Trotec TDP 370 E User manual

TRT-BA-TDP370E-TDP750E-TC2020-12-001-EN
TDP 370 E / TDP 750 E
EN
ORIGINAL INSTRUCTIONS
DEEP WELL PUMP

2 EN
deep well pump TDP 370 E / TDP 750 E
Table of contents
Notes regarding the instructions ..........................................2
Safety .....................................................................................2
Information about the device................................................6
Transport and storage...........................................................6
Assembly and installation.....................................................6
Operation ...............................................................................9
Available accessories............................................................9
Errors and faults....................................................................9
Maintenance ........................................................................10
Technical annex...................................................................11
Disposal ...............................................................................15
Declaration of conformity ...................................................16
Notes regarding the instructions
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Warning
Warnings marked with this symbol indicate a risk of
falling.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
instructions must be observed.
You can download the current version of the instructions and
the EUdeclaration of conformity via the following link:
TDP 370 E
https://hub.trotec.com/?id=44444
TDP 750 E
https://hub.trotec.com/?id=44445
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/ or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
General safety
• Do not use the device in potentially explosive rooms.
• Do not use the device in aggressive atmosphere.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.

EN 3
deep well pump TDP 370 E / TDP 750 E
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• When positioning the device, observe the minimum
distances from walls and other objects as well as the
storage and operating conditions specified in the Technical
data chapter.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
General safety warnings – Electrical safety
• The device is to be supplied with a rated residual current
of no more than 30mA by means of an RCD (Residual
Current protective Device).
• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!
• The electrical connection must correspond to the
specifications in chapter Technical data.
• Insert the mains plug into a properly secured mains
socket.
• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.
• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Defective power cables pose a serious health risk!
• Should the connection line of the device be damaged, it
must be replaced by the manufacturer, his customer
service or similarly qualified personnel in order to avoid
hazards.
• Should there be a risk of flooding, install the plug
connections in a flood-proof area. There is a risk of
electric shock!
• Make sure that the mains voltage corresponds to the
specifications on the nameplate.
• Have all electrical installations carried out by an expert
according to the national regulations and the device-
specific requirements.
• Do not use the power cable to drag the device.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Protect the power supply cable against heat, oil and sharp
edges. Make sure that the power supply cable is not
crushed, kinked or subjected to other mechanical stresses.
• Only use splash-proof extension cables intended for
outdoor use whilst observing the device's power input.
Before using cable drums, always unroll the cable
completely. Check the cable for damage. The use of
extension cables which are not approved for outdoor use
can result in injuries due to electric shock.
• Before performing any work on the device, in case of leaks
in the water system, before taking work breaks or when
not in use, remove the mains plug from the mains socket.
General safety warnings – Personal safety
• Never use the device with persons or animals in the water
or pumping medium or if they could access it. There is a
risk of electric shock!
• Never insert any objects or limbs into the device.
• This appliance is not a toy! Keep away from children and
animals. Do not leave the device unattended during
operation.
Device-specific safety warnings for deep well
pumps
• Only operate the device in an upright position.
• Keep in mind, that lubricants are used within the device.
These might potentially cause damages or contaminations
if emitted. Do not use the device for drinking water or in
garden ponds with either a fish population or valuable
plants.
• Do not carry the device by holding it at the connection
cable or hose. Do not fasten it there either.
• Do not place any objects on the device – not even to
weight it down. The device will sink to the ground due to
its own weight.
• After the set-up of the device, its mains plug must be
readily accessible during operation.
• Prevent dry running of the device! Before start-up the
device must be completely submerged in the pumping
medium.
• Wear sturdy shoes to protect yourself against electric
shock.
• Before taking the device into operation, have the following
checked by an expert:
– earthing, neutral conductor and RCD must be
functioning properly and correspond to the national
regulations,
– electrical plug connections must be protected from
moisture.
• Provide appropriate frost protection.

