True T-12G User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
AVAILABLE AT:
T-12G
T-12G
Model Doors
Capacity
(Cu.Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†H*HP Voltage Amps
NEMA
Config.
Cord Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
T-12G 1 12
340
324
7/8
632
233/8
594
631/8
1604
1/5
1/4
115/60/1
230-240/50/1
5.0
3.0
5-15P
▲
9
2.74
215
98
† Depth does not include 13/8" (35 mm) for door handle. ▲Plug type varies by country.
* Height does not include 1" (26 mm) for upper door hinge.
1/06
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility costs,
exceptional food safety and the
best value in today’s food service
marketplace.
Oversized, factory balanced,
refrigeration system holds 33°F
to 38°F (.5°C to 3.3°C) for the
best in food preservation.
300 series stainless steel front.
The very finest stainless with
higher tensile strength for fewer
dents and scratches.
Energy efficient, “Low-E”,
double pane thermal glass door.
Adjustable, heavy duty PVC
coated shelves.
Positive seal self-closing door.
Lifetime guaranteed door hinges
and torsion type closure system.
Bottom mounted units feature:
”No stoop” lower shelf.
Storage on top of cabinet.
Compressor performs in coolest,
most grease free area of kitchen.
Easily accessible condenser coil
for cleaning.
T Series:
Reach-In Glass Door Refrigerator
R

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
T-12G TFEY30E TFEY30S TFEY30P TFEY303
T-12G
DESIGN
• True’s glass door reach-in’s are
designed with enduring quality that
protects your long term investment.
• True’s commitment to using the
highest quality materials and
oversized refrigeration systems
provides the user with colder product
temperatures, lower utility costs,
exceptional food safety and the
best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
134A refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains 33°F
to 38°F (.5°C to 3.3°C) for the best in
food preservation.
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger
fan blades give True reach-in’s a more
efficient low velocity, high volume
airflow design. This unique design
insures faster temperature recovery
and shorter run times in the busiest of
foodservice environments.
• Bottom mounted condensing unit
positioned for easy maintenance.
Compressor runs in coolest and most
grease free area of the kitchen.
Allows for storage area on top of unit.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel
front. Anodized quality aluminum
ends, back and top.
• Interior - attractive, NSF approved,
white aluminum liner. 300 series
stainless steel floor with coved
corners.
• Insulation - entire cabinet structure is
foamed-in-place using high density,
CFC free, polyurethane insulation.
• Welded, heavy duty galvanized base
rail dipped in rust inhibiting enamel
paint for corrosion protection inside
and out.
• Base rail fitted with leg levelers (legs
not available).
DOOR
• “Low-E”, double pane thermal
glass door assembly with extruded
aluminum frame.
• Door fitted with 15" (381 mm) long
extruded handle.
• Positive seal self-closing door. Lifetime
guaranteed door hinges and torsion
type closure system.
• Magnetic door gasket of one piece
construction, removable without tools
for ease of cleaning.
SHELVING
• Three (3) adjustable, heavy duty PVC
coated wire shelves 2013/16"L x 17"D
(529 mm x 432 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves
are adjustable on 1/2" (13 mm)
increments.
LIGHTING
• Fluorescent interior lighting. Lights
activated by rocker switch mounted
below door. Safety shielded.
MODEL FEATURES
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
• NSF-7 compliant for open food
product.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for final connection to a
115/60/1 phase - 15 amp dedicated
outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒230 - 240V / 50 Hz.
❒21/2" (64 mm) diameter castors.
❒Additional shelves.
❒Remote cabinets (condensing unit
supplied by others; system comes
standard with 404A expansion valve
and requires R404A refrigerant).
Consult factory technical service
department for BTU information.
115/60/1
NEMA-5-15R
ELEVATION PLAN VIEW
T Series:
Reach-In Glass Door Refrigerator
601/8"
(1528 mm)
631/16"
(1602 mm)
5/16"
(8 mm)
25/8"
(67 mm)
64"
(1626 mm)
2413/16"
(631 mm)
265/32"
(665 mm)
4617/32"
(1182 mm)
235/16"
(593 mm)
13/8"
(35 mm)
15/16"
(24 mm)
2411/16"
(628 mm)
