit above or below this temperature range may result in overheating or reduced perfor-
mance.
Switch the unit o immediately if it has accidentally fallen, was dropped or was exposed to vibra-
tions.
To prevent accidents, please contact the dealer or our customer service center to have the unit checked
and repaired.
Carefully read the instructions for the electric devices that you intend to connect to your power
supply unit.
Make sure that the device you are connecting is switched o before you connect it.
A device starting up suddenly may lead to accidents or injuries.
If the protective function is activated and the output of the device is switched o, disconnect the electric
devices from the power output. Switch the unit o in case of non-use/storage in order to prevent electric
shock and the battery from discharging unnecessarily, etc.
CAUTION
9
4. TRANSPORTATION
1. Carry the unit using the handle on top of the product.
ATTENTION
Keep the unit away from
other objects when moving.
ATTENTION
Take extra care to ensure that the unit is never
allowed to fall to the ground.
2. Placing the unit on a stable surface.
ATTENTION
Place the unit on a stable surface.
By doing so, it is also easier to read the indicators.
3. Transporting the device.
DANGER
The unit should not be subjected to any impact or vibrations.
Otherwise there is a risk of ire.
Keep the unit‘s original packaging and use it when you need to transport the unit.
10
Button and connector explanations
A. AC output power button
B. 230V AC output (Type F)
C. AC output LED indicator
D. 8mm input port (DC7909) for AC charger or compatible solar panels
E. 8mm port (DC7909) LED indicator
F. Built in LED lashlight
G. LED lashlight power button
H. 6mm (DC6514) & cigarette lighter port power button
I. 2x 6mm ports (DC6514)
J. Cigarette lighter port
K. 6mm (DC6514) & cigarette lighter port LED indicator
L. 2x USB port
M. USB port LED indicator
N. USB port power button
5. GET TO KNOW YOUR KODAK PPS500
A
C
E
F
G
H
I
J
K
L
M
N
B
D
11
6. CHARGING
Before use or storage, plug your KODAK PPS500 into the wall until it is fully charged. If the display shows
less than 20% capacity, plug it into a power source, like an AC outlet or a solar panel as soon as possible.
To preserve battery lifespan, please use and recharge at least every 3 month.
You will know that the KODAK PPS500 is charging when you see the red LED indicator lashing once per
second. It is fully charged when all battery segments stop blinking and remain solid. The KODAK PPS500
will be fully recharged after 67 hours. Always use the supplied AC charger.
ATTENTION
Only charge the unit when the ambient temperature is between 0 and +40 °C (32-104 °F).
End the charging process by switching o the unit and pulling the plug out of the socket.
KODAK PPS500 8mm input port is compatible with both KODAK Solar Panels SP50 and SP100 with an
input voltage of at least 36V. Place your solar panel where it will get as much direct sunlight as possible.
Solar charge times depend on weather conditions. It is fully charged when all battery segments stop
blinking and remain solid.
NOTE
Don‘t place the solar panels in shaded areas or behind windows.
Although you should seek out the shade on sunny days, your solar panels will collect more energy
when fully exposed to the sunlight. Windows are decreasing the eiciency.
The LCD Display indicates the charge level of your KODAK
PPS500. The battery icon on the display is divided into
ive segments, approximating 20%-40%-60%-80% -100%
capacity. As you use the unit, the number of lit segments
will reduce, indicating the remaining charge. Once your
KODAK PPS500 is fully charged, all battery segments will
be lit and remain solid.
The INPUT section in the upper part of the display indi-
cates the power to the KODAK PPS500 from your char-
ging source (mains supply or solar panel). When char-
ging from a solar panel, this charging power will change
as you change the orientation of the solar panel relative
to the sun.
The OUTPUT section in the lower section of the display indicates the amount of power your devices are
drawing from KODAK PPS500. This information is displayed in Watts (W).
Please note that the charging time may vary depending on the ambient temperature involving the solar
charger. End the charging process by switching o the unit and pulling the plug out of the socket.