4 EN
deep well pump TDP 370 E / TDP 750 E
Intended use
The device TDP 370 E/ TDP 750 E is exclusively designed for
pumping clear water from greater depths serving as service
water for the home and garden.
The device can be applied for the following purposes:
• water withdrawal from wells and shafts
• rain water withdrawal from cisterns
In either case, the water must comply with the conditions
specified in the technical data.
The device is fully submersible (watertight encapsulation) and
can be immersed up to 20m into the pumping medium.
Improper use
• The device is not suitable for continuous operation (e.g. as
recirculation pump for ponds).
• Using the device in swimming pools and the like is
prohibited.
• The device is not suitable as permanent, automatic
overflow protection (of e.g. wells or fountains or for the
regulation of the groundwater level). Use a stationary
waste water pumping system for building and property
drainage for these purposes.
• The device is not suitable for increasing the pressure of
existing water supply networks.
• The device is not suitable for pumping potable water.
• The device must not be used for aggressive, abrasive,
caustic, corrosive, combustible or explosive pumping
media, e.g.:
– brine
– sandy water
– food
– cleaning agents
– fuels (e.g. petrol, diesel)
– oils
– greases
– petroleum
– nitro-cellulose thinner
– waste water from lavatories and urinal installations
• The device must not be used at freezing temperatures.
• Any unauthorised modifications, alterations or structural
changes to the device are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
electric devices in damp areas.
• have read and understood the instructions, especially the
Safety chapter.
Safety signs and labels on the device
Note
Do not remove any safety signs, stickers or labels from
the device. Keep all safety signs, stickers and labels in
legible condition.
The following safety signs and labels are attached to the device:
This label indicates the following safety warnings:
• Prevent dry running of the pump! Before start-up the pump
must be completely submerged in the pumping medium.
• Carefully read the instructions before starting or using the
pump.
This label indicates the following safety warnings:
• The device is not suitable for water with high sand content!
Do not use at freezing temperatures
This symbol indicates that the device must be protected
from frost.
Keep out of the reach of children – not a toy
This symbol indicates that the device is not a toy and is
thus not suitable for children.
Do not pull the mains plug by the power cable
This symbol indicates that you must not pull the mains
plug out of the socket by the power cable.
Staying in water prohibited
This symbol indicates that the device must not be
operated with persons or animals in the water.
Not suitable for pumping potable water
This symbol indicates that the device is not suitable for
pumping potable water.

EN 5
deep well pump TDP 370 E / TDP 750 E
Device may start up without warning
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Device may start up without warning
This symbol indicates that the device may start up
without warning when it is switched on.
General warning sign
This symbol indicates that you must be aware of the
dangers that can occur when working with the device.
Do not use damaged power cables or mains plugs
This symbol indicates that the device must no longer be
operated if the power cable is damaged.
Pull the mains plug
This symbol indicates that the mains plug must be
removed from the socket when the device is not in use.
Device may start up without warning
Information marked with this symbol indicates that the
instructions must be observed.
Residual risks
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of electrical voltage
Before any work on the device, remove the mains plug
from the mains socket!
Hold onto the mains plug while pulling the power cable
out of the mains socket.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Behaviour in the event of an emergency
1. Switch off the device.
2. In an emergency, disconnect the device from the mains
feed-in: Hold onto the mains plug while pulling the power
cable out of the mains socket.
3. Do not reconnect a defective device to the mains.
Overheating protection
The device is provided with a thermal protection circuit which is
activated by overheating of the device and then switches the
device off.
Switch the device off and let it cool down. Investigate the cause
of overheating. Should the problem persist, please contact the
customer service.

6 EN
deep well pump TDP 370 E / TDP 750 E
Information about the device
Device description
The device TDP 370 E/ TDP 750 E is particularly well suited for
pumping clear water from greater depths, e.g. from wells or
shafts.
The device is able to pump up to 5100l per hour from a
working depth of up to 20metres. In doing so, the device
reaches a delivery head of up to 40metres (TDP 370 E) or
50metres (TDP 750 E).
The water temperature must not exceed 35°C.
Info
The illustrations in these instructions feature the device
TDP 370 E by way of example. The represented
operating steps and explanations also apply to device
TDP 750 E unless otherwise mentioned.
Device depiction
1
2
4
5
6
3
No. Designation
1Connection for pressure line with 1¼" internal thread
2Pump motor
3Spacer foot
4Dirt strainer
5Suspension eye
6Power cable
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
Before transporting the device, observe the following:
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Do not use the power cable to drag the device.
• Do not carry the device by holding it at the power cable or
hose.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• in an upright position where it is protected from dust and
direct sunlight
• with a cover to protect it from invasive dust, if necessary
• Check whether there is residual water left in the device,
and drain any residual water to prevent rust formation.
• Put the protective cap on the pressure connection to
protect the inside of the device against dust and dirt.
If you do not use the device for an extended period of time, it
must be cleaned thoroughly after its last application and before
recommissioning. Deposits and residues could lead to start-up
difficulties.
For restart, please proceed according to the Start-up chapter.
Assembly and installation
Scope of delivery
• 1x Deep well pump
• 1x Spacer foot
• 2x Mounting screws (spacer foot)
• 1x Manual
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.

