True TGN-1R-1S-HC User manual

TEC_TM_076 | REV. A | EN 11/30/2021 Page 1 of 20
TGN RefRiGeRaToRs aNd fReezeRs
INSTALLATION MANUAL
TRUE MANUFACTURING CO., INC.
TGN-1R-1S-HC TGN-2R-2S-HC
TRUE MANUFACTURING CO., INC.
2001 East Terra Lane • O’Fallon, Missouri 63366-4434
[phone] • FAX: [phone]
International FAX: [phone] • (800)-325-6152
Parts Department: (800)-424-TRUE (424-8743)
Parts Department FAX: [phone]
218876
North America – Canada and Caribbean
Warranty Phone: [phone]
Warranty Fax: [phone]
Warranty Email: [e-mail]
Technical Phone: [phone]
Technical Email: [e-mail]
7:00am–6:00pm CST Monday–Friday,
8:00am–12:00pm Saturday
UK, Ireland, Middle East, Africa
& India
Phone: [phone]
[e-mail]
8:30am–5:00pm M–F
European Union & Commonwealth of
Independent States
Phone: [phone]
[e-mail]
8:00am–5:00pm M–F
Australia
Phone: [phone]
[e-mail]
8:30am–5:00pm M–F
Mexico
Phone: [phone]
[e-mail]
9:00am–5:30pm M–F
Latin America
Phone: [phone]
[e-mail]
9:00am–5:30pm M–F
INSTALLATION MANUAL
TGN Refigerators and Freezers
Original Instructions

TGN Refrigerators and Freezers www.truemfg.com
TEC_TM_076 | REV. A | EN11/30/2021Page 2 of 20
THANK YOU
FOR YOUR PURCHASE
Safety Information
Safety Precautions & Proper Disposal..........3
Cabinet Dsiposal Warning................................3
Prior to Installation
Ownership .............................................................4
Cabinet Specification.........................................4
Cabinet Location .................................................4
Notice to Customer ............................................4
Clearances..............................................................4
Wire Gauge Chart................................................4
Installation
Uncrating................................................................5
Cabinet Location .................................................6
Leveling Legs & Castors ....................................6
Leveling...................................................................7
Sealing the Cabinet to the Floor....................7
Electrical Safety....................................................8
Cabinet Setup
Shelf Installation................................................10
Cabinet Operation
Startup...................................................................11
Temperature Control Location.....................11
Sequence of Operation...................................12
Maintenance, Care, and Cleaning
Condenser Coil Cleaning................................14
Stainless Steel Care & Cleaning....................16
Cabinet Adjustments, Servicing &
Component Replacement
Sevicing & Replacing Components ............17
Warranty
Warranty ...............................................................19
Congratulations!
You have just purchased the finest commercial refrigerator available. You can expect many
years of trouble-free operation.
Table of Contents

TGN Refrigerators and Freezers
TEC_TM_076 | REV. A | EN 11/30/2021 Page 3 of 20
www.truemfg.com
How to Maintain Your True Refrigerator to Receive the Most Efficient and Successful Operation
You have selected one of the finest commercial refrigeration units made. It is manufactured under strict quality controls with only the best
quality materials available. Your TRUE cooler, when properly maintained, will give you many years of trouble-free service.
WARNING – Use this appliance for its intended purpose as described in this Installation Manual.
• Take care during operation, maintenance or repairs to avoid
cuts or pinching from any part/component of the cabinet.
• Units may pose a tipping hazard while uncrating, during
installation, or when moving the unit.
• Ensure the unit is properly installed and located in accordance
with the Installation Instructions before use.
• This appliance is not to be used, cleaned or maintained by
persons (including children) with reduced physical, sensory or
mental capabilities or lack of experience and knowledge, unless
they have been given supervision or instruction.
• DO NOT allow children to play with the appliance or climb,
stand, or hang on the unit's shelves to prevent damage to the
refrigerator and personal injury.
• DO NOT touch the cold surfaces in the freezer compartment
when hands are damp or wet. Skin may stick to these extremely
cold surfaces.
• Unplug the refrigerator before cleaning and making repairs.
• Setting temperature controls to the 0 position or powering
off an electronic control may not remove power from all
components (e.g., light circuits, perimeter heaters, and
evaporator fans).
• DO NOT store or use gasoline, or other flammable vapors and
liquids, in the vicinity of this or any other appliance.
• DO NOT store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• Keep fingers out of the “pinch point” areas; clearances between
the doors and cabinet are necessarily small; be careful closing
doors when children are in the area.
• DO NOT use electrical appliances inside the food storage
compartments of the units unless the appliances are of the
type recommended by the manufacturer.
NOTE: All servicing must be performed by a qualified
technician.
See the serial label inside the cabinet for the units refrigeration type. For Hydrocarbon Refrigeration (R290 only), see below:
DANGER – Risk of fire or explosion. Flammable refrigerant used. DO NOT use mechanical devices to defrost
refrigerator. DO NOT puncture refrigerant tubing; follow handling instructions carefully. To be repaired only by trained
service personnel.
DANGER – Risk of fire or explosion (flammable refrigerant used), consult repair manual/owner’s guide before
attempting to service this product. All safety precautions must be followed. Dispose of properly in accordance with
local and federal regulations. Follow all safety precautions.
CAUTION – Keep all ventilation openings clear of obstruction in the appliance enclosure or in the structure housing
the appliance.
DANGER!
RISK OF CHILD
ENTRAPMENT
Proper Disposal of the Cabinet
Child entrapment and suffocation are not problems of the past.
Junked or abandoned refrigerators are still dangerous, even if
they will sit for “just a few days.” If you are getting rid of your old
refrigerator, please follow the instructions below to help prevent
accidents.
Before throwing away your old refrigerator or
freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily
climb inside.
DANGER – Risk of fire or explosion. Flammable
insulation and/or refrigerant used. Dispose of all
in accordance with local and federal regulations.
Follow all safety precautions.
Cabinet Disposal Warning
Refrigerant Safety & Warning Information
Basic Safety & Warning Precautions