6.1. PV (SOLAR PANEL) CHARGING
6.2. DISPLAY
12
General Information
Rated battery capacity 500Wh
Rated battery voltage 25.4VDC
Weight 5,66 kg (12.47 lbs)
Dimensions 260 x 170 x 325 mm (10.2 x 6.7 x 12.8 inch)
Operating temperature 0 - 40 °C (32 -104 °F) at 1090% relative humidity
Suitable storage temperature -20 - 40 °C (4 - 104 °F)
Certiicates CE, ETL, FCC, ROHS, UN38.3
Management system Temperature control, Surge protection,
Short circuit protection
Special Feature Built in lashlight
Lifecycles 300 (up to 80%)
Warranty 24 months
Inverter AC output
Rated output | Peak output 300W |500W
Rated voltage | Rated frequency 220 Vac | 50Hz
Inverter output Pure Sine Wave
Output
USB ports 5V, 2.1A (21W max. for both ports combined)
Cigarette lighter port 12V, 10A
(120W max. for all ports combined)
6mm ports (DC6514)
Input
8mm port (DC7909) 25V, 3.5A (120W max.)
Estimated using & recharging times*
Cellphone (5.5Wh) ~90.0 recharges
Tablet (33Wh) ~15.0 recharges
Laptop (60W) ~8.0 hours
Drone (68Wh) ~7.0 recharges
Mini Fridge (70W) ~7.0 hours
Gaming console (95W) ~5.0 hours
*Values may vary depending of the power consumption of your device.
7. TECHNICAL SPECIFICATIONS
13
8. USING THE KODAK PPS500
Check the remaining battery capacity
Press the power button once to display the remaining battery capacity. To ensure you never run out of
power, please recharge KODAK PPS500 before use or storage. It is highly recommend to recharge
KODAK PPS500 at least once every 3 months.
Power ON / OFF procedure
• Main function of POWER button
Turn on: Pressing the Master power button for more than 1 second turns on KODAK PPS500, after which,
LED power indicator and LCD screen will light up. Following that.
Turn o: Pressing the Master power button for more than 1 second turns o KODAK PPS500 after which,
the LCD screen will turn o. When all buttons are o the LED power indicator will also turn o.
• Main function of DC button
Turn on: Pressing the DC ON button for more than 1 second activates DC output, after which the DC po-
wer LED will light up and the display will show „DC ON“
Turn o: Pressing the DC ON button for more than 1 second deactivates the DC output, after which the
DC power LED will turn o and the display will show „DC OFF“
• Main function of AC button
Turn on: Pressing the AC ON button for more than 1 second activates AC output, after which the AC po-
wer LED will light up and the display will show „AC ON“.
Turn o: Pressing the AC ON button for more than 1 second deactivates the AC output, after which the
AC power LED will turn o and the display will show „AC OFF“.
Intelligent cooling
The KODAK PPS500 intelligent system will turn on fans for cooling when any of these conditions are met:
1) Inverter load > 400W 2) 5V USB load > 10W 3) TypeCPD load > 30W 4) 12V cigarette lighter load > 50W
5) PV input power > 100W
In addition, KODAK PPS500 intelligent controll system will adjust the PV input or AC output power based
on the outer case temperature of the outer case in order to ensure that the outer case can be handled
safely. DO NOT use KODAK PPS500 when any fan is broken.
Inverter output frequency setting
• Turn on the Master power button and the DC power button. Ensure the AC button is switched o.
• Press the DC power button and the AC power button and hold for 1 second to enter settings.
• Press the AC power button to choose the inverter AC output frequency.
• Press the DC power button and the AC power button and hold for 1 second to exit settings.
Appropriate temperature usage
• Charge protection: KODAK PPS500 can charge your device when the ambient temperature is bet-
ween 0 - 40°C. Outside this temperature range, the system automatically stops charging but will restart
once the temperature is back inside the acceptable range.
• Discharge protection: KODAK PPS500 can power your devices when the ambient temperature is bet-
ween 0 - 40 °C. Outside this temperature range the system automatically stops charging your device
but will restart once the temperature is back inside the acceptable range.
Best-use strategy
• If you plug in devices that have a high power requirement, the charge level of KODAK PPS500 can drop
quickly and you will not be able to extract the entire 500Wh of energy.
14
Devices are not recharging.
If your devices are not recharging as they should using KODAK PPS500 follow these steps:
1. Ensure the output port has been turned on. The red LED next to the power button should be lit up.
2. Check the Battery Display. If it is at 20% or below, recharge your KODAK PPS500.
3. Verify your device is suitable for use with the KODAK PPS500.
All of the KODAK PPS500 output ports have their own max. power.
Check the KODAK PPS500’s technical speciications to ensure your device is compatible.
