TROY-BILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Op e r a t O r ’sMa n u a l
Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
Lawn Edger — Model 554
Form No. 769-05506
(October 6, 2009)
48
45
60 61 17
14 30
13
23
46
22
49
12
118
24
50 18
65
43
36
40
38
27
9
37
2
18
34
36
41
8
58
40
4
47
20
29
6
63
16
52
64
15
35
33
31
53
56
5
25
62A
19
42
28
39
21
44
3
51
57
55
7
59
57
11
54
32
26
62B
10
17
Handle, Frame & Wheel Assembly
Ref. Part No. Description
1687-02022 Curb Height Adjustment Lever
2687-02125A Curb Height Adjuster Plate
3687-02126 Blade Plate Assembly
4710-0191 Screw ⁄-24
5710 - 0 411 Screw ⁄-16
6710-04389 Hex Screw, ⁄-18
7710-0599 Self-tapping Screw, ⁄-20
8710-0654A Screw, ⁄-16
9710-0726 Hex Screw, ⁄-12
10 710-0870 Hex Screw ⁄-18
11 710 -1143A Hex Screw, ⁄-18
12 710 -1174 Carriage Bolt, ⁄-18
13 710-1205 Rope Guide (Eye Bolt)
14 710-3180 Hex Screw, ⁄-18
15 711- 0 4361 Axle Shaft .50x6.65
16 711-04440 Frame Spacer .50x9.25
17 712-04063 Lock Flange Nut, ⁄-18
18 712-04065 Flange Nut ⁄-16
19 712-0417A Flange Nut, ⁄-18
20 714-3010 Clevis Pin ⁄ x .625
21 718-04012 Bearing Cup
22 720-0142 Grip
23 720-0279 Wing Nut
24 720-04072A Star Knob
25 726-0299 Push Cap ⁄” rod
26 931-04207 Bearing Block
27 731-05063 Debris Guard
28 731-05064 Blade Guard
29 732-0188A Double Torsion Spring
30 932-0369 Compression Spring
31 732-04045 Torsion Spring
32 932-04169 Compression Spring
33 734-1264 Wheel 7 x 1.75 T-Tread
Ref. Part No. Description
34 734-1268 Wheel 8 x 1.75 T-Tread
35 936-0179 Flat Washer ⁄ x 1.25 x .10
36 936-0232 Wave Washer .531 x .781 x .013
37 736-0234 Flat Washer, .385 x 1.5 x .075
38 736-0258 Flat Washer .385 x 1.0 x .135 †
39 936-04088 Flat Washer .635x1.24x.181
40 936-0452 Bell Washer,.396 x 1.140
41 738-04149 Shoulder Screw, ⁄-16
42 738-0706C Shoulder Screw
43 738-0929 Shoulder Screw, ⁄-16
44 941-0524 Bearing, .625 ID x 1.57 OD
45 746-04035 Control Cable (Briggs & Stratton)
46 946-04036 Wheel Adjustment Cable
47 747-04110 Blade Adjustment Rod
48 747-0976A-0637 Bail Handle
49 749-04183-0637 Upper Handle
50 749-04234-0637 Lower Handle
51 950-04105 Spacer, .63 x 1.12 x 1.06
52 750-04129 Spacer
53 950-04142 Pulley Mount Spacer
54 750-0547 Spacer, .64 x.88 x .50
55 954-04032B Belt
56 756-04148 Flat Idler Pulley, 2.5 OD
57 956-0449 Sheave
58 756 -1150A Combination Flywheel Pulley
59 781-0427-0637 Belt Guard
60 781-0741A Depth Index Bracket
61 781-0742-0637 Depth Index Lever
62A 781-0748-0637 Tri-Star Blade
62B 781-0080-0637 Edger Blade
63 787-01081A-0638 Bracket Plate
64 787-01239-0638 Dual Wheel Bracket
65 787-01304-0638 Frame
18
Handle, Frame & Wheel Assembly
