True Value Weist A101000600 User manual

10’ X 10’ Weist Gazebo
Item#: A101000600
TV. #: 187018
IMPORTANT:
KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
WARNING:
1. Two people are required for assembly.
2. Some parts may contain sharp edges. We recommend that that youwear protective gloves.
3. When assembling and using this product, basic safety precautions should always be followed to
reduce the risk of personal injury or damage. Please read all instructions before assembly and
usage.
4. Do not leave the gazebo up where there is a risk of high winds, as possible damage will occur to
the structure. The manufacturer or retailer is not liable for any loss of the product or other items
due to the failure to take down the gazebo during strong wind.
5. WARNING: Keep all flame and heat sources away from this gazebo fabric. This gazebo is made
with fabric that meets CPAI-84 specifications for flame resistance. It is not fire proof. The fabric will
burn if left in continuous contact with any flame source. The application of any foreign substance to
the gazebo fabric may render the flame-resistant properties ineffective.
PREPARATION:
Before beginning assembly of this product, make sure all parts are present. Compare parts with
package contents list. If any part is missing or damaged, do not attempt to assemble the product.

Pieza Part Number Descripción Cantidad Diagrama de la pieza
1 P000200280 Upper post 4 PCS
2 P000200281 Down post 4 PCS
3 P000400599 Long support pipe 8 PCS
4 P000400600 Short support
pipe 4 PCS
5 P000600877 Top short pipe 4 PCS
6 P000600878 Top long pipe 4 PCS
A P000100170 Base 4 PCS
B P000500709 Pipe connector 4 PCS
C P000500710 Big top connector 1 PCS
D P001100366 Small canopy 1 PCS
E P001100365 Big canopy 1 PCS
F P001200123 Mosquito netting 1 PCS
AA H070010025 Stake 8 PCS
BB P008300002 Rope 8 PCS
CC H070010011 Big stake 8 PCS
DD P005100264 Plastic ring 48 PCS
Parts List

Assembly step:
Fig.1: Insert both ends of short support pipe (4) into long support pipe (3), and then insert another
end of long support pipe (3) into pipe connector (B), with gradient circular tube upwards.
Fig.2: Insert one end with contracted pipe of top short pipe (5) into top long pipe (6), then insert top
long pipe (6) into big top connector (C), put big canopy (E) onto frame before installing fourth top
long pipe (6), do not spread out. Insert fourth top long pipe (6) into big top connector (C). (See next
step diagram).
Fig.3: Insert another end of top short pipe (5) into pipe connector (B). Put small canopy (D). (See
next step diagram)

Fig.4: Insert one end with spring fastener of upper post (1) into pipe connector (B).
Fig 5: Insert one end with contracted pipe of down post (2) into upper post (1); insert another end of
down post (2) into base (A).

A
Fig 6: At last, unfold the big canopy (E); put hooks of the canopy four corners into holes of down posts. Then
attach the ring on the canopy to the hook on the base (A) to secure the canopy as Fig 6 showed. Secure whole
gazebo with stake (AA). Tie the string and tieback to the post as above picture showed.
Fig 7: Use rope (BB) to tie up four corners; strengthen with big stake (CC) as above drawing showed.
Fig 8: Hang mosquito netting (F) onto support pipes (3, 4) with plastic ring (DD).
1 YEAR LIMITED WARRANTY
This product is warranted for 1 year against any defects in material and workmanship. If defective, the
product will be repaired or replaced free of charge. Simply provide proof of purchase and return the
product to your place of purchase. Normal wear or damage due to abuse, mishandling, or unauthorized
repairs is not covered. Thewarranty gives you specific legal rights and you may have other rights which
vary from state to state.
Before returning to your retailer, call Sunjoy Group at 1(866) 578‐6569 anytime 24 hours / 7 days a
week, or email to [email protected] or visit www.sunjoyonline.com for more information or
assistance.
Manufactured for and distributed
by True Value® Company
Chicago, IL 60631-3505
© 2020 True Value Company
Made in China