What should I do if the unit gets wet?
Immediately turn o the unit and wait until you are certain that it is completely dry before turning it back
on. If you are unsure about when it is safe to turn it back on, please contact after sales service.
Recharging via solar panels takes longer than it is supposed to.
Charging via solar panels is subject to various inluences. We have listed a few here for you.
1. Not all solar charge times are created equal. Most solar panel manufacturers calculate recharge times
using the following equation: Devices Watt Hours / Solar Panel Watts = Solar Recharge Times.
So theoretically, a 13W solar panel would charge a 50 Wh battery pack in 3.84 hours (50/13 = 3.84) – and
this is the number you could ind in marketing material for a solar panel. However, in order to standardize
results across all manufacturers, these tests are completed in laboratory settings. The truth is, on a good,
sunny day, you’ll received about 5075% of your solar panel’s rated wattage.
2. Perfect placement is key. Although you should seek out the shade on sunny days, your solar panels
will collect more energy when fully exposed to the sunlight. Windows also have a habit of decreasing
eiciency. So keep those panels outside and in the bright sunlight and align them properly.
9. TROUBLESHOOTING
15
10. FREQUENTLY ASKED QUESTIONS (FAQ)
1. What type of battery is in my KODAK PPS500?
KODAK PPS500 contains a 500Wh lithium ion battery pack. Lithium ion batteries are much smaller and
lighter than normal lead-acid batteries and also can be cycled many more times.
2. How do I know if my KODAK PPS500 is charged?
To check the charge level of your KODAK PPS500, refer to the LCD display. The battery icon indicates the
battery status of total charge remaining. KODAK PPS500 can be used until it is empty but we recommend
to recharge when the level is below 20%.
3. Can I charge the KODAK PPS500 while supplying power at the same time?
Yes. The AC output supports simultaneous charging and discharging.
Please note, however, that this only makes sense with a remaining battery capacity of more than 10%.
4. Can I take the KODAK PPS500 on a plane?
No, you can’t. KODAK PPS500 contains a large number of lithium-ion batteries with a capacity considered
to be hazardous by airlines.
5. What does a pure-sine wave inverter mean?
You have probably heard the terms DC and AC power. DC stands for Direct Current, and is the only type of
power that can be stored in a battery. AC stands for Alternating Current, which is the type of power your
devices use when they’re plugged into the wall. An inverter turns a DC output into AC output and it can
do this with quite high eiciency. You can see this by turning on the AC port and looking at the output on
the LCD display.
A pure-sine wave inverter, like the one found in your KODAK PPS500, produces an output signal that is
exactly the same as that supplied by an AC wall plug in your house. Although integrating a pure-sine
wave inverter takes more components, it is then compatible with almost all AC electric devices you use
in your house. So in the end, the pure-sine wave inverter allows KODAK PPS500 to safely power almost
everything under 300W device that you would normally plug into the wall.
6. How do I know if my device will work with the KODAK PPS500?
Firstly, you’ll need to check the amount of power your device requires. This may require some research on
your end. An online search or examining the user guide for your device should suice. To be compatible
with the KODAK PPS500, you should use devices that require less than 300 W.
Secondly, you will need to check the capacity for the individual output ports. For example, the AC port is
monitored by an inverter that allows for 300W of continuous power. This means if your device is drawing
more than 300W for an extended period of time, KODAK PPS500’s inverter will shut o.
NOTE
In case of overload, the unit switches o automatically and the output is interrupted.
Plasma or LED TVs with screens greater than 41“, desktop computers, and other devices with high
power consumption, as well as household devices with luctuating power consumption or with power
factor correction may not operate normally or at all, even if the their speciied operating power
is below 300W.
16
1. Charging to maximum capacity
Fully charge KODAK PPS500 prior to long-term storage. Charge it in a suitable working temperature
(0 - 40 °C (32 - 104 °F)) at least once every three months and store the power supply unit only in a dry
and dust-free environment which is out of reach of children. Suitable storage temperature: -20 to 40°C
(-4-104 °F). Keep out of direct sunlight. Make sure that the unit rests on a stable surface.
2. System shutdown
If the system shuts down automatically because of lower battery capacity, please recharge it.
3. Cleaning
Wipe away any dirt using a damp cloth.
ATTENTION
Gasoline, thinner, kerosene, petroleum, etc. have the characteristics of solvents.
Do not use.
