Tronix Dimmit 214-305 User manual

USER MANUAL
LED indicator
Program key, short press 5 times to reset the device
Dip switches to select DALI or 0/1-10V output, DALI DT6 or DT8 color type, DALI address or
group control mode, DALI address to be controlled, DALI group to be controlled
Program key, short press 5 times to reset the device
DALI
0/1-10V
110-240V
power inputLBluetooth to DALI+0/1-10V
2 in 1 Converter with Relay
Input/Output: 110-240V ~ 50/60Hz
Max 5A
DA/-
Prog.
DA/+
NDALI (DA, DA)
or
0/1-10V output (+, -)
DALI Add.
Relay output,
NArt. 214-305
max. 5A
1 2 3 4 5 6 7 8 9 10
L1 ta=-20 ℃-+50℃
Tronix Lighting | 5406XP 41 | Netherlands
Bluetooth to DALI+0/1-10V 2 in 1 Converter
Article 214-305
Important: Read All Instructions Prior to Installation
Function introduction
•Bluetooth to DALI+0/1-10V 2 in 1 converter based on bluetooth mesh network
•Bluetooth signal input, DALI signal output to DALI line or 0/1-10V signal output, 110-240VAC power input
•With relay output, max. 5A for traditional incandescent & HV halogen lamps, max 1.6A for LED load
•Compatible with universal bluetooth gateway
•DALI signal or 1-10V signal output selectable by DIP switch
•Built-in DALI bus power supply, no extra DALI bus PS required
•With max. 50mA DALI bus power current output
•To supply control current to up to 25 DALI control gears
•DALI DT6 or DT8 device type selectable by DIP switch under DALI mode
•Color control according to DALI specifications of Device Type 8,
•Color type: Tc, XY coordinates, RGBW selectable by DIP switches
•DALI address control mode or group control mode selectable by DIP switch
•Enables to select the DALI address (00-63) to be controlled by DIP switches
•Enables to select the DALI group (0-15) to be controlled by DIP switches
•Enable to control 1 DALI Group of devices or 1 DALI Address on DALI line
Input Output, relay
110-240VAC Max. 4mA Max. 20mA
Max. Current
Power Current Operating
temperature
-20℃-+50℃
Signal
Output, DALI Output,
0/1-10V
DALI PS
current
Max. 50mA
DALI current
consumption
Switching
voltage
110-240VAC
Relative
humidity
8% to 80%
Environment
Dimensions
95x37x20mm
Others
Incandescent: 5A
LED: 1.6A
Bluetooth
2.4GHz
Product Data
•Enable to control all devices on DALI line via broadcast
•Waterproof grade: Ip20

USER MANUAL
•DO NOT set the DIP switches with power applied to the device.
•DO NOT install with power applied to device.
•DO NOT expose the device to moisture.
Safety & Warnings
DIM
DT8 Tc
1 2 345678
1 2 3 4 5 6 7 8 9 10 Dial down
Note: please first select output signal by the dial switch.
2) Select DALI Device Type (DT6/DT8 Color Type) to be Controlled Using Dial Switches 8-9
DT8 XY Coordinates
DT8 RGBW
1 2 345678
910
Address Mode
Dial down
1 2 345678
Note: once DALI output is selected, please then select the DALI device type you would like to control by
the dial switches.
3) Select DALI Address or Group Control Mode Using Dial Switch 7
Group Mode
1 2 3456789
910
DALI
1 2 345678
Operation
1) Select DALI or 0/1-10V Output Using Dial Switch 10
0/1-10V
1 2 345678910
910
Dial up
0
1
2
3
4
5
6
Dial down
1 2 345678
Note: once DALI device type is selected, please then select address control mode or group control mode
by dial switch.
4) Select the DALI Group to be Controlled Using Dial Switches 2-6
Note: here device type is selected as DIM as an example, please select your correct DALI device type.
9
10
11
12
13
14
15
1 2 34567
7
Controlled group 910 Controlled group
Note: 1) once DALI device type and group control mode are selected, please then select the DALI group
(0-15 selectable) to be controlled on DALI line by dial switches.
2) The control gears that are assigned to the selected DALI group on DALI line will be controlled.
3) The control gears shall be first grouped by a DALI master controller, please refer to the user manual of
corresponding master controller.
8
8
910
10
910
1 2 3 4 5 6 7 8 9 10
Dial up
Dial down
1 2 3 4 5 6 7 8 9 10
Dial up
1 2 3 4 5 6 7 8 9 10
Dial up
Broadcast

USER MANUAL
5) Select the DALI Address to be Controlled Using Dial Switches 1-6
Note: here device type is selected as DIM as an example, please select your correct DALI device type.
Controlled address 1 2 345678910 Controlled address 1 2 345678910
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
Note: 1) once DALI device type and address control mode are selected, please then select the DALI address
(00-63 selectable) to be controlled on DALI line by dial switches.
2) The control gear with the selected DALI address on DALI line will be controlled.
6) Do wiring after above all settings are completed according to wiring diagram.
7) Pair the converter to the bluetooth mesh network and control it through the APP:
1 2 3 4 5 6 7 8 9 10
Dial up
Dial down

USER MANUAL
Step 1: Download the smart APP (searching Dimmit” from App Store and
Google Play) and setup an account. Then add the bluetooth device.
Tap “+” to
add device
Tap “Lighting”
Tap “Light Source
(BLE)”
Step 2: Short press the “Prog.” button 5 times, the LED indicator will flash rapidly.
Step 3: Then LED indicator will stay solid on to indicate the bluetooth to
DALI+0/1-10V converter is added successfully. Then you can control it
through the APP.

USER MANUAL
Wiring Diagram
When 0/1-10V Output Selected
L N
0/1-10V Dimmable
Driver
ACL
ACN
DIM+
DIM-
LED+
LED-
LED+ V+
LED- V-
LED light
Max. 1.6A for LED Load
DALI
0/1-10V
LBluetooth to DALI+0/1-10V DA/-
2 in 1 Converter with Relay Prog.
DA/+
N
Input/Output: 110-240V ~ 50/60Hz
Max 5A
DALI Add.
NArt. 214-305
1 2 3 4 5 6 7 8 9 10
L1 ta=-20℃-+50℃
Tronix Lighting | 5406XP 41 | Netherlands
When DALI Output Selected
Note: 1) Max. 50mA DALI bus PS output to supply control current to up to 25 control gears.
2) The max. LED load of the relay is 1.6A, and the number of control gear can be switched by
the relay depends on the load of each control gear.
L N
DALI Bus
DA
DA
DALI DT6/DT8 Control Gear
L
N
DA
DA
DALI DT6/DT8 Control Gear
L
N
LED+
LED-
LED+
LED-
LED+ V+
LED- V-
LED+ V+
LED- V-
LED light
LED light
Max. 1.6A for LED Load
DALI
0/1-10V
LBluetooth to DALI+0/1-10V DA/-
2 in 1 Converter with Relay Prog.
DA/+
N
Input/Output: 110-240V ~ 50/60Hz
Max 5A
DALI Add.
NArt. 214-305
1 2 3 4 5 6 7 8 9 10
L1 ta=-20℃-+50℃
Tronix Lighting | 5406XP 41 | Netherlands