TGN Refrigerators and Freezers www.truemfg.com
TEC_TM_076 | REV. A | EN11/30/2021Page 4 of 20
Prior to Installation
Ownership
To ensure that your unit works properly from the first day, it must
be installed properly. We highly recommend a trained refrigeration
mechanic and electrician install your TRUE equipment. The cost of
a professional installation is money well spent.
Before you start to install your TRUE unit, carefully inspect it for
freight damage. If damage is discovered, immediately file a claim
with the delivery freight carrier.
TRUE is not responsible for damage incurred during shipment.
Cabinet Specification
This appliance is rated for open food storage.
Cabinet Location
• Appliance tested for IEC to ISO Climate Class 5 [104°F (40°C)
temperature, 40% relative humidity].
• For proper operation, ambient temperatures shall not be less
than 60°F (15.5°C) and no greater than 104°F (40°C).
• Appliance is not suitable for outdoor use.
• Appliance is not suitable for an area where a pressure washer or
hose may be used.
• Ensure the location will provide adequate clearances and
sufficient airflow for the cabinet.
• Ensure the power supply for the cabinet matches the cabinet
specification sheet or cabinet data plate and is within the
rated voltage (+/-5%). Also, that the amp rating of the circuit is
correct and that it is properly grounded.
• The cabinet should always be plugged into its own individual
dedicated electrical circuit. The use of adapter plugs and
extension cords is prohibited.
Notice to Customer
Loss or spoilage of products in your
refrigerator/freezer is not covered by
warranty. In addition to following
recommended installation procedures, you
must run the refrigerator/freezer for 24 hours
prior to usage to verify its proper operation.
115
Volts Distance In Feet To Center of Load
AMPS 20 30 40 50 60 70 80 90 100 120 140 160
2 14 14 14 14 14 14 14 14 14 14 14 14
3 14 14 14 14 14 14 14 14 14 14 14 12
4 14 14 14 14 14 14 14 14 14 12 12 12
5 14 14 14 14 14 14 14 12 12 12 10 10
6 14 14 14 14 14 14 12 12 12 10 10 10
7 14 14 14 14 14 12 12 12 10 10 10 8
8 14 14 14 14 12 12 12 10 10 10 8 8
9 14 14 14 12 12 12 10 10 10 8 8 8
10 14 14 14 12 12 10 10 10 10 8 8 8
12 14 14 12 12 10 10 10 8 8 8 8 6
14 14 14 12 10 10 10 8 8 8 6 6 6
16 14 12 12 10 10 8 8 8 8 6 6 6
18 14 12 10 10 8 8 8 8 8 8 8 5
20 14 12 10 10 8 8 8 6 6 6 5 5
25 12 10 10 8 8 6 6 6 6 5 4 4
30 12 10 8 8 6 6 6 6 5 4 4 3
35 10 10 8 6 6 6 5 5 4 4 3 2
40 10 8 8 6 6 5 5 4 4 3 2 2
45 10 8 6 6 6 5 4 4 3 3 2 1
50 10 8 6 6 5 4 4 3 3 2 1 1
230
Volts Distance In Feet To Center of Load
AMPS 20 30 40 50 60 70 80 90 100 120 140 160
5 14 14 14 14 14 14 14 14 14 14 14 14
6 14 14 14 14 14 14 14 14 14 14 14 12
7 14 14 14 14 14 14 14 14 14 14 12 12
8 14 14 14 14 14 14 14 14 14 12 12 12
9 14 14 14 14 14 14 14 14 12 12 12 10
10 14 14 14 14 14 14 14 12 12 12 10 10
12 14 14 14 14 14 14 12 12 12 10 10 10
14 14 14 14 14 14 12 12 12 10 10 10 8
16 14 14 14 14 12 12 12 10 10 10 8 8
18 14 14 14 12 12 12 10 10 10 8 8 8
20 14 14 14 12 10 10 10 10 10 8 8 8
25 14 14 12 12 10 10 10 10 8 8 6 6
30 14 12 12 10 10 10 8 8 8 6 6 6
35 14 12 10 10 10 8 8 8 8 6 6 5
40 14 12 10 10 8 8 8 6 6 6 5 5
50 12 10 10 8 6 6 6 6 6 5 4 4
60 12 10 8 6 6 6 6 6 5 4 4 3
70 10 10 8 6 6 6 5 5 4 4 2 2
80 10 8 8 6 6 5 5 4 4 3 2 2
90 10 8 6 6 5 5 4 4 3 3 1 1
100 10 8 6 6 5 4 4 3 3 2 1 1
Wire Gauge Chart
CLEARANCES
TOP SIDES BACK
TGN Freezer 3" (76.2 mm) 0" (0 mm) 3" (76.2 mm)
TGN Refrigerator 0" (0 mm) 0" (0 mm) 1" (25.4 mm)
WARNING – Warranty is void if ventilation is insufficient.