4. Failure
Failure to maintain your KODAK PPS500 by following these steps can result in battery damage which will
void the product warranty.
Charge, supply current between 0 and 40°C (32 - 104 °F). Store between -20 and 40°C (-4 - 104 °F).
Using the battery at temperatures outside the lower and upper limits reduces the battery‘s running time.
Do not connect a continuous load of more than 300 W.
The unit‘s output stops automatically in case of overloading, since it reduces the running time of the
battery.
Do not continue to charge the battery after it has charged completely.
Pay attention to the indicated capacity. Do not charge the battery once it has been fully charged or the
charging process has been concluded. Otherwise the service life of the lithium battery may be reduced.
Switch o the unit if it is not being used.
Unnecessary power consumption also reduces the running time of the lithium battery.
Fully charge the battery prior to placing it in storage.
Fully charge the power supply unit prior to lengthy periods of non-use for storage and recharge the unit
at least once a year. After prolonged storage, it may be necessary to charge and discharge the battery
several times in order to reach full capacity.
11. STORAGE AND DOWNTIME MAINTENANCE
12. SERVICE LIFE OF LITHIUM ION BATTERIES
17
13. DISPOSAL AND RECYCLING
Lithium ion battery
As soon as the end of the battery‘s service life is reached, the entire lithium ion
battery can be recycled. Do not open or disassemble the unit.
Electric device
Old electric devices may not be disposed together with normal household waste.
According to the directive 2012/19/EU, the device must be disposed of in a controlled
manner at the end of its service life. The recyclable materials contained in the unit
shall be sent to recycling to reduce the burden on the environment.
This unit contains lithium ion batteries. These are hazardous materials and are subject to speciic trans-
port and handling regulations. Lithium ion batteries may ignite or explode if handled incorrectly.
For the safe disposal of the unit, contact a collection point or your local municipality for more information
and indicate that the unit contains lithium batteries.
Package
The product package consists of recyclable materials. Dispose of these in an environmentally friendly
manner and sort the materials in the provided collection systems.
REPAIR TERMS AND CONDITIONS
1. In the case of device failure which can be attributed to poor workmanship, please take the original
sales receipt with purchase date (invoice, etc.) to the retail store. In case of normal use, the power
supply unit will be repaired or replaced free of charge within the two year warranty period. In additi-
on to that, the customer must bear any shipping charges that may occur.
2. The repair is not free of charge in the following cases, even within the warranty period.
• A warranty card or certiicate or sales receipt with purchase date (invoice, etc.) is not presented.
• The equipment failure was caused by improper use (including use that does not comply with the
instructions set forth in the manual).
• Defects were caused by improper repairs, modiications, disassembly, etc.
• Equipment failure was caused by careless operation (dropping/falling/impact/contact with luids/
deposits - on the inside or outside of the machine) or improper maintenance (mildew, dust, etc.).
• Damage was caused by use of unit for purposes other than intended (charged and recharged
more than 500 times, etc.)
• Equipment failure occurred due to external inluences, such as power supply or other electric
devices and/or damage during inspection or repair.
• Faults that can be attributed to causes that are not cited above are beyond our scope of respon-
sibility.
3. Note that we do not assume any liability for consequential damages (foreseeable damages, psy-
chological damages, etc.).
18
Contact distributor for technical support / customer service
USA/Canada [Delta Millenium Inc.]
216 Route 206 Suite 1
Hillsborough, NJ 08844
USA
Toll-Free:
8887655428
EMail:
info@digitalsupportdesk.com
EUROPE [GBT GmbH]
An Gut Nazareth 18A
52353 Düren
Germany
Telephone:
+49 (0) 2421 / 20 85 60
EMail:
info@gbt-international.com
AFRICA [GBLT South Africa]
Unit 94 & 96
Allandale Business Park
CNR Morkels & Le Roux
Halfway House
Midrand, Johannesburg
South Africa
Telephone:
+27 (0) 11 / 516 0001
EMail:
sales@gbt-international.co.za
14. WARRANTY AND CUSTOMER SERVICE
19
GBT GMBH
© 2019 GBT GmbH
An Gut Nazareth 18A, 52353 Düren, Germany | Phone: 02421 / 208560
The Kodak trademark, logo and trade dress are used under license from Kodak.
All information contained in this document is subject to change without notice.
Table of contents
Other Kodak Power Supply manuals