EN 7
deep well pump TDP 370 E / TDP 750 E
Start-up
Mounting the spacer foot
The spacer foot (3) must be attached to the device prior to initial
start-up. To do so, please proceed as follows:
1. Insert the spacer foot(3) into the bottom side of the device.
2. Screw the spacer foot(3) to the bottom side of the device
by using the supplied screws(7).
3
7
Connecting the pipe or hose line
The device may be operated using either a hose line or a pipe.
Ex factory, the device is delivered with a 1¼" internal thread.
Please observe the following information regarding water
discharge:
• The device cannot be moved flexibly when using a solid
pipe.
• Please note that the conveying capacity declines with an
increasing height of the pressure line.
Note
If you want to connect a flexible hose as pressure line,
do not use a suction hose or a non-pressure-resistant
hose. Use pressure-resistant hoses only.
Connecting the pressure line
Warning
Make sure that all parts of the pressure line are
installed professionally. In case of an improper
assembly or when using unsuitable parts, there is a
risk of injury due to the pressurized pumping medium.
1. Remove the protective cap(8) from the pressure
connection(1).
8
1
Note
Keep the protective cap(8) of the pressure connection
so you can use it when storing the pump to protect the
inside of the pump against dust and dirt.
2. Connect the pressure line to the pressure connection(1)
using a suitable adapter (1¼"). To do so, apply thread seal
tape (e.g. Teflon tape) to the threaded connector of the
pressure line to ensure a leak-proof connection.

8 EN
deep well pump TDP 370 E / TDP 750 E
Positioning the device
Please observe the following information regarding the device
set-up and before switching the device on:
• The shaft/the drill hole should be vertical and the shaft
walls should not have any protruding edges or projections.
• The shaft/the drill hole should have an edge length/a
diameter of at least 125mm.
• Do not leave the device running unattended.
• Check whether the hose or pipe was attached properly.
• Make sure that the power cable(6) is not under tensile
load and has enough clearance.
• Make sure that the mains connection corresponds to the
specifications provided in the technical data.
• Check the mains socket for its proper condition. The mains
socket's fusing must be sufficient.
• Make it impossible for moisture to reach mains plug or
socket. There is a risk of electric shock!
Warning of electrical voltage
There is a risk of electric shock when submerging the
device in the pumping medium.
Before submerging the device in the pumping medium,
please note the following:
• Make sure that the mains plug is removed.
• Check the mains plug and the power cable(6) for damage.
Do not under any circumstances use the device if you
detect damages on the mains plug or power cable(6).
Warning of electrical voltage
Electric shock due to damaged power cable(6).
Do not under any circumstances use the power
cable(6) for lowering, securing, positioning or lifting
the device. Only use a suitable cord or rope, e.g. a
nylon cord or a wire rope.
Warning
There is a risk of falling into the shaft or drill hole.
Position the device in a way that the shaft or drill hole
opening is closed before, during and after operation to
prevent persons or animals from falling in.
Note
At the bottom of ponds and other waterbodies deposits
may have accumulated over time. To prevent the
device from being damaged, it should not be lowered
all the way to the ground. Observe a minimum distance
of 50cm to the ground.
1. Fasten a suitable cord or rope, e.g. a nylon cord or a wire
rope, to the suspension eye(5) on top of the device.
20 m
5
2. Slowly lower the device and the cord/rope into the
pumping medium. Pay attention to the following:
ðThe device must be lowered into the pumping medium
perpendicularly.
ðThe device must be completely submerged in the
pumping medium. Regularly check the water level to
prevent the device from running dry.
ðObserve a minimum distance of 50cm to the ground
(see also schematic representation in the chapter
Technical annex).
3. Attach the cord or rope to an easily accessible position, so
you can pull the device back out as required.
Installation with pressure switchTDPDS/ TDPDSP
(optional)
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
For switching a connected deep well pump on or off and for
monitoring the pressure in the pipe, the device can be installed
together with pressure switch TDPDS or TDPDSP.
See also chapter Available accessories.
Recommendation for usage:
• in order to install and use the device in a permanent/
stationary manner, use the pressure switch TDPDS
• in order to install and use the device in a temporary/
location-independent manner, use the pressure switch
TDPDSP