TGN Refrigerators and Freezers
TEC_TM_076 | REV. A | EN 11/30/2021 Page 5 of 20
www.truemfg.com
Installation
WARNING – Units may pose a tipping hazard
while uncrating, during installation, or when
moving the unit.
Fig. 1. Remove the exterior packaging.
Fig. 2. Shipping bolt locations. Fig. 3. When lifting unit, do not use countertops, doors/drawers, or grills as a lifting
point.
Uncrating
Required Tools
Required tools include (but may not be limited to) the following:
• Adjustable wrench
• Phillips screwdriver
• Level
Procedure
1. Remove the outer packaging (cardboard and bubble wrap
or Styrofoam corner and clear plastic). See fig. 1. Inspect for
concealed damage. Again, immediately file a claim with
the freight carrier if there is damage.
2. With an adjustable wrench, remove all shipping bolts securing
the wood skid to the bottom of the cabinet. See fig. 2.
NOTE: Move the unit as close as possible to the final location
before removing the wooden skid. Some models may require
removing the front and/or rear grill/cover to access the
shipping bolts.
3. If leveling legs or castors will not be used, remove the
cabinet from the wood skid and set the skid aside.
NOTE: DO NOT lift the cabinet by the countertops, doors,
drawers, or grills.
If leveling legs or castors will be used, rotate the cabinet on
the skid (see fig. 3) and see the installation instructions on
page 6.
NOTE: Remember to leave cabinet upright for 24 hours before
plugging into a power source. Keys for cabinet with door locks are
located in the warranty packet.

TGN Refrigerators and Freezers www.truemfg.com
TEC_TM_076 | REV. A | EN11/30/2021Page 6 of 20
Installation (cont.)
Fig. 1. Turn the leveling legs clockwise to lower the unit.
Cabinet Location
1. Ensure that the drain hose or hoses are positioned in the pan.
2. Free the plug and cord from inside the lower rear of the cooler
(DO NOT plug in).
3. Place the unit close enough to the electrical supply so that the
extension cords are never used.
Leveling Leg, 6" Leveling Leg, or Castor Installation
Leveling legs are provided to assist with leveling the cabinet.
Adjustable legs provide 6" (152 mm) of clearance under the
cabinet. Castors provide cabinet mobility.
NOTE: If the cabinet has a center leveling screw, castor, or leg,
make sure it is adjusted properly so it makes full contact with
the floor after the cabinet has been leveled.
Required Tools
Required tools include (but may not be limited to) the following:
Adjustable Wrench
Procedure —Leveling Legs
With access to the bottom of the cabinet, thread the leveling legs
into the holes used to secure the cabinet to the skid. See figs. 1
and 2.
Procedure —6" (152 mm) Leveling Legs
1. Access the bottom of the cabinet and thread the leveling legs
into the rail. See figs. 3 and 4.
2. Verify that the cabinet is level.
3. If the cabinet is not level, gently lift and support the low end
of the cabinet. With an adjustable wrench, screw the bottom
stem of the leveling leg in or out to level and support the
cabinet. See fig. 5.
Procedure —Castors
1. Loosen the castor bolt enough to slide the provided castor
shims between the castor bearing and the bottom rail of
the cabinet. See fig. 6.
2. Install the desired number of shims. If more than one shim is
used, turn the slots at a 90˚ angle to each other, so the slots do
not align. See figs. 7 and 8.
3. Tighten and secure the shims and castors with the optional
castor wrench. Lower the cabinet and verify that it is level. If
the cabinet is not level, repeat the process until the cabinet is
level and supported.
Fig. 2. Turn the leveling legs counterclockwise to raise the unit.
Fig. 5. Turn the bottom stem to level the
cabinet.
Fig. 3. Locate the threaded hole in the
rail.
Fig. 4. Screw in the leveling legs.
Lower Rail Assembly
Seismic
Leg
Snug Fit
Here
Rail End
Bottom Stem

