SPECIFY MODEL NO. WHEN ORDERING PARTS DATE REVISED DATE PAGE
46CC 20" Gas Chain Saw 11/26/2004 N/A 1/2
MODEL NO. TB4620CC / 41AY60AR766
SERVICE SPARE PARTS LIST
14 57 58 59
65
64
68
66
62
61
79
76 77
78
126
125
124
123
86
85
84
83
82
81
70
106
69
91
90
87
7174
89 88
60
73
63
75
127
105
103
104
102
99
100
101
98
97
14
91
96
95
94
93
14
125
6
7
43
113 11
15 115
116 117
118
18
19
23
25
29
31
32
39
40
41
42
43
33
35
28 27
26
34
8
9
21
20 13
10
120
44 45
47
50 52
53
54
6
51
48
36
37
108
14
114
22
16
34
119
17
38
46
49
12
92
69
67
24
128
107
30
55
80
63
65
109
121
122
56
110
111
131
130
129
112
71
72

No. Parts No. Description Q No. Parts No. Description Q No. Parts No. Description Q No. Parts No. Description Q
1 MC-9NAB-5/16-24 NUT 1 34 MC-9014-310208 WASHER 1 67 MC-9182-310001 FILTER, FUEL 1 100 MC-9124-310209 GROMMET 1
2 MC-9228-31B206 FLYWHEEL 1 35 MC-9082-310201 BAFFLER 1 68 MC-9129-310004 HOSE 1 101 MC-9028-310202 TRIGGER 1
3 MC-9157-310201 SEAL 2 36 MC-9228-310217 MUFFLER BODY ASS'Y 1 69 MC-9SKKZY10/14-01 SCREW 2 102 MC-9028-310201 RELEASE. TRIGGER 1
4 MC-9DB-620201 BEARING 2 37 MC-9SKKBY10/24-0.5 SCREW 1 70 MC-9124-310202 BOOT, CARB 1 103 MC-9072-310203 LATCH, HIGH IDLE 1
5 MC-9SREB-10/24-2.75 SCREW 4 38 MC-9211-310201 PLATE 1 71 MC-9228-310207 CAP, OIL 2 104 MC-9024-310207 SPRING 1
6 MC-9WFB-0.2 WASHER 6 39 MC-9183-310201 SCREEN 1 72 MC-9129-310209 HOSE 1 105 MC-9068-310203 FRAME, REAR 1
7 MC-9072-310201F CRANKCASE LOWER 1 40 MC-9082-310205 BAFFLER 1 73 MC-9013-310201 PLUG 1 106 MC-9SGKBY10/24-0.5 SCREW 2
8 MC-9221-310001 KEY 1 41 MC-9017-310204 COVER, MUFFLER 1 74 MC-9252-310002 FILTER 1 107 MC-9WOC-08 WASHER 1
9 MC-9228-310203F C'SHAFT/C'ROD ASS'Y 1 42 MC-9158-310201 LOCKPLATE 1 75 MC-9131-310206 WASHER 2 108 MC-9124-310205 SPACER 1
10 MC-9155-310201 BEARING 1 43 MC-9NAC-10/24 NUT 2 76 MC-9043-310203 PLATE, BAR 1 109 MC-9043-310205 PLATE 1
11 MC-9076-310201 O RING 1 44 MC-9131-310203 EYELET 1 77 MC-9043-310202 PLATE, FLANGE 1 110 MC-9012-330301 GROMMET 1
12 MC-9228-310208 PUMP ASS'Y 1 45 MC-9014-310204 FLANGE 1 78 MC-9SKKBY6/19-0.375 SCREW 1 111 MC-6014-M96A01 WASHER 2
13 MC-9154-310201 CONNECTOR 1 46 MC-9102-310202 PLATE 1 79 MC-9SJKB-12/14-1.5 SCREW 1 112 MC-6182-210101 FILTER 1
14 MC-9SKKBY8/16-0.5 SCREW 6 47 MC-9014-310202 GASKET 1 80 MC-9228-31B202 HANDLE ASS'Y 1 113 MC-9073-310201 GEAR, WORM 1