EN 9
deep well pump TDP 370 E / TDP 750 E
Operation
Switching the device on
Once you have completely installed the device as described in
the Start-up chapter, you can switch it on.
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
Note
Please note that the device is designed for
max.40switch-on/switch-off operations per hour.
Before every restart, wait for at least 3minutes.
1. Plug the mains plug into a sufficiently fused mains socket.
2. After switch-on, regularly check whether the device
operates correctly. Turn off the power supply if after start-
up of the motor the pump shows an unusual operational
behaviour (such as strong vibrations at the pump or
pressure line, a fluctuating flow rate or similar). If you
leave the device unattended for a longer period of time,
interrupt the device's power supply.
Switching the device off
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
1. Hold onto the mains plug (6) while pulling the power cable
out of the mains socket.
Shutdown
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
1. Hold onto the mains plug while pulling the power cable out
of the mains socket.
2. Pull the device out of the pumping medium by means of
the cord or rope.
3. Disconnect the pressure line.
4. Clean the device according to the Maintenance chapter.
5. Store the device according to the Storage chapter.
Available accessories
Warning
Only use accessories and additional equipment
specified in the instructions.
Using insertion tools or accessories other than those
specified in the instructions may cause a risk of injury.
Accessories Article number
TDP DSP (with plug) 4.610.000.291
TDP DS (without plug) 4.610.000.290
Errors and faults
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
Warning of electrical voltage
Tasks which require the housing to be opened
must only be carried out by authorised specialist
companies or by Trotec.
• Switch off the device.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
The device does not start:
• Check the power connection.
• Check the power cable and mains plug for damage.
• Check the on-site fusing.
• The device might have overheated and the thermal
protection circuit is activated.
If so, wait for approx. 10minutes before restarting the
device. If the device is not starting, have the electrics
checked by a specialist company or by Trotec.
• The water temperature is above 35 °C and the thermal
protection circuit is activated.

10 EN
deep well pump TDP 370 E / TDP 750 E
The device is running, but not pumping any water:
• Check whether the dirt strainer(4) is clogged. Remove any
obstructions.
• Check whether the water level is too low or the device is
not completely submerged. If necessary, submerge the
device deeper into the water.
• Check whether the used hose diameter is too small.
• Check whether the hose line is kinked or blocked. Remove
kinks and/ or blockages.
The device switches off after a brief runtime:
• Check the water for dirt. If the water is too dirty, the device
will become hot and the thermal protection circuit will
switch the device off.
• Check whether the water temperature is too high. The
device might have overheated due to a too high water
temperature and the thermal protection circuit is activated.
• Check the power connection.
• Check the power cable and mains plug for damage.
• Check the on-site fusing.
Insufficient or decreasing conveying capacity:
• Check whether the dirt strainer(4) is clogged. Remove any
obstructions.
• Check the hose diameter and the delivery head. An
excessive delivery head paired with a small hose diameter
can cause a reduction of the conveying capacity.
• Check whether the hose line is kinked or blocked. Remove
kinks and/ or blockages.
Note
Wait for at least 3 minutes after maintenance and
repair work. Only then switch the device back on.
Your device still does not operate correctly after these
checks?
Please contact the customer service. If necessary, bring the
device to an authorized specialist electrical company or to
Trotec for repair.
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
Notes on maintenance
Inside the device, there are no parts that need to be maintained
or lubricated by the user.
Safety signs and labels on the device
Check the safety signs and labels attached to the device at
regular intervals. Replace illegible safety signs!
Cleaning
• Clean the device with a soft, damp and lint-free cloth.
Protect electrical components from moisture. Do not use
any aggressive cleaning agents such as cleaning sprays,
solvents, alcohol-based or abrasive cleaners to dampen
the cloth.
• Rinse the inside of the device with clear, lukewarm water.