TGN Refrigerators and Freezers
TEC_TM_076 | REV. A | EN 11/30/2021 Page 7 of 20
www.truemfg.com
Installation (cont.)
Leveling
Proper leveling of your TRUE cooler is critical to operating success
(for non-mobile models). Leveling impacts effective condensate
removal and door operation.
Procedure
Level the unit front-to-back and side-to-side.
1. Position the level on the inside floor of the unit near the doors
(the level should be parallel to cabinet front). Level the cabinet.
2. Position the level at the inside rear of cabinet (again, the level
should be placed parallel to cabinet back). Level the cabinet.
3. Perform procedures similar to steps 1 and 2 by placing the
level on inside floor (left and right side, parallel to the depth of
the cooler). Level the cabinet.
NOTE: If the cabinet has a center leveling screw, castor, or leg,
make sure it is adjusted properly so it makes full contact with
the floor after the cabinet has been leveled.
Sealing the Cabinet to the Floor
Asphalt floors are susceptible to chemical attack. A layer of tape
may be placed on the floor prior to applying the sealant to protect
the floor.
Procedure
1. Position the cabinet, allowing 3" (73 mm) between the wall
and the rear of the cabinet to ensure proper ventilation.
2. Level the cabinet. The cabinet should be level side-to-side
and front-to-back. To check that the cabinet is level, place a
carpenter's level on the interior cabinet floor in four places:
a. Position the level on the inside floor of the cabinet, near
the doors (the level should be placed parallel to the cabinet
front). Level the cabinet.
b. Position the level at the inside rear of the cabinet (the level
should be placed parallel to the cabinet back). Level the
cabinet.
c. Perform procedures similar to a. and b. by placing the level
on the left and right inside floor (level should be parallel to
the cabinet sides). Level the cabinet.
3. Draw an outline of the cooler base on the floor.
4. Raise and block the front side of the cabinet.
5. Apply a bead of NSF-approved sealant (see list below) to the
floor, 1/2" (13 mm) inside the front part of the outline drawn in
step 4. The bead of sealant must be heavy enough to seal the
entire cabinet surface when the cabinet is lowered on top of
the sealant.
6. Raise and block the rear of the cabinet.
7. Apply sealant to the floor on the other three sides, as outlined
in step 5.
8. Examine the the cabinet to ensure that it is sealed to the floor
around the entire perimeter.
NSF-Approved Sealants
• 3M #ECU800 Caulk
• 3M #ECU2185 Caulk
• 3M #ECU1055 Bead
• 3M #ECU1202 Bead
• Armstrong Cork – Rubber Caulk
• Products Research Co. #5000 Rubber Caulk
• G.E. Silicone Sealer
• Dow Corning Silicone Sealer
Fig. 6. Loosen castor bolt.
Fig. 8. Position multiple shims at
90˚ angles.
Fig. 7. Install shim(s).
Leveling
Shim
Lower Rail Assembly
Bearing
Race
Snug Fit
Here
Rail End
Castor
Castor
Stem
P

TGN Refrigerators and Freezers www.truemfg.com
TEC_TM_076 | REV. A | EN11/30/2021Page 8 of 20
Installation (cont.)
How to Connect Electricity
• The power cord from this appliance is equipped with a
grounding plug which minimizes the possibility of electric
shock hazard.
• The wall outlet and circuit should be checked by a licensed
electrician to make sure the outlet is properly grounded.
• If the outlet is a standard 2-prong outlet, it is your personal
responsibility and obligation to have it replaced with the
properly grounded wall outlet.
• DO NOT, under any circumstances, cut or remove the ground
prong from the power cord. For personal safety, this appliance
must be properly grounded.
• Before your new unit is connected to a power supply, check
the incoming voltage with a voltmeter. If the recorded voltage
is less than the rated voltage for operation (+/-5%) and amp
rating, correct immediately. Refer to cabinet data plate for this
voltage requirement.
• The refrigerator/freezer should always be plugged into a
dedicated electrical circuit. This provides the best performance
and prevents building wiring circuits from being overloaded,
which could cause a fire hazard from overheated wires.
• Never unplug your refrigerator/freezer by pulling on the power
cord. Always grip plug firmly and pull straight out from the
outlet.
• When moving the refrigerator/freezer, for any reason, be careful
not to roll over or damage the power cord.
• Repair or replace immediately all power cords that have
become frayed or otherwise damaged. DO NOT use a power
cord that shows cracks or abrasion damage along its length or
at either end.
• If the supply power cord is damaged, it should be replaced with
original equipment manufacturer (OEM) components. To avoid
hazard this should be done by a licensed service provider.
Cabinet Wiring Diagram
The cabinet's wiring diagram is in the exterior servicing
compartment space of the cabinet.
A copy of the wiring diagram may also be obtained at
www. truemfg.com/support/serial-number-lookup
Fig. 1. Fully insert the power cord into
the receptacle.
Fig. 2. Push the red button to remove
the plug.
Use of Adapter Plugs
NEVER USE AN ADAPTER PLUG! An adapter plug
alters the original OEM plug configuration when
connecting it to a power source.
TRUE will not warranty any refrigerator/freezer that has been
connected to an adapter plug.
Use of Extension Cords
NEVER USE AN EXTENSION CORD! An extension
cord is determined to be any component that
adds length to the original OEM power cord when
connecting it to a power source.
TRUE will not warranty any refrigerator/freezer that has been
connected to an extension cord.
NEMA Plug Configurations
60 HZ USE ONLY!
TRUE uses these types of NEMA plugs shown. If you DO NOT have
the proper outlet, have a licensed electrician verify and install the
correct power source.
International (IEC) Plugs Only
International cabinets may be supplied with a power cord that will
require installation. Install this cord before connecting the unit to a
power source.
NOTE: International plug configurations will vary by country
and voltage
Installation
Fully seat the power cord into the cabinet receptacle until it locks
in position. See fig. 1.
Removal
Depress the red button. See fig. 2.
Electrical Installation & Safety

