Home Decorators Collection Gabriel 151-100-7D User manual

THANK YOU
USE AND CARE GUIDE
Gabriel 7pc Cushioned Dining Set
Questions, problems, missing parts? Before returning to the store,
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Home Decorators Collection.
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
call Home Decorators Collection Customer Service
e strive
(4-Dining Chairs and 2-Swivel Rockers)
Item #7630110289
Model #151-100-7D
7
HOMEDECORATORS.COM
1-800-245-2217

2
Table of Contents
Safety Information
DANGER: Please keep children out of the assembly area
during assembly.
IMPORTANT: Please check the tightness of bolts
periodically.
Warranty
Table of Contents....................................................... 2
Safety Information...................................................... 2
Warranty......................................................................2
One Year Frame and Fabric Limited Warranty.............................2
Pre-Assembly ............................................................3
Planning Assembly ................................................................3
Hardware Included..................................................................3
Package Contents .................................................................. 4
Assembly ................................................................... 5
................................................................2
What Is Covered
What Is Not Covered ................................................................2..
.... ..
................................................................2
Care Instructions ..
ONE YEAR FRAME AND FABRIC LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Care Instructions
ARNING: Do not stand on the chair. Do not sit on theW
Before using, wipe with a clean, dry cloth. Do not use bleach or solvents. Treat the frame with liquid wax for maximum protection against UV light
and salty, damp air. When not in use, store furniture in a cool, dry place. If your set includes cushions or mesh fabric, they may be cleaned by
hand with a mild solution of soap and water. Rinse cushions thoroughly and allow to drip dry. Do not machine wash or tumble dry, as cushions
may shrink. Do not use bleach or solvents on fabrics.
armrests.
You may contact our customer service department with any questions by phone at 1-800-245-2217 or visit www.homedecorators.com.
We warrant the frame and fabric to be free of manufacturing defects to the original purchaser for one year.

3
Pre-Assembly
PLANNING ASSEMBLY
It will take two people about 45 minutes to complete the assembly process.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA 32
BB 32
CC
1
DD
32
Bolt (M6x18)
Hex wrench
HOMEDECORATORS.COM
Please contact 1-800-245-2217 for further assistance.
Washer (M6)
AA BB CC DD
JJ KK
EE FF GG
LL
HH
II
MM
Part Description Quantity
EE 6
FF 8
GG
8
HH
Washer plate
8
4
II
Nut
Bolt (M8x42)
Bolt cap
JJ 4
KK 16
LL
Nut cap
16
MM Spanner 2
Washer
Lock washer
Bolt (M8x35)
Bolt cap (M6)

4
Pre-Assembly(continued)
PACKAGE CONTENTS
Part Description Quantity
A Right armrest 4
B Left armrest 4
A
C
B
D
C Seat panel
4
D Back panel 4
F
E
Part Description Quantity
EChair seat (with metal plate) 2
F Chair base (with metal plate) 2
H
G
G Seat cushion
6
H
Back cushion 6

5
Assembly (Dining Chairs)
1 Attaching armrests to the back panel
□
□
□
HOMEDECORATORS.COM
Please contact 1-800-245-2217 for further assistance.
Attach the armrests (A) and (B) to the back panel (D) with washers (BB) and bolts (CC) using the hex wrench (DD).
Do not fully tighten bolts until the end of step 2.
CC
DD BB
A B
D
th surface.
Use another two washers (BB) and bolts (CC) to secure the armrests
Do not fully tighten bolts until the end of step 2.
BB
CC
DD
to the back panel using the hex wrench (DD).
2Attaching the seat panel
□Attach the seat panel (C) to the tabs (2) of the armrests (A) and (B)
Note that the leg rest tube (1) is curved and shall stay in front.
□
Fully tighten all bolts (CC) when all bolts are in place.
3Turning over the chair
□Cover all bolts with bolts caps (AA).
□
□Repeat steps 1 through 3 for the other chairs.
BB
CC
DD
1
C
A
B
2
with washers (BB) and bolts (CC) using hex wrench (DD).
AA
AA
Turn the chair upright.

6
4
□Place the chair seat (E) upside down on a smooth surface.
□Align the chair base (F) to the chair seat (E).
IMPORTANT: You may need to loosen pre-installed bolt s
to ensure chair seat (A) and chair base (B) will line up.
IMPORTANT: You may need to loosen the pre-installed
bolts to ensure the chair seat (E) and chair base (F) will line up.
T-rocker (4) of the chair base (F), another is pre-installed on
the U-bar (5) of the chair seat (E) to show the proper way
to assemble.
IMPORTANT: It is critical to follow the correct assembly for
the stability and safety of the chair.
IMPORTANT:
5Attaching the chair base
□On one side attach the steel plate (3) to the U-bar (5) of the chair seat (E) with two bolts (II) and one washer plate (EE)
from below the U-bar (5), and with two washers (FF), two lock washers (GG) and two nuts (HH) from above the steel plate (3)
using two spanners (MM). (Fig.1)
□
On the other side attach the steel plate (3) to the T-rocker (4) of the chair base (F), with two bolts (JJ) and one washer plate (EE)
from below the steel plate (3), and with two washers (FF), two lock washers (GG) and two nuts (HH) from above the T-rocker (4)
using two spanners (MM). (Fig.2)
□Completely tighten all bolts (II and JJ) and pre-installed bolts when all bolts and nuts are in place.
e steel plate (3) is pre-installed on thenO
II
EE
EE
HH
GG
FF
HH
GG
FF
EE
JJ
E
F
E
F
Aligning the chair base to the chair seat
5
4
Completely tighten all nus (HH) and pre-installed nuts .
3
3
Fig. 1
Fig. 2
Assembly (Swivel Rockers)

7
Assembly (continued)
6Attaching the bolt caps
□Cover all bolts (II and JJ) and pre-installed bolts with bolts caps (LL).
□Cover all nuts (HH) and pre-installed nuts with nut caps (KK).
HH
KK
II/JJ
LL
7Turning over the chair
□Turn over the chair and check the stability.
□
□
Repeat st .riahcrehtoehtrof7hguorht4spe
G
H
G
H
HOMEDECORATORS.COM
Please contact 1-800-245-2217 for further assistance.
Place cushions (G and H) on the chairs and secure to chair frames with hook and loop straps.

Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8.00 a.m. – 6.00 p.m., EST, Monday-Friday
Retain this manual for future use.