EN 11
deep well pump TDP 370 E / TDP 750 E
Technical annex Technical data
Parameter Value
Model TDP 370 E TDP 750 E
Max. flow rate 85l/min 85l/min
Max. delivery head 40m 50m
Max. submersion depth
20 m
20 m
Speed 2850rpm 2850rpm
Max. pressure 3,7bar 5,2bar
Min. ambient temperature 0°C 0°C
Max. ambient temperature 35°C 35°C
Power supply 220V - 240V ~ 50Hz 220V - 240 V ~ 50 Hz
Number of phases 1 1
Max. power input 700W 1000W
Max. pump capacity 370W 750W
Protection type of the pump IPX8 IPX8
Protection class I I
Connection type CEE 7/7 CEE 7/7
Cable length of the pump 23m 23m
Min. drill hole diameter 125mm 125mm
Minimum distance to the ground 50cm 50cm
Threaded connector, inner diameter 1¼" 1¼"
Pump dimensions
(lengthx widthx height) 605x 100x 100(mm) 687x 100x 100(mm)
Pump weight 10kg 11kg
Conditions for the pumping medium (water)
Max. water temperature 35°C
Max. particle size 1.8mm
Max. chloride content 1.5mg/l
Max. hydrogen sulphide content 400mg/l
Min. pH 6.5
Max. pH 8.0

12 EN
deep well pump TDP 370 E / TDP 750 E
Schematic representation
TDP 370 E
20 m max.
max.
35°
40 m max.
0,5 m min.
TDP 750 E
20 m max.
max.
35°
50 m max.
0,5 m min.
Performance chart (delivery head/ flow rate)
TDP 370 E
TDP 750 E

EN 13
deep well pump TDP 370 E / TDP 750 E
Wiring diagram TDP 370 E/TDP 750 E

14 EN
deep well pump TDP 370 E / TDP 750 E
Exploded assembly drawing

EN 15
deep well pump TDP 370 E / TDP 750 E
No. Part Name Quantity No. Part Name Quantity
1Plastic discharge cover 1 27 Diffuser cover 5
2O ring 1 28 Flat washer 2
3Non-return valve 1 29 Shaft sleeve 1
4O ring 2 30 Rubber bearing 1
5Bolt 4 31 Filter 1
6Spring washer 4 32 Bolt 2
7Lock washer 1 33 Pump base 1
8Outlet 1 34 Inlet 1
9O ring 1 35 Bolt 2
10 O ring 4 36 Impeller 1
11 Capacitor 1 37 Diffuser 1
12 Wiring cap 3 38 Oil chamber cover 1
13 Wave-washer 1 39 Mechanical seal 1
14 Upper insulating ring 1 40 Outer casing 1
15 Motor housing 1 41 Oil chamber 1
16 Down insulating ring 1 42 Winding stator 1
17 O ring 1 43 Upper bearing seat 1
18 Mechanical seal 1 44 Capacitor box 1
19 Flat washer 2 45 Flat washer 2
20 Bearing 1 46 Bolt 2
21 Lock ring 3 47 Cable presser 1
22 Screw 2 48 Cable shield 1
23 Diffuser 4 49 Brass washer 1
24 Impeller 4 50 Cable shield 1
25 Rotor 1 51 Cable short shield 1
26 Bearing 1 52 Electric cable 1
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website https://de.trotec.com/shop/.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.

16 EN
deep well pump TDP 370 E / TDP 750 E
Declaration of conformity
The text below sets out the contents of the declaration of
conformity. The signed declaration of conformity can be found
at https://hub.trotec.com/?id=44444.
Declaration of conformity
in accordance with the ECMachinery Directive 2006/42/EC, AnnexII,
Part1, SectionA
Herewith, we– TrotecGmbH– declare that the machinery
designated below was developed, constructed and produced in
compliance with the requirements of the ECMachinery
Directive in the version 2006/42/EC.
Product model/ Product: TDP 370 E
TDP 750 E
Product type: deep well pump
Year of manufacture as of: 2020
Relevant EU directives:
• 2011/65/EU: 1July 2011
• 2014/30/EU: 29March 2014
• 2014/35/EU:8 September 2017
Applied harmonised standards:
• EN 55014-1:2006
• EN 55014-1:2006/A1:2009
• EN 55014-1:2006/A2:2011
• EN 60335-1:2012/A11:2014
• EN 60335-1:2012/A13:2017
• EN 60335-2-41:2003
• EN 60335-2-41:2003/A1:2004
• EN 60335-2-41:2003/A2:2010
• EN61000-3-2:2014
• EN 61000-3-3:2013
• EN 62233:2008
Applied national standards and technical specifications:
• AfPS GS 2019:01
• EN 55014-2:2015
• EN 60335-12012/A13:2017
Manufacturer and name of the authorised representative of
the technical documentation:
Trotec GmbH
Grebbener Straße 7, D-52525 Heinsberg
Phone: [phone]
E-mail: [email protected]
Place and date of issue:
Heinsberg, 30.09.2019
Detlef von der Lieck, Managing Director

Trotec GmbH
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