TGN Refrigerators and Freezers
TEC_TM_076 | REV. A | EN 11/30/2021 Page 9 of 20
www.truemfg.com
NOTES

TGN Refrigerators and Freezers www.truemfg.com
TEC_TM_076 | REV. A | EN11/30/2021Page 10 of 20
Cabinet Setup
Standard Accessories - Shelf Installation
Procedure
1. Determine the desired height for the shelf/pan slide.
2. Align the shelf/pan slide tabs with the notches in the front and
rear pilasters at the desired height. See fig. 1.
3. Slide the tabs into the notches and verifythe unit is leve. See
fig. 2.
4. Gently push down to lock the shelf/pan slide into position. See
fig. 3.
5. Repeat steps 1-3 for the remaining shelf/pan slides. Be sure to
install the slides in pairs at the same height. See fig. 4.
6. Slide the wire shelves into the top slide channels. See fig. 5.
NOTE: The bottom slide channels will accommodate a
product pan. See fig. 6. Product pans are not included.
Shelf Adjustment
Shelving is adjustable for customer application. This cabinet meets
the IEC Shelf Weight Capacity of 173lb (78.47kg).
Fig. 1. Line the tabs up with the notches.
Fig. 2. Position the shelf/pan slide
Fig. 3. Push down to make sure the slide is fully seated.
Fig. 4. Installed shelf/pan slide
Fig. 5. Position the wire shelving.
Fig. 6. If desired, slide product pans into the channels. Product pans not included.
A
B

TGN Refrigerators and Freezers
TEC_TM_076 | REV. A | EN 11/30/2021 Page 11 of 20
www.truemfg.com
Cabinet Operation
Startup
• The compressor is ready to operate when the unit is purchased.
All you need to do is plug in the cooler.
• Excessive tampering with the control could lead to service
difficulties. If replacing the temperature control is ever needed,
be sure to order the replacement from your TRUE dealer or
recommended service agent.
• Good air flow inside your TRUE unit is critical. Take care to
prevent product from pressing against the sides or back
wall and coming within 4" (101.6 mm) of the evaporator
housing. Refrigerated air off the evaporator coil must circulate
throughout the cabinet for even product temperatures.
NOTE: If the unit is disconnected or shut off, wait 5 minutes
before restarting.
RECOMMENDATION – Before loading product, run your TRUE
unit empty for 24 hours to verify proper operation. Remember,
our factory warranty DOES NOT cover product loss!
Electronic Temperature Control
On the front of the top grill.
ECO°C
°F
Temperature Control & Light Switch Location
The light symbol shows the approximate location of the light
switch.
The electronic temperature control can act as a light switch.
To control the light, press the up arrow .
FOR MORE INFORMATION
For more information regarding a cabinet's temperature control adjustment or general sequence of operation,
please see our Temperature Control Adjustment—Sequence of Operation Manual in our resource library at
https://www.truemfg.com/Service-Manuals/Sequence-of-Operation or follow the QR code.

TGN Refrigerators and Freezers www.truemfg.com
TEC_TM_076 | REV. A | EN11/30/2021Page 12 of 20
Cabinet Operation (cont.)
General Sequence of Operation — Refrigerator and Freezer Cabinets
When the cabinet is plugged in...
• Interior lights will illuminate on glass door models (see previous page for light switch location).
• An electronic control with digital display will illuminate (if installed).
• There may be a short delay before the compressor and/or evaporator fan(s) start. This delay may be determined by time or by
temperature, which could be the result of an initial defrost event that will last at least 6 minutes.
• The temperature control/thermostat may cycle the compressor and evaporator fan(s) on and off together. Every cabinet will
require a defrost event to ensure the evaporator coil remains clear of frost and ice buildup. Defrost is initiated by a defrost timer or
by the electronic control.
EXCEPTION – Models TSID, TDBD, TCGG, and TMW do not have an evaporator fan(s).
• The temperature control/thermostat senses either an evaporator coil temperature or air temperature, NOT product temperature.
• An analog thermometer, digital thermometer, or electronic control display may reflect the refrigeration cycle swings of up and
down temperatures, NOT product temperature. The most accurate method to determine a cabinet's operation is to verify
the product temperature.
• Refrigerators with mechanical temperature controls will defrost during every compressor off-cycle.
• Freezers with mechanical temperature controls will defrost by time initiation as determined by a defrost timer.
EXCEPTION – Models TFM, TDC, THDC and TMW require a manual defrost. The frequency of this manual defrost will
depend on the cabinet's usage and ambient conditions.
• An electronic control with a digital display (if installed) will show dEF during defrost.
NOTE: The display may have a short delay before showing a temperature after a defrost event has expired and instead
show dEF during a refrigeration cycle.
• Models with an analog or digital thermometer may show higher than normal temperatures during defrost.
• A refrigerator will use the evaporator fans to clear the coil during defrost.
EXCEPTION – Models TSID, TDBD, and TCGG do not have an evaporator fan(s).
• A freezer will use heaters to clear the evaporator coil during defrost.
NOTE: The evaporator coil heater and drain tube heater are only energized during defrost. Defrost is terminated when a
specific evaporator coil temperature is reached or by a time duration.