15 MC-9124-310201 FITTING, PULSE LINE 1 48 MC-9124-310203 BOOT 1 81 MC-9228-310216 COVER ASS'Y 1 114 MC-9WFN-0.4 WASHER 1
16 MC-9072-310202F CRANKCASE UPPER 1 49 MC-9287-310201 CARB 1 82 MC-9SKKBY10/14-02 SCREW 2 115 MC-9WDZ-0.722 WASHER 1
17 MC-9014-310212 GASKET 1 50 MC-9014-310201 FLANGE 1 83 MC-9SKKBY10/14-0.68 SCREW 1 116 MC-9155-310203 BEARING 1
18 MC-9036-310201 CLAMP, WIRE HOSE 1 51 MC-9131-310204 EYELET 1 84 MC-9228-310204 AIR CLEANER ASS'Y 1 117 MC-9228-310211 DRUM SPRKT ASS'Y 1
19 MC-9059-310201 CONDUIT, FLEX 1 52 MC-9024-310202 SPRING 1 85 MC-9067-310202 COVER 1 118 MC-9228-310210 CLUTCH ASS'Y 1
20 MC-9CA-0.46 RING 2 53 MC-9124-310204 BOOT 1 86 MC-9214-310101 SCREW 2 119 MC-9NHC-09 NUT 1
21 MC-9PC-10-32.5 PIN 1 54 MC-9SREB-10/24-1.625 SCREW 2 87 MC-9228-310242 CHOKE ASS'Y 1 120 MC-9124-310202 BOOT, CARB 1
22 MC-9290-310201 PISTON 1 55 MC-9228-31B201 STARTER ASS'Y 1 88 MC-9114-310202 ROD, CHOKE 1 121 MC-9SKKBY10/14-0.625 SCREW 1
23 MC-9189-310201 RING, PISTON 2 56 MC-9SKKBY10/14-0.625 SCREW 2 89 MC-9013-310202 PLUG 1 122 MC-9SKKBY10/24-0.5 SCREW 1
24 MC-9292-310201F CYLINDER 1 57 MC-9WFZ-0.18 WASHER 1 90 MC-9228-310213 ISOLATOR ASS'Y 1 123 MC-9220-31B203 CHAIN 1
25 MC-9295-320001 SPARK PLUG 1 58 MC-9223-310201 1 91 MC-9228-310214 CABLE ASS'Y 2 124 MC-9040-31B203 BAR (TROY-BILT LOGO) 1
26 MC-9SKKBY10/24-0.62 SCREW 2 59 MC-9183-310202 SCREEN 1 92 MC-9228-310232 COVER ASS'Y, HANDLE 1 125 MC-9082-310204 PLATE 1
27 MC-9014-310203 FLANGE 1 60 MC-9228-310205 FUEL/OIL TANK ASS'Y 1 93 MC-9SKKBY8/16-0.625 SCREW 3 126 MC-9228-310241 CHAIN BRAKE ASS'Y 1
28 MC-9131-310202 EYELET 1 61 MC-9142-310002 PRIMER, REMOTE 1 94 MC-9SKKBY-8/16-1 SCREW 1 127 MC-9NAZ-5/16-18 NUT 2
29 MC-9288-310201-CH IGNITION ASS'Y 1 62 MC-9129-310214 HOSE 1 95 MC-9010-310203 WIRE 1 128 MC-9072-310206 PLATE 1
30 MC-9191-310201 STUD 1 63 MC-9SKKBY10/24-1 SCREW 4 96 MC-9228-310222 ISOLATOR ASS'Y 1 129 MC-9042-310201 WRENCH 1
31 MC-9051-310202 CONTACT, CROUNT 1 64 MC-9043-310201 PLATE 2 97 MC-9WFB-4.9-17 WASHER 1 130 MC-9120-MD0701 CARRY CASE 1
32 MC-9SKKBY10/24-0.75 SCREW 1 65 MC-9124-310206 SPACE 4 98 MC-9024-310206 SPRING 1 131 MC-9017-310214 SCABBARD 1
33 MC-9STDZY10/24-2.79 SCREW 2 66 MC-9228-310206 CAP, FUEL 1 99 MC-9010-310201 CABLE 1
REVISION DATE
Jun-02
PAGE
2/2
SPECIFY MODEL NO. WHEN ORDERING PARTS
46CC 20" Gas Chain Saw
MODEL NO. TB4620CC / 41AY60AR766
REVISED DATE
N/A
DATE
11/26/2004
SERVICE SPARE PARTS LIST