TGN Refrigerators and Freezers
TEC_TM_076 | REV. A | EN 11/30/2021 Page 13 of 20
www.truemfg.com
NOTES

TGN Refrigerators and Freezers www.truemfg.com
TEC_TM_076 | REV. A | EN11/30/2021Page 14 of 20
Maintenance, Care & Cleaning
Fig. 4. Verify all blockages have been removed.
Fig. 1. Swing door louver grill screw location.
Fig. 2. Carefully remove the grill.
Fig. 3. Never brush across the coil fins.
CAUTION - Take care during operation, maintenance or repairs to
avoid cuts or pinching from any cabinet part/component.
Condenser Coil Cleaning
When using electrical appliances, basic safety precautions should be
followed, including the following:
WARNING – Electrical shock or burn hazard.
Unplug the unit or turn off the power supply before
proceeding. DO NOT clean appliance with a pressure
washer or hose.
CAUTION – Risk of eye injury. Eye protection is
recommended.
CAUTION – Coil fins are sharp. Gloves are
recommended.
Required Tools
Required tools include (but may not be limited to) the following:
Procedure
1. Disconnect power to unit.
2. Remove the front louvered grill from the cabinet. See fig. 1 and 2.
3. With a stiff bristle brush, carefully clean accumulated dirt from
the front condenser coil fins See fig. 3.
4. With dirt removed from the surface of the coil, use a flashlight
to verify that you can see through the coil and observe the
condenser fan blade spinning. See fig. 4.
If the view is clear, reinstall louvered grill, connect unit to
power and verify operation.
If the view is still blocked with dirt, proceed to step 6.
5. Remove the condenser base bolts. See fig. 5.
6. Remove the condenser coil brackets (if applicable).
7. Carefully slide the condensing unit out (tubing connections are
flexible). See fig. 6. Gently blow compressed air or CO₂ through
the coil until it is clean.
8. Carefully vacuum any dirt around and behind the condensing
unit area.
9. Reinstall the coil brackets (if applicable). Then carefully slide the
compressor assembly back into position and bolt it in place. See
fi g. 7.
10. Reinstall the louvered grill, connect power to the unit, and verify
operation.
• 1/4" nut driver
• 3/8" nut driver
• Stiff bristle brush
• Tank of compressed air
• Vacuum cleaner
• Flashlight
• Eye protection
• Gloves

TGN Refrigerators and Freezers
TEC_TM_076 | REV. A | EN 11/30/2021 Page 15 of 20
www.truemfg.com
Maintenance, Care & Cleaning (cont.)
Fig. 5. Remove condenser base bolts.
Fig. 6. Carefully slide the condensing unit out.
Fig. 7. Carefully slide the condensing unit back into position and replace the bolts.
Important Warranty Information
THE CLEANING OF THE CONDENSER IS NOT
COVERED BY WARRANTY!
If you have any questions, please contact your local
TRUE Manufacturing Service Department. See the front cover for
locations and contact information.
• Condenser coils accumulate dirt and require cleaning every 30
days or as needed.
• A dirty condenser coil can result in non-warranted repairs and/
or cabinet failure.
• Proper cleaning involves removing dust from the condenser by
using a soft brush, vacuuming the condenser with a shop vac,
or using CO₂, nitrogen or pressurized air.
• Do not place any filter material in front of the condensing coil.
• On most units, the condenser is accessible by removing the
cabinet's outer grill cover.
• If you cannot remove the dirt adequately, please contact your
licensed refrigeration service provider.

TGN Refrigerators and Freezers www.truemfg.com
TEC_TM_076 | REV. A | EN11/30/2021Page 16 of 20
Maintenance, Care & Cleaning (cont.)
Stainless Steel Care & Cleaning
CAUTION – DO NOT use any steel wool, abrasive or chlorine-
based products to clean stainless steel surfaces.
Stainless Steel Opponents
There are three basic things which can break down your stainless
steel’s passivity layer and allow corrosion to form.
• Scratches from wire brushes, scrapers, steel pads, and other
items that can be abrasive to stainless steel’s surface.
• Deposits left on your stainless steel can leave spots. You may
have hard or soft water depending on what part of the country
you live in. Hard water can leave spots. Hard water that is
heated can leave deposits if left to sit too long. These deposits
can cause the passive layer to break down and rust your
stainless steel. All deposits left from food prep or service should
be removed as soon as possible.
• Chlorides which are present in table salt, food and water, as well
as in household and industrial cleaners. These are the worst
type of chlorides to use on stainless steel.
Stainless Steel Cleaning and Restoration
DO NOT use stainless steel cleaners or similar solvents to clean
plastic or powder-coated parts. Instead, use warm soapy water.
• For routine cleaning and removal of grease and oil, apply white
vinegar, ammonia, or any good commercial detergent* with a
soft cloth or sponge.
• Stainless steel polish (e.g., Zep® Stainless Steel Polish, Weiman®
Stainless Steel Cleaner & Polish, Nyco® Stainless Steel Cleaner
& Polish, or Ecolab® Ecoshine®) and olive oil can act as a barrier
against fingerprints and smears.
• Degreasers* (e.g., Easy-Off® Specialty Kitchen Degreaser or
Simple Green® Industrial Cleaner & Degreaser) are excellent for
removal of grease, fatty acids, blood and burnt-on foods on all
surfaces.
* DO NOT use detergents or degreasers with chlorides or phosphates.
• For restoration/passivation or removing stubborn stains and
discoloration, Brillo® Cameo®, Zud® Cleanser, Ecolab® Specifax™
First Impression® Metal Polish, Sheila Shine, or talc can be
applied by rubbing in the direction of the polish lines.
NOTE: The use of proprietary names is intended for example
only and does not constitute or imply an endorsement.
Omission of proprietary cleansers from this list does not imply
inadequacy.
8 Tips to Help Prevent Rust on Stainless Steel
Maintain the Cleanliness of Your Equipment
Avoid build-up of hard stains by cleaning frequently. Use
cleaners at the recommended strength (alkaline chlorinated or
non-chloride).
Use the Correct Cleaning Tools
Use non-abrasive tools when cleaning your stainless steel products.
The stainless steel’s passive layer will not be harmed by soft cloths
and plastic scouring pads.
Clean Along Polishing Lines
Polishing lines ("grain") are visible on some stainless steels. Always
scrub parallel to polishing lines when visible. Use a plastic scouring
pad or soft cloth when you cannot see the grain.
Use Alkaline, Alkaline-Chlorinated or Non-Chloride
Cleaners
While many traditional cleaners are loaded with chlorides, the
industry is providing an ever increasing choice of non-chloride
cleaners. If you are not sure of your cleaner’s chloride content,
contact your cleaner supplier. If they tell you that your present
cleaner contains chlorides, ask if they have an alternative.
Avoid cleaners containing quaternary salts, as they can attack
stainless steel, causing pitting and rusting.
Rinse
When using chlorinated cleaners, you must rinse and wipe dry
immediately. It is better to wipe standing cleaning agents and
water as soon as possible. Allow the stainless steel equipment to
air dry. Oxygen helps maintain the passivity film on stainless steel.
Never Use Hydrochloric Acid (Muriatic Acid) on
Stainless Steel
Even diluted, hydrochloric acid can cause corrosion, pitting and
stress corrosion cracking of stainless steel.
Water Treatment
To reduce deposits, soften hard water when possible. Installation
of certain filters can remove corrosive and distasteful elements.
Salts in a properly maintained water softener can also be to your
advantage. Contact a treatment specialist if you are not sure of the
proper water treatment.
Regularly Restore & Passivate Stainless Steel
Stainless steel gets its stainless properties from the protective
chromium oxides on its surface. If these oxides are removed by
scouring, or by reaction with harmful chemicals, then the iron in
the steel is exposed and can begin to oxidize, or rust. Passivation is
a chemical process that removes free iron and other contaminants
from the surface of stainless steel, allowing the protective
chromium oxides to re-form.

TGN Refrigerators and Freezers
TEC_TM_076 | REV. A | EN 11/30/2021 Page 17 of 20
www.truemfg.com
Cabinet Adjustments, Servicing, & Component Replacement
NOTE: Any cabinet adjustments are to be made AFTER the
cabinet has been verified level and properly supported.
Servicing & Replacing Components
• Replace component parts with original equipment
manufacturer (OEM) components.
• Have a licensed service provider service your unit to minimize
the risk of possible ignition due to incorrect parts or improper
service and to ensure the operator's health and safety.
• Unplug the refrigerator/freezer before cleaning or making
any repairs. Setting temperature controls to the 0 position or
powering off an electronic control may not remove power
from all components (e.g., light circuits, perimeter heaters, and
evaporator fans).
FOR MORE INFORMATION
For additional maintenance instruction, please visit the media center at
www.truemfg.com

TGN Refrigerators and Freezers www.truemfg.com
TEC_TM_076 | REV. A | EN11/30/2021Page 18 of 20
NOTES

TGN Refrigerators and Freezers
TEC_TM_076 | REV. A | EN 11/30/2021 Page 19 of 20
www.truemfg.com
Warranty Information (USA & Canada Only)
Three-Year Parts & Labor Warranty
TRUE warrants to the original purchaser of every new TRUE refrigerated unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, under normal and proper use and
maintenance service as specified by TRUE and upon proper installation and start-up in accordance with the instruction packet supplied with eachTRUE unit.TRUE’s obligation under this warranty is
limited to a period of three (3) years from the date of original installation or 39 months after shipment date fromTRUE, whichever occurs first.
Any part covered under this warranty that is determined byTRUE to have been defective within three (3) years of original installation or thirty-nine (39) months after shipment date from
manufacturer, whichever occurs first, is limited to the repair or replacement, including labor charges, of defective parts or assemblies.The labor warranty shall include standard straight time labor
charges only and reasonable travel time, as determined byTRUE.
Warranty does not cover standard wear parts which include door gaskets, incandescent bulbs or fluorescent bulbs. Warranty also does not cover issues caused by improper installation or lack of basic
preventative maintenance, which includes regular cleaning of condenser coils.
Additional Two-Year HFC Compressor Warranty & Additional Four-Year Hydrocarbon Compressor Warranty
In addition to the three (3) year warranty stated above,TRUE warrants its hermetically and semi-hermetically sealed HFC compressor to be free from defects in both material and workmanship
under normal and proper use and maintenance service for a period of two (2) additional years and for Hydrocarbon Units, an additional four (4) years from the date of original installation but not to
exceed five (5) years and three (3) months for HFC compressors and not to exceed seven (7) years and three (3) months for HC compressors after shipment from the manufacturer.
Compressors determined byTRUE to have been defective within this extended time period will, at TRUE’s option, be either repaired or replaced with a compressor or compressor parts of similar
design and capacity.
The two (2) year extended HFC or four (4) year HC extended compressor warranty applies only to hermetically and semi-hermetically sealed parts of the compressor and does not apply to any
other parts or components, including, but not limited to: cabinet, paint finish, temperature control, refrigerant, metering device, driers, motor starting equipment, fan assembly or any other electrical
component, etcetera.
404a/134a/Hydrocarbon Compressor Warranty
The two (2) year HFC compressor and four (4) year HC compressor warranty detailed above will be voided if the following procedure is not carefully adhered to:
1. This system contains R404A, R134A, or R290 refrigerant and polyol ester lubricant. The polyol ester lubricant has rapid moisture absorbing qualities. If long exposure to the ambient
conditions occur, the lubricant must be removed and replaced with new. For oil amounts and specifications please callTRUE Technical Service Department (855-372-1368). Failure to comply with
recommended lubricant specification will void the compressor warranty.
2. Drier replacement is very important and must be changed when a system is opened for servicing. An OEM exact replacement should be used. The new drier must also be the same capacity
as the drier being replaced.
3. Micron level vacuums must be achieved to ensure low moisture levels in the system. 500 microns or lower must be obtained.
Warranty Claims
All claims for labor or parts must be made directly through TRUE. All claims should include: model number of the unit, the serial number of the cabinet, proof of purchase, date of installation, and all
pertinent information supporting the existence of the alleged defect.
In case of warranty compressor, a picture of the compressor model tag must be returned toTRUE along with above listed information. For warranty claim information, visit: www.truemfg.com/
support/warranty-support. Any action for breach of these warranty provisions must be commenced within six (6) months of the defect giving rise to the breach.
TRUE reserves the right to request any failed part covered under warranty to be returned.
What is NOT Covered by this Warranty
TRUE’s sole obligation under this warranty is limited to either repair or replacement of parts, subject to the additional limitations below.This warranty neither assumes nor authorizes any person to
assume obligations other than those expressly covered by this warranty.
No Consequential Damages.TRUE is not responsible for economic loss; profit loss; or special, indirect, or consequential damages, including without limitation, losses or damages arising from
food or product spoilage claims whether or not on account of refrigeration failure.
Warranty is NOT Transferable.This warranty is not assignable and applies only in favor of the original purchaser/user to whom delivered. Any such assignment or transfer shall void the
warranties herein made and shall void all warranties, express or implied, including any warranty of merchantability or fitness for a particular purpose.
Improper Usage.TRUE assumes no liability for parts or labor coverage for component failure or other damages resulting from improper usage or installation or failure to clean and/or maintain
product as set forth in the warranty packet provided with the unit.
Relocation of Cabinet for Repair. TRUE is not responsible for the cost to move a cabinet for any reason from its position of operation on the customer’s premises to make a warranty repair.
Non OEM Parts. Use of non OEM parts without manufacturer’s approval will void cabinet warranty.
Alteration, Neglect, Abuse, Misuse, Accident, Damage During Transit or Installation, Fire, Flood, Acts of God. TRUE is not responsible for the repair or replacement of any parts that
TRUE determines have been subjected after the date of manufacture to alteration, neglect, abuse, misuse, accident, damage during transit or installation, fire, flood, or act of god.
Improper Electrical Connections. TRUE is not responsible for the repair or replacement of failed or damaged components resulting from incorrect supply voltage, the use of extension cords, low
voltage, or unstable supply voltage.
No Implied Warranty of Merchantability or Fitness for a Particular Purpose.There are no other warranties, expressed, implied or statutory, except the three (3) year parts & labor
warranty and the additional two (2) year HFC compressor and the additional four (4) year HC compressor warranty as described above.These warranties are exclusive and in lieu of all other
warranties, including implied warranty and merchantability or fitness for a particular purpose. There are no warranties which extend beyond the description on the face hereof.
Outside USA & Canada.This warranty does not apply to, and TRUE is not responsible for, any warranty claims made on products sold or used outside the United States and Canada. This warranty
only applies to units shipped fromTRUE’s manufacturing facilities after October 1, 2019 for USA Foodservice & Retail and after July 1, 2020 for Canada.
Environmental Attributes
Any and all environmental attributes, including environmental offset credit rights, with respect to TRUE® Refrigeration units manufactured after September 1, 2015, shall remain the property of
TRUE Manufacturing Co., Inc. and are not transferred.
This warranty only applies to units installed after January 1, 2020 for USA Foodservice & Retail and after July 1, 2020 for Canada. BP_03.2021

11/30/2021Page 20 of 20 TEC_TM_076 | REV. A | EN
www.truemfg.com
EA & BP_975552_03.2021
